Double Insulated
Finishing Sander
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
ESPAÑOL: PÁGINA 15
FRANÇAISE : PAGE 29
MODEL 340
IMPORTANT
Part No. 900008 - 04-29-02
Advertisement
Table of Contents
Related Manuals for Porter-Cable 340
Summary of Contents for Porter-Cable 340
- Page 1 900008 - 04-29-02.qxd 5/23/02 Instruction manual To learn more about Porter-Cable visit our website at: http://www.porter-cable.com Copyright © 2002 Porter-Cable Corporation 2:17 PM Page 1 ESPAÑOL: PÁGINA 15 FRANÇAISE : PAGE 29 Double Insulated Finishing Sander MODEL 340 IMPORTANT Please make certain that the person who is...
-
Page 2: General Safety Rules
900008 - 04-29-02.qxd 5/23/02 WARNING: SOME DUST CREATED BY POWER SANDING, SAWING, GRINDING, DRILLING, AND OTHER CONSTRUCTION ACTIVITIES contains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: · lead from lead-based paints, ·... - Page 3 900008 - 04-29-02.qxd 5/23/02 Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts. Avoid accidental starting. Be sure switch is OFF before plugging in. Carrying tools with your finger on the switch or plugging in tools that have the switch ON invites accidents.
-
Page 4: Specific Safety Rules And Symbols
WARNING: There are certain applications for which this tool was designed. Porter-Cable strongly recommends that this tool NOT be modified and/or used for any application other than for which it was designed. If you have any questions relative to its application DO NOT use the tool until you have written Porter-Cable and we have advised you. -
Page 5: Additional Safety Rules For Paint Removal
900008 - 04-29-02.qxd 5/23/02 ADDITIONAL SAFETY RULES FOR PAINT REMOVAL WARNING: Extreme care should be taken when removing paint. The peelings, residue, and vapors of paint may contain lead, which is poisonous. Exposure to even low levels of lead can cause irreversible brain and nervous system damage;... -
Page 6: Extension Cord Selection
5/23/02 MOTOR Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C. - Page 7 Before starting to work, make sure you have the right abrasive for the material on which the sander is to be used. Make sure you use the correct size abrasive paper or cloth. Cut, do not tear, the abrasive sheets to size.
- Page 8 ABRASIVE section, or the ATTACHING CONVENTIONAL ABRASIVE section of this manual. Position the sander to the punch (see Fig. 6), aligning the sander pad with the two corner guides on the punch. Push sander onto the punch until seated (see Fig. 7). Remove sander from punch.
-
Page 9: Operation
HOW TO HOLD SANDER Model 340 is designed to be held either around the housings, Fig. 9, or by the top of the housings, Fig. 10. When sanding for long periods, it is recommended you periodically alternate between the two holding positions. - Page 10 CAUTION: Wear safety glasses while using compressed air. ACCESSORY PADS Model 340 is supplied with a Standard Profile, PSA (Pressure Sensitive Adhesive) Pad. This pad and some special purpose pads are available to fit this machine. To install one of these accessory pads: CAUTION: DISCONNECT TOOL FROM POWER SOURCE.
-
Page 11: Using The Sander
Let the sander do the work. FINE FINISHING The action of the Porter-Cable Finishing Sander causes thousands of tiny abrasive grits to move in circular orbits against the work at high speed. Each grain moves in the same direction at a constant speed so the cutting action is uniform over the entire pad surface. -
Page 12: Maintenance
CABINETS AND DOORS The orbital motion of the Porter-Cable Finishing Sander is ideally suited for finishing doors, cabinet fronts and other installations where wood grain is often perpendicular to that of a joining piece. Since the motion is circular, the machine may be moved in any direction and crossed from one part to the other without regard to direction of grain. -
Page 13: Service And Repairs
In any communications, please give all information shown on the nameplate of your tool (model number, type, serial number, etc.). A complete line of accessories is available from your Porter-Cable • Delta Supplier, Porter-Cable • Delta Factory Service Centers, and Porter-Cable Authorized Service Stations. - Page 14 PORTER-CABLE LIMITED ONE YEAR WARRANTY Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period.
- Page 15 Pour obtenir des pièces et accessoires pour les produits Porter-Cable • Delta, s’adresser à tout distributeur Porter- Cable • Delta, centre de service agréé ou centre de service d’usine Porter-Cable • Delta. Si vous n’avez accès à aucun de ces centres, appeler le 888-848-5175 et on vous dirigera vers le centre de service d’usine Porter-Cable •...
