R-1917
INSTALLATION INSTRUCTIONS
OWNER'S MANUAL
AND
DIRECT VENT
WALL FURNACE
MODELS
DV-210-7SG
DV-215-7SG
EFFECTIVE DATE
NOVEMBER, 2000
This appliance may be installed in an
aftermarket permanently located, manu-
factured (mobile) home, where not pro-
hibited by state or local codes.
This appliance is only for use with the
type of gas indicated on the rating plate.
This appliance is not convertible for use
with other gases, unless a certified kit is
used.
WARNING: If not installed, operated and
maintained in accordance with the manu-
facturer's instructions, this product could
expose you to substances in fuel or from
fuel combustion which can cause death or
serious illness.
Page 1
Advertisement
Table of Contents
Related Manuals for Empire Comfort Systems DV-210-7SG
Summary of Contents for Empire Comfort Systems DV-210-7SG
- Page 1 INSTALLATION INSTRUCTIONS OWNER'S MANUAL DIRECT VENT WALL FURNACE MODELS DV-210-7SG DV-215-7SG WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing EFFECTIVE DATE property damage, personal injury or NOVEMBER, 2000 loss of life.
- Page 2 Introduction Important Always consult your local Building Department regarding regulations, All correspondence should refer to complete Model No., Serial No. and codes or ordinances which apply to the installation of a direct vent wall type of gas. furnace. Notice: During initial firing of this unit, its paint will bake out and Instructions to Installer smoke will occur.
-
Page 3: Safety Information For Users Of Lp-Gas
SAFETY INFORMATION FOR USERS OF LP-GAS by point with the members of your household. Someday Propane (LP-Gas) is a flammable gas which can cause fires and explosions. In its natural state, propane is odorless and when there may not be a minute to lose, everyone's safety will colorless. - Page 4 Qualified Installing Agency Installation and replacement of gas piping, gas utilization equipment or accessories and repair and servicing of equipment shall be performed only by a qualified agency. The term "qualified agency" means any individual, firm, corporation or company which either in person or through a representative is engaged in and is responsible for (a) the installation or replacement of gas piping or (b) the connection, installation, repair or servicing of equipment, who is experienced in such work,...
- Page 5 1. Attach 5" (127mm) diameter air inlet tube onto the collar of air drop When the vent cap is to be installed on vinyl siding or it appears that a assembly. Be sure 5" (127mm) diameter air inlet tube is placed as projection within 6"...
- Page 6 purpose of input adjustment to a maximum of 7.0" w.c. (1.743kPa). Compounds used on threaded joints of gas piping shall be resistant to the action of liquefied petroleum gases. The gas lines must be checked for Propane gas models will have a manifold pressure approximately 10.0" leaks by the installer.
- Page 7 Thermostat Location These heating thermostats are specially designed for use on self-generat- ing systems. They should never be used on line or low voltage A.C. circuits. Exterior Wall — The thermostat may be mounted on an exterior wall above the heater if it is located in the same stud space as the vent tubes and MAIN BURNER is a minimum of 6"...
-
Page 8: For Your Safety Read Before Lighting
FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot which must be lighted by •... -
Page 9: Service And Maintenance Suggestions
SERVICE AND MAINTENANCE SUGGESTIONS CALL SERVICEMAN SYMPTOMS Lit match goes out as it enters lighter port. Check for proper size of pilot flame. Certain wind conditions will blow out match. Ignite Check for defective or weak thermopile. match, and as it flares, thrust match through opening. Check input, reduce as needed. - Page 10 Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store. Shipments contingent upon strikes, fires and all causes beyond our control. Page 10 R-1917 Empire Comfort Systems, Inc. Nine Eighteen Freeburg Ave. Belleville, Illinois 62222-0529...
-
Page 11: Optional Blower
DVB-1 For Direct Vent Wall Furnaces OPTIONAL BLOWER DV-210-(7, 9)SG and DV-215-(7, 9)SG Cleaning the Blower Wheel In some areas, such as near bedrooms and on floors with a hard surface, the blower wheel will be filled with lint very quickly. A visual check of the blower wheel should be made after 30 days use.
