OWNER´S MANUAL
Vehicle and Infotainment
ŠKODA KAROQ

Advertisement

Table of Contents
loading

Related Manuals for Skoda KAROQ 2017

Summary of Contents for Skoda KAROQ 2017

  • Page 1 OWNER´S MANUAL Vehicle and Infotainment ŠKODA KAROQ...
  • Page 2 Documentation of vehicle delivery   Date vehicle handover ŠKODA Partner Stamp and signature of the vendor I confirm that I have taken delivery of the specified vehicle in good condi- tion, have received information on how to operate it correctly, and have had the terms of the warranty explained to me.
  • Page 3 1st vehicle owner 2nd vehicle owner This vehicle with the official registration This vehicle with the official registration number number (filled in by the vendor) belongs to: belongs to: Title, Name/Company: Title, Name/Company: Address: Address: Telephone: Telephone: ŠKODA partner ŠKODA partner Service consultant: Service consultant: Telephone:...

  • Page 4: Table Of Contents

    Lane Assist » page 240 Useful links Offroad mode » page 212 Before starting off Parking Adjusting the seat » page 81 Electric parking brake » page 201 Adjusting the steering wheel » page 20 Parking the vehicle » page 203 Exterior mirrors »...
  • Page 5 Seat belts Viisibility Table of Contents Using seat belts Windscreen wipers and washers Liability for defects and ŠKODA warranty for Inertia reel and belt tensioners Rear view mirror new cars Airbag system Seats and head restraints Accident data recorder (Event Data Description of the airbag system Front seats Recorder)
  • Page 6 Infotainment settings - Columbus, Amundsen, Data connection Running in the engine and economical Bolero driving Internet connection Infotainment system settings Avoiding damage to your vehicle Establishing a connection using the CarStick Radio menu settings device Assist systems Media menu settings Establishing a connection using a SIM card in General information the external module...
  • Page 7 Inspecting and replenishing Fuel ® AdBlue and its refilling Engine compartment Engine oil Coolant Brake fluid Vehicle battery Wheels Wheels and tyres Operating in winter conditions Do-it-yourself Emergency equipment and self-help Emergency equipment Changing a wheel Puncture repair kit Jump-starting Towing the vehicle Remote control and removable light - changing the battery...

  • Page 8: Liability For Defects And Škoda Warranty For New Cars

    One of the conditions for service from the ŠKODA warranty is that all service Liability for defects and ŠKODA warranty for new cars work has been carried out in a timely and adequate manner and in accordance with ŠKODA AUTO provisions. It must be proven that service work has been Materials defect liability carried out properly and in accordance with the ŠKODA AUTO provisions Your ŠKODA Partner, as a vendor, is liable to you for material damage to your...
  • Page 9 If your vehicle should break down during a journey due to an unexpected de- fect, you can claim services to ensure your continued mobility under the terms of the mobility warranty, including the following services: Breakdown assis- tance at the site of the breakdown and towing to a ŠKODA Service Partner, technical assistance on the phone or on-site commissioning.

  • Page 10: Accident Data Recorder (Event Data Recorder)

    Reading out the EDR requires special equipment with specific access authori- Accident data recorder (Event Data Recorder) zation and a legally prescribed diagnostic connection in the vehicle “on-board diagnostics”), and the ignition will need to be switched on. The vehicle is equipped with a device that serves as an accident data recorder (referred to solely as “EDR”...

  • Page 11: Radio Equipment - Information On Directive 2014/53 / Eu

    » Fig. 1 or Enter the following address in your web browser. http://go.skoda.eu/owners-manuals The web page with a model overview of the ŠKODA brand is opened. 2. Select the desired model - a menu with the manuals is displayed. 3. Select the construction period as well as the language.

  • Page 12: About The Owner's Manual

    Enter the following address in your web browser. The pictures in the Owner's Manual are for illustrative purposes only. The illus- trations can differ in minor details from your vehicle; they are only intended to http://go.skoda.eu/owners-manuals provide general information. › Select the desired model.

  • Page 13: Tutorial Videos

    Read the QR-Code » Fig. 3 or Enter the following address in your web browser. http://go.skoda.eu/owners-manuals-videos Note The tutorial videos are only available in some language versions. MyŠKODA App application Fig. 4 The MyŠKODA App application is available for devices with the Android (Google) or iOS (Apple) system.

  • Page 14: Notes

    Notes Terms used “Specialist” - Workshop - a workshop that carries out specialist service tasks for ŠKODA vehicles. A specialist can be a ŠKODA Partner, a ŠKODA Service Partner, or an independent workshop. “ŠKODA Service Partner” - A workshop that has been contractually author- ised by ŠKODA AUTO or its distribution partner to perform service work on ŠKODA vehicles and to sell ŠKODA Genuine Parts.

  • Page 15: Online Services

    In order for the Care Connect services to work, a mobile network must be or after entering the following address into the web browser. available. http://go.skoda.eu/connectivity Infotainment Online Infotainment Online services expand Infotainment functions e.g. with the fol- User and vehicle registration, activation of online services lowing functions.

  • Page 16: Managing Online Services

    If required, confirm the user change by tapping the Change main user function tering the following address into the web browser. surface. http://go.skoda.eu/connect-video Note Electronic version of the instructions for registration and service activation By deleting the registered vehicle in the user account on the ŠKODA Connect Current information on registration and activation of Online Services can be Portal website, the user is deleted in Infotainment.

  • Page 17: Emergency Call

    › Select the desired service to display designations and service status. Enabled localisation services › For detailed information about the service, tap the function surface  . › To the Switch on / off services, tap the function surface with the “check- Fig.

  • Page 18: Care Connect Services

    Minor accident Buttons and control lights of Care Connect services » Fig. 11 The option for establishing a connection to the emergency call centre or to the Indicator light for system status. breakdown service appears in the Infotainment screen. A connection is established to the information telephone number by pressing the button in the event of problems with Online Services or for Manual connection to the emergency call centre ›...

  • Page 19: Infotainment Online Services

    Online updating of the navigation data (valid for the infotainment Colum- Note  bus) and import of POI Categories » page 175 The availability of the services listed always refers to the period of validity of Conditions for the use of online services the contract.

  • Page 20: Safety

    Driving safety Safety Passive Safety In the interests of traffic safety, the following information must be observed. ▶ Do not become distracted from concentrating on the traffic situation, (e.g. by your passengers or mobile phone calls). General information ▶ Never drive when your driving ability is impaired, (e.g. due to medication, al- ...
  • Page 21 Adjust the seat backrest so that the highest point of the steering wheel WARNING  can be reached with your arms at a slight angle. The adjustable seats and all head restraints must be adjusted to match ■ Adjust the steering wheel so that the distance between the steering wheel the body size at all times and the seat belt must always be fastened proper- ...

  • Page 22: Adjusting The Steering Wheel

    Adjusting the steering wheel position Passenger’s correct seating position  Read and observe on page 19 first. For passenger safety and to reduce the risk of injury in an accident, the follow- ing instructions must be observed. Position the front passenger seat back as far as possible. The front pas- ...

  • Page 23: Seat Belts

    WARNING (Continued) Seat belts The lock tongue should only be inserted into the lock which is the correct ■ one for your seat. Wrong use of the safety belt will reduce its capacity to Using seat belts protect and the risk of injury increases. ...
  • Page 24 WARNING Always ensure that the webbing of the seat belts is properly routed. Seat ■ belts which are not correctly adjusted can themselves cause injuries even in minor accidents. A seat belt which is hanging too loose can result in injuries as your body is ■...

  • Page 25: Inertia Reel And Belt Tensioners

    Fastening middle VarioFlex seat › Grip the lock tongue » Fig. 19and press the red button in the lock tongue, the lock tongue pops out. › Grip the lock tongue and press the red button in the seat belt buckle; the lock tongue pops out.

  • Page 26: Airbag System

    WARNING Airbag system Any work on the belt tensioner system, including the removal and installa- ■ tion of system components because of other repair work, must only be car- Description of the airbag system ried out by a specialist garage. ...
  • Page 27 The forward movement of the body is cushioned when it makes contact with When triggered, the airbag is filled with gas and unfolds. The inflation of the the fully inflated airbag and the risk of injury to the remaining body parts is airbag is carried out in a fraction of a second.
  • Page 28 WARNING (Continued) Safety instructions The front passenger airbag must be deactivated if using a rear-facing ■ child seat on the front passenger seat » page 27, Airbag deactivation. If Fig. 22 this is not done, there is a risk of the child suffering severe or even fatal in- Safe distance from the steering juries if the front passenger airbag is deployed.

  • Page 29: Airbag Deactivation

    Deactivating an airbag should be considered in cases such as the ones WARNING (Continued) below. The airbag system operates using pressure sensors located in the front ■ ▶ A child seat is mounted on the front passenger seat, in which the child is doors.

  • Page 30: Transporting Children Safely

    › Carefully insert the key into the slot in the key switch as far as the stop. Transporting children safely › Use the key to turn the slot of the key switch carefully into the position . › Pull the key out of the slot in the key switch »...
  • Page 31 WARNING (Continued) Use of a child seat on the front passenger seat (variant 1) Pay particular attention to the information provided by the manufacturer ■ Does not apply to Taiwan of the child safety seat regarding the correct routing of the belt. Seat belts which are not correctly adjusted can themselves cause injuries even in mi- nor accidents.
  • Page 32 Set the front passenger seat belt as high up as possible. ▶ Child safety and the side airbag With child safety seats in groups 1, 2 and 3, make sure that the loop-around ▶ fittings attached to the child seat headrest is positioned in front of or at the Fig.
  • Page 33 Use of child safety seats which are secured with a safety belt Never use a rear-facing child seat on the front passenger seat if the passenger airbag is activated. This child safety seat is positioned in the deployment area of the front passenger airbag.

  • Page 34: Fastening Systems

    First, remove the caps in order to access the locking eyes» Fig. 27. After Fastening systems removing the child seat, replace he caps. attachment points of the  system WARNING Always refer to the instructions of the manufacturer of the child seat ■...
  • Page 35 Front passenger seat Size class of Front passenger seat Rear seats Rear seat Group with front airbag switched the child seat with activated front air bag Outside Centre 9-18 kg 15-25 kg 22-36 kg The size category is shown on the label attached to the child seat. If the front passenger seat is fitted with system attachment points, it is suitable for the installation of an ...
  • Page 36 The attachment points for attaching the belt of a child seat with the Attachment points of the   system   system are located on the rear side of the rear seat backrests » Fig. Some country-specific models can also be fitted with an attachment point »...
  • Page 37 Transporting children safely...

  • Page 38: Operation Cockpit Overview

    Fig. 29 Cockpit example for LHD Operation...
  • Page 39 Operating lever for adaptive cruise control Operation Steering wheel locking lever Depending on equipment fitted: Cockpit ▶ Ignition lock ▶ Starter button Overview Bar with buttons and warning lights (depending on the equip- Electric power windows ment fitted): Electric exterior mirror adjustment ▶...

  • Page 40: Instruments And Warning Lights

    The brightness of the instrument lighting can be adjusted in Infotainment in Instruments and warning lights the menu /  →  → Light.  Instrument cluster Engine revolutions counter  Introduction The tachometer » Fig. 30 on page 38 shows the actual engine speed per minute.

