2001 IMPREZA SERVICE MANUAL
BODY SECTION
This service manual has been prepared
to provide SUBARU service personnel
with the necessary information and data
for the correct maintenance and repair
of SUBARU vehicles.
This manual includes the procedures
for maintenance, disassembling, reas-
sembling, inspection and adjustment of
components and diagnostics for guid-
ance of experienced mechanics.
Please peruse and utilize this manual
fully to ensure complete repair work for
satisfying our customers by keeping
their vehicle in optimum condition.
When replacement of parts during
repair work is needed, be sure to use
SUBARU genuine parts.
All information, illustration and specifi-
cations contained in this manual are
based on the latest product information
available at the time of publication
approval.
FUJI HEAVY INDUSTRIES LTD.
QUICK REFERENCE INDEX
HVAC SYSTEM
(HEATER, VENTILATOR AND A/C)
HVAC SYSTEM (AUTO A/C)
(DIAGNOSTICS)
AIRBAG SYSTEM
AIRBAG SYSTEM (DIAGNOSTICS)
SEAT BELT SYSTEM
LIGHTING SYSTEM
WIPER AND WASHER SYSTEMS
ENTERTAINMENT
COMMUNICATION SYSTEM
GLASS/WINDOWS/MIRRORS
BODY STRUCTURE
INSTRUMENTATION/DRIVER INFO
SEATS
SECURITY AND LOCKS
IMMOBILIZER (DIAGNOSTICS)
SUNROOF/T-TOP/CONVERTIBLE TOP
(SUNROOF)
EXTERIOR/INTERIOR TRIM
AC
AC
AB
AB
SB
LI
WW
ET
COM
GW
BS
IDI
SE
SL
IM
SR
EI
G1830GE6

Advertisement

Table of Contents
loading

Related Manuals for Subaru Impreza 2001

Summary of Contents for Subaru Impreza 2001

  • Page 1 HVAC SYSTEM (AUTO A/C) (DIAGNOSTICS) AIRBAG SYSTEM AIRBAG SYSTEM (DIAGNOSTICS) This service manual has been prepared to provide SUBARU service personnel SEAT BELT SYSTEM with the necessary information and data for the correct maintenance and repair of SUBARU vehicles. LIGHTING SYSTEM...

  • Page 2: Body Section

    2001 IMPREZA SERVICE MANUAL QUICK REFERENCE INDEX BODY SECTION EXTERIOR BODY PANELS CRUISE CONTROL SYSTEM CRUISE CONTROL SYSTEM (DIAGNOSTICS) G1830GE6...

  • Page 3: Communication System

    COMMUNICATION SYSTEM Page General Description ..................2 Horn System ....................3 Horn ......................5 Horn Switch....................6...

  • Page 4: General Description

    GENERAL DESCRIPTION COMMUNICATION SYSTEM 1. General Description A: PREPARATION TOOL 1. GENERAL TOOLS TOOL REMARKS NAME Circuit Used for measuring resistance and voltage. Tester COM-2...

  • Page 5: Horn System

    HORN SYSTEM COMMUNICATION SYSTEM 2. Horn System A: SCHEMATIC 1. HORN TO POWER SUPPLY ROUTING MB-4 MB-5 HORN RELAY HORN RELAY : LHD MODEL : RHD MODEL HORN HORN HORN SWITCH (BLACK) 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 GG74-20 COM-3...

  • Page 6: Horn Relay

    HORN SYSTEM COMMUNICATION SYSTEM B: INSPECTION 1. HORN RELAY Check continuity between terminals (indicated in table below) when terminal No. 4 is connected to battery and terminal No. 3 is grounded. When current Between terminals Continuity exists. flows. No. 1 and No. 2 Between terminals Continuity does not No.
  • Page 7 HORN COMMUNICATION SYSTEM 3. Horn A: REMOVAL 1) Remove horn bracket mounting bolt (A). 2) Disconnect harness connector and remove horn assembly (B). BO0001 B: INSTALLATION Install in the reverse order of removal. C: INSPECTION With 12 V direct current supply between horn termi- nal and case ground, check that the horn sounds properly.

  • Page 8: Horn Switch

    HORN SWITCH COMMUNICATION SYSTEM 4. Horn Switch C: INSPECTION Check continuity between terminals. A: REMOVAL WARNING: Before servicing, be sure to read the notes in the AB section for proper handling of the driver airbag module. <Ref. to AB-3, CAUTION, Gen- eral Description.>...
