Pancake Compressor
Instruction
manual
MODEL
CPFAC2040P
IMPORTANT
Please make certain that the person who is
To learn more about Porter-Cable
to use this equipment carefully reads and
visit our website at:
understands these instructions before
starting operations.
http://www.porter-cable.com
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
PROFESSIONAL POWER TOOLS
Type ___________________________________________
Serial No. _______________________________________
Copyright © 2004 Porter-Cable Corporation
Part No. D26130-041-1
Advertisement
Table of Contents
Related Manuals for Porter-Cable CPFAC2040P
Summary of Contents for Porter-Cable CPFAC2040P
- Page 1 Instruction manual MODEL CPFAC2040P IMPORTANT Please make certain that the person who is To learn more about Porter-Cable to use this equipment carefully reads and visit our website at: understands these instructions before starting operations. http://www.porter-cable.com The Model and Serial No. plate is located on the main housing of the tool.
-
Page 2: Safety Guidelines - Definitions
SAFETY GUIDELINES - DEFINITIONS This manual contains information that is important for you to know and understand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols below. Please read the manual and pay attention to these symbols. - Page 3 IMPORTANT SAFETY INSTRUCTIONS Improper operation or maintenance of this product could result in serious injury and property damage. Read and understand all warnings and operation instructions before using this equipment. WARNING: Risk of explosion or fire What Could Happen It is normal for electrical contacts within the motor and pressure switch to spark.
- Page 4 WARNING: Risk of Bursting Air Tank: The following conditions could lead to a weakening of the tank, and result in a violent tank explosion and could cause property damage or serious injury. What Could Happen Failure to properly drain condensed water from tank, causing rust and thinning of the steel tank.
- Page 5 WARNING: Risk of Electrical Shock What Could Happen Your air compressor is powered by electricity. Like any other electrically powered device, If it is not used properly it may cause electric shock. Repairs attempted by unqualified personnel can result in serious injury or death by electrocution.
- Page 6 WARNING: Risk of Burns What Could Happen Touching exposed metal such as the compressor head or outlet tubes, can result in serious burns. WARNING: Risk from Moving Parts What Could Happen Moving parts such as the pulley, flywheel, and belt can cause serious injury if they come into contact with you or your clothing.
- Page 7 WARNING: Risk of Unsafe Operation What Could Happen Unsafe operation of your air compressor could lead to serious injury or death to you or others. SAVE THESE INSTRUCTIONS HAZARD...
-
Page 8: Specifications
DUTY CYCLE 50%-75% average duty cycle be maintained; that is, the air compressor pump should not run more than 30-45 minutes in any given hour. ACCESSORIES 8 - ENG CPFAC2040P 1.875" 1.250" 15 amps Time Delay 110 PSIG 135 PSIG... -
Page 9: Installation
Unpacking Remove unit from carton and discard all packaging. HOW TO SET UP YOUR UNIT Location of the Air Compressor Locate the air compressor in a clean, dry and well ventilated area. The air compressor should be located at least 12" away from the wall or other obstructions that will interfere with the flow of air. -
Page 10: Extension Cords
Extension Cords Using extension cords is not recommended. The use of extension cords will cause voltage to drop resulting in power loss to the motor and overheating. Instead of using an extension cord, increase the working reach of the air hose by attaching another length of hose to its end. -
Page 11: Know Your Air Compressor
"cut-out" pressure. Safety Valve: If the pressure switch does not shut off the air compressor at its "cut-out" pressure setting, the safety valve will protect against high pressure by "popping out" at its factory set pressure (slightly higher than the pressure switch "cut-out"... -
Page 12: How To Use Your Unit
This procedure is required before the air compressor is put into service and when the check valve or a complete compressor pump has been replaced. Make sure the On/Auto/Off lever is in the "OFF"... -
Page 13: Before Each Start-Up
Before Each Start-Up: Place On/Auto/Off lever to "OFF". Turn the regulator knob counter- clockwise to set the outlet pressure to zero. Attach hose and accessories. NOTE: The hose or accessory will require a quick connect plug if the air outlet is equipped with a quick connect socket. -
Page 14: To Drain Tank
When servicing, you may be exposed to voltage sources, compressed air, or moving parts. Before servicing unit unplug or disconnect electrical supply to the air compressor, bleed tank of pressure, and allow the air compressor to cool. -
Page 15: To Replace Regulator
Make sure the valve disc moves freely inside the check valve and the spring holds the disc in the upper, closed position. The check valve may be cleaned with a solvent, such as paint and varnish remover. Screwdriver In open position nothing is visible. - Page 16 Before you store the air compressor, make sure you do the following: Review the "Maintenance" section on the preceding pages and perform scheduled maintenance as necessary. Set the On/Auto/Off lever to "OFF" and unplug unit. Turn the regulator counterclockwise and set the outlet pressure to zero.
- Page 17 NOTES 17 - ENG D26130...
-
Page 18: Limited Warranty
• Use reasonable care in the operation and maintenance of the product as described in the Owners Manual(s). • Deliver or ship the product to the nearest Porter-Cable Authorized Warranty Service Center. Freight costs, if any, must be paid by the purchaser.