  • Page 41: Warning Lights

    Front seat belt warning light » page 41 Fuel gauge  Adaptive Cruise Control (ACC) » page 41  Fig. 32 Power steering » page 41   Fuel gauge Steering lock (KESSY system) Stabilisation control (ESC) » page 42 ...
  • Page 42 WARNING Bulb failure » page 46  Ignoring illuminated warning lights and related messages or instructions ■ Diesel particle filter (diesel engine) » page 46  in the display of the instrument cluster may lead to serious personal injury Windscreen washer fluid level »...
  • Page 43 Switch off the ignition, start the engine again and travel a short distance. WARNING ▶ If the warning light does not go off, stop the vehicle, do not continue ▶   If the warning light lights up at the same time as warning light ■...
  • Page 44 You can drive on, exercising appropriate caution. Seek assistance from a spe- ▶ Stability Control (ESC) / traction control (ASR)  cialist garage immediately.  Read and observe on page 40 first. WARNING flashes – the ESC or TCS is currently active. ...
  • Page 45 WARNING EPC warning light (petrol)  When a fault in the airbag system occurs, there is a risk of the system not  Read and observe on page 40 first. being triggered in the event of an accident. Therefore, this must be checked immediately by a specialized garage.
  • Page 46 Other incidents When the hazard warning light system is switched on, this will cause all of the The illumination of the warning light can have the following reasons. turn signal lights as well as both warning lights to flash.  ▶...
  • Page 47  lights up – a rear seat belt is fastened. Main beam  When the seat belt is fastened/unfastened, the particular light lights up briefly  Read and observe on page 40 first. and indicates the current belt status! lights up – the main beam or the headlight flasher is switched on. ...
  • Page 48 It is possible to continue driving with due caution. Seek assistance from a ▶  Engine oil pressure specialist garage immediately.  Read and observe on page 40 first. CAUTION flashes – the engine oil pressure is too low.  ...
  • Page 49 To clean the filter, and where traffic conditions permit » , drive as follows for  High-beam assistant at least 15 minutes or until the indicator light  goes out.  Read and observe on page 40 first. 4th or 5th gear engaged (automatic transmission: position D / S). ...

  • Page 50: Information System

     Front assist Information system  Read and observe on page 40 first. Driver information system Illuminates   Display in the instrument cluster ▶ Front Assist has recognised the risk of a collision or automatically triggered an emergency braking manoeuvre »...
  • Page 51 An acoustic signal will also sound if you drive the vehicle above 6 km/h when a Display » Fig. 35 door is open. Optimal gear engaged  Gear recommendation (e.g.    means that it is advantageous to switch ...

  • Page 52: Operation Of The Information System

    Function surfaces and screen display » Fig. 36 Operation using the multifunctional steering wheel Vehicle representation (the zones of the vehicle are shown in different colours, corresponding to any warning messages that occur. The warn- ing messages are displayed once you touch the “vehicle”) ...

  • Page 53: Driving Data (Multifunction Display)

    Warning when the preset speed is exceeded - allows the setting of a speed Driving data (Multifunction display) limit where, if exceeded, an acoustic warning signal and a warning message ap-  pears on the display of the instrument cluster. Introduction Dynamic Road Sign Display - traffic signs display »...
  • Page 54 Graphic fuel level display (if the estimated range is less than 300 km, the Memory vehicle starts to approach the symbol ) Approximate range Fig. 40 Memory display Use the function surfaces   to select one of the following preset lists. ▶...

  • Page 55: Menus In The Display Of The Instrument Cluster

    Average speed Radio ▶ Driving time Currently playing station (name/frequency). ▶ ▶ ▶ The selected frequency range (e.g. FM) optionally with the number of the Note station button (e.g. FM3), if the station is stored in the memory list. Disconnecting the vehicle battery will delete all memory data. ▶...

  • Page 56: Service Intervals

    Assist systems menu item Displaying the distance and days until the next service interval The following systems are activated/deactivated in the Assist systems menu Fig. 41 item. Button in the instrument cluster ▶ Lane Assist ▶ Assist system for blind spot monitoring Rear Traffic Alert ▶...

  • Page 57: Personalization

    These values are then continuously matched according to the actual operating An account can be changed at a later time in Infotainment in the menu /   conditions of the vehicle. →  → Vehicle status →  (if the Tyre Pressure Monitoring System is displayed first of all, then use the arrow ...

  • Page 58: Unlocking And Opening

    Voice control - acoustic signals. ▶ Unlocking and opening Navigation - home address, alternative routes, recommended route, reminder ▶ of the lack of fuel. Unlocking and locking Note  Introduction The scope of the personalisation functions is dependent on the type of Info- tainment package.
  • Page 59 Unlocking/locking with the remote control key Locking / unlocking - KESSY Fig. 43 Key with pop-out key bit  Read and observe on page 56 first. Fig. 44 Vehicle unlocking / vehicle locking Description of the key » Fig. 43 ...
  • Page 60 › If the boot lid is closed after locking the vehicle and the key with which the To lock, press the  » Fig. 45 button. vehicle was locked remains in the luggage compartment, the lid is automatical- Locking is displayed in the button by the illumination of the symbol in the ...
  • Page 61 WARNING Opening / closing door If the car is locked and the safe securing system activated, no people must remain in the car as it will then not be possible to either unlock a door or open a window from the inside. The locked doors make it more difficult for rescuers to get into the vehicle in an emergency –...

  • Page 62: Anti-Theft Alarm System

    Locking is displayed in the button by the illumination of the symbol . Child safety lock When with electric operation in addition to the electric window is blocked in the respective door. Malfunctions  Read and observe on page 56 first. Synchronising the remote control If the buttons on the remote control key have been operated several times be- yond the effective range of the system or the battery in the remote control...

  • Page 63: Manually Operated Tailgate

    The alarm system is activated automatically approximately 30 seconds after These functions should be deactivated if there is a possibility that the alarm the vehicle is locked. This is automatically disabled after release. will be triggered by movements (e.g. by people or animals) within the vehicle interior or if the vehicle has to be transported (e.g.

  • Page 64: Electric Boot Lid

    Open/close boot lid Electric boot lid  Introduction The boot lid (hereinafter as lid) can be operated electrically and manual in the event of an emergency » page WARNING Ensure that the lock is properly engaged after closing the lid. Otherwise, ■...
  • Page 65 If the flap meets an obstacle when it is closed, it stops, an acoustic signal Description of operation sounds and the flap moves back a few centimetres. Ways to stop the lid movement ▶ By pressing the button » Fig. ▶...

  • Page 66: Window Operation

    › To open/close, move one foot in the sensor area below the rear bumper Malfunctions quickly in the direction of the arrow » Fig.  Read and observe on page 62 first. The brake light in the rear window illuminates and the lid opens/closes auto- matically.

  • Page 67: Power Windows

    Power window buttons » Fig. 52 CAUTION Front door left Keep the windows clean to ensure the correct functionality of the electric ■ power windows. Front door right Always close the windows before disconnecting the battery. ■ Rear door, left Rear door, right Note Deactivate/activate the buttons in the rear doors (the deactivation may be...

  • Page 68: Panoramic Tilt / Slide Sunroof

    The convenience operation will only function correctly if all the windows auto- Force limiter matically open/close properly.  Read and observe on page 64 first. Convenience opening or closing the window using the key in the driver's door locking cylinder is only possible within 45 seconds of locking the vehicle. The electrical power windows are fitted with a force limiter.
  • Page 69 WARNING Force limiter When operating the sliding/tilting roof and the sunshade, proceed with  Read and observe on page 67 first. caution to avoid causing crushing injuries – risk of injury! The sliding/tilting roof is fitted with a force limiter. CAUTION If there is an obstacle, the closing process is stopped and the glass pane re- During the winter, remove any ice and snow in the vicinity of the sliding/tilt-...
  • Page 70 The sunshade can also be operated by pressing and holding the appropriate Activate operation of the sliding/tilting roof button (starts movement of the sunshade) and releasing it when the sunshade reaches the desired position. Fig. 55 Operation of the sliding/tilting Activating operation of the sunshade roof ...

  • Page 71: Lights And Visibility

    All seats occupied, boot loaded  Lights and visibility Driver seat occupied, boot loaded  Light In the event of another vehicle loading condition, the setting for positions . .  can be used.  Introduction The Full LEDFront headlights s utomatically adjust to vehicle loading and driv- ing conditions, so they do not have manual headlight range control.
  • Page 72 Note Turn signal and main beam The setting (activation/deactivation) of the convenience turn signal is stored (depending on the Infotainment type) in the active user account personalisa- Fig. 58 tion » page Operating lever: Turn signal and main beam operation Automatic driving light control Fig.
  • Page 73 WARNING Light Assist The automatic driving lamp control (position  only operates as a sup- port and does not release the driver from his responsibility to check the light and, if necessary, to switch on the light depending on the prevailing light conditions.
  • Page 74 If there is a fault, the error message will appear in the instrument cluster dis- Switch off the fog lights/rear fog lights in reverse order. play. Seek help from a specialist garage. Note WARNING If an accessory is connected to the trailer socket, the rear fog lamp does not light up on the vehicle.

  • Page 75: Interior Lighting

    › Switch off the ignition and lock the car. Hazard warning light system After removing the ignition key and opening the driver's door, an audible warn- ing sounds. After a few seconds, or after closing the driver's door, the acoustic Fig.
  • Page 76 Switching on/off (by pressing the relevant switch version 2 and 3) Operation of the lights from the front seats » Fig. 64 Reading lamp left  Fig. 63 Reading lamp right  Operation of the lights from the front seats: Variant 1 Automatic operation - switch or position ...

  • Page 77: Viisibility

    Version 1 - (turning the switch » Fig. 65 The ambient lighting can be adjusted in Infotainment in the menu /  →   → Background lighting. Switching off  Reading lamp left Description of the function surfaces » Fig. 67 ...

  • Page 78: Windscreen Wipers And Washers

    Windscreen and rear window heater Front sun visor Fig. 68 Buttons for the front and rear window heater: Climatronic / Fig. 69 Fold down flap / flip up flap / make-up mirror and parking per- manual air conditioning mit holder ...
  • Page 79 Wipers and washers off CAUTION  Single windscreen wipe (sprung position) If the windscreen wipers are in rest position, they cannot be folded out from  ■ the windscreen. The wipers must be set to the service position to raise them ...

  • Page 80: Rear View Mirror

    Rear wipers and washers / reversing camera cleaning system Headlight cleaning system  Read and observe on page 76 first. Fig. 71 Operating the windscreen wip- Headlights are cleaned under the following conditions. ers and washing system The ignition is switched on. ...

  • Page 81: Exterior Mirrors

    Interior mirror dimming Exterior mirrors Fig. 73 Exterior mirror operation  Read and observe on page 78 first. Fig. 72 Interior rear-view mirror manual dimming/auto-darkening The exterior mirrors can (depending on vehicle equipment) have a manual or  Read and observe on page 78 first.
  • Page 82 Manual folding mirrors WARNING The mirror can be manually folded towards the side windows. To put it back to Do not touch the exterior mirror surfaces, if the exterior mirror heating is its original position, it should be folded back from the side window until it audi- switched on - hazard of burning.

