Oki C831 Installation Instructions Manual

C831 - Installing Additional RAM
Install additional RAM to increase the memory
capacity of your printer in cases such as if
occur. Your printer supports 256 MB and 512 MB
RAM.
Note
Use only genuine Oki Data products. The performance
cannot be guaranteed when using other products.
The static electricity may damage parts. Discharge the
static electricity from your body by touching grounded
metallic parts, etc., before work.
Memo
For banner printing, installing additional memory is
recommended.
1 Turn off your printer, and then unplug
the AC cord and Ethernet or USB cable.
Reference
"Turning Off the Power" P.22
2 Open the access cover (1) on the right
side of a printer.
3 Slide the metal plate (2) upward to
remove.
Note
If the SD memory card socket is attached, remove
the SD memory card.
(1)
metal plate (2), and slide it upward.
1
2
ENGLISH - 1
(2) Pinch the lower part of the metal
plate (2), and pull it forward.
4 Make sure the LED (3) indicated by the
arrow turns off. If it is lit, wait until it
turns off.
5 Insert the additional RAM (4) into the
printer.
Note
Be sure to check a direction of an additional RAM.
The additional RAM has small dents on its connector,
6 Install the metal plate (2).
(1) First, insert the upper part of the
metal plate (2) in the printer, then
install the metal plate.
2
3
4
2
