Porsche 911 Carrera Owner's Manual page 210

Warning!
The Allen key can rotate or y out and thereby
cause serious personal injury if the converti-
ble top is actuated.
Always remove the Allen key B from the drive
axle C before operating the convertible top.
When you have opened the convertible top
compartment lid, try to close the convertible
top using the rocker switch. If the convertible
top cannot be closed, continue with emergency
operation.
208
Mobile Roofs
Opening side aps "F"
1. Remove ignition key.
2. Use the screwdriver to remove plastic lid E
from the lining from behind.
3. Insert Allen key B into the drive axle for the left
side flap F. Turn Allen key counterclockwise (in
direction of arrow) until the side flap F is fully
open (perceptible stop).
4. Repeat procedure with the right side flap.
Remove the Allen key.