  • Page 83: Seats And Head Restraints

    Electrical adjustment Seats and head restraints Front seats  Introduction WARNING Only adjust the driver's seat when the vehicle is stationary – risk of acci- ■ dent! Caution when adjusting the seat! You may suffer injuries or bruises as a ■...
  • Page 84 Retrieving the saved setting Note › With the ignition off and open driver's door, press the desired memory but- If the inclination angle of the seat backrest relative to the seat surface is ■ greater than approx. 110°, then it is not possible for safety reasons to save this ›...
  • Page 85 Stopping the ongoing adjustment WARNING (Continued) › Press any button on the driver's seat or the  button on the remote control When moving the seat backrest, keep limbs out of the area between the ■ key. seat and seat backrest – risk of injury! Never transport the following items on the seat backrest when folded ■...

  • Page 86: Rear Seats

    CAUTION Rear seats When operating the seat backrests, the seat belts must not be pinched - there Seat backrests is a risk of damage to the seat belts. VarioFlex rear seats Adjusting the seats Fig. 80 Adjusting seats in forward/back direction Fig.
  • Page 87 › To adjust the seat backrest to upright position, pull on the loop in the direc- CAUTION tion of arrow and hold the arm in the forward movement until the lock When operating the seat backrests, the seat belts must not be pinched - there clicks.
  • Page 88 Folding up the middle seat Fold up the upholstered seats Fig. 84 Folding up the middle seat Fig. 85 Fold up the upholstered seats › Before folding up Fold up the upholstered seats with the fastening strap on the headrest guide ›...
  • Page 89 Before unlocking Folding back into the starting position is accomplished in the reverse order. › Move the outer seat backwards as far as it will go and fold up » › On the centre seat, remove the headrest and fold up the seat »...

  • Page 90: Headrests

    The plugs and sockets can be soiled with upholstered or removed seats. This Adjusting the height of the rear headrests can lead to functions being restricted. Cleaning › Clean the connectors with a cloth moistened with spirits. › Carefully remove dirt from the sockets with a vacuum cleaner. ›...

  • Page 91: Seat Heaters

    Note WARNING For VarioFlex, the extended headrest can only be removed from the middle If you have a limited pain and / or temperature sensitivity, e.g. due to medi- seat only when the safety button » Fig. 91 is held. cation, paralysis or because of chronic illness (e.g.

  • Page 92: Practical Features

    Switching heating on/off (applies to Climatronic) Practical features › Press the button  on the Climatronic, then tap the function surface » Fig. Passenger compartment features When the heating is switched on, the symbol in the function surface is or- ...
  • Page 93 Parking ticket holder Storage compartments in the doors Fig. 94 Parking ticket holder  Read and observe on page 90 first. Fig. 96 Storage compartments: in the front door/in the rear door The parking ticket holder » Fig. 94 is provided for the attachment of e.g. park- ...
  • Page 94 Telephones that support the Qi standard for wireless charging, can also be Storage compartment in the front centre console charged wirelessly in the storage compartment. While wireless charging is taking place, no objects may be between the pad and the telephone being charged. WARNING The phone may become warm during wireless charging, so it should be ■...
  • Page 95 USB inputs Storage compartment on the dash panel Fig. 99 USB front inputs Fig. 101 Opening storage compartment/ non-lockable storage compart- ment Fig. 100  Read and observe on page 90 first. USB input on the back › To open press the button »...
  • Page 96 Waste container Fig. 103 Beverage holder on the middle rear seat backrest  Read and observe on page 90 first. Fig. 104 Waste container: inserting and moving/opening The cup holders are located in the front centre console , the rear centre console »...
  • Page 97 Closing takes place in reverse order. Storage compartment for storing two coins and a card Storage compartment Replace bags › Remove the waste container from the slot. The part with the cup holder can be removed or rotated. By removing, the in- ›...
  • Page 98 › To close, swivel the compartment against the direction of the arrow until it Opening the air supply when the air conditioning system is switched on allows audibly clicks into place. cooled air to flow into the storage compartment. Opening the air inlet when the air conditioning system is on causes fresh or in- The maximum permissible load of the glasses compartment is 250 g.
  • Page 99  The maximum permissible load of each of the hooks is 2 kg. Read and observe on page 90 first. WARNING The storage pockets are located on the inside of the front seats » Fig. 113 are used to store small and light objects (e.g. mobile phones). Never leave any heavy or sharp-edged objects in the pockets of the items ■...
  • Page 100  Read and observe on page 90 first. WARNING During the trip to the table must be in folded-down - otherwise there is ■ The removable through-loading bag (hereinafter referred to as through-load- danger of injury. ing bag) is used exclusively for transporting skis and poles (max. 2 pairs). Do not use any cups or beakers which are made of brittle material (e.g.

  • Page 101: Electrical Sockets

    Electrical sockets 12-volt socket in the front centre console  Introduction WARNING Do not place anything on the dashboard. These objects might slide or fall ■ down when driving and may distract you from concentrating on the traffic – risk of accident! Make sure that while driving no objects can enter the driver's footwell - ■...
  • Page 102 › To use, fold up the cover of the socket in the direction of arrow » Fig. 120 12 volt socket in luggage compartment and plug the electrical appliance plug into the socket. Fig. 119 An automatic deactivation of the socket can take place, for example, for Cover of the 12 volt power out- the following reasons.

  • Page 103: Ashtray And Cigarette Lighter

    Ashtray and cigarette lighter Cigarette lighter  Introduction The ashtray can be used for disposing of ash, cigarettes, cigars and the like etc WARNING Never place hot or flammable objects in the ashtray – risk of fire! Ashtray Fig. 122 Cigarette lighter ...
  • Page 104 CAUTION WARNING Never exceed the maximum permissible load of the holder - there is a risk of Be careful with the adapter- otherwise there is a risk of finger injury. damage or functional impairment. Attach in the opening in the middle backrest Attaching the rear headrests Fig.

  • Page 105: Transport Of Cargo

    Transport of cargo Fig. 127 Adjusting the holder size Luggage compartment  Introduction When transporting heavy objects, the driving characteristics change due to the shift in centre-of-gravity. Therefore, adjust the speed and driving mode ac- cordingly.  Read and observe on page 102 first.
  • Page 106 CAUTION Fixing nets Never exceed the maximum permissible load of the respective fasteners, ■ nets, hooks etc. - these could be damaged. Make sure that the heating elements of the rear window heater or the fila- ■ ments of the antenna built into the rear are not damaged by abrasive items. Do not place sharp objects in the nets and storage compartments in the lug- ■...
  • Page 107 Inserting hook Fastening strip with moveable hook › Place the hook in the direction of the slant on the fastening strip and straighten in the direction of the arrow » Fig. 132. Fig. 131 › Press in the hook in the direction of arrow and fold down in the direction Move the hook over the fasten- of arrow...
  • Page 108 Fasten the flooring Luggage compartment cover Fig. 134 fixing the floor covering  Read and observe on page 103 first. Fig. 135 Remove the luggage compartment cover The flooring can be fastened with the hook to the strip on the left side of the luggage compartment.
  • Page 109 Fitting Fig. 138 › Place the fixtures on the cover above the brackets on the side trim Removing the roll-up cover » Fig. 135. › Press on the two sides to the upper side of the cover in the region of the mounts .
  • Page 110 WARNING Net partition Depending on the equipment fitted, a “safety loop” can be on the net parti- tion belts. Never try to detach the “loop”. In the event of an accident, the net partition could become detached and thus occupants sustaining inju- ries.
  • Page 111 Cargo Elements Storage compartments under the floor covering Fig. 141 Removing cargo element / Load fastening example Fig. 142 Variant 1: Fold floor covering/storage compartment under the floor covering  Read and observe on page 103 first. Depending on the equipment fitted, Cargo elements can be stored under the floor in the boot.
  • Page 112 Using the storage compartments - variant 2 Description of the light » Fig. 144 › Raise the floor of the luggage compartment in the direction of the arrow and Button to turn the light that has been removed on / off hook the hook on the bar, on the left side of the luggage compartment Part that lights up when the lamp is in the mount »...

  • Page 113: Variable Loading Floor In The Luggage Compartment (Estate)

    The area under the variable loading floor can be used to stow small objects. Variable loading floor in the luggage compartment (Estate) The maximum permissible load of the variable loading floor in the upper posi- tion is 75 kg. For the transport of heavy loads, adjust the variable loading floor Positions of the variable loading floor in the lower position.

  • Page 114: Heating And Ventilation

    WARNING Heating and ventilation For road safety when transporting cargo on the roof rack, observe the fol- lowing instructions. Heating, manual air conditioning system, Climatronic Always distribute the load on the roof rack evenly and secure properly us- ■  Introduction ing suitable lashing straps or tensioning straps.
  • Page 115 When the function is switched on, the indicator lamp below the button lights Note The air inlet in front of the windscreen must be free of e.g. ice, snow or ■ leaves to ensure that the heating and cooling system operates properly. Information on the cooling system After switching on the cooling Condensation from the evaporator of the air ■...
  • Page 116 Adjust the temperature for the left side (or for both sides) Note Reduce the temperature/ Increase the temperature ▶  In order to ensure adequate thermal comfort, there may be an increase in en- ■ Adjust the temperature for the right side (or for both sides) gine idle speed during operation of the Climatronic in some circumstances.
  • Page 117 Switch the temperature synchronisation on/off throughout the entire Air distribution control  interior of the vehicle according to the temperature setting on the  Read and observe on page 112 first. driver's side   Switch Air Care function on/off The recirculation mode prevents contaminated outside air getting into the In- Set the auxiliary heater and ventilation ...
  • Page 118 CAUTION Air outlet vents We recommend not smoking in the vehicle when the recirculating air opera- tion is switched on. The smoke sucked from inside the vehicle is deposited on the evaporator of the air conditioner. This produces a permanent odour when the air conditioning system is operating which can only be eliminated through considerable effort and expense (replacement of compressor).

  • Page 119: Auxiliary Heating (Auxiliary Heating And Ventilation)

    Closing WARNING › Turn the regulator » Fig. 152 downwards. The auxiliary heating must never be operated in closed rooms (e.g. garag- ■ › Turn the regulator » Fig. 153 downwards. es) – risk of poisoning! The auxiliary heating must not be allowed to run during refuelling – risk of ■...
  • Page 120 Individually controlled air conditioning: In the Infotainment system, in menu Power on / off /  tap die  function surface.  Then follow the instructions on the Infotainment screen. When automatic switching on is activated, the warning light in the  symbol button lights up for about 10 seconds after the ignition is turned off »...
  • Page 121 Only one preset time can be active. The activated preset time will be deactiva- Display warning light Meaning ted again after it has started automatically. For the next start, activate one of The auxiliary heating has been switch- the preset times. Lights up green for 2 seconds.

