- Page 1 INSTALLATION INSTRUCTION Installing MiVoice MX-ONE Hardware, Overview Catarina Sten Göran Lannergren Globen Mitel R&D MX-ONE & CMG INSTALLATION INSTRUCTION...
- Page 2 Mitel or any of its affiliates or subsidiaries. Mitel and its affiliates and subsidiaries assume no responsibility for any errors or omissions in this document.
-
Page 3: Target Group
This section lists requirements that must be fulfilled before the installation starts. 1.3.1 TRAINING Personnel working with Mitel MX-ONE systems must have the training required to perform their tasks correctly. It is recommended for engineers installing the MX-ONE to be acquainted with the following areas: •... -
Page 4: Site Planning
NTRODUCTION 1.3.3 SAFETY All personnel involved in installation must read and understand the safety instructions prior to installation, see the description document for SAFETY. 1.3.4 SITE PLANNING Read through each device installation documentation, and from there, conclude where the equipment shall be installed. For MX-ONE, an analogue trunk line generates a touch or leakage current which if there are several analogue trunk lines installed, it calls for the installation to be in a “Restricted Access Location”. - Page 5 MX-ONE H NSTALLING OICE ARDWARE VERVIEW OVERVIEW MIVOICE MX-ONE PRODUCTS BOARDS IN MIVOICE MX-ONE The following circuit boards can be used in the exchange. For technical data about the boards, see document 20/1531-ASP11301, INSTALLATION CHASSIS IN A CABI- NETT Table 1...
- Page 6 MX-ONE P VERVIEW OICE RODUCTS MITEL MX-ONE CHASSIS 2.2.1 MX-ONE 1U CHASSIS, PROD NO. 87L00032XAA-A The MX-ONE 1U (prod. No. 87L00032xAA-A) is a 1U high subrack with space for 1pcs of 40mm board or 2 pcs of 20mm boards mounted horizontally. It has 3 cooling fans (on the left hand side).
- Page 7 MX-ONE H NSTALLING OICE ARDWARE VERVIEW Time slot MGU/10 Figure 2: MX-ONE Lite, 87L00039AAA-A, equipped with MGU2, ASU and 3 additional boards 2.2.3 MX-ONE CLASSIC, 7U CHASSIS In the MX-ONE Classic (prod. No. BFD76140/x) the boards are mounted vertically in this 19 inch wide subrack.
- Page 8 MX-ONE P VERVIEW OICE RODUCTS Figure 4: Fan Unit SERVERS There are several types of servers used in the MX-ONE. The ASU Servers in three versions and the Standard Servers. For technical data about the servers, see document INSTALLATION CHASSIS IN A RACK.
- Page 9 MX-ONE H NSTALLING OICE ARDWARE VERVIEW Figure 6: 2U height AC/DC Power Unit, 800 - 3200W 2.4.2 87L00034AAA-A, 1U POWER UNIT The Aspiro 1U height Power Unit is delivered with one 800W rectifier module with a spare slot for one extra rectifier to support a total of 1600W. An optional kit with Controller (PCC) and cables for battery is available.
-
Page 10: Environmental Requirements
NVIRONMENTAL EQUIREMENTS ENVIRONMENTAL REQUIREMENTS Read through each device installation documentation, and from there, conclude that all of the equipment can be installed. For MX-ONE, an analogue trunk line generates a touch or leakage current which if there are several analogue trunk lines installed, calls for the installation to be in a “Restricted Access Location". -
Page 11: Installation Preparation
MX-ONE H NSTALLING OICE ARDWARE VERVIEW INSTALLATION PREPARATION The site is prepared mostly during the site planning stage, as described in the environ- mental spec for MX-ONE SITE PLANNING. Should these preparations not be complete, perform the following steps before starting the installation: Mark where to position the equipment and where to mount wall supports (if required). - Page 12 ARTHING EARTHING It is vital that all MX-ONE hardware building blocks are properly connected to a common earth. Make sure that the different units, the MX-ONE Service Node, the Standard Server, the MX-ONE Lite, the MX-ONE Classic, the AC/DC unit and the fan unit, are connected to the common earth when these units are screwed into a 19”...
- Page 13 MX-ONE H NSTALLING OICE ARDWARE VERVIEW INSTALLING CHASSIS IN A CABINET These chapters describes the installation of hardware components in the BYB 501 cabinet. The recommended installation order is from the bottom of the cabinet to the top. For details see doc 20/1531-ASP11301 Installing Chassis in a Cabinet Depending on the configuration, some pieces of hardware can be pre-installed.
- Page 14 ABLING Figure 9: Workflow for the MX-ONE Installation CABLING Cabling involves both internal and external connections on site. External cabling is the routing of cables for grounding, to power equipment and other external devices. Internal cabling is the routing of cables within a cabinet or between cabinets. For details about cables, cable connection and marking see document 21/1531-ASP11301 INSTALLATION BOARDS AND CABLING chapter 3.
-
Page 15: Connection Of External Cables
SOFTWARE INSTALLATION AND CONFIGU- RATION For software installation and configuration of MX-ONE, see the installation instructions for INSTALLING AND CONFIGURING MIVOICE MX-ONE. For software installation and configuration of MX-ONE Messaging, see the installation instructions for Fax Mail and Voice Mail. -
Page 16: Installation Test
Make sure all cable connector screws are firmly tightened. 11.2 INSTALLATION TEST FOR MIVOICE MX-ONE To check functionality for the MX-ONE telephones (if available) proceed as follows: Make calls from an IP telephone to another IP telephone, to an analog telephone, to a Dect phone, to a digital telephone and to a external number. -
Page 17: Concluding Routines
MX-ONE H NSTALLING OICE ARDWARE VERVIEW CONCLUDING ROUTINES Before leaving the installation site, complete the following steps: Clean up the site and remove objects like wrapping paper and cable pieces. Dispose of waste material according to local regulations. Print one copy of the safety document, and place it visible on site, see the description for SAFETY.
