Page 1: Side View
Side view Fig. 1 Vehicle side overview. Key to fig. Fuel filler flap Roof antenna Outside door handle Outside mirror – Additional turn signal light Lift points for the jack Side marker light...
Page 2: Front View
Front view Fig. 2 Vehicle front overview. Key to fig. Inside mirror with sensor on mirror base for: – Rain sensor (if equipped) – Low-light sensor (if equipped) Windshield wipers Engine hood release Headlights (on both left and right) Fog lights/static cornering lights (on both left and right, if equipped) Threaded hole for the front towing eye (behind cover) Turn signals (on both left and right)
Page 3: Rear View
Rear window – Rear window defroster High-mounted brake light Taillights (on both left and right) Volkswagen emblem. Area for: – Rear hatch release – Rear Assist camera (if equipped) License plate lights Threaded hole for the rear towing eye (behind cover)
Page 4 Driver door overview Fig. 4 Overview of controls in the driver door. Key to fig. Door handle Power locking button for locking and unlocking the vehicle Knob for adjusting the outside mirrors – – – Adjusting outside mirrors – Outside mirror heating Buttons for operating the power windows Indicator light for the power locking system Lever for releasing the engine hood...
Page 5 HI GH L OW – Intermittent operation for windshield wipers º – Windshield wiper – “One-tap wiping” – Windshield wiper – Automatic wipe/wash for windshield – Lever with buttons for the Volkswagen Information System Multi-function steering wheel controls (if equipped)
Page 6 – Mute switching for radio or activation of voice control – Audio, Navigation ∃, – Control buttons for the Volkswagen Information System Ignition switch (vehicles without Keyless Access) or location for the emergency start feature for the Keyless Access locking and starting system...
Page 7: Upper Center Console
Center console overview Applicable only in the United States Upper center console Fig. 6 Overview of the upper center console. Key to fig. Switch for emergency flashers PASSENGER AIR BAG light (front airbag for front seat passenger) Radio Radio or Radio & Navigation system (factory-installed) ⇒ b ooklet Navigation system ⇒ ...
Page 8 Applicable only in Canada Upper center console Fig. 7 Overview of the upper center console. Key to ⇒ f ig. Switch for the emergency flashers PASSENGER AIR BAG light (front airbag for front seat passenger) Radio Radio or Radio & Navigation system (factory-installed) ⇒ b ooklet Navigation system ⇒ ...
Page 9: Lower Center Console
Lower center console Fig. 8 Overview of the lower center console. Key to fig. Lever for: – Manual transmission – Automatic transmission Parking brake lever Storage compartment with cup holders in the center console Storage compartment Starter button for the Keyless Access locking and starting system (if equipped) Center armrest with storage compartment (if equipped) 12 Volt socket...
Page 10 Applicable only in the United States Front passenger side overview Fig. 9 Overview of the front passenger side. Key to fig. Passenger front airbag location in the instrument panel (approximate) Opening handle for the upper glove compartment (if equipped) – –...
Page 11 – – Air vents Opening handle for the lower glove compartment...
Page 12 Symbols on the roof console Symbol Meaning Interior and reading lights Power sunroof Mobile Phone Package 3-button module (if equipped) ⇒ b ooklet...
Page 13: Instrument Cluster
Displays (Premium version) Service reminder display More information: Warning and indicator lights Volkswagen Information System Shifting Warranty and Maintenance Service reminder information ⇒ b ooklet WARNING Driving on today's roads demands the full attention of the driver at all times. Driver distrac- tion causes accidents, collisions and serious personal injury! Never use the buttons in the instrument cluster while driving.
Page 14 Please first read and note the introductory information and heed the WARNINGS Instrument explanations ⇒ f ig. Speedometer. Tachometer (thousands of revolutions per minute when the engine is running). The red zone at the end of the scale indicates maximum permissible engine rpm (revolutions per minute) for all gears after the break-in period.
Page 15 Please first read and note the introductory information and heed the WARNINGS Instrument explanations ⇒ f ig. Engine oil temperature indicator The engine has reached operating temperature when the needle moves into the center of the gauge under normal driving conditions. The needle may move farther to the right on the gauge with a heavier engine load at high outside temperatures.
Page 16 WARNING Driving on today's roads demands the full attention of the driver at all times. Driver distrac- tion causes accidents, collisions and serious personal injury! Never set the stopwatch when the vehicle is moving. NOTICE To help prevent engine damage, always avoid high engine speeds, full throttle acceleration and heavy engine loads when the engine is cold.
Page 17 Light flashing or lit – sometimes with acoustic warnings. light Stop! ⇒ Check malfunction and take corrective action. Contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance if necessary. Priority 2 warning Yellow Light flashing or continuously lit – sometimes with acoustic warn- light ings.
Page 18 WARNING Failure to heed warning lights can cause the vehicle to break down in traffic and result in a collision and serious personal injury. Never ignore warning lights or text WARNINGS. Always stop the vehicle as soon as it is safe to do so. Park the vehicle at a safe distance from moving traffic and where no part of the hot cata- lytic converter and exhaust system can come into contact with flammable materials under the vehicle, such as dry grass, brush, spilled fuel, etc.
Page 19 14 Selector lever position, Shifting Gear recommendation, Shifting Multi-Function Indicator (MFI) and menus for different settings, Volkswagen Information System Service reminder display, Service reminder display Warning and information texts The status of various vehicle functions and components is monitored when the ignition is switched on and while driving.
Page 20 When the vehicle is not moving or when you are driving at very low speeds, the temperature displayed may be slightly higher than the actual outside temperature. The measurement range is from -40 °F (-40 °C) to +122 °F (+50 °C). Compass display (if applicable) On vehicles equipped with compass display, the current compass direction is indicated in the instru- ment cluster display when the ignition and navigation system are switched on.
Page 21 Open door, engine hood, or rear hatch ⇒ f ig. 15 Selector lever position, Shifting Gear recommendation, Shifting Multi-Function Indicator (MFI) and menus for different settings, Volkswagen Information System Service reminder display, Service reminder display Alternative speed display Warning and information texts The status of various vehicle functions and components is monitored when the ignition is switched on and while driving.