  • Page 122: Infotainment Introductory Information

    This verification is carried out by reading the QR code Introduction to the subject » Fig. 157 or after typing the following address into the web browser. http://go.skoda.eu/compatibility WARNING Only use Infotainment in such a way that you have control of the vehicle ■...
  • Page 123 Switches Infotainment on/off  Description - Infotainment Bolero - Overview of Infotainment menus » page 126  - Display of the main screen “HOME” » page 127  Volume up  Volume down  Touchscreen » page 122 Description - Infotainment Amundsen Fig.
  • Page 124 Description - Infotainment Swing External module Does not apply to Infotainment Swing. Fig. 162 Example of an external module Depending on the vehicle configuration and infotainment type, all the follow- ing elements must not be included in the external module. Fig.

  • Page 125: Infotainment Operation

    Menu item with “Checkbox” Infotainment operation  - Function is switched on ▶ ▶  - Function is switched off Infotainment operation  Opens a sub-menu of the menu item with a “pop-up window” Screen areas Functional surfaces The screen areas which confirm a function or a menu are called “function sur- Fig.
  • Page 126 Description of the alphanumeric keyboard » Fig. 166 Operating the menus Input line Context-dependent: ▶  - Switch from upper case to lower case and vice versa ▶  - Switch to special characters ▶  - Switch to numbers Context-dependent: ▶...
  • Page 127 Gesture control Restart Infotainment Switching Infotainment on / off Only valid for Infotainment Columbus. Only valid for Infotainment Columbus. › To switch on Infotainment, press  › To switch off Infotainment, hold Fig. 167  Example of a menu with Applies to Infotainment Amundsen, Bolero, Swing gesture control ›...
  • Page 128 "Screen off" mode Infotainment menus With the ignition on and functions Switch off screen (in 10 seconds) and Display clock Applies to Infotainment Columbus, Amundsen, Bolero. when screen is off » page 131 enabled, it is possible to display the time and date when the Infotainment screen is switched off.

  • Page 129: Configuration Wizard

    Vehicle system settings » page 196  Configuration wizard Navigation menu » page 174 (Applies to Infotainment Columbus, Amund-  The configuration wizard is automatically displayed if there are at least two sen) non-selected menu items after turning on Infotainment, or if a new personali- List of traffic reports (TMC) (applies to Infotainment Columbus, Amund- ...

  • Page 130: Voice Control

    Applies to Infotainment Swing CAUTION › Activate data transfer in Infotainment. Press the button and then tap on  The messages are generated by Infotainment. Flawless clarity (e.g. road or ■ the function surface Activate data transfer for ŠKODA apps. city name) cannot always be guaranteed.
  • Page 131 Operation principle Voice commands Enter Fig. 172 The voice command must only be issued when the symbol is displayed  Example of screen display and the input tone has completely faded on the Infotainment screen. The in- put tone can be switched on / off. To do so, tap the sensor field and then ...

  • Page 132: Updating The Infotainment Software

    Navigation - applies to Infotainment Columbus If the set Infotainment language matches with the language of the currently http://go.skoda.eu/updateportal selected country when entering the destination, then the destination address Applies to Infotainment Columbus, Amundsen, Bolero is entered in one step.

  • Page 133: Infotainment Settings - Columbus, Amundsen, Bolero

    Touchscreen tone - Switch on/off audible tone when touching the screen ■ Infotainment settings - Columbus, Amundsen, Bolero No navigation announcements during calls - Switching on / off the nav. announce- ■ ments during a telephone call (not applicable to Infotainment Bolero) Infotainment system settings Display settings sound settings...
  • Page 134 › Date: - Date settings Tap the sensor field and then the function surface  → Mobile device data ■  Date format: - Set the date format transfer. ■ Activate data transfer for ŠKODA apps- Turning data transfer on and off ■...
  • Page 135 ® Find devices - Search for available Bluetooth devices ■ Network settings Bluetooth audio (A2DP/AVRCP) - Activate/deactivate the ability to connect a ■ Applies to the infotainment Columbus with seated in the external module SIM ® Bluetooth audio device (e.g. MP3 player, tablet etc...) card as well as for the Infotainment Amundsen with the connected Carstick- Device.

  • Page 136: Radio Menu Settings

    The information on available software updates is obtained from a ŠKODA If you lose reception in the given the region, Infotainment will automatically partner or from the following ŠKODA Internet pages. set another available region. http://go.skoda.eu/updateportal Advanced settings (DAB) › Radio menu settings In the Radio main menu, select the DAB range and tap on the function sur- face ...

  • Page 137: Media Menu Settings

    L-band Enter/change PIN for parental settings - Management of the PIN code for parental ■ For the DAB radio reception in different countries, different broadcasting control ranges are used. In some countries the DAB radio reception is only possible in Parental settings: - Parental control settings ■...

  • Page 138: Smartlink+ Menu Settings

    Call settings: - Setting the phone functions of the SIM card inserted in the ex- Delete text messages - Delete the data stored on the SIM card text messages ■ ■ ternal module during a call (applies to Infotainment Columbus with the SIM All - Delete all text messages ■...

  • Page 139: Navigation Menu Settings

    Activate data transfer for ŠKODA apps- Activate/deactivate data transfer for Google Earth™ settings - Enable / disable display of special destinations in the ■ ■ ™ ŠKODA applications Google Earth map (applies to Columbus Infotainment when displaying the ® ™ MirrorLink®...
  • Page 140 ■ ŠKODA partner or on the following ŠKODA Internet pages. nouncements (applies to Infotainment Columbus) ■ Comprehensive - All nav. announcements http://go.skoda.eu/updateportal Brief - Short nav. announcements ■ Congestion only - Only nav. announcements when a route is changed ■...

  • Page 141: Infotainment Settings - Swing

    Summer time - Switches summer time on/off ■ Infotainment settings - Swing Automatic summer time - Switches the automatic switch to summer time on/off ■ Date: - Date settings ■ Infotainment system settings Date format: - Set the date format ■...

  • Page 142: Radio Menu Settings

    Radio Data System (RDS) - enable/disable RDS function (receiving additional in- ■ The information on available software updates is obtained from a ŠKODA formation from the station)  partner or from the following ŠKODA Internet pages. http://go.skoda.eu/infotainment Infotainment...

  • Page 143: Media Menu Settings

    Sort station list: - Sort types of radio stations in the station list ■ Import contactsTelephone menu settings Group - Sort by transmitted program type ■ › In the Telephone main menu, tap on the function surface  . Alphabetically - Alphabetical sorting according to station name ■...

  • Page 144: Radio

    Radio text display (DAB) / image presentation (DAB)  Radio Settings of menu Radio » page 134 » page 140  service Information symbol in the status line Symbol Meaning Introduction to the subject Traffic signal is available  Depending on the vehicle equipment fitted and the Infotainment type, ana- Traffic signal is not available ...
  • Page 145 Symbol Meaning List of available stations The transmitter reception is not secure (DAB) (applies to Info-  tainment Amundsen, Bolero, Swing) Stations with image broadcasting (DAB) (does not apply to info-  tainment Swing) Refresh list Depending on Infotainment, the station list update takes place as follows: Frequen- Columbus Amundsen, Bolero...
  • Page 146 Assign station logo manually Note › Tap on the function surface in the Radio main menu  → Station logos. If the station that is currently set does not transmit traffic reports or the sig- ■ › Tap on an occupied station button and select the data carrier (SD card, USB). nal is not available, then Infotainment automatically searches in the back- ›...

  • Page 147: Media

    Playback control - Columbus, Amundsen, Bolero Media Operation Action service Play / Pause Tap  Main menu Tap  after 3 s from the start of the track playback Fig. 176 Finger movement to the right of the Plays the current track from the start Media: Display example screen area »...
  • Page 148 Folder/track list » Fig. 177 Playback control - Swing Selected audio source / audio source folder (movement within the folder Operation Action takes place by pressing the function surface for the folder) Options folder/track playback Play / Pause Tap  Display of multimedia database (only available in the source directory) (not Tap ...

  • Page 149: Audio Sources

    › Display of files/track list (only available in the bibliography) To eject, press the button  The CD/DVD is moved to the starting position. Select the audio source  If the ejected CD/DVD is not removed within 10 seconds, it is retracted again for safety reasons.
  • Page 150 SD card USB input Installation location of the USB input and information regarding its use Fig. 180 » page Columbus, Amundsen, Bolero: The USB input audio source can be connected directly or via a connecting ca- Insert SD card ble. ›...
  • Page 151 Connect / disconnect Note › ® To connect the Bluetooth player with Infotainment- follow the same in- Files that have already been copied are recognised and cannot be copied ■ structions as for pairing Infotainment with a telephone» page 158. again (shown in grey).
  • Page 152 Supported audio file formats Supported audio sources and file formats - Columbus, Amundsen, Bolero Maximum Codec type Max bit Multi File suffix sampling Playlists (File formats) rate channels rate Supported audio sources Windows Media File sys- 384 kbit / Source Interface Type Specification...

  • Page 153: Images

    Supported audio sources and file formats - Swing Images Image viewer Supported audio sources Source Interface Type Specification File system main menu Standard SD reader SD, SDHC, SDXC Applies to Infotainment Columbus, Amundsen, Bolero. size USB stick; Fig. 182 HDD (without any spe- Images: main menu cial software);...
  • Page 154 Control viewed images Supported image file formats and sources Operation Action Supported image sources Moving your finger across the screen to the Source Type Specification File system left (with initial representation) Display of the next image Standard size SD, SDHC, SDXC FAT16 Tap ...

  • Page 155: Video Dvd

    Operation Action Video DVD Tap  after 3 s after the start of the Play the current video from the start video player playback Fast rewind Press and hold  main menu Play the next video Tap  Only valid for Infotainment Columbus. Fast forward Press and hold ...

  • Page 156: Media Command

    Symbol Operation Media Command Confirmation  Operation Main menu Return to Video DVD main menu Introduction to the subject Supported video sources and file formats Applies to Infotainment Columbus, Amundsen. Supported video sources Fig. 185 File sys- ŠKODA Media Command appli- Source Interface Type...
  • Page 157 CAUTION Select source and control playback If several devices are connected to the infotainment using WLAN, there is ■ › To select the playback source tap the function surface in the main menu  the risk of the WLAN overloading and thus also Media Command being ren- and select the source tablet.

  • Page 158: Telephone

    Operating system Operating system Telephone Type Format Android Introductory information MPEG-1;2 and   Introduction to the subject Layer 3 (mp3)  (4,1+)  WARNING Audio  (4,1+)  The general binding country-specific regulations for operating mobile phones in the vehicle must be observed. ...

  • Page 159: Pairing And Connecting

    › List of connected telephones, which are available as the source of tele- To display, press the button.  phone contacts If another, menu id displayed which was open last, to display the Telephone ▶  - no telephone is connected for telephone contacts main menu, press the button again ...
  • Page 160 Infotainment Bluetooth can be displayed. ces. › http://go.skoda.eu/compatibility Confirm the PIN code (enter and confirm if necessary). WARNING conditions for pairing Do not Pair and connect a telephone to Infotainment when the vehicle is in The ignition is switched on.
  • Page 161 Note Vehicle antennas are used to receive the mobile radio signal of the connected phone. Possible connection types ® Depending on the number of connected Bluetooth devices, connection type, as well as the use of the SIM card in the external module, the following functions are available.
  • Page 162 Applies to Infotainment Amundsen, Bolero Applies to Infotainment Columbus with SIM card inserted in external mod- The second device (additional The first device (main phone) phone) Symbol Symbol Operation colour HFP (Incoming / outgoing calls), SMS, HFP (incoming calls), telephone contacts, External device can be connected to use telephone ®...

