  • Page 1 About the Battery System Locate Battery Housing Identify Connector Ports Install Battery Fuses USING THE BATTERY Charge Battery Set Up Power Management MAINTAINING THE BATTERY Replace Battery Troubleshooting APPENDIXES Battery Disposal Specifications Invitium Battery System Model BAT-24CM OPERATIONS MANUAL Planar Systems, Inc.
  • Page 2 Information in this document has been carefully checked for accuracy; however, no guarantee is Contents given to the correctness of the contents. This document is subject to change without notice. Planar Index provides this information as reference only. Reference to other vendors’ product does not imply any recommendation or endorsement.

  • Page 3: Table Of Contents

    Regulatory Information Specifications Invitium Battery System BAT-24CM Information....... . . iv .

  • Page 4: Regulatory Compliance

    If any cord or cable is frayed or damaged, replace it immediately with another of USING THE BATTERY the same type and rating as supplied by Planar. The safety and regulatory listing and certifications are based on cables supplied by Planar.
  • Page 5 Service support Warranty Other than battery installation and replacement, the Invitium battery system requires no routine maintenance. Should your battery system require repair, return the unit to Planar GETTING STARTED Systems for servicing to maintain product warranty. See the About the Battery System...

  • Page 6: About The Invitium Battery System

    About the Invitium Battery System QUICK LINKS Contents As a component of the Planar Invitium medical workstation, the Invitium battery Index system is designed specifically for point-of care use. It is modular, compact, and ergonomically suited for effective utilization in the medical environment.

  • Page 7: Locate The Battery Housing

    MAINTAINING THE BATTERY Replace Battery Troubleshooting APPENDIXES Battery Disposal Specifications Invitium Battery System BAT-24CM In operation Check that all cords and cables are securely connected before you turn on the Invitium workstation. Do not block the vent holes on the battery housing.

  • Page 8: Identify The Connector Ports

    Set Up Power Management MAINTAINING THE BATTERY Replace Battery Troubleshooting APPENDIXES Battery Disposal Specifications Invitium Battery System BAT-24CM Legend 1 Standard IEC 120–250V AC input power 2 A, 250 V replaceable 2 USB serial port Communication channel between the power supply and...

  • Page 9: Install The Battery Fuses

    MAINTAINING THE BATTERY Replace Battery Troubleshooting APPENDIXES Battery Disposal Specifications Invitium Battery System BAT-24CM About the battery fuses The Invitium battery system requires two 6 A fuses. These are available from any hardware store. Securing the fuse connection Use the screwdriver to turn the fuse holder approximately a quarter to the right, or until you feel it lock.

  • Page 10: Charge The Battery

    APPENDIXES after the current supplied to the batteries drops below .5 amps. Charge the batteries Battery Disposal for 10 hours for every eight charges to 100%. Specifications Invitium Battery System BAT-24CM charging controller board, and power consumption efficiency Charge Time...
  • Page 11 Install Battery Fuses prevent further battery discharging. The sleep mode is intended to prevent the batteries from deep discharge. USING THE BATTERY Charge Battery Set Up Power Management MAINTAINING THE BATTERY Replace Battery Troubleshooting APPENDIXES Battery Disposal Specifications Invitium Battery System BAT-24CM...

  • Page 12: Set Up The Power Management System

    Set Up Power Management MAINTAINING THE BATTERY Replace Battery Troubleshooting APPENDIXES Battery Disposal Specifications Invitium Battery System BAT-24CM Easier power management Unlike earlier Invitium battery systems, this system has no charge indicator panel. The charge level indicator is software-driven, complying with the Microsoft Windows HID Power Device Specification.
  • Page 13 Troubleshooting APPENDIXES Battery Disposal Specifications Invitium Battery System BAT-24CM Low battery alarm User-selectable alarm that is audible or silent. The alarm is triggered when the battery charge level reaches its low battery limit.
  • Page 14 MAINTAINING THE BATTERY Replace Battery Troubleshooting APPENDIXES Battery Disposal Specifications Invitium Battery System BAT-24CM Alarm action An alarm action to hibernate or shut down can be selected in the Power Options Properties menu. Alarm notification You must select a notification for the alarm you choose.
  • Page 15 Product Information Warranty GETTING STARTED About the Battery System Locate Battery Housing Identify Connector Ports Install Battery Fuses USING THE BATTERY Charge Battery Set Up Power Management MAINTAINING THE BATTERY Replace Battery Troubleshooting APPENDIXES Battery Disposal Specifications Invitium Battery System BAT-24CM...

