3Com Router 3000 ADSL2+ Family Getting Started Guide

LEDs

LED
LAN1/LAN2/LAN3/LAN4
DSL LNK
DSL ACT
ISDN LNK
ISDN ACT
SYS
PWR

Console port

Attribute
Connector
Interface standard
Baud rate
Service

Ethernet interface

Attribute
Connector
Interface type
Operating mode
OFF means no link is present.
Steady ON means a link is present.
Blinking means the interface is sending and/or
receiving data.
OFF means no ADSL/ADSL2/ADSL2+ line is activated.
Steady ON means the ADSL/ADSL2/ADSL2+ line is
activated.
Blinking means the connected two parties are
negotiating parameters.
OFF means no data is being sent or received.
Blinking means the interface is sending and/or
receiving data.
OFF means the ISDN link is not activated.
ON means the ISDN link has been activated.
OFF means no data is being sent or received on the
ISDN link.
Blinking means data is being sent and/or received on
the ISDN link.
Blinking means the system is operating normally.
Steady ON or OFF means the system is improperly
operating.
OFF means no power is being supplied.
Steady ON means power is being supplied.
RJ45
Asynchronous RS232
9600 (default) to 115200 bps
Connection to an ASCII terminal
Connection to the serial interface on a PC to run the
terminal emulation program on the PC
Command line interface (CLI)
Auxiliary (AUX) port
10BASE-T
RJ45
MDI/MDIX auto-sensing
10 Mbps
Full duplex/half duplex
Description
Description
10/100BASE-T
10/100 Mbps auto-sensing
Full duplex/half duplex
Supports only L2 switching
4
