Initial Settings
1 Press FUNCTION to select AUX1/AUX2.
Press FUNCTION repeatedly until AUX1/
AUX2 appears in the display.
2 Push MULTI-CONTROL up to turn
AUX1/AUX2 on.
AUX1 :ON/AUX2 :ON appears in the display.
# To turn AUX off, push MULTI-CONTROL
down.
Setting the rear output and
subwoofer controller
This unit's rear output (rear speaker leads out-
put and RCA rear output) can be used for full-
range speaker (R-SP :FUL) or subwoofer
(R-SP :S/W) connection. If you switch the rear
output setting to R-SP :S/W, you can connect
a rear speaker lead directly to a subwoofer
without using an auxiliary amp.
Initially, the unit is set for rear full-range speak-
er connection (R-SP :FUL). When rear output is
connected to full range speakers (when
R-SP :FUL is selected), you can connect other
full range speakers (P/O :FUL) or a subwoofer
(P/O :S/W) to the RCA rear output.
1 Press FUNCTION to select R-SP.
Press FUNCTION repeatedly until R-SP ap-
pears in the display.
2 Push MULTI-CONTROL up or down to
switch the rear output setting.
Pushing MULTI-CONTROL up or down will
switch between R-SP :FUL (full-range speaker)
and R-SP :S/W (subwoofer) and that status
will be displayed.
# When no subwoofer is connected to the rear
output, select R-SP :FUL.
# When a subwoofer is connected to the rear
output, set for subwoofer R-SP :S/W.
# When the rear output setting is R-SP :S/W,
you cannot operate the following procedure.
3 Push MULTI-CONTROL left or right to
switch the subwoofer output or rear out-
put.
Pushing MULTI-CONTROL left or right will
switch between P/O :S/W and P/O :FUL and
that status will be displayed.
Notes
! Even if you change this setting, there is no
output unless you turn the subwoofer output
on (refer to Using subwoofer output on page
60).
! If you change this setting, subwoofer output
in the audio menu return to the factory
settings.
Switching the telephone
muting/attenuation
Sound from this system is muted or attenu-
ated automatically when the signal from the
equipment with mute function is received.
! The sound is muted or attenuated, MUTE
or ATT are displayed and no audio adjust-
ment is possible.
! Sound from this system returns to normal
when the muting or attenuation is can-
celed.
1 Press FUNCTION to select TEL.
Press FUNCTION repeatedly until TEL appears
in the display.
2 Push MULTI-CONTROL left or right to
switch the telephone muting/attenuation.
Pushing MULTI-CONTROL left or right will
switch between TEL ATT (attenuation) and
TEL MUTE (muting) and that status will be dis-
played.