Page 22 Malfunctions or low operating fluid levels may cause vehicle dam- age and vehicle breakdown ⇒ Check malfunction as soon as possible. Contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance if necessary. Information text –...
Page 23 WARNING Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury. Never ignore warning lights or text WARNINGS. Always stop the vehicle as soon as it is safe to do so. Park the vehicle at a safe distance from moving traffic and where no part of the hot cata- lytic converter and exhaust system can come into contact with flammable materials under the vehicle, such as dry grass, brush, spilled fuel, etc.
Page 24 A minus sign in front of the number of miles (kilometers) or days means that service is overdue. Resetting the oil change service reminder If the service was not performed by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility, the oil change service reminder can be reset as follows: Vehicles with Premium display: Switch off the ignition.
Page 25 Vehicles with Premium display: Switch off the ignition. Switch on the emergency flashers. Press and hold the button in the instrument cluster. Switch on the ignition. Release the button. A confirmation message appears in the display. Confirm request with the in the windshield wiper lever or the button on the multi-function steering wheel.
Page 26 The number of menus in the instrument cluster display depends on the electronics and equipment on the vehicle. An authorized Volkswagen dealer or an authorized Volkswagen Service Facility may be able to add or modify functions depending on your vehicle's equipment.
Page 27 ming). Check the settings and correct as necessary once the vehicle battery has built up a sufficient charge. Applicable only in the United States Menu structure – overview (Basic version) Please first read and note the introductory information and heed the WARNINGS Multi-Function Indicator (MFI) ▪...
Page 28 ▪ Consumption --.- mpg (l/100 km) (current fuel consumption) ▪ Av. consumption --.- mpg (l/100 km) (average fuel consumption) ▪ Range -- mi (km) ▪ Route -- mi (km) ▪ Odometer -- mi (km) ▪ Average speed --- mph (km/h) ▪...
Page 29 Using the instrument cluster menus Fig. 16 In vehicles without a multi-function steering wheel: Use button 1 in the windshield wiper lever to confirm menu items and rocker switch 2 to switch menus. Fig. 17 Right side of the multi-function steering wheel (if equipped): Controls for the menus in the instrument cluster.
Page 30 Selecting a setting Windshield wiper lever: Press the button Multi-function steering wheel: Push the button (⇒ f ig. 17) to select a setting. Returning to the main menu level Windshield wiper lever: Use the rocker switch (⇒ f ig. 16) to select Back. Press the button to select or to toggle between different options within the current menu.
Page 31 When the ignition is switched on and memory 1 or 2 is displayed, press the button on the windshield wiper lever or the button on the multi-function steering wheel to toggle between the 2 memories. The memory accumulates and stores information about distance driven and fuel used from the time the ignition was switched on until the time it was switched off.
Page 32 Display Function Coolant Coolant temperature (digital display). temperature Speed warning When the set speed (from 20–155 mph or 30–250 km/h) is exceeded, an --- mph acoustic warning sounds and a visual message may also appear in the instrument cluster display. Speed warning --- km/h Switching between the displays...
Page 33 Settings menu Function Units Set the units in which temperature, fuel consumption, and distances should be displayed (for example, whether to show distance driven in miles or kilometers). Service View the service reminder display Factory setting Reset the functions in the Settings menu back to the factory settings. Lights &...
Page 34 Driving checklists and warnings Introduction In this section you’ll find information about: Getting ready and driving safely Driving in other countries Driving through water on roads More information: Sitting properly and safely Transporting Starting and stopping the engine Saving fuel and helping the environment Consumer information WARNING...
Page 35 For diesel engines: Is ultra low-sulfur diesel fuel Refueling readily available? ¥ Are engine oil (Engine oil) and other operating fluids that meet Volkswagen quality and perfor- ¥ mance requirements available where you will be driving? For more information, please see ⇒ ...
Page 36 Are special or heavy-duty tires necessary for the kind of driving expected? ¥ NOTICE Volkswagen is not responsible for mechanical damage that may result from substandard fuel or service or the unavailability of Genuine Volkswagen parts. Driving through water on roads...
Page 37: Technical Data
Technical data Introduction In this section you’ll find information about: Important vehicle labels Engine data Dimensions Your vehicle's engine type is shown on the vehicle identification label. The specifications in this Manual refer to the base model. The stated values may vary, depending upon different equipment or models, as well as with respect to special vehicles and vehicles exported to different countries.
Page 38 Fig. 19 Vehicle identification number (VIN). Please first read and note the introductory information and heed the WARNINGS Factory-installed safety certificates, stickers, and signs containing important information regarding vehicle operation can be found in the engine compartment and on certain vehicle components, such as inside the fuel filler flap, on the passenger sun visor, in the driver door jamb, or on the luggage compartment floor.
Page 39: Engine Data
Fuel grade sticker An information sticker listing the correct fuel grade for your vehicle, Refueling. Engine data Please first read and note the introductory information and heed the WARNINGS Gasoline engines Maximum power Injection Engine ID Maximum torque No. of output technology code...
Page 40 NOTICE Please be careful when parking your vehicle in areas with parking barriers or curbs. These vary in height and could damage your bumper and related parts if the front of your vehicle hits a barrier or curb that is too high while you are getting into or out of a parking spot. Always be careful when you enter a driveway or drive up or down steep ramps or over curbs or other obstacles.
Page 41 Indicator light in the remote control vehicle key Replacing the remote control vehicle key battery Synchronizing the remote control vehicle key More information: Volkswagen Information System Power locking and closing system Starting and stopping the engine Consumer information Emergency closing and opening DANGER 20 mm button cells and other lithium batteries will cause serious personal injury and even death within a short time if swallowed.
Page 42 Replacing the remote control vehicle key battery. If this is not the problem, the key should be resynchronized by an authorized Volkswagen dealer, an authorized Volkswagen Service Facility, or another qualified workshop, Synchronizing the remote control vehicle key.
