Data Conferencing

lThe ViewStation is T.120-compliant and supports data conferencing when
paired with either a ShowStation IP or NetMeeting. Data conferencing features
are only available on point-to-point video calls and are off by default.

Using a ShowStation IP

The ShowStation works best when you have two ViewStations, two
ShowStations with LAN cards, and an RJ-45 cable. Follow these steps to
connect and use this configuration:
1. Use the ViewStation's blue-tipped cable to connect the ShowStation's LAN
card to the LAN port of the ViewStation. You can also connect the
ShowStation and ViewStation to the same local area network.
2. Find out the name of the ShowStation. Click on the Toolbar icon on the
main menu of the ShowStation. The Site Name is under the Preferences tab.
3. Turn on the ViewStation.
