- Page 1 7” Portable DVD Player: Extra Screen User’s Manual 20060919...
-
Page 2: Important Safety Instructions
Important Safety Instructions CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USE-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. - Page 3 Important Safety Instructions CAUTION: These servicing instructions are for use by qualifi ed service personnel only. To reduce the risk of electric shock, do not perform any servicing other than that contained in the operating instructions unless you are qualifi ed to do so. Refer to service manual for servicing instructions.
- Page 4 To fi nd out how to properly dispose of this product, please go to www.polaroid. com and click on “Company“ or call the customer service number for your country listed in the instruction manual.
-
Page 5: Table Of Contents
Important Safety Instructions View of Front Panel View of Side Panel System Connections Power Supply Troubleshooting Specifi cations Contents... -
Page 6: View Of Front Panel
POWER button: press to access or to exit the standby mode +/- button: press to adjust the value of brightness and color MODE button: press to change the brightness and color level; press and hold 1-2 seconds to change the aspect ratio Speaker Power indicator: turns red when in standby mode, does not light when powered on... -
Page 7: View Of Side Panel
Volume control: used to adjust the volume of the headphones and speaker Headphone jack: used to connect headphones for private listening. When the headphones are connect- ed to this jack, the unit speaker automatically turn off. Audio input jack: used for audio input Video input jack: used for audio output DC 9.5V output jack: used for output power to the master DVD player DC 9.5V input jack : used to connect the power and car adapters... -
Page 8: System Connections
Connecting to the Master Unit Make sure that the master DVD player, extra screen, and any other electrical equipment are off before connecting. Connect the AC adapter to the extra screen and connect the extra LCD screen with the master DVD player using the power supply cord to supply power to the master screen. -
Page 9: Power Supply
Using the AC Adapter Connect the AC adapter to the jack marked DC 9.5 IN on the right side of the extra screen. Plug the two-prong end of the power cord into a grounded electrical outlet. Notes: • Turn the player’s power off before unplugging. Using the Car Adapter The player is supplied withe a car adapter for powering the unit and charging the battery in a vehicle. -
Page 10: Troubleshooting
If you suspect there is something wrong with the DVD player, immediately turn off the power. Disconnect the power connector and check that there is no smoke or excessive heat coming from the unit. Never open or try to repair the unit yourself. There are no user serviceable parts inside. SYMPTOM There is no sound There is no picture... -
Page 11: Specifi Cations
Power Consumption Dimensions Weight DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE For service, support and warranty information, visit www.polaroid.com. “Polaroid” and “Polaroid and Pixel” are trademarks of Polaroid Corporation, Waltham, MA, USA. Specifi cations 7 inches 20Hz-20kHz <25W 205mm x 153mm x 41mm Approximately 1.12kg...