Page 43 To find the nearest qualified independent repair facility, locksmith, or Volkswagen dealer which can cut and code replacement vehicle keys, call the VW Customer Care Hotline at 1-800-822-8987 or visit http://www.vw.com and search for “replacement keys.” Canadian customers can contact an authorized Volkswagen dealer or Volkswagen Service Facility or call the Volkswagen Canada Customer CARE Center at 1-800-822-8987.
Page 44 Fig. 23 Remote control vehicle key: Remove old battery. Please first read and note the introductory information and heed the WARNINGS Volkswagen recommends having the battery in the remote control vehicle key changed by an author- ized Volkswagen dealer or an authorized Volkswagen Service Facility.
Page 45 Special handling may apply – see http://www.dtsc.ca.gov/hazardouswaste/perchlorate. Obey all legal requirements regarding handling and disposal of these batteries. Authorized Volkswagen dealers and authorized Volkswagen Service Facilities are familiar with the requirements, and we recommend that you have them perform this service for you.
Page 46 Leaving the vehicle unlocked for longer periods of non-use (for example, in your garage) can cause the vehicle battery to drain so that the engine can no longer be started. More information: Exterior views Volkswagen Information System Vehicle key set Doors Rear hatch...
Page 47 From the outside with Keyless Access, Unlocking or locking the vehicle with Keyless Access. From the inside with the power locking button, Unlocking or locking the vehicle from the inside. Special functions of the power locking system can be turned on or off by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
Page 48 Note: Depending on the central remote control settings, it may be necessary to press the button on the remote control vehicle key twice to unlock all doors and the rear hatch, Volkswagen Information System. If you would like to have these settings changed, please see your authorized Volkswagen dealer or authorized Volkswagen Service Facility.
Page 49 If the vehicle was unlocked with the remote control vehicle key and the door or the rear hatch has not been opened within a few seconds, the vehicle is automatically locked again. This feature helps pre- vent you from leaving the vehicle unlocked unintentionally. NOTICE Check to make sure that the windows go down slightly when you unlock the vehicle.
Page 50 Volkswagen emblem on the rear hatch is pressed. The following functions are then enabled without active use of the remote control vehicle key: Keyless Entry: Unlocking the vehicle with the sensor surfaces on the door handles of the driver or passenger door ⇒ ...
Page 51 All turn signals flash twice to confirm that the vehicle has been unlocked and once to confirm that it has been locked. If the vehicle was unlocked and within the next few seconds neither a door nor the rear hatch has been opened, the vehicle is automatically locked again.
Page 52 Your vehicle may be equipped with an anti-theft alarm system or pre-equipped for anti-theft alarm system installation. If the vehicle is pre-equipped for installation of the anti-theft alarm system, the alarm system can be retrofitted by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Page 53 Forcibly opening a door. Forcibly opening the engine hood. Forcibly opening the rear hatch. Switching on the ignition with an invalid key. Disconnecting the vehicle battery. Deactivating the alarm Unlock the vehicle with the unlock button on the remote control vehicle key or switch on the ignition with a valid remote control vehicle key.
Page 54 Doors Introduction In this section you’ll find information about: Display More information: Exterior views Vehicle key set Power locking and closing system Power windows Emergency closing and opening WARNING A door that is not closed properly may open suddenly when the vehicle is moving and cause severe injuries.
Page 55 When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds. If a door is not closed properly, the vehicle icon appears in the instrument cluster display showing an open door ⇒ ...
Page 56: Rear Hatch
Rear hatch Introduction In this section you’ll find information about: Display Opening the rear hatch Closing the rear hatch More information: Exterior views Power locking system Transporting Emergency closing and opening WARNING Accidents and severe personal injuries can result if you unlock, open, or close the rear hatch when someone is in the way.
Page 57: Opening The Rear Hatch
Do not place any objects on the rear spoiler. The rear spoiler could be damaged. If the vehicle must be pushed, do not push against the rear spoiler. The rear spoiler and the rear hatch could be damaged. NOTICE Never use the gas strut to hold or clamp a load in place. This can damage the rear hatch and make it impossible to close.
Page 58 Volkswagen emblem. Opening with the Volkswagen emblem Unlock the vehicle or rear hatch, or open a door. Using your thumb, press the top of the Volkswagen emblem ⇒ f ig. 29 and move the top of the emblem down.
Page 59 Closing the rear hatch Fig. 30 Opened rear hatch: Recessed grips for closing. Please first read and note the introductory information and heed the WARNINGS Closing the rear hatch Grasp one of the recessed grips in the rear hatch trim ⇒ f ig.
Page 60: Power Windows
Power windows – features Power window pinch protection More information: Volkswagen Information System Power locking and closing system WARNING Improper use of power windows can result in serious personal injury. Never let anyone get in the way of a power window when closing it.
Page 61 Switches in the driver door Key to fig. For the window in the driver door. For the window in the passenger door. Opening or closing windows Function Action Opening: Press the switch. Closing: Pull the switch. Stopping automatic Press/pull the respective switch again. movement: You can still use the power windows for several minutes after the ignition is switched off as long as the driver or passenger door has not been opened.
Page 62 If the power windows malfunction, the one-touch feature, as well as pinch protection may not work properly. See an authorized Volkswagen dealer or authorized Volkswagen Service Facility right away. If convenience closing of the power windows from the outside requires removing the cover cap of the lock cylinder on the driver door, the cover cap must be reinstalled after the vehicle is locked ⇒ ...
Page 63 If closing takes longer than about 10 seconds, pinch protection is turned on again. The window stops again if there is resistance. If the window still will not close, please see an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Page 64: Power Sunroof
Remove leaves and other objects from the sunroof guiderails regularly either by hand or using a vacuum cleaner. If the power sunroof malfunctions, pinch protection may not function properly. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Page 65 Opening or closing the power sunroof Fig. 32 In the headliner: Rotary switch for the power sunroof. A: Turn the rotary switch to slide the sunroof open or closed. B: Press or pull the switch to tilt open or to close. Please first read and note the introductory information and heed the WARNINGS The rotary switch must be turned to its home position ⇒ ...
