Page 1
Bluetooth Sound Bar with Built-In Subwoofer CHT912 INSTRUCTION MANUAL...
Page 2
FCC Warnings WARNING:Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 4
AC/DC adapter 1. Placing on the table Ventilation When placing the Sound Bar on an entertainment center, bookshelf, or any type of enclosed space, be sure to allow at least 2-3 inches of space around the Sound Bar for ventilation. If the Sound Bar is enclosed in a tight space, without ventilation, heat generated from the Sound Bar could produce a potential heat hazard.
You will need : • Tape Measure • Level • Manual or Electric drill • Pencil 2.1. Mounting on the wooden wall You should use 2 pieces of short screws 2 pieces of EVA 1. Use the TAPE MEASURE to decide how high you’d like to hang the sound bar on the wall.
Page 6
2.2. Mounting on the dry wall You should use 2 pieces of short screws 2 pieces of EVA 2 pieces of plastic tubes...
Page 7
1. REMOTE SENSOR: Ensure this area is not covered or blocked by any object. 2. STANDBY button: Press to turn the speaker bar off or on. 3. SOURCE button: Press to switch between Bluetooth receiver, AUX, LINE in and FM. 4.
Page 8
1. STANDBY button: Press to turn the unit on or off. 2. BT button: Press to switch to Bluetooth mode. 3. SCAN button: Press to scan for available radio stations in FM Radio mode. 4. MUSIC button: Press to switch to the EQ optimized for music. 5.
Page 9
1. It includes one 2025 button cell battery. (pre-installed) 2. Removes the transparent sheet. OPEN PUSH...
4. When successfully paired and connected, blue LED indicator will be light only and stop blinking. 5. If your device should become upaired or it is unable to connect, blue LED indicator will continue flashing and blinking. Repeat the above steps to try to pairing. 6.
Problem What to do No power Check that the power is switched on at the wall. Check if the power cord is properly connected to the power outlet. Check that the volume control is NOT at minimum No sound setting. Check that it is NOT set to mute.
Page 13
Power Source :……………………. AC120V, 60Hz Power Source of Remote Control:……DC 3V, 1X CR2025 battery (Included) Power Consumption:…………………………………….< 1W Audio Power : Woofer ………………………………….... 30W Left Channel ……………………………...10W Right Channel………………………….....10W Radio Coverage …..………………………....…. FM 87.5-108.0 MHz Impedance of Speakers : Woofer ……………………………….…..… 8 Ohm,18W x 2 Left Channel ……………………………..
