- Page 1 Pocket PC Phone Quick Start Guide www.htc.com...
-
Page 2: Table Of Contents
Contents 1. What’s in the Box? .................... 3 2. The Pocket PC Phone ..................4 3. Getting Ready ....................8 4. Making a Call ....................13 5. Synchronizing Outlook Information ............. 15 6. Setting Up E-mail Accounts ................17 7. Sending a Message ..................19 8. -
Page 3: What's In The Box
1. What’s in the Box? Battery AC Adapter Pouch USB Sync Cable Pocket PC Phone User Manual and Quick Start Guide Headset Getting Started CD... -
Page 4: The Pocket Pc Phone
2. The Pocket PC Phone... - Page 5 No. Item Function Notification LED 1 This LED shows the following: • A blinking Blue light for Bluetooth system notification of powered-up and ready to transmit radio frequency signal. • A blinking Green light for Wi-Fi status. • When both Bluetooth and Wi-Fi are enabled, their lights blink alternately. Speaker Listen to audio media or phone call.
- Page 7 No. Item Function Jog Wheel While on Today screen or using applications, scroll up or down to navigate through menus, program instructions; press the wheel to carry out a selection. During a call or while playing music, scroll up or down to adjust the sound volume. OK Button Press to confirm your data entries, or to exit the program in use.
-
Page 8: Getting Ready
Accessory Function AC adapter Converts AC to DC for recharging the battery. USB Sync cable Connects your device to a PC and synchronize data. Stereo headset Provides a volume control slider and a Send/End button. Press the Send/End button to pick up a call or put a call on hold;... - Page 9 Inserting the mini SD card Inserting the SIM card Install the memory card On the right side panel of your device, pry open the mini SD slot cover. Open from the side of the cover where it shows an arrow. Insert the mini SD memory card into the slot carefully.
-
Page 10: Install And Charge The Battery
Install and charge the battery New batteries are shipped partially charged. Before you start using your device, it is recommended that you install and charge the battery. To install the battery, remove the back cover first, and then insert the battery by aligning the exposed copper part of the battery pack with the protruding copper conductor which is at the bottom of the battery slot. - Page 11 Check the battery power • Tap the battery level icon ( ) on the Today screen. The Power Settings screen will then open where you can see the current battery power level. Battery power indicator When the battery power gets very low, a warning message will be displayed. When you see this, immediately save your data by synchronizing with your PC, or save your data on a secondary storage card, and then turn off your device.
- Page 12 Turn on your Pocket PC Phone Press and hold POWER to turn on your device. When you turn on your device for the first time, a Quick Start Wizard will guide you through the screen calibration process and the setup of regional settings, date and time, password, Outlook e-mail, and POP3/IMAP4 e-mail accounts.
-
Page 13: Making A Call
4. Making a Call Like a standard mobile phone, you can use your device to make, receive, and keep track of phone calls and send SMS messages. In addition, you can make and receive video calls. The Phone screen From the Phone screen, you can access Call History, Speed Dial, and Phone settings. To open the Phone screen, do one of the following: •... - Page 14 Phone screen Video Call screen Note The other party’s image will appear on the screen about 3 to 5 seconds after a connection is established, depending on the signal strength. The streaming image quality may also be influenced by the signal.
-
Page 15: Synchronizing Outlook Information
5. Synchronizing Outlook Information Using Microsoft® ActiveSync®, you can synchronize information on your device with information on your PC, such as Outlook content. ActiveSync is already installed on your device, but you need to install it on your PC if you don’t already have it. Insert the Getting Started CD into the CD drive of your PC. - Page 16 PC requirement to run ActiveSync 4.x To connect your device to the PC, you must have the Microsoft® ActiveSync® program installed on your PC. ActiveSync 4.x is included in the Getting Started CD, which is compatible with the following operating systems and applications: •...