  • Page 16: Replace The Battery

    MAINTAINING THE BATTERY Replace Battery Troubleshooting APPENDIXES Battery Disposal Specifications Invitium Battery System BAT-24CM Replacement tips The Invitium battery system weighs 25 pounds. Handle it carefully. The unit is heavily weighted toward the front of the cart. As you remove it from the cart, you feel its heaviness.
  • Page 17 4 Reconnect the four terminal cable connectors. Push in the connector until you APPENDIXES feel the connection click. Battery Disposal 5 Reattach the retaining bracket with the two screws. Specifications Invitium Battery System BAT-24CM Replacement tips Use only Yuasa NP 12-12 or B&B EP 12-12 batteries.
  • Page 18 Install Battery Fuses 4 Reinsert the three screws, one in the back and two in the front. USING THE BATTERY Charge Battery Set Up Power Management MAINTAINING THE BATTERY Replace Battery Troubleshooting APPENDIXES Battery Disposal Specifications Invitium Battery System BAT-24CM...

  • Page 19: Troubleshooting

    Replace Battery System run time is too short. Troubleshooting APPENDIXES Battery Disposal Specifications Invitium Battery System BAT-24CM Possible Cause AC power is not connected. Input fuse needs to be replaced. Over-temperature protection is activated. Output power cord not connected properly.

  • Page 20: Battery Disposal

    Charge Battery Check with your local ordinances for proper disposal procedures. Set Up Power Management MAINTAINING THE BATTERY Replace Battery Troubleshooting APPENDIXES Battery Disposal Specifications Invitium Battery System BAT-24CM...

  • Page 21: Battery System Specification

    Set Up Power Management Output MAINTAINING THE BATTERY Replace Battery Troubleshooting APPENDIXES Battery Disposal Specifications Invitium Battery System BAT-24CM • Intelligent communications (USB host) • Cooling fan • Externally accessible fuses Input voltage 85 to 265 VAC Input frequency 47 to 63 Hz Inrush current limiting <50A peak...
  • Page 22 MAINTAINING THE BATTERY Replace Battery Troubleshooting APPENDIXES Battery Disposal Specifications Invitium Battery System BAT-24CM Sealed lead acid; quantity – 2 Yuasa NP12-12 or B and B EP12-12 12 Ah each 12 V nominal 9.5 to 14.4 V approx. 250 full charge cycles...
  • Page 23 APPENDIXES Battery Disposal Specifications Invitium Battery System BAT-24CM The battery system is plugged into an AC power source. During charging mode, the attached load to the battery system is operational. The batteries charge. The cooling fan runs only when the unit is plugged into an AC power source.
  • Page 24 APPENDIXES Battery Disposal Specifications Invitium Battery System BAT-24CM The batteries are charged using a constant current/constant voltage algorithm. A constant current of 3.0 amps max is applied to each battery until the voltage on the battery reaches 14.4 V. The current exponentially decreases to maintain 14.4 V on the battery.

  • Page 25: Index

    USB serial port Troubleshooting cables/connectors charge time APPENDIXES charging battery charging controller board Battery Disposal cleaning guidelines Specifications Invitium Battery System BAT-24CM compliance components, identifying controller board, charging customer support discharge protection discharging battery disposing of battery fuses guidelines cleaning...

  • Page 26: Overview Of Standard Warranty

    Systems unless directed by Planar customer service. MAINTAINING THE BATTERY Planar will validate the defect, repair the unit, and return the unit to you. The typical Replace Battery turnaround time is 10 business days.
  • Page 27 Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product modification, or failure to follow instructions supplied with the product. GETTING STARTED b) Repair or attempted repair by anyone not authorized by Planar. About the Battery System c) Any damage of the product due to shipment.
  • Page 28 Exclusion of Damages QUICK LINKS THE LIABILITY OF PLANAR IS LIMITED TO THE COST OF REPAIR OR REPLACEMENT OF Contents THE PRODUCT. PLANAR SHALL NOT BE LIABLE FOR THE FOLLOWING: Index DAMAGE TO OTHER PROPERTY CAUSED BY ANY DEFECTS IN THE PRODUCT,...

  • Page 29: Regulatory Information

    U.S. Federal Communications Compliance Statement Index The Planar Invitium Battery (model BAT-24CM) have has been tested and found to comply within the limits of a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are Regulatory Compliance designed to provide reasonable protection against interference in a residential installation.
  • Page 30 (EMC) Warranty laws. Planar Systems, Inc. has made great efforts to support the medical device industry, in particular medical device manufacturers and medical device system integrators. We offer state-of-the-art systems that are compliant with worldwide accepted medical device safety...
  • Page 31 Amendments 1 and 2. To help the medical device designer evaluate the suitability of these Contents workstations, Planar has also conducted EMC testing to IEC 60601-1-2 as it can be applied. The display with its power supply alone does not represent a functional medical device.
  • Page 32 Symbol explanations QUICK LINKS Following are explanations of the symbols found on the Invitium battery, model BAT-24CM). Contents Index Regulatory Compliance Product Information UL 60601-1 CAN/CSA C22.2 NO.601.1 Warranty CLASS 8750 GETTING STARTED About the Battery System Locate Battery Housing...
