- Page 1 SHAPE ® Manuel d’utilisation / User Manual / Manual de uso / 使 用 手 册 / 사용 설명서 / 取扱説明書 Français : page 2 English : page 11 Español : página 20 中文：第28页 한국어 : 37 페이지 日本人 : ページ 46...
-
Page 2: Safety Information
Our policy of continual product improvement means that Focal-JMlab reserves the right to modify the technical specifications of its products without notice. Product may vary from images. -
Page 3: Package Contents
U s e r M a n u a l Thank you for purchasing a Focal product. We welcome you to our universe of high-fidelity sound. For over 30 years, Focal has been designing, developing and manufacturing exceptional loudspeakers, and more recently, headphones. - Page 4 SHAPE ® U s e r M a n u a l SHAPE 40 The SHAPE 40 loudspeaker is a professional nearfield monitor loudspeaker with two active channels (two internal amplifiers), composed of one 4" (10cm) low/midrange flax sandwich membrane loudspeaker driven by two passive side radiators and one 'M' profile Aluminum- magnesium tweeter (fig.
-
Page 5: Installation
If necessary, it is perfectly acceptable to turn the loudspeakers over from the normal position and have the tweeter at the bottom in order to meet this rule. SHAPE loudspeakers must... - Page 6 SHAPE ® U s e r M a n u a l Stereo Positioning Once you have decided on positioning, you have 4 height adjustable decoupling spikes. These spikes enable you to significantly reduce the mechanical We recommend that you position the loudspeakers coupling of the loudspeakers to the surface on which in such a way as to make an equilateral triangle.
- Page 7 Running In The transducers used in SHAPE loudspeakers are complex mechanical assemblies which need a period of running in to operate at their best and to become acclimatised to the temperature and humidity conditions of your environment.
- Page 8 FR (full range: high pass filter deactivated) when the loudspeakers are used in 2.0 stereo configuration. Shape 40 has a 2-position switch: FR and 80 Hz. Shape 50 and 65 have a 4-position switch: FR, 45, 60 and 90 Hz. It is recommended to use positions 45, 60, 80 (Shape 40) or 90 Hz if a system is used with one or more subwoofer(s) or if the listening room tends to strongly increase the lower frequencies.
-
Page 9: Mains Power Connector
" (70 mm) for the Shape 40, 50 and 65. Use M6 screws. 10 - MOUNTING TO A TABLE STAND OR A MICROPHONE STAND The fastening point underneath the Shape 40 and Shape 50 is for mounting the loudspeaker to a table stand or a microphone stand. - Page 10 SHAPE ® U s e r M a n u a l System SHAPE 40 SHAPE 50 SHAPE 65 • Frequency response (+/-3dB) 60Hz - 35kHz 50Hz - 35kHz 40Hz - 35kHz 102dB SPL 106dB SPL 109dB SPL • Maximum SPL (musical signal)