  • Page 163: Use The Sim Card In The External Module

    › Confirm the entered PIN code by tapping  confirm. Use the SIM card in the external module › or: Tap the function surface  to save the PIN code and confirm it. Applies to Infotainment Columbus with the SIM card slot in the external mod- Change PIN code ule.
  • Page 164 For example, if you enter 32, the unit will display contacts with the letter se- Display the contact details  quence DA, FA, EB, etc. next to the numerical keypad. Select the telephone number in the contact details Edit the telephone number of the contact before dialling ...
  • Page 165 The function surface can be assigned a different number for the preferred Management of preferred contacts (favourites) contact. To restore the emergency number, it is necessary to remove the telephone Fig. 191 from the list of paired external devices » page 160 and then to pair and con- Favourite contacts nect again.

  • Page 166: Text Messages (Sms)

    End conference call  Phone call Display conference call  Depending on the conversation context, the following functions can be carried Conference details out. During the ongoing conference call, press the function surface  . ▶ End dialling / reject incoming call / end call ...
  • Page 167 Drafts- Open a list of drafts (messages in progress) Contact list  After the list has been opened the following functions can be executed. Deleted- Open a list of deleted messages  Send contact details - Send contact details (business card) (applies to Info- Insert a contact in the recipient list ...

  • Page 168: Data Connection

    Forwarding a message with the option to edit the message before sending  Data connection Reply to the sender via a message  Internet connection Infotainment Columbus Fig. 194 WLAN / Bluetooth® / SIM card Possible connection types » Fig. 194, Using WLAN, by connecting Infotainment with the external device hot spot...

  • Page 169: Establishing A Connection Using The Carstick Device

    If your data provider is not available in the list, ask your provider whether one Infotainment Amundsen of the displayed providers can be used. The parameters of the telephone service provider network can be set in the →  → Network → Network settings menu item. ...

  • Page 170: Establishing A Connection Using The Bluetooth Rsap Profile

    CAUTION Set infotainment hotspot When inserting an incorrectly sized SIM card or in the wrong direction, there is The infotainment hotspot is factory-set. a risk of damage to the external module. The setting can be changed in the →  → WLAN → Mobile hotspot → Hotspot ...
  • Page 171 › › If Infotainment WLAN is not activated, then switch this on in the →  → Switch the Infotainment hotspot on/off in the →  → WLAN → Mobile hot-   WLAN → WLAN → WLAN menu item. spot →...

  • Page 172: Smartlink

    SmartLink system. If no external device is connected, then a menu with supported SmartLink communication systems is displayed » Fig. 198, http://go.skoda.eu/connectivity-smartlink Main menu » Fig. 198 Depending on the model of the connected external device, some applications Supported communication systems can be operated using Infotainment , voice or using the buttons on the multi- function steering wheel.

  • Page 173: Android Auto

    If route guidance is taking place at this moment in Infotainment, then there Connection / disconnection is the option to start the route guidance in the Android Auto application. And Connection set-up vice versa, if route guidance is currently taking place in the Android Auto ap- ›...

  • Page 174: Mirrorlink

    By connecting the external device to Apple CarPlay, all currently connected ® MirrorLink ® Bluetooth devices are disconnected. Introduction to the subject During the duration of connection, Bluetooth devices cannot be connected to infotainment. The SIM card inserted in the external module can only be used A connection can only be established with an external device that supports the for data services.

  • Page 175: Applicationškoda Oneapp

           (applies to the infotainment Swing) http://go.skoda.eu/infotainment To show / hide the function buttons, press the controller  (applies to Info- For the full functionality of the ŠKODA One App application, data transfer tainment Amundsen, Bolero).

  • Page 176: Navigation

    A possible connection between the mobile telephone and the Infotainment Navigation system via WLAN will be terminated after a connection is established using SmartLink. Introductory information Connection via WLAN (applies to Infotainment Columbus, Amundsen) › Navigation - function sequence Switch on the ignition. ›...
  • Page 177 Maps - Import of the navigation data available for the respective countries/re- ■ ŠKODA partner or on the following ŠKODA Internet pages. gions (applies to Infotainment Columbus) » page 175, Update navigation data http://go.skoda.eu/updateportal online Update navigation data online ▶ Select the desired list entries. When activated online services Infotainment Online »...
  • Page 178 Main menu Fig. 203 Fig. 204 Navigation: Main menu Card description › To display, tap the sensor field The following information and function surfaces can be displayed in the  › or: Tap the sensor field and then the function surface  . map.

  • Page 179: Search For Destination And Enter

    ™ In the Google Earth Card is represented by the map of the downloaded from additional window the Internet pictures. › To display, tap the function surface » page 184, Options for map display, Fig. 205 Split screen ™ The map and symbol display in the Google Earth map is dependent on the provider, American company Google, Inc.
  • Page 180 › Function surfaces » Fig. 207 Route guidance is enabled - From the main Navigation menu, tap the func- tion surface  → Tap Enter destination Searching for a destination or POI (point of interest) by name » page 178 ›...
  • Page 181 Enter destination using the address Enter destination on the map and using GPS coordinates Fig. 210 Enter destination using the address: Main menu/list of places Fig. 211 Enter destination: via the map point / using the GPS coordi- found nates Show menu Show menu ›...
  • Page 182 Entering a destination via the map coordinates Fig. 212 Menu after tapping the map point Fig. 214 List of car parks searched for: In the navigation data / online Tap on the map to display the symbol  and a menu with the following menu Infotainment allows for a quick search of petrol stations, restaurants or car items (depending on the context) »...

  • Page 183: Saved Destinations

    List of stored destinations Note › In the Navigation main menu, tap the function surface  → Destinations. With activated function  → Fuel options → Select preferred fuel station function ac- › Select function surface » Fig. 215 and one of the following categories of tivated, the preferred fuel stations are displayed in the first three positions saved destinations »...

  • Page 184: Import Your Own Goals

    “MyDestination”application is dis- played. http://go.skoda.eu/my-destination Access to the ŠKODA Connect Portal is the website ŠKODA Connect refer to. This is carried out by reading the QR code »...
  • Page 185 Guidance to an online destination Goals in vCard format › Tip on the traffic obstruction icon in the map. In the Infotainment memory, a custom destination can be imported in the There are details of the selected target appears » page 187, vCard format (*.vcf) from an SD card or a USB source.

  • Page 186: Map

    There are details of the selected target appears » page 187, Image with GPS coordinates Clear all own POI categories › In the Navigation main menu, tap the function surface  → Manage memory → Fig. 218 Delete "My POIs". Image with GPS coordinates ›...
  • Page 187 Display of the route from the current vehicle location to the destination Types of manual scale change  Touching the screen with two fingers and pulling them apart or closing them ▶ Presentation of the destination or the next interim destination in the map ...
  • Page 188 The map is in the 2D display.  Options for map display in the split screen The map is centred (the function surface  is hidden).  Only valid for Infotainment Columbus. The map scale is max. 10 km away. ...

  • Page 189: Route Guidance

    Road sign display Destination details Infotainment offers the option of displaying the traffic signs stored in the navi- gation data or detected by the front camera during guidance on the Infotain- ment screen » Fig. 204 on page 176. › To switch on/off the road sign display in the main menu Navigation, tap on the function surface ...
  • Page 190 Route calculation and start route guidance Route calculation for the trailer When driving with a trailer or any other accessory connected to the trailer Fig. 225 socket, we recommend that you switch on the trailer recognition, if necessary Alternative routes to set the maximum speed for towing a trailer.
  • Page 191 The last navigation announcement can be repeated in the main Navigation Graphical driving recommendations menu by tapping on the function surface  →  . The timing of the nav. announcement is dependent on the type of road and on the driving speed.

  • Page 192: Route

    › By turning off the ignition for longer than 120 minutes. Remaining distance to the destination  Chosen route type (economic, fastest, shortest) Abort route guidance Current vehicle position (address / GPS coordinates) If the ignition is switched off and on again, then the route guidance is contin- The display of the arrival time or the remaining driving time can be adjusted as ued depending on the stop time in one of the following ways.
  • Page 193 Store route Remove transit point › In the area , tap the function surface Save. In the Navigation main menu, tap the function surface  → Change route in map. ▶ › ▶ Save the edited route as a new route or replace the existing saved route. Tap on function surface Delete waypoint.

  • Page 194: Waypoint Mode

    If a new route available, then a message is displayed on the Infotainment. The main menu is displayed» Fig. 229. › Tap the function surface Retrieve to start route guidance. Any ongoing route guidance is terminated after the selection of this way- point mode menu.
  • Page 195 Automatically set waypoints Reverse tour - Reverse the order of waypoints (suitable for guiding along a ■ waypoint tour in the reverse direction) Manually set waypoints Next. Waypoint. - Skip to the next waypoint ■ Split screen Waypoints with the number of already set waypoints / maxi- Start - starts route guidance ■...

  • Page 196: Traffic Reports

    › Choose the desired waypoint tour, and then select one of the following menu TMC Traffic Information (with strikethrough icon, the Infotainment is out  items. of range of any traffic information provider) Online traffic report  Store the waypoint tour on the SD card ...
  • Page 197 Update The dynamic route function is turned on.  The list of traffic reports will be updated by Infotainment on a continuous ba- The traffic congestion included in the traffic information is on the route.  sis. The traffic obstruction will be evaluated by Infotainment as of great im- ...

  • Page 198: Vehicle Systems

    Depending on the vehicle equipment with manual air conditioning: Set-  Vehicle systems ting the auxiliary heating and ventilation / operating the heated wind- screen CAR - Vehicle settings Operation of the steering wheel heating  Introduction to the subject Vehicle system settings ...

  • Page 199: Driving

    Electronic immobiliser and steering lock Driving  Read and observe on page 197 first. Starting-off and Driving The electronic immobiliser (hereinafter referred to as immobiliser) makes it Starting and stopping the engine more difficult for someone to attempt to steal or use your vehicle without au- thorisation.
  • Page 200 Starting the engine Switching the ignition on/off › On vehicles with Ignition lock, turn the key to position and the engine starts» Fig. 235 on page 198 . Release the key, the engine will start auto- matically. If the engine does not start within 10 seconds, turn the key to position .

  • Page 201: Start-Stop-System

    If the system determine that the engine is not needed when the vehicle stops Note or is at a standstill (e.g. at the traffic lights), it turns off the engine and starts it The engine running noises may be louder at first for a short time after start- ■...
  • Page 202 Requirements for the system to function correctly Note The following conditions must be met for the system to function correctly. If the driver's seat belt is removed for more than approx. 30 seconds or the ■ The driver's door is closed. driver's door is opened during automatic stop mode, the engine will have to be ...