Page 66 The power sunroof will now close without pinch protection! If the power sunroof still will not close, please see an authorized Volkswagen dealer or an author- ized Volkswagen Service Facility. WARNING Without pinch protection, the power sunroof will close with enough force to cause serious personal injury.
Page 67 Pull and hold the switch at the rear. The sunroof will open and close on its own. When the sunroof is closed once again, release the switch. If the sunroof still will not close, contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Page 68 Pinch protection does not prevent fingers or other body parts from being pressed against the roof frame, thereby causing injury. If the power sunroof malfunctions, pinch protection may not function properly. See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
Page 69 Adjusting the seating position Introduction In this section you’ll find information about: Examples of improper seating positions Proper seating position Manual controls on the driver and front passenger seats Adjusting the front and rear head restraints ...
Page 70 4 inches (10 cm). If these requirements cannot be met for physical reasons, contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility to see whether adaptive equipment is available. Always hold the steering wheel on the outside of the steering wheel rim with your hands at the 9 o'clock and 3 o'clock positions to help reduce the risk of personal injury if the driv- er's airbag inflates.
Page 71 WARNING Some kinds of cigarette lighters can be lit unintentionally, or crushed causing a fire that can result in serious burns and vehicle damage. Always make sure that there are no lighters in the seat tracks or near other moving parts before adjusting the seats.
Page 72 Only the proper seating position ensures optimum protection by the safety belt and airbag. Contact your authorized Volkswagen dealer or authorized Volkswagen Service Facility or call the Volkswagen Customer CARE Center at 1-800-822-8987 for information about possible modifications...
Page 73 For your own safety and to reduce injuries in the event of sudden braking maneuvers or accidents, Volkswagen recommends the following seating positions: Applies to all vehicle occupants: Adjust head restraints so that the upper edge of the head restraint is at least at eye level or higher.
Page 74 Manual controls on the driver and front passenger seats Fig. 36 Controls on the left front seat. Please first read and note the introductory information and heed the WARNINGS The controls on the front passenger seat mirror those on the driver seat. fig.
Page 75 Adjusting the front and rear head restraints Fig. 37 Adjusting the head restraints. Please first read and note the introductory information and heed the WARNINGS All seats are equipped with head restraints. There are notches in the head restraint guide rods so that the head restraint can lock into place. Only properly installed head restraints can lock into place at the adjustment range notches.
Page 76 WARNING Driving without head restraints or with improperly adjusted head restraints increases the risk of serious injuries in a collision. Always drive with the head restraints in place and properly adjusted to help minimize the risk of neck injury in a crash. Every person in the vehicle must have a properly adjusted head restraint to minimize the risk of neck injury in a crash.
Page 77 Removing the front head restraints Sit in the back seat behind the head restraint you want to remove. Pull the head restraint all the way up ⇒ in Adjusting the front and rear head restraints. Recline the backrest with the head re- straint so that there is enough overhead clearance to remove it.
Page 78 NOTICE When removing or reinstalling the head restraint, take care that the head restraint does not strike the headliner or other parts of the vehicle. The headliner or other parts of the vehicle could otherwise be damaged. Adjusting the steering wheel position Fig.
Page 79: Center Armrest
Center armrest Fig. 41 Front center armrest. Please first read and note the introductory information and heed the WARNINGS Your vehicle may be equipped with a front center armrest. Front center armrest There is a storage compartment in the center armrest, Storage areas. To raise the center armrest, pull the armrest upward in the direction of the arrow ⇒ ...
Page 80: Seat Functions
Seat functions Introduction In this section you’ll find information about: Seat heating Seat heating More information: Adjusting the seating position Safety belts Airbag system Child safety and child restraints Outside mirrors WARNING Improper use of seat adjustment controls can cause severe personal injuries. Always sit properly at all times before starting to drive and while the vehicle is moving.
Page 81 Fig. 43 In the center console: Seat heating buttons for the front seats (Climatronic). Please first read and note the introductory information and heed the WARNINGS Your vehicle may be equipped with a seat heating feature. When the ignition is switched on, the front seats can be electrically heated by heating elements that warm the seat backrest and cushion.
Page 82 If you smell an odor, immediately shut off seat heating and have it checked by an authorized Volkswagen dealer or authorized Volkswagen Service Facility. Never install leather upholstery on a vehicle with seat heating that originally had cloth upholstery. The seat heating elements for seats with cloth seats will overheat if the cloth up- holstery is replaced with leather upholstery.
Page 83 Please first read and note the introductory information and heed the WARNINGS Your vehicle may be equipped with a seat heating feature. When the ignition is switched on, the front seats can be electrically heated by heating elements that warm the seat backrest and cushion. Do not use the seat heating if any of the following conditions apply: If the seat is not being used.
Page 84 If you smell an odor, immediately shut off seat heating and have it checked by an authorized Volkswagen dealer or authorized Volkswagen Service Facility. Never install leather upholstery on a vehicle with seat heating that originally had cloth upholstery. The seat heating elements for seats with cloth seats will overheat if the cloth up- holstery is replaced with leather upholstery.
Page 85: Safety Belts
Check the condition of all safety belts regularly. If a safety belt shows damage to webbing, bindings, retractors or buckles, have the safety belt re- placed by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility ⇒ More information:...
Page 86 WARNING Not wearing a safety belt or wearing an improperly positioned safety belt increases the risk of severe personal injury or death. Safety belts offer optimum protection only when they are used properly. Properly worn safety belts are the single most effective means of reducing the risk of serious injury and death in a collision or other accident.
Page 87 Volkswagen for your vehicle, model, and model year. Safety belts that were subject to stress in an accident and stretched must be replaced with a correct, new safety belt, preferably by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
Page 88 The safety belt warning light comes on for 6 seconds when the ignition is switched on. A warning ª chime also sounds for up to 6 seconds if the driver's safety belt is not buckled. The chime stops soon- er if the driver buckles his or her safety belt. The warning light and the chime go out when both driver and front passenger have bucked their safety belts.
