Video Cassette
Recorder

Operating Instructions

Owner's record
The model number is located at the rear and front of the unit
and the serial number on the top. Record these numbers in
the spaces provided below. Refer to them whenever you call
upon your Sony dealer regarding this product.
Model No. _________________________
Serial No. _________________________
G
SLV-765HF
©1996 by Sony Corporation
3-800-552-31(1)
SLV-765HF
3-800-552-31 (1)