  • Page 203: Brakes And Parking

    WARNING Brakes and Parking Greater physical effort is required for braking when the engine is switch- ■  Introduction ed off – risk of accident! During the braking procedure on a vehicle with manual transmission, ■ when the vehicle is in gear and at low revs, press the clutch pedal. Other- The wear of the brake pads is dependent on the operating conditions and driv- wise, the functionality of the brake system may be impaired –...
  • Page 204 Emergency braking function If, while driving, a fault occurs in the brake system, the parking brake can be used as an emergency brake » › Pull the  button in the direction of arrow » Fig. 240 hold (you hear an audible signal), the vehicle starts to brake strongly.
  • Page 205 For the activation, deactivation and correct functioning of the system, the CAUTION following basic conditions are required. In some washing systems it is necessary that the vehicle can roll freely. There- The driver's door is closed. fore, the system must be deactivated before driving through a car wash. ...

  • Page 206: Manual Gear Changing And Pedals

    CAUTION Manual gear changing and pedals If not in the process of changing gear, do not leave your hand on the gear shift  Introduction lever while driving. The pressure from the hand can cause the gear shift mech- anism to wear excessively. CAUTION Pedals When stopping on a slope, never try to hold the vehicle using the accelerator...
  • Page 207 Forward mode / sports programme - the gear change takes place in the WARNING (Continued) position S at higher engine speeds than in mode D If the vehicle stalls, with engine running, in the D, S, R or Tiptronic mode, ■...
  • Page 208 The selector lever is not locked when quickly moving across the position N If you do not pull one of the rocker switches for a certain time, manual (e.g. from R to D/S). This, for example, helps to rock out a vehicle that is stuck, shifting of the gears is deactivated automatically.

  • Page 209: Running In The Engine And Economical Driving

    Accelerate to maximum speed when starting (launch control function) For an economical driving style, the following instructions must be observed. The launch control function is available in mode S or Tiptronic. Avoid unnecessary acceleration and braking. ▶ ▶ Observe the recommended gear »...

  • Page 210: Avoiding Damage To Your Vehicle

    “Green leaf” Avoiding damage to your vehicle The greener the leaf, the more economic the driving style. With less economi- cal driving, the leaf is presented without any green colouring or it can be com- Driving Tips pletely hidden. Only drive on such roads and in such terrain that match the vehicle parameters bar graph »...

  • Page 211: Assist Systems

    › Therefore determine the depth of the water before driving through bodies of Assist systems water. The water level must not reach above the lower edge of the lower brace » Fig. 247. General information › Drive at a maximum speed of walking pace, otherwise a shaft may form in front of the vehicle which could enable water to enter the vehicle system ...

  • Page 212: Braking And Stabilisation Systems

    The sensor is part of the ACC » page 229 and Front Assist » page 235sys- WARNING tems. The general information relating to the use of assistance systems must be observed » page 209, in section Introduction. The sensor function may be impaired in the event of one of the following sit- uations arising.
  • Page 213 › or: In the Infotainment system, in menu /  tap on function surface  → With deactivation the warning light lights up in the instrument cluster   ESC system: → Activated. an appropriate message is displayed in the instrument cluster. With deactivation the warning light extinguishes in the instrument cluster Activation ›...

  • Page 214: Offroadmode

    Brake Assist (HBA) Trailer stabilisation system (TSA)   Read and observe on page 210 first. Read and observe on page 210 first. The HBA increases the braking effect and helps to reduce the braking dis- The TSA helps the combination stable in situations where the trailer sways and tance.
  • Page 215 Function Hill Descent Assist  Read and observe on page 212 first. The hill descent assistant (hereinafter referred to as assist system), with its au- tomatic braking action on all wheels, ensures a constant speed is maintained on a steep slope when driving forwards and reversing. During an intervention, the white warning light ...
  • Page 216 WARNING ABS Offroad For the correct operation of the assistant the road surface must be suffi-  Read and observe on page 212 first. ciently adherent. The assistant cannot properly fulfil its function on slushy soil due to physical reasons (e.g. ice or mud). - there is a risk of an accident! ABS Offroad supports the driver when braking on an unpaved surface (e.g.

  • Page 217: Parking Aid (Parkpilot)

    ParkPilot - Settings for the parking aid ■ Parking aid (ParkPilot) Activate automatically - Activate/deactivate the compact parking aid display ■  (when driving forward) Introduction Front volume - Adjust the volume of the beeps for obstacle detection in front ■...
  • Page 218 Note Fig. 253 If with Version 3 vehicles not all fields around the vehicle silhouette are ac- ■ Sampled areas and range of the tive after activation, the vehicle should be moved forwards or backwards. sensors The signal tones for front obstacle recognition are factory-set to be higher ■...
  • Page 219 Road display Seek help from a specialist garage. The road display » Fig. 254 indicates the road on which the vehicle would Note take the current steering wheel and shift / selector lever position. The system can only be activated with the button at a speed of below 15 The shift lever is in the neutral position and the gear selector is in mode N.

  • Page 220: Rear Traffic Alert And Wizard For "Blind Spot"Monitoring

    Disable / Enable WARNING The brake function can be enabled / disabled in the Infotainment in the menu The general information relating to the use of assistance systems must be Parking and manoeuvring » page 215. observed » page 209, in section Introduction.
  • Page 221 Rear Traffic Alert- Operation Wizard for “Blind Spot”Monitoring - Operation  Read and observe on page 218 first. At a speed over 15 km/h, the area alongside and behind the vehicle is moni- tored by the system. At the same time, the distance and the difference in speed between your vehicle and the other vehicles in the monitored area can be measured.
  • Page 222 Note The brightness of the indicator light is dependent on the setting of the vehi-  cle lighting. With the low or high beam on the brightness of the light will be lower. Activation / deactivation  Read and observe on page 218 first.

  • Page 223: Reversing Camera

    System fault Operating principle In the case of a system fault, an error message appears. Seek help from a spe- cialist garage. Reversing camera  Introduction The rear view camera (following as system) helps the driver when parking and manoeuvring by displaying the area behind the vehicle on Infotainment screen (hereinafter only known as screen).

  • Page 224: Park Assist

    When driving from a horizontal surface into a slope or a depression. ■ Guidelines and function surfaces When driving from a slope or a depression onto a horizontal surface. ■ Park Assist  Introduction Park Assist (following referred to system) helps drivers park in suitable parallel and perpendicular parking places or also to manoeuvre out of parallel parking spaces.
  • Page 225 Do not use the system if snow chains or an emergency wheel are fitted. Conditions for the system function ■ If wheels other than those approved by ŠKODA AUTO are fitted, the result- The system can look for a parking space only if the following basic conditions ■...
  • Page 226 Note Parking If the symbol  (km / h) is shown in the display while you are looking for a parking space, the vehicle speed should be reduced below 40 km / hr (parallel parking) or below 20 km / hr (Transverse parking). Switch to park mode Fig.
  • Page 227 ›  Continue driving forwards until  appears in the display. Read and observe on page 222 first. › Stop and ensure that the vehicle does not continue to move forward until the The system supports the driver when parking forward in the parking space parking procedure starts.

  • Page 228: Cruise Control System

    WARNING Automatic brake assist The general information relating to the use of assistance systems must be ■  Read and observe on page 222 first. observed » page 209, in section Introduction. After pressing the clutch pedal, no interrupted control occurs! For exam- ■...

  • Page 229: Speed Limiter

    This is only possible within the range which is permitted by the power output WARNING and braking power of the engine. Always deactivate the cruise control system after use to prevent the sys- ■ tem being switched on unintentionally. WARNING The control does not resume if the set speed for the existing traffic con- ■...
  • Page 230 Function Operation description - Variant without CCS Fig. 271 Controls of the speed limiter (version without CCS)  Read and observe on page 227 first. Fig. 270 Instrument cluster display: Examples of Speed Limiter status displays Overview of the speed limiter controls »...

  • Page 231: Adaptive Cruise Control (Acc)

    Operation description - Variant with GRA Operation description - Variant with ACC Fig. 272 Controls the speed limiter (ver- sion with GRA)  Read and observe on page 227 first. Fig. 273 Controls the speed limiter (version with ACC)  Overview of the control elements of the speed limiter »...
  • Page 232 The front of the vehicle and the distance to the vehicle ahead is monitored by Settings in Infotainment a radar sensor » page 209.  Read and observe on page 230 first. The state in which the ACC maintains the speed or the proximity is described as control from here on.
  • Page 233 Regulation according to the vehicle in the adjacent lane During regulation your vehicle may be regulated according to the vehicle in the adjacent lane. This could occur at speeds above about 80 km/h when your vehicle is moving faster than the vehicle in the adjacent lane on the driver's side. The display shows the detected vehicle is in the adjacent lane.
  • Page 234 Operation overview Start control  Read and observe on page 230 first. Basic requirements for start of control The ACC is activated.  On vehicles with manual transmission, the second gear or a higher gear is  selected and the current speed is greater than 30 km/h. On vehicles with automatic transmission, the selector lever is in the D/S ...
  • Page 235 Set the distance with the lever Set/change desired speed › Set the switch  Adjust in the spring-tensioned position  or  » Fig. 276  Read and observe on page 230 first. on page 232. The display of the instrument cluster shows line »...
  • Page 236 Overtaking and towing  Read and observe on page 230 first. When overtaking When your vehicle is being controlled at a speed that is lower than the set speed and the turn signal is operated, ACC assesses this situation as meaning that the driver wishes to overtake.

  • Page 237: Front Assist

    ACC fault Operation With an ACC fault, an error message appears. Seek help from a specialist ga-  Read and observe on page 235 first. rage. The system support is provided in the following manner. Front Assist ▶ Alerts you about a dangerous proximity to the vehicle ahead. ▶...
  • Page 238 Automatic braking - a stationary obstacle Warning and automatic braking If the driver does not respond to the advance warning of the risk of a collision with a stationary obstacle in a speed range of approximately 30 km/h to 60 Fig.

  • Page 239: Select The Driving Mode (Driving Mode Selection)

    If the driver does not respond to the advance warning, the system begins to Select the driving mode (Driving Mode Selection) automatically brake the vehicle.  Introduction Disable/enable By selecting the driving mode, the driving behaviour can be adapted to the de- ...
  • Page 240 Note Mode Snow The maximum vehicle acceleration (kick down function) is possible also in driv-  Read and observe on page 237 first. ing mode Eco. The mode is suitable for driving on slippery or snow-covered roads. Mode normal The driving profile Snow does not allow the automatic transmission to be set to ...

  • Page 241: Proactive Passenger Protection (Crew Protect Assist)

    Note Function The currently selected driving mode is displayed in the infotainment system ■  Read and observe on page 239 first. in the status bar next to the symbol . The selected driving mode and the setting of the mode Individual is stored in ■...

  • Page 242: Spurhalteassistent (Lane Assist)

    CAUTION Spurhalteassistent (Lane Assist) Do not attach any stickers or similar objects in front of the sensor on the wind-  Introduction screen to avoid impairing the functions of the system. Note Fig. 282 The system is designed for driving on motorways and roads with adequate ■...
  • Page 243 If the position within the lane is changed, the system quickly adapts and holds the newly-selected position. Steering wheel vibrations In the following situations, it may occasionally be the case that due to the steering wheel vibrations the syst4em indicates that a driver steering interven- tion is required.

  • Page 244: Traffic Jam Assistant

    Sensor covered / dirty The traffic jam assistant is an extension of the systems Lane Assist » page 240 If the windscreen is dirty, iced or misted up in the sensor area, a message ap- and ACC » page 229 and works by using the functions of these two systems.