Page 89 The physical principles of a frontal collision are simple. Both the moving vehicle and the passenger possess energy ⇒ f ig. 46, which varies with vehicle speed and body weight. Engineers call this energy “kinetic energy.” The higher the speed of the vehicle and the greater the vehicle's weight, the more energy has to be “absorbed”...
Page 90 Please first read and note the introductory information and heed the WARNINGS Many people believe that it is possible to resist the forces of an impact by holding tight or bracing themselves. That is simply not true! Even at low collision speeds, the forces acting on the body are too much for the body to be held in the seat with the arms and hands.
Page 91 United States and Canada. Although your Volkswagen is equipped with airbags, you still have to wear the safety belts provided. Front airbags, for example, are activated only in some frontal collisions. The front airbags are not activated in all frontal collisions, in side and rear collisions, in rollovers, or in cases when the condi- tions for deployment stored in the electronic control unit are not met.
Page 92 WARNING Improper use and care of safety belts increases the risk of severe personal injury or death. Regularly check safety belts and related parts for damage. Damaged safety belts must be replaced; they cannot be repaired. Always keep safety belts clean. Never catch, damage or chafe safety belt webbing on sharp edges.
Page 93 Make sure the seat backrest of the rear seat bench is in an upright position and securely latched in place before using the safety belt ⇒ Hold the safety belt by the tongue and pull it slowly and evenly across the chest and pelvis. Do not twist the safety belt webbing ⇒ ...
Page 94 Fig. 54 Proper safety belt positioning for expectant mothers. Please first read and note the introductory information and heed the WARNINGS Wearing safety belts improperly can cause serious injury or death. Safety belts can only work when they are correctly positioned on the body. A properly worn safety belt also helps to position the occu- pant so that an airbag can provide maximum protection when deployed.
Page 95 Contact your authorized Volkswagen dealer or authorized Volkswagen Service Facility or call the Volkswagen Customer CARE Center at 1-800-822-8987 for information about possible modifications to your vehi-...
Page 96: Safety Belt Extender
The extender adds about 8 inches (20 cm) to the safety belt. Always remove the safety belt extender when it is not needed and stow it safely. Contact an authorized Volkswagen dealer or authorized Volkswagen Service Facility if you believe you may need an extender.
Page 97 The airbag will not be able to provide enough protection for an occupant not wearing a safety belt. Only use the safety belt extender approved by Volkswagen for your vehicle.
Page 98 Never use the safety belt extender to secure a child restraint. Never use a safety belt extender on your Volkswagen that you got from another automo- bile manufacturer or from an automotive parts store.
Page 99 The front safety belts also have load limiters to help reduce the forces applied to the body in a crash. Heed all safety regulations if the vehicle or individual components of the system have to be scrapped. Your authorized Volkswagen dealer and authorized Volkswagen Service Facility are familiar with these regulations, Service and disposal of belt pretensioners.
Page 100 Authorized Volkswagen dealers and authorized Volkswagen Service Facilities are familiar with the requirements, and we recommend that you have them perform this service for you.
Page 101 Always obey local vehicle lighting laws. The driver is always responsible for the correct headlight settings. More information: Exterior views Volkswagen Information System Changing a light bulb WARNING Crashes and other accidents can happen when you cannot see the road ahead and when you cannot be seen by other motorists.
Page 102 Before they burn out, HID lamps can flicker. A message will then appear in the MFI. This is your reminder to see an authorized Volkswagen dealer or an authorized Volkswagen Service facility to check the headlights.
Page 103 The convenience turn signal feature can be deactivated by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
Page 104 Switching lights on and off Fig. 71 Headlight switch next to the steering wheel. Fig. 72 Headlight switch next to the steering wheel (with fog lights and automatic headlight control). Please first read and note the introductory information and heed the WARNINGS Adjust the light switch to the desired position ⇒ ...
Page 105 Acoustic warning when lights are not switched off In the following situation, a warning chime will sound if you take the key out of the ignition and open the driver door. This is to remind you that lights are still on. Light switch in position , if the vehicle has no orientation lighting, Coming home and Leaving home feature (orientation lighting).
Page 106 Static cornering lights Your vehicle may have fog lights under the front bumper, which on some models are also static cornering lights. On some models the static cornering lights may be integrated in the headlights. At speeds below about 25 mph (40 km/h), the light on one side of the vehicle will come on automatically when you turn a corner.
Page 107 Daytime running lights (DRL) Separate lamps are installed in the headlights or in the front bumper for the daytime running lights (DRL). When the daytime running lights are switched on, only these separate lamps come on ⇒ The daytime running lights are switched on whenever the ignition is switched on and the light switch is in position AUTO If the light switch is in position...
Page 108 The delay period can be adjusted in 10 second intervals and the function can be switched on and off in the Lights & Vision menu, Volkswagen Information System. If the “Coming home” feature is switched on and the driver door is opened, no warning chime will...
Page 109 Instrument panel lighting and headlight range adjustment Fig. 73 To the left of the steering wheel: Thumbwheel to adjust instrument panel lighting (vehicles without manual headlight range adjustment). Fig. 74 To the left of the steering wheel: Thumbwheel to adjust instrument panel lighting 1 and headlight range adjustment 2 (if equipped).
Page 110 Turn the thumbwheel to the desired position (2): Position Vehicle loading condition – Front seats occupied and an empty luggage compartment. All seats occupied and an empty luggage compartment. All seats occupied and a fully loaded luggage compartment Only the driver seat occupied and a fully loaded luggage compartment. –...
Page 111 Button Function Glove and luggage compartment lights The glove and luggage compartments may have lights that come on automatically when they are opened and go off when they are closed. Background lighting When the ignition and headlights are switched on, the background lighting in the roof console lights There may also be footwell lighting.
