Cisco TelePresence SX20 Codec
Contents Introduction

H320 status

xStatus H320 Gateway Status

Returns the state of the H320 Gateway, if the codec is paired with an ISDN Link.
Value space of the result returned:
<OK/OKWithWarning/Error/Inactive/Warning>
Example:
xStatus H320 Gateway status
*s H320 Gateway Status: Error
** end

xStatus H320 Gateway Address

Returns the IPv4 address of the ISDN Gateway, if the endpoint is paired to one.
Value space of the result returned:
<OK/OKWithWarning/Error/Inactive>
Example:
xStatus H320 Gateway Status
*s H320 Gateway Status: Inactive
** end

xStatus H320 Gateway Number

Returns the IPv6 address of the ISDN Gateway if the endpoint is paired to one.
Value space of the result returned:
<String>
Example:
xStatus H320 Gateway Number
*s H320 Gateway Number: ""
** end
SX20 Codec API Reference Guide TC6.2, JULY 2013.
D14949.04
About the API xConfiguration

xStatus H320 Gateway Mode

xStatus H320 Gateway Reason

xStatus H320 Gateway Id

136
xCommand
Returns information on the type of calls the ISDN Gateway is configured for, if the codec is paired
with an ISDN Link.
Value space of the result returned:
<Unknown/PRI/BRI/External/G703>
Example:
xStatus H320 Gateway Mode
*s H320 Gateway Mode: Unknown
** end
Shows the reason for rejected Gateway registration. Only available if the codec is connected to an
ISDN Link.
Value space of the result returned:
<String>
Example:
xStatus H320 Gateway Reason
*s H320 Gateway Reason: ""
** end
Returns the unique identification of the H320 Gateway, if the codec is paired with an ISDN Link. .
Value space of the result returned:
<String>
Example:
xStatus H320 Gateway Id
*s H320 Gateway Id: "00:50:60:0B:EF:11"
** end