  • Page 245: Traffic Sign Recognition

    The assistant for emergencies is an extension of the systems Lane Assist WARNING » page 240 and ACC » page 229 and works by using the functions of these Please take note of the general points relating to the use of assistance ■...
  • Page 246 Trailer recognition The system can display the following (vertical) traffic signs where identified. ■ Show road signs relevant to trailers - Activating / deactivating the display of road Speed limit. ■ ▶ signs relevant to trailers ▶ Overtaking prohibited. Use for route calculation - Activation / deactivation taking trailers in account ■...

  • Page 247: Fatigue Detection System

    Pause recommendation Note The icon appears and the following message for a few seconds in the display The setting (activation/deactivation) of the auxiliary display will be saved (de- of the instrument cluster  and a message about the detected fatigue. An au- pending on Infotainment type) in the active user account personalisation dible signal is also emitted.
  • Page 248 A message on the screen informs about the storage of the tyre pressure val- WARNING ues. Please take note of the general points relating to the use of assistance ■ systems » page 209, in section Introduction. Note Having the correct tyre inflation pressure is always the driver's responsi- ■...

  • Page 249: Towing Device And Trailer

    Towing device and trailer Hitch  Introduction The maximum trailer load is dependent on the engine and the vehicle equip- ment. The valid specification for your vehicle is to be found in the technical ve- hicle documentation, the Declaration of Conformity (what is known as a COC document) or can be requested from a ŠKODA partner.

  • Page 250: Using Hitch

    WARNING CAUTION Take care with the towing device - it may cause injury. Never exceed the permissible total weight of the accessories incl. load and ■ maximum length of the accessories - There is a risk of damage to the towing When swinging out the ball rod away from the central area of the rear ■...
  • Page 251 Headlights WARNING (Continued) The front of the vehicle may lift up when a trailer (accessory) is being towed After the electrical connection between the vehicle and trailer (accesso- ■ and the headlights may dazzle other road users. Set the range of the headlights ry) the trailer / accessory lights should be checked for function.
  • Page 252 Permissible trailer weight, braked (kg) Engine Transmission Permissible trailer load, unbraked (kg) with gradients up to 12%. 1.6 l/85 kW TDI CR 1500 MG 4x4 2000 2.0 l/110 kW TDI CR DSG 4x4 2000 The valid valve for your vehicle is to be found in the technical vehicle documentation, as well as the Declaration of Conformity (what is known as a COC document) or can be requested from a ŠKODA partner. Conditions for including a trailer (accessory) in the anti-theft alarm system.

  • Page 253: General Maintenance

    ŠKODA Service Partner General Maintenance  Read and observe on page 251 first. Care and maintenance All ŠKODA Service Partners operate according to the most recent guidelines Service work, adjustments and technical alterations and instructions from ŠKODA AUTO . All service and repair work is therefore carried out on time and at the appropriate quality.

  • Page 254: Cleaning And Care

    ŠKODA Service Partners are liable for any defects of ŠKODA Genuine Acces- Airbags sories for a period of 2 years after installation or delivery in accordance with  Read and observe on page 251 first. the materials defect liability, unless agreed otherwise in the purchase agree- ment or any other agreements.
  • Page 255 When using the care product, always observe the instructions on the packag- Give the vehicle a good rinse after washing it and dry it off using a chamois ing. We recommend that you use the preservative from the ŠKODA Original leather.
  • Page 256 During cleaning, always keep a sufficiently large spraying distance in particu- ■ Vehicle compo- Facts of the Remedy lar from the parking sensors, the reversing camera lens, the external decora- nent matter tive and protective plastic parts (e.g. roof racks, spoilers, protective strips) and Wiper / wiper other vehicle parts made of non-metallic materials, such as rubber hoses or in- Soiling...
  • Page 257 Do not polish the paintwork in a dusty environment - risk of paint scratch- ■ Removing snow and ice from the windscreens Do not apply any paint care products to door seals or window guides. ■ Fig. 291 Plastic parts ■...
  • Page 258 CAUTION Caring for the interior ® Natural leather / Faux leather / Alcantara / material ■  Read and observe on page 253 first. In lengthy periods in bright sunlight, it might be sensible to cover these ma- ■ terials in order to avoid bleaching. Vehicle compo- Facts of the Fresh stains (e.g.

  • Page 259: Inspecting And Replenishing

    Petrol and diesel refuelling Inspecting and replenishing Fuel  Introduction Fig. 292 Stickers with prescribed fuel Fig. 293 Open fuel filler flap/unscrew tank cap/place the tank cap on the fuel filler flap Fig. 294 The correct fuel for your vehicle is specified on the inside of the fuel filler flap Fuel filler tube on vehicles with »...
  • Page 260 › Remove the pump nozzle from the fuel filler neck and put it back in the Prescribed petrol 98/(95) RON / ROZ pump. We recommend using petrol 98 RON. › Place the filler cap onto the fuel filler neck and turn it in the opposite direc- Optionally, petrol 95 RON can be used (slight power loss, a slightly increased tion to the arrow until it securely engages fuel consumption).

  • Page 261: Adblue ® And Its Refilling

    ® Only use AdBlue that corresponds to the standard ISO 22241-1. Do not add Diesel fuel ® additives to AdBlue  Read and observe on page 257 first. ® The AdBlue -consumption depends on driving style, the operating tempera- ture of the system and on the weather conditions. The correct fuel for the vehicle is specified on the inside of the fuel filler flap »...

  • Page 262: Engine Compartment

    › ® If the available travel distance that can be driven with the existing AdBlue Remove the tank cap and place in the recess on top of the fuel filler flap in tank capacity drops down to 0 km, then no motor start is possible. In this the direction of arrow ›...

  • Page 263: Bonnet

    WARNING (Continued) Open the bonnet and close Allow the engine to cool. ■ Never open the bonnet if you can see steam or coolant flowing out of the ■ engine compartment – risk of scalding! Wait until the steam or coolant has stopped escaping.

  • Page 264: Engine Oil

    › Let the engine compartment door drop from about 20 cm in height for it to Windscreen washer fluid lock into place securely. › Check that the lid is closed. Fig. 298 If the bonnet lid is not properly closed, the display of the instrument cluster Windscreen washer fluid reser- will show this.

  • Page 265: Coolant

    › Petrol engines: VW 504 00, VW 502 00, VW 508 00, ACEA A3/ACEA B4 or Add oil of the correct specification in increments of 0.5 litres » page 262. ▶ › API SN, (API SM); Check the oil level . ›...
  • Page 266 Refilling WARNING The coolant expansion tank must always contain a small amount of coolant The following warning instructions must be followed at all times when ■ » working in the engine compartment » page 260. › Never open the end cover of the coolant expansion reservoir while the ■...

  • Page 267: Brake Fluid

    Brake fluid Vehicle battery  Introduction Fig. 301 Brake fluid reservoir The vehicle battery represents a power source for the motor to start and for the supply of electrical consumers in the car. Automatic consumer shutdown - Discharge protection of the vehicle battery The on-board power supply tries as follows to avoid draining the vehicle bat- tery when it is heavily loaded.
  • Page 268  Read and observe on page 265 first. WARNING (Continued) Keep the vehicle battery away from people who are not completely inde- ■ The battery condition is checked regularly by a specialist garage as part of the pendent, especially children. inspection service.
  • Page 269 › After charging has been successful: Switch off the charger and remove the CAUTION mains cable from the power socket. Disconnect the vehicle battery only with the ignition turned off - there is a ■ › Disconnect the terminals of the charger from the vehicle battery. risk of damaging the electrical system of the vehicle.

  • Page 270: Wheels

    The specified running direction must be strictly adhered to, otherwise the fol- Wheels lowing tyre characteristics may be degraded. ▶ Driving stability. Wheels and tyres ▶ Traction. ▶ Tyre noise and tyre wear. Advice on tyre/wheel usage WARNING New tyres, during the first 500 km, new tyres do not offer optimum grip and appropriate care should therefore be taken when driving.
  • Page 271 Tyre diameter in inches The tyre wear increases in the following circumstances. This information serves merely as information for the prescribed tyre Incorrect tyre pressure. ▶ pressure. This is not a list of shared tyre sizes for your vehicle. These are in ▶...

  • Page 272: Operating In Winter Conditions

    Speed symbol - indicates the maximum permissible speed for a vehicle fit- Spare wheel ted with tyres in the category concerned A warning label is displayed on the rim of the temporary spare wheel. Only use speed this to reach the nearest specialist garage since it is not intended for perma- symbol nent use.
  • Page 273 category specified for the mounted tyres in Infotainment (only applies to cer- tain countries). This specification defines the maximum vehicle speed with mounted all-season or “winter”tyres that may not be exceeded. Snow chains The snow chains improve driving in wintry road conditions. Before fitting the snow chains, remove the full wheel trims.

  • Page 274: Do-It-Yourself

    Placement of reflective vest Do-it-yourself Emergency equipment and self-help Fig. 306 Stowage compartment for the Emergency equipment reflective vest in the front door Placement of the first aid kit and warning triangle Fig. 305 Placing of the first-aid kit and the warning triangle The reflective vest can be stowed in the storage compartment inside the...

  • Page 275: Changing A Wheel

    WARNING WARNING Always properly secure the fire extinguisher, there is a risk of injury in the The factory-supplied lifting jack is only intended for your model of vehi- ■ event of sudden braking or a vehicle collision. cle. Under no circumstances attempt to lift other vehicles or loads with this –...
  • Page 276 › Jack up the vehicle» page 276 until the wheel that needs changing is clear of WARNING the ground. A tightening torque which is too high can damage the bolts and threads › Unscrew the wheel bolts and place them on a clean surface (cloth, paper, and this can result in permanent deformation of the contact surfaces on etc.).
  • Page 277 Installing the trim Removing/stowing wheel in vehicles with sound system › Press the wheel trim onto the wheel rim at the designated valve opening. › Then press the trim into the wheel rim until its entire circumference locks Fig. 310 correctly in place.
  • Page 278 › Push the wheel wrench onto the wheel bolt to the stop. Use the associated Anti-theft wheel bolts upper section for the anti-theft wheel bolts » Fig. 312 on page 276. › To loosen the screws, hold the wrench end and turn the screw about one Fig.

  • Page 279: Puncture Repair Kit

    Jacking points for the car jack are directly under the marking on the bottom Do not remove foreign bodies which have penetrated into the tyre (e.g. nails beam panel» Fig. 315 - , etc.). › Insert the crank into the mount on the jack »...
  • Page 280 Inflation hose with plug Sealing and inflating tyres Air compressor (the layout of the controls may be different depending on  Read and observe on page 277 first. the type of air compressor delivered with the vehicle) Tyre inflation hose Sealing ›...

  • Page 281: Jump-Starting

    Once a tyre inflation pressure of 2.0 – 2.5 bar is achieved, continue the journey Jump-starting at a maximum speed of 80 km/h (50 mph).  Introduction WARNING If the tyre does not inflate to at least 2.0 bar, the damage is too great. The ■...