Page 112 Sun protection Introduction In this section you’ll find information about: Sun visors Windshield made of heat-insulating glass WARNING Sun visors can reduce visibility. Always stow sun visors when not needed to block sun glare. Sun visors Fig. 76 In the headliner: Sun visor. Please first read and note the introductory information and heed the WARNINGS Sun visor adjustment: Flip the sun visor down toward the windshield.
Page 113 Windshield made of heat-insulating glass Fig. 77 Heat-reflective windshield with communications window (blue shaded area). Please first read and note the introductory information and heed the WARNINGS Windshields made of insulating glass have a transparent metallic infrared-reflecting coating. There is an uncoated area (communications window) just above the inside rearview mirror ⇒ ...
Page 114 Sun protection Introduction In this section you’ll find information about: Sun visors Windshield made of heat-insulating glass WARNING Sun visors can reduce visibility. Always stow sun visors when not needed to block sun glare. Sun visors Fig. 76 In the headliner: Sun visor. Please first read and note the introductory information and heed the WARNINGS Sun visor adjustment: Flip the sun visor down toward the windshield.
Page 115 Windshield made of heat-insulating glass Fig. 77 Heat-reflective windshield with communications window (blue shaded area). Please first read and note the introductory information and heed the WARNINGS Windshields made of insulating glass have a transparent metallic infrared-reflecting coating. There is an uncoated area (communications window) just above the inside rearview mirror ⇒ ...
Page 116: Windshield Wipers And Washer
Windshield wipers and washer Introduction In this section you’ll find information about: Indicator light Windshield wiper lever Windshield wiper functions Windshield wiper service position Rain sensor Checking and refilling windshield washer fluid More information: Exterior views Climate control Working in the engine compartment...
Page 117: Windshield Wiper Lever
Lights Possible cause Proper response Refill windshield washer reservoir at the next Not enough windshield washer fluid. opportunity When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds. NOTICE Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Page 118 The intermittent wiping for the front windshield depends on the driving speed. The higher the speed, the faster the wipers move. If the wiper blades freeze to the windshield, loosen them carefully. Volkswagen recommends using a deicing spray. Windshield wiper functions...
Page 119 If there is something on the windshield, the wiper will try to wipe it away. If it continues to block the wiper, the wiper will stop moving. Remove the obstacle and switch the wiper on again. Windshield wiper service position Fig.
Page 120: Rain Sensor
Rain sensor Fig. 80 Windshield wiper lever: Adjusting rain sensor 1. Fig. 81 Inside the front windshield above the inside mirror: Sensitive rain sensor surface. Please first read and note the introductory information and heed the WARNINGS When switched on, the rain sensor automatically shortens or lengthens the time between wiping intervals depending on how hard it is raining ⇒ ...
Page 121 Check if there is still enough windshield washer fluid in the reservoir. Refill with an appropriate windshield washer fluid that is recommended by Volkswagen ⇒ Follow the directions on the container. In cold weather, always use a special windshield washer antifreeze solution that will help keep the...
Page 122 If necessary, blend with a suitable windshield washer fluid antifreeze agent. NOTICE Never mix cleaning solutions recommended by Volkswagen with other cleaning agents. If you do, this could cause sediments or other by-products that can clog the windshield washer nozzles.
Page 123 Remember that the inside and outside rearview mirrors will not show everything behind you. There can be blind spots. Blind spots can be significantly larger if the mirrors are not properly adjusted. More information: Exterior views Volkswagen Information System Adjusting the seating position Shifting Braking and parking...
Page 124: Inside Mirror
NOTICE Broken glass in the auto-dimming mirrors can cause electrolyte fluid leakage. Liquid electrolyte leaked from a broken mirror glass will damage any plastic surfaces it comes in contact with. Clean up spilled electrolyte fluid immediately with clear water and a sponge. Inside mirror Fig.
Page 125: Outside Mirrors
The auto-dimming feature can be switched on and off with the switch on the inside mirror (2). When auto-dimming is activated, the indicator light is on. If the ignition is switched on, the sensor automatically darkens the inside mirror depending on the amount of light shining into the vehicle from the rear.
Page 126 Turn the rotary knob to the desired position: Neutral position. Outside mirror folded out, no heating or adjustment possible. WARNING Improper use of the folding outside mirrors can cause personal injury. Always make sure that nobody is in the way when folding the mirrors in or out. Make sure that you do not get your finger caught between the mirror and the mirror base when moving the mirrors.
Page 127: Driving Tips
Driving tips Introduction In this section you’ll find information about: Stowing luggage Driving with an open rear hatch Driving a loaded vehicle Weights and axle weights Always stow heavy objects in the luggage compartment and make sure that the rear seat backrests are securely latched.
Page 128 WARNING Heavy loads will influence the way your vehicle handles and increase stopping distances. Heavy loads that are not properly stowed or secured can cause loss of control and serious injury. Secure the load properly to keep it from shifting. Always remember when transporting heavy objects that a change in the center of gravity also changes the way your vehicle handles: –...
Page 129 Driving with an open rear hatch can lead to serious personal injury. If you have to drive with an open rear hatch, make sure that all objects and the hatch itself are properly secured and take appropriate measures to keep toxic exhaust fumes from entering the vehicle. WARNING Driving with an unlatched or open rear hatch can lead to serious personal injury.
Page 130 Securely stow all luggage, Stowing luggage. Drive especially carefully and accelerate gently. Avoid sudden braking and driving maneuvers. Brake earlier than you would if you were not driving a loaded vehicle. If applicable, observe information about driving with a roof rack, Roof rack. WARNING Heavy loads can change the way your vehicle handles and increase stopping distances.
Page 131 WARNING Exceeding maximum permissible weight ratings can result in vehicle damage, accidents, and serious personal injury. Never let the actual weights at the front and rear axles exceed the permissible Gross Axle Weight Rating. Also, never let the total of these actual weights exceed the Gross Vehicle Weight Rating.
Page 132: Luggage Compartment
Luggage compartment Introduction In this section you’ll find information about: Folding the rear seat backrest forward and back into place Luggage compartment cover Shopping bag hooks Always stow heavy objects in the luggage compartment and make sure that the rear seat backrests are securely latched in their upright position.
