06 Basic Operations

Setting MTS/SAP mode

When watching conventional TV programs, you may enjoy
stereo sound and/or Secondary Audio Programs (SAP), using
the Multi-channel Television Sound (MTS) function.
• Stereo broadcasts
You can enjoy, for example, sports, shows, and concerts in
dynamic stereo sound.
• SAP broadcasts
MAIN sound: The normal program soundtrack (either in mono
or stereo).
SAP sound: Listen to second language, supplementary com-
mentary and other information. (SAP is mono sound.)
• Conventional TV programs in this manual designate TV channels that
are received through the conventional VHF/UHF frequencies or
conventional cable TV channels.
• When stereo sound is difficult to hear, you can manually switch to
the MONO mode to obtain clearer sound.
• Once the MONO mode is selected, the Plasma Display sound
remains mono even if the Plasma Display receives a stereo broad-
cast. You must reselect the STEREO mode if you want to hear stereo
sound again.
• Selecting MTS while the input source is in VIDEO, S-VIDEO, COMPO-
NENT and HDMI does not change the type of the sound. In this case,
the sound is determined by the video source.
SPLIT
DTV
SIGNAL
Each time you press the MTS button, MTS toggles as shown
below.
STEREO mode
STEREO
• In each of the MTS/SAP modes selected using the MTS button, the
display changes depending on broadcasting signals being received.
22
En
07-PDP42A3HD-Eng (19-23)
SPLIT P IN P SWAP
INPUT SHIFT
SPLIT SPLIT
CH+ CH–
CH
DELETE
MTS LIST
SAP mode MONO mode
SAP SAP MONO MONO
22

Using the multiscreen functions

You can display a sub-picture within the main picture. In this
way you can watch a TV program or monitor the video input
from any connected device while watching TV or another video
input.
Use this function following the procedures below to select the
Twin (2-screen) or PIP (picture in picture) mode.
• In the multiscreen function, the sound of a main input is always
output.
PIP (picture in picture)
Main input
Twin 1 (2-screen)
Main input
Twin 2 (2-screen)
Main input
1
Press the MENU button.
2
Press the c or d button to move to Screen, then press
the \ or OK button.
3
Press the c or d button to move to PIP/TWIN, then
press the \ or OK button.
Screen
Screen Size Auto
Main Input Analog TV
PIP/TWIN
Screen Saver
Move Adjust Return
05.4.20, 4:30 PM
Sub-picture
Sub-picture
Sub-picture