-
Page 17: Setting Up E-Mail Accounts
6. Setting Up E-mail Accounts The E-mail Setup Wizard makes it easy and simple to set up your Outlook e-mail and POP3/IMAP4 accounts on your device. Set up e-mail accounts using E-mail Setup Wizard Tap Start > Messaging. Tap Menu > Tools > New Account to access the E-mail Setup Wizard. The E-mail Setup Wizard guides you step-by-step through the setup process. - Page 18 Set up a POP3/IMAP4 e-mail account Set up a POP3 or IMAP4 e-mail account on your device if you have an e-mail account with an Internet service provider (ISP) or an account that you access using a VPN server connection (typically a work account).
-
Page 19: Sending A Message
7. Sending a Message Your device is capable of sending and receiving E-mail, SMS, and MMS messages as long as it is connected to the network. Although you can send text messages (SMS) to only mobile phone numbers, MMS messages can be sent to both mobile phone numbers and e-mail addresses. Compose and send a message In the message list, tap Menu >... -
Page 20: Browsing The Internet
8. Browsing the Internet You can set up connections to the Internet or to a corporate network to browse the Internet. The pre-loaded browser, Internet Explorer Mobile, is a full-featured Internet browser, and optimized for use on your device. Use Internet Explorer Mobile Tap Start >... -
Page 21: Using The Camera
9. Using the Camera Taking photos and recording video clips along with audio is easy with your device’s built-in cameras. Launch camera • Tap Start > Programs > Camera. • Tap Start > Programs > Pictures & Videos, then tap the Camera icon. •... -
Page 22: Using Pictures & Videos
10. Using Pictures & Videos The Pictures & Videos program collects, organizes, and sorts all of The down arrow your captured images and video clips on your device. You can use this program to view/play pictures, GIF images, GIF animations, and video clips. You can even view pictures as a slide show, beam them, send them via e-mail, edit them, or set them as the... - Page 23 Play videos Tap Start > Programs > Pictures & Videos. By default, the contents of the My Pictures folder will be shown. To find the video clips that you captured, tap the down arrow ( ) next to the My Pictures folder and tap My Documents.
-
Page 24: Entering Information
11. Entering Information When you start a program or select a field that requires text or numbers, the Input Panel icon becomes available on the menu bar. Tap the Input Selector arrow (that appears next to the Input Panel icon) to open a menu where you can select a text input method and customize input options. -
Page 25: Status Indicators
12. Status Indicators The Today screen displays important information, such as upcoming appointments and status indicators. Following are some of the status icons that you may see on your device: Icon Description New e-mail or text messages; SMS notification of voice mail New multimedia (MMS) message New MSN message There are more notifications. - Page 26 Icon Description 3G UMTS network available 3G UMTS connecting 3G UMTS in use GPRS available GPRS connecting GPRS in use EDGE available EDGE connecting EDGE in use Roaming Connection is active Connection is not active Synchronization in progress Synchronization error ActiveSync notification Wi-Fi function enabled, but device not connected to a wireless network yet...
- Page 27 Icon Description Wireless network(s) detected Connecting to wireless network (arrows moving); Connected to wireless network Synchronizing via Wi-Fi Vibration mode Sound on Sound off Alarm No SIM card inserted Battery is fully charged Battery power is very low Battery charging Device is locked Device is unlocked Bluetooth headset detected...
-
Page 28: Customizing Your Pocket Pc Phone
13. Customizing Your Pocket PC Phone You can customize the look and feel of your device and set the time and date according to the current time zone. Customize the Today screen Tap Start > Settings > Personal tab > Today. On the Appearance tab, select the desired theme for the background of the Today screen. -
Page 29: Securing Your Pocket Pc Phone
14. Securing Your Pocket PC Phone There are two kinds of security on your device. You can protect your SIM card from unauthorized use by assigning a (Personal Identification Number). Additionally, you can prevent unauthorized access to any part of the device by using password protection. Protect your SIM card with a PIN Tap Start >... -
Page 30: More Information
15. More Information For more instructions, refer to the User Manual or contact your local dealer for assistance.
