Lennox SLP98UHV series User's Information Manual

Hide thumbs Also See for SLP98UHV series:
1
2
3
4
5
6
7

Advertisement

Quick Links

Download this manual See also: Unit Information, User Manual
©2017 Lennox Industries Inc.
Dallas, Texas, USA
506443-01
04/2017
Supersedes 10/2015
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
WARNING
Improper installation, adjustment, alteration, service
or maintenance can cause property damage, personal
injury or loss of life. Installation and service must be
performed by a licensed professional HVAC installer or
equivalent, service agency, or the gas supplier.
WARNING
FIRE OR EXPLOSION HAZARD.
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
U S E R ' S I N F O R M AT I O N
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Leave the building immediatly
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire
department.
M A N U A L
SLP98UHV
SERIES
VARIABLE
CAPACITY

GAS FURNACE

Advertisement

loading

Related Manuals for Lennox SLP98UHV series

Summary of Contents for Lennox SLP98UHV series

  • Page 1: Gas Furnace

    U S E R ’ S I N F O R M AT I O N M A N U A L ©2017 Lennox Industries Inc. Dallas, Texas, USA SLP98UHV 506443-01 04/2017 SERIES Supersedes 10/2015 VARIABLE CAPACITY GAS FURNACE WARNING...
  • Page 2 SLP98UHV Parts Identification DURALOK HEAT EXCHANGER TOP CAP ASSEMBLY AIR INTAKE COLLAR BURNERS CABINET FLUE COLLAR PRESSURE SWITCH ASSEMBLY VARIABLE SPEED GAS VALVE AND COMBUSTION AIR MANIFOLD INDUCER ® SURELIGHT VARIABLE SPEED INTEGRATED BLOWER CONTROL MOTOR FIGURE 1 NOTE - This manual must be left with the equipment user. WARNING Notice to Homeowner Before attempting to perform any service or maintenance,...

  • Page 3: Safety Instructions

    Take care to maintain established clearances gas. Because of this, Lennox recommends the use of a surrounding the furnace. carbon monoxide detector in your home, even if you do 4 - DO NOT store chlorine or fluorine products near unit not own gas appliances.
  • Page 4 8 - Move gas valve switch to ON position. See figure 2. Start-Up & Operation Information 9 - Replace the outer access panel. WARNING 10 - Tur n on all electrical power to to the unit 11 - Se t the thermostat to desired setting. If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal NOTE - When unit is initially started, steps 1 through...

  • Page 5: Service Reminder

    Service Reminder Inspect the furnace for obvious signs of deterioration. Call your Lennox service technician if the unit will not op- Inspect the furnace venting system to make sure it is in erate. Before calling, always check the following to be...

  • Page 6: Safety Precautions

    4 - Check the cleanliness of filters and change if If you discover any of the following, shut down your necessary (monthly). unit, and contact a Lennox dealer for an inspection by a licensed professional service technician (or equiv- 5 - Check the condition and cleanliness of burners and alent).

  • Page 7: Repair Parts List

    RepairParts List The following repair parts are available through Lennox dealers. When ordering parts, include the complete furnace model number listed on the CSA International nameplate -- Example: SLP98UH070V36B. All service must be done by a licensed professional installer (or equivalent), a service agency, or the gas supplier.