Page 133 WARNING Unsecured or incorrectly stowed items can fly through the vehicle, causing serious personal injury during hard braking or sharp steering or in an accident. Loose items can also be struck and thrown through the passenger compartment by the front airbags if they inflate. To help reduce the risk of serious personal injury: Always stow all objects securely in the vehicle.
Page 134 Folding the rear seat backrest forward and back into place Fig. 86 Rear seat: release button right backrest 1, left backrest 2. Fig. 87 Rear seat backrest folded forward. Please first read and note the introductory information and heed the WARNINGS The rear seat backrest is divided into 2 sections.
Page 135: Luggage Compartment Cover
WARNING Improper folding and improper latching of the rear seat backrest can cause serious personal injury. Always make sure there are no people or animals in the area around the rear seat backrest when folding it forward. Never fold the rear seat backrest forward or back while the vehicle is moving. When folding the rear seat backrest back up, make sure that the safety belt does not get caught or damaged.
Page 136 Fig. 89 In the luggage compartment: Installing and removing the luggage compartment cover. Please first read and note the introductory information and heed the WARNINGS When you open or close the rear hatch, the supporting cords, when attached, will automatically raise or lower the luggage compartment cover.
Page 137 NOTICE Things on the luggage compartment cover can damage it. The defroster heating wires or antenna in the rear window can be damaged by objects that rub against them. Shopping bag hooks Fig. 90 In the luggage compartment: Shopping bag hook. Please first read and note the introductory information and heed the WARNINGS Shopping bag hooks may be located on the upper left and right of the luggage compartment ⇒ ...
Page 138: Roof Rack
Roof rack Introduction In this section you’ll find information about: Attaching the roof rack base carrier and roof rack Securing a load on the roof rack The roof of your vehicle has been designed to optimize aerodynamics and does not have traditional rain gutters that are used to attach many kinds of roof racks.
Page 139 Make sure that the rear hatch does not touch items on the roof rack when opened. If a roof rack is installed, fuel consumption increases due to increased air resistance. Attaching the roof rack base carrier and roof rack Fig. 91 Attachment points for the base carrier and roof rack. Please first read and note the introductory information and heed the WARNINGS The base carrier is the basis of a complete roof rack system.
Page 140 WARNING Installing or using a base carrier or roof rack improperly can cause the entire system to fly off the vehicle, causing accidents and injuries. Always follow the installation instructions provided by the manufacturer. Use the base carrier and roof rack only if they are undamaged and properly installed. Secure the roof rack base carrier only at the attachment points shown in the illustration .
Page 141 WARNING Loose or improperly secured items can fall off the roof rack and cause accidents and injuries. Always use suitable, undamaged tie-down ropes and ratchet straps. Secure the load properly.
Page 142: Trailer Towing
A trailer hitch can fall off while driving or rip loose or while pulling a trailer causing the trailer to separate from the vehicle. NOTICE Installing a trailer hitch of any kind will cause expensive damage to your vehicle that will not be covered by any Volkswagen Limited Warranty.
Page 143: Tires And Wheels
UTQG classification Volkswagen recommends that all work on tires and wheels be done by an authorized Volkswagen dealer or authorized Volkswagen Service Facility. They are familiar with the technical requirements and recommended procedures, have the necessary special tools and spare parts, and can properly dispose of old tires.
Page 144 For technical reasons it is usually not possible to use wheel rims from other vehicles. Even wheel rims from the same model may not fit properly. Check with an authorized Volkswagen dealer or authorized Volkswagen Service Facility if necessary.
Page 145 The tires and wheels are essential parts of the vehicle's design. The tires and wheels approved by Volkswagen are specially matched to the characteristics of the vehicle for good road holding and safe handling when in good condition and properly inflated.
Page 146 Old tires can fail suddenly and without warning. Volkswagen recommends replacing tires that are 6 years and older. This also applies to tires that look new (including the tire on the compact spare wheel) or that seem to still be usable with tread depth that has not yet reached the legal minimum depth ⇒ ...
Page 147 In most cases, you cannot use wheel bolts from a different vehicle. Even wheel rims from the same model may not fit properly. Tires and wheel rims approved by Volkswagen have been matched precisely to your vehicle model and contribute considerably to good handling and safe vehicle performance.
Page 148 Volkswagen for your vehicle and model. Never use tires that are larger or wider than the dimensions of the tires approved by Volkswagen for your vehicle and model. Larger tires could scrape and rub on the vehicle body or other parts of the vehicle.
Page 149: Tire Inflation Pressure
Tire inflation pressure Fig. 93 On the driver door jamb: Location of the tire inflation pressure label. Please first read and note the introductory information and heed the WARNINGS The correct tire inflation pressure for the factory-installed tires is listed on a label. The factory-installed tires may be summer, winter, or all-season tires.
Page 150 WARNING Incorrect tire pressure can cause a sudden tire failure or blowout, loss of control, collision, serious personal injury, and even death. Always inflate tires to the recommended and correct cold tire pressure before driving off. Low tire pressure can cause tires to get too hot, resulting in tread separation, sudden loss of pressure, and blowouts.
Page 151 Engine Tire size Tire pressure 235/45 R18 94H 235/40 R19 92H 215/60 R16 95T 215/55 R17 94H 2.0L/140 hp (103 kW) TDI 235/45 R18 94H 235/40 R19 92H Compact spare wheel T125/90 R16 The Tire Pressure Monitoring System is configured at the factory with the correct tire inflation pressure applicable for the vehicle model, engine and factory-installed tires.
Page 152 Engine Tire size Tire pressure The tire inflation pressure is also listed on the sticker inside the driver door jamb ⇒ f ig. 93. The tire inflation pressures for the road tires are listed on this label. The inflation pressure for the compact spare is as specified on the tire pressure label or on a separate label for the compact spare, if there is one.
