System Configuration
The illustration below shows the typical system configuration.
DMX-P01
Digital Portable
Mixer
Output cable
(supplied with
the WRR-
861B/862B)
DMX-P01 Digital
Portable Mixer
14
System Configuration
XLR type audio
cable (not
supplied)
WRR-861B/862B UHF
Synthesized Diversity
Tuner
F-112 Dynamic
Microphone
WRT-8P
WRR-855B/861B/862B
UHF Synthesized
Diversity Tuner
PDW-510/510P/530/
530P XDCAM
Camcorder
ECM-674/678
Electret
Condenser
Microphone
