COMPASS APP
1.0 Display Map
In COMPASS mode, the direction is displayed in the centre
part of the Deep X face.
The angle in degrees is displayed in the upper part of the
display.
1.1 Calibrating
While in COMPASS mode, press SET button to go to the
calibrating function. Select CALIBRATE, then from the screen
with arrows, do a complete turn (360°) and press SET button.
Your compass is now calibrated.
1.2 Declination
To compensate for the deviation between magnetic North &
geographic North, you can adjust the offset of the compass.
While in COMPASS mode, press SET button then select
DECLINATION; use (+)/(-) keys to adjust the declination (West
or East). Press SET once complete.
24
1.3 Power-On defaults
Unit of Measure - Degrees
Calibration Status – Un-calibrated
Declination 0°
1.4 Boundary Conditions
Range - 0-359°
Cardinal Points - N, NE, E, SE, S, SW, W, NW
Declination - 45°W - 0° - 45°E
