300 Rigid Pavement Design
Table of Contents
300 Rigid Pavement Design ............................................... 300-1
300.1 Introduction ............................................................................... 300-1
300.2 Types of Concrete Pavement.................................................... 300-1
301 Design Parameters .............................................................. 300-2
301.1 Modulus of Rupture ................................................................... 300-2
301.2 Modulus of Elasticity ................................................................. 300-2
301.3 Load Transfer Coefficient .......................................................... 300-2
301.4 Composite Modulus of Subgrade Reaction ............................... 300-2
301.5 Loss of Support ......................................................................... 300-2
301.6 Effective Modulus of Subgrade Reaction .................................. 300-3
302 Thickness Determination .................................................... 300-3
302.1 Ramps and Interchanges .......................................................... 300-3
303 Jointing and Shoulder Considerations ............................. 300-3
303.1 Transverse Joints...................................................................... 300-3
303.2 Expansion and Pressure Relief Joints ...................................... 300-3
303.3 Longitudinal Joints .................................................................... 300-4
303.4 Intersection Jointing Details ...................................................... 300-4
303.5 Shoulder Considerations ........................................................... 300-4
303.6 Edge Course Design ................................................................. 300-5
304 Concrete Pavement Usage Guidelines .............................. 300-5
304.1 Item 451 Reinforced Concrete Pavement ................................. 300-5
304.2 Item 452 Non-Reinforced Concrete Pavement ......................... 300-5
304.3 Item 884 Warranty Concrete ..................................................... 300-5
304.4 Item 305 Concrete Base ........................................................... 300-5
304.5 Class of Concrete ..................................................................... 300-6
305 Warranty Concrete ............................................................... 300-6
306 Smoothness Specifications ................................................ 300-6
307 Composite Pavement .......................................................... 300-6
July 2014
Advertisement
Table of Contents
Related Manuals for Huawei Y360-U03
Summary of Contents for Huawei Y360-U03
-
Page 1: Table Of Contents
300 Rigid Pavement Design Table of Contents 300 Rigid Pavement Design ..........300-1 300.1 Introduction ................300-1 300.2 Types of Concrete Pavement............ 300-1 301 Design Parameters .............. 300-2 301.1 Modulus of Rupture ..............300-2 301.2 Modulus of Elasticity ..............300-2 301.3 Load Transfer Coefficient ............ -
Page 2: 300 Rigid Pavement Design
300 Rigid Pavement Design 307.1 Composite Pavement Design............ 300-6 307.2 Composite Pavement Typical Section Design ......300-7 307.3 Composite Pavement Warranty ..........300-7 307.4 Composite Pavement Smoothness Specifications ....300-7 July 2014... -
Page 3: 300.1 Introduction
300 Rigid Pavement Design 300 Rigid Pavement Design 300.1 Introduction Rigid pavements can be constructed with contraction joints or no joints, with dowels or without dowels, and with reinforcing steel or without steel. For jointed concrete pavements, regardless of whether reinforced or non-reinforced, the AASHTO/ODOT method of pavement design calculates the same required thickness. -
Page 4: 301 Design Parameters
300 Rigid Pavement Design 301 Design Parameters ODOT's method for the design of rigid pavement limits the designer to prescribed input parameters. The input values prescribed are based on Ohio materials and ODOT Specifications. 301.1 Modulus of Rupture Modulus of rupture, as determined under a breaking load, measures the flexural strength or extreme fiber stress, of the concrete slab. -
Page 5: 301.6 Effective Modulus Of Subgrade Reaction
300 Rigid Pavement Design 301.6 Effective Modulus of Subgrade Reaction The effective modulus of subgrade reaction (k) is the composite modulus of subgrade reaction as modified by the loss of support. Figure 301-3 is a nomograph that determines the effective modulus of subgrade reaction. -
Page 6: 303.3 Longitudinal Joints
300 Rigid Pavement Design To control pressure buildup, expansion joints and pressure relief joints are used. The most common need for an expansion joint or a pressure relief joint is to protect bridge back-walls. Four types of pressure relief joints are detailed in the Standard Construction Drawings. For new pavement construction, the Type A joint should be provided at all bridge approaches where the bridges are over 300 feet (90 m) apart. -
Page 7: 303.6 Edge Course Design
300 Rigid Pavement Design complexity of construction. Tying concrete shoulders to the driving lanes provides lateral support and spreads the load over a greater area. Concrete shoulders should use non-reinforced concrete even if the driving lanes are reinforced. The plans should include a note modifying the transverse joint spacing of the non-reinforced shoulders if tied to reinforced driving lanes. -
Page 8: 304.5 Class Of Concrete
300 Rigid Pavement Design 304.5 Class of Concrete Class QC1 is recommended for all mainline, shoulder, and ramp concrete in excess of 250 feet (75 m) of continuous pavement. Class QC MS or QC FS may be used for smaller, repair-type areas. These mixes are intended for joint and crack repairs or individual slab replacements. - Page 9 300 Rigid Pavement Design 307.2 Composite Pavement Typical Section Design Composite pavement should be constructed using Item 305 Concrete Base. The width of the concrete base should be extended beyond the wearing surface by 3 inches (75 mm). Item 409 Sawing and Sealing Asphalt Concrete Pavement Joints is recommended for most newly constructed composite pavements.
-
Page 10: List Of Figures
300 Rigid Pavement Design List of Figures Figure Date Subject 301-1 July 2016 Rigid Pavement Design Parameters 301-2 July 2008 Composite Modulus of Subgrade Reaction (k 301-3 July 2008 Effective Modulus of Subgrade Reaction (k) 302-1 July 2016 Rigid Pavement Design Example 302-2 July 2008 Rigid Pavement Design Chart Segment 1... - Page 11 301-1 July 2016 Rigid Pavement Design Parameters Reference Section MATERIAL PROPERTIES Modulus of Rupture (S’ 700 psi Modulus of Elasticity (E 5,000,000 psi Load Transfer Coefficient (J) - Doweled, Edge Support* Load Transfer Coefficient (J) - Doweled, No Edge Support* * Edge support includes tied concrete shoulders, integral curb, widened lane, etc.
- Page 12 301-2 Composite Modulus of Subgrade July 2008 Reaction (k Reference Section & Figure 301.4, 302-1 (step 3)
- Page 13 301-3 Effective Modulus of Subgrade July 2008 Reaction (k) Reference Section & Figure 301.6, 302-1 (step 4)
- Page 14 302-1 Rigid Pavement Design Example July 2016 Reference Section Page 1 Given: Pavement of choice: Doweled, jointed concrete • Subbase: 6 inches Item 304 Aggregate Base • Shoulders: Tied, jointed, concrete • Number of Lanes: 4 (2 per direction) • Functional Classification: Principal Arterial (Rural) •...
- Page 15 302-1 Rigid Pavement Design Example July 2016 Reference Section Page 2 Step 2 - Determine the subgrade resilient modulus (M ) using the formula given in Section 203.1. = 1200 * CBR = 1200 * 5 = 6000 psi Step 3 - Determine the composite modulus of subgrade reaction (k ) using Figure 301-2.
- Page 16 302-2 Rigid Pavement Design Chart July 2008 Segment 1 Reference Section & Figure 302, 302-1 (step 5)
- Page 17 302-3 Rigid Pavement Design Chart July 2016 Segment 2 Reference Section & Figure 302, 302-1 (step 5)
- Page 18 Surface Treated Shoulder and 303-1 July 2008 Stabilized Aggregate Shoulder Reference Section Typical Sections 205.1, 303.5, 303.6...