  • Page 282: Towing The Vehicle

    The jump-start cables must be attached in the following sequence. Towing the vehicle › Attach clamp to the positive terminal of the discharged battery. › Attach clamp to the positive terminal of the current-giving battery. Information about the towing process ›...
  • Page 283 Driver of the towed vehicle Removing/inserting protective grille › › If possible, the vehicle should be towed with the engine running. Operate the To remove, insert the clamp for taking off the full wheel trims in the recess brake booster and power steering only if the engine is running, otherwise the in the protective grille and remove the protective grille in the direction of ar- brake pedal must be depressed more strongly and more power has to be di- »...

  • Page 284: Remote Control And Removable Light - Changing The Battery

    › Tighten the towing eye using a wheel wrench or similar object. To do this, Key with fold-out key bit insert the wheel wrench through the eye. › To remove, unscrew the towing against the direction of arrow Vehicles with a tow hitch For vehicles with factory-fitted towing device, at the back there is no mount for a screw-in towing eye.

  • Page 285: Emergency Unlocking / Locking Of Doors

    CAUTION Remote control of the auxiliary heating If an incorrect battery type is used or a non-rechargeable battery, there is a risk of damaging the light and the vehicle's electrical system. Emergency unlocking / locking of doors Unlocking/locking the driver's door Fig.

  • Page 286: Replacing Windscreen Wiper Blades

    Locking the door without locking cylinders Selector lever emergency release Fig. 325 Left door/right door Fig. 327 Remove / release the selector lever › › Open the respective door. Switch on the parking brake. › › In vehicles with the panel , remove this panel »...
  • Page 287 Attaching the windscreen wiper blade Replacing the windscreen wiper blades › Push the windscreen wiper blade in the opposite direction of the arrow until it locks into place. Check that the windscreen wiper blade is correctly Fig. 328 attached. Setting the service position for ›...

  • Page 288: Fuses And Light Bulbs

    Fuses in the dashboard - LHD Fuses and light bulbs Fuses  Introduction Fig. 331 Blown fuse Fig. 332 Storage compartment on the driver's side  Read and observe on page 286 first. The fuse box is located behind the storage compartment on the driver's side. Individual electrical circuits are protected by fuses.
  • Page 289 Fuses in the dashboard - RHD Fuse assignment in the dashboard Fig. 334 Fuses Fig. 333 Storage compartment on the front passenger side  Read and observe on page 286 first. The fuse box is located behind the storage compartment on the front passen- ger side.
  • Page 290 Consumer Consumer Air blower for air conditioning,heating Central locking- front and rear door right, power window - right, exterior mirrors right - heating, fold-in function, setting the mirror Electric steering lock surface USB ports, diagnostics connector, Phonebox 12-volt power outlets Instrument cluster, emergency call Right side belt tensioner Reversing camera...
  • Page 291 Fuses in the engine compartment Fuse assignment in engine compartment Fig. 336 Fuses Fig. 335 Fuse box cover: Removing cover / plastic clip for fuses  Read and observe on page 286 first.  Changing a fuse Read and observe on page 286 first.

  • Page 292: Bulbs

    WARNING Consumer Always read and observe the warnings before completing any work in the ■ Databus, battery data module engine compartment » page 260. Windscreen wipers Accidents can be caused if the road in front of the vehicle is not suffi- ■...
  • Page 293 › Press the attachment securing lugs in the direction of arrows , and care- Removing bulbs for low and main beam fully pull out the bulb holder with the bulb. › Grasp the holder in area › Remove the faulty bulb from the holder in the direction of the arrow ›...
  • Page 294 › Remove the key in the direction of the arrow Changing the bulbs for fog lights › Attach the connector to the new holder with the light bulb. › Insert a new holder with the bulb in the headlamp and turn it in the direction Fig.
  • Page 295 CAUTION Ensure that when re-inserting the light the wiring harness between the body ■ and the light is not jammed and the seal » Fig. 344 is correctly inserted - Otherwise there is a risk of water ingress and damage to the electrical installa- tion.

  • Page 296: Technical Data

    Vehicle identification data Technical data Technical data Fig. 346 Rating plate Basic vehicle data  Introduction The details given in the vehicle's technical documentation always take prece- dence over the details in the Owner's Manual. The listed performance values were determined without performance-reduc- Type plate ing equipment, e.g.
  • Page 297 The towed weight is made up of the actual weights of the loaded towing vehi- Measurement of fuel consumption and CO emissions according to cle and the loaded trailer. ECE Regulations and EU Directives WARNING The data on fuel consumption and CO emissions were not available at the Do not exceed the specified maximum permissible weights –...
  • Page 298 Dimensions Fig. 347 Vehicle dimensions The vehicle dimensions given in the vehicle's technical documentation always take precedence over the details in the Owner's Manual. The dimensions listed below are for the basic model without any optional equipment. Vehicle dimensions for operating weight without driver (in mm) »...
  • Page 299 Overhang angle Fig. 348 Overhang angle Angle » Fig. 348 Approach angle Departure angle The values shown indicate the maximum incline of an embankment, up which the vehicle can drive at a slow speed without collision of the bumper or under- body.

  • Page 300: Vehicle-Specific Details Per Engine Type

    Vehicle-specific details per engine type  Introduction The values given have been determined in accordance with the rules and conditions specified in statutory or technical regulations for determining operational and technical data for motor vehicles. The exhaust gas standard is specified in the vehicle's technical documentation, as well as in the declaration of conformity (in so-called COC document). The declaration of conformity (the so-called.
  • Page 301 2.0 l/110 kW TDI CR engine Output (kW at 1/min) 110/3500-4000 Maximum torque (Nm at 1/min) 340/1750-3000 Number of cylinders/displacement (cm 4/1968 Transmission MG 4x4 DSG 4x4 Speed limits (km/h) Acceleration 0-100 km/h (s) Technical data...

  • Page 302: Index

    Adjusting the seats manually Anti-blocking system (ABS) Index Advice on tyre/wheel usage Anti-theft alarm system Trailer Favourite Anti-theft wheel bolts A2DP/AVRCP Flagged destination 133, 161 Abort route guidance Online goals Apple CarPlay 42, 211 own goal applications saved destination Disclaimer search see Automatic Distance Control Armrest...
  • Page 303 Automatic transmission bolero Selector lever emergency release external module Call list infotainment Description Auxiliary heating (auxiliary heating and ventila- Call list tion) Bonnet In infotainment Boot Car battery set to Hooks Automatic consumer shutdown Auxiliary heating (heating and ventilation) Boot lid Disconnecting and reconnecting Radio remote control Automatic locking...
  • Page 304 Check Compatible sources Brake fluid DVD video Engine oil Pictures additional information Oil level Component protection Radio Text and images presentation Checking Computer 134, 141 Battery condition see multifunction display DAB Slideshow Coolant Conditions for pairing Data connection Children and safety Conference call Amundsen Child safety lock...
  • Page 305 Destination details Driver information system Electrical boot lid set the top position of the lid Destination management Driving Destination details Emissions Electrical power windows Favourite Fuel consumption Electric boot lid Storage Maximum speed Force limiter through water Destination on the map Manual operation Destination entered in map Driving mode...
  • Page 306 Vehicle tool kit External module Force limiter Warning triangle CD / DVD Electric boot lid SD card Sliding/tilting roof Emergency spare SIM card Window Removing / stowing Video DVD Front assist Emission control system Warning light 47, 48 Emissions Front Assist Engine Disable/enable Factory settings...
  • Page 307 Gear change Infotainment Online Gear recommendation Infotainment operation I-PAD holder Information on the selected gear Infotainment screen I-Size Gear changing Infotainment operation using an application in Ignition lock lever the external device Images Genuine parts Infotainment Overview Display Glasses storage box Infotainment Restart main menu Google Earth™...
  • Page 308 Jukebox Speed limiter with ACC Liste gekoppelter externer Geräte Speed limiter with CCS Jump-starting List of available hotspots Speed limiter with GRA List of traffic reports Turn signal/main beam Load Windscreen wipers 77, 78 KESSY localisation services Liability for defects deactivating Lock Light...
  • Page 309 main menu Display of traffic signs Media Command Android car Display options in the split screen Control Apple carplay Fast Map Main menu Images Google Earth™ Supported formats MirrorLink® Lane guidance Memory radio Main menu Memory Function for the seat Video DVD Manual scale Menu DVD-Video...
  • Page 310 navigation Network additional window Map alignment Data connection Contacts Map scale Data roaming Demo mode Most common routes setting destination search Navigation data set to Favourites Navigation data update Values of the downloaded data Map orientation nav. announcements New route obstruction of traffic Nav.
  • Page 311 Online services Park Passive Safety Change the user Rear traffic alert Pedals Delete the user Park assist Floor mats Electronic manual Parking Personalisation instructions video Park Assist Configuration wizard localisation services Automatic brake assist Personalization Private mode Leaving a parallel parking space Operating principle Services Management Malfunctions...
  • Page 312 Requirements and restrictions Refill Supported file formats Windscreen washer fluid radio Pin code refilling Broadcasting set to AdBlue L-band Playback Refilling main menu Media Coolant Radio stations Logo 143, 144 Video DVD Engine oil scan Pockets Reflective vest serve 180, 183 Refuelling Radio Fuel...
  • Page 313 Road Signs I-Size Memory Function of the electrically adjustable infotainment display ISOFIX seat TOP TETHER Rear Roller blind Rear seat backrests see Luggage compartment cover SAFE, SAFELOCK Setting See SafeLock Roof Storing in memory of remote control key Load Save radio see Instrument cluster Save channel Roof racks...
  • Page 314 sound Telephone Sockets sound system Time and date 131, 139 12-volt socket in the interior surround Top speeds 12 volt socket in luggage compartment system information Units 132, 139 230 V ŠKODA Connect Update software Software Update 130, 133 vehicle User profile Software updates Video DVD...
  • Page 315 Starting the engine Switching the lights on and off SIM card Jump-starting Telephone 156, 157 Switch off Telephone book Start the route guidance Alarm Text messages (SMS) Status bar switch on / offTraffic User profile dynamic route status line Voicemail Navigation system information Telephone book...
  • Page 316 traffic Turning on Infotainment Update the navigation data Detail of the traffic report Turn signal Uphill start assistant Traffic Turn signal system 93, 148 List of traffic reports Warning light Safe removal Traffic Information (TMC) Tutorial videos Useful equipment Traffic jam assistant Clothes hook Tyre Cup holders...
  • Page 317 Vehicle tool kit Waypoint mode Winter operation Main menu All season tyres Vehicle width Record waypoints Diesel fuel Verwaltung gekoppelter Geräte Set waypoint manually Snow chains Vest Waypoint tour memory Vehicle battery Video DVD Winter tyres Waypoint tour memory Playback Winter tyres Weather conditions Set to...
  • Page 318 Services Manager set to ŠKODA Connect Online Services Enable services Register ŠKODA OneApp application Index...
  • Page 319 Index...
  • Page 320 Index...
  • Page 321 Index...
  • Page 322 Reprinting, duplicating, translating and any other use, either in whole or in part, Issued by: ŠKODA AUTO a.s. is not permitted without the written consent of ŠKODA AUTO a.s. © ŠKODA AUTO a.s. 2017 ŠKODA AUTO a.s. expressly reserves all rights relating to copyright laws. Subject to change.
  • Page 324 Návod k obsluze Karoq anglicky 07.2017 57A012720AA  57A012720AA...

Table of Contents