Page 153: Tire Wear And Damage
If a tire is damaged, do not drive any farther. Get expert assistance. If no external damage is visible, slowly and carefully drive to the nearest authorized Volkswagen dealer, authorized Volkswagen Service Facility, or other qualified workshop and have the vehicle checked.
Page 154 Never drive with a damaged tire or rim. Get expert assistance instead. If no external damage is visible, slowly and carefully drive to the nearest authorized Volkswagen dealer, authorized Volkswagen Service Facility, or other qualified workshop and have the vehicle checked.
Page 155 Please heed the following: Do not drive faster than 50 mph (80 km/h)! Avoid full-throttle acceleration, hard braking and fast cornering! Do not use snow chains on the compact spare wheel, Snow chains. After installing the compact spare wheel, check the tire pressure as soon as possible, Tire inflation pressure in cold tires, Tire inflation pressure in cold tires.
Page 156: Tire Labeling
Tire labeling Fig. 96 International tire labeling. Please first read and note the introductory information and heed the WARNINGS Knowing about tire specifications makes it easier to choose the correct replacement tires. Radial tires have specifications marked on the sidewall. Tire labeling (example) Meaning Brand, Logo...
Page 157 Tire labeling (example) Meaning Labeling according to international regulations (E) including E4 ... number of the approving country. The multi-digit approval number is listed next. Tire identification number (TIN) – In some cases the manufacturing date is only on one side of the tire: The tire complies with the requirements of the United States Department of Transportation, responsible for issuing safety standards.
Page 158 Load rating code The load index indicates the maximum permissible load per individual tire in pounds (kilograms). 1356 lbs (615 kg) 1388 lbs (630 kg) 1433 lbs (650 kg) 1521 lbs (690 kg) 1609 lbs (730 kg) 1653 lbs (750 kg) 1709 lbs (775 kg) 100 1763 lbs (800 kg) 101 1819 lbs (825 kg)
Page 159: Winter Tires
Top speed rating and tire inflation pressure for V winter tires depend on the engine installed in your vehicle. Be sure to ask you authorized Volkswagen dealer or authorized Volkswagen Service Facility about the maximum permissible speed and the required tire inflation pressure for the winter tires that...
Page 160: Snow Chains
The tire taken off the rear axle can then be used to replace the flat front tire. Be sure to install the unidirectional tires so that they will run in the proper direction. Volkswagen recommends installing the snow chains before mounting the wheel to the vehicle.
Page 161 Snow chains can scratch or damage wheel rims if they have direct contact with the rims. Volkswagen recommends using coated snow chains. Glossary of tire and loading terminology Please first read and note the introductory information and heed the WARNINGS...
Page 162 Cold tire inflation pressure The tire pressure recommended by the vehicle manufacturer for a tire of a specified size that has not been driven for more than a couple of miles (kilometers) at low speeds in the 3 hour period before the tire pressure is measured or adjusted.
Page 163 Passenger car tire A tire intended for use on passenger cars, multipurpose passenger vehicles, and trucks, that have a gross vehicle weight rating (GVWR) of 10,000 pounds or less. A layer of rubber-coated parallel cords. Ply separation A parting of rubber compound between adjacent plies. Pneumatic tire A mechanical device made of rubber, chemicals, fabric, and steel or other materials, that, when mounted on an automotive wheel, provides the traction and contains the gas or fluid that sustains the...
Page 164 Sidewall separation The parting of the rubber compound from the cord material in the sidewall. Speed rating (letter code) A standardized letter code indicating the maximum speed at which a tire is designed to be driven for extended periods of time. The ratings range from 93 mph or 150 km/h (“P”) to 186 mph or (300 km/h) “Y”.
Page 165 150 lbs (68 kg), mean that less weight can be carried as luggage or other cargo. The tire pressure label on your Volkswagen also lists the maximum combined weight of all of the occupants and luggage or other cargo that the vehicle can carry.
Page 166 WARNING Overloading a vehicle can cause loss of vehicle control, a crash or other accident, serious personal injury, and even death. Carrying more weight than your vehicle was designed to carry will prevent the vehicle from handling properly and increase the risk of the loss of vehicle control. The brakes on a vehicle that has been overloaded may not be able to stop the vehicle in a safe distance.
Page 167 Traction: AA, A, B or C Temperature: A, B or C For example: Treadwear 200, Traction AA, Temperature A. All passenger car tires must conform to Federal Safety Requirements in addition to these grades. Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course.
Page 168 Recalibrating the TPMS to reset the benchmark cold tire inflation pressure with proper use of the SET button is explained below, Tire Pressure Monitoring System (TPMS) and recalibration with the SET button. More information: Volkswagen Information System Transporting Tires and wheels Braking and parking...
Page 169 WARNING Incorrect tire pressures and/or underinflation can cause sudden tire failure, loss of control, collision, serious personal injury or even death. When the warning symbol appears in the instrument cluster, stop and inspect the tires. Incorrect tire pressure and/or underinflation can cause increased tire wear and can affect the handling of the vehicle and stopping ability.
Page 170 Remember that tire pressure can only be properly measured when the tire is “cold”, Tire inflation pressure. Only replace old tires with tires that have been approved by Volkswagen for your vehicle type. Applicable only in the United States...
Page 171 System malfunction. 4 tires and pressing the SET button, take the vehicle to an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. Have the system checked. When the ignition is switched on, several warning and indicator lights come on briefly for a function...
Page 172: Storage Areas
Storage areas Introduction In this section you’ll find information about: Storage compartment in the doors Storage compartment on the driver side Storage compartment in the front center console Storage compartment in the center console Storage compartment in the front center armrest ...
Page 173 WARNING Some kinds of cigarette lighters can be lit unintentionally, or crushed causing a fire that can result in serious burns and vehicle damage. Always make sure that there are no lighters in the seat tracks or near other moving parts before adjusting the seats.
Page 174 Storage compartment on the driver side Fig. 99 On the driver side: Storage compartment. Please first read and note the introductory information and heed the WARNINGS To open the compartment, pull the handle ⇒ f ig. 99 (1) in the direction of the arrow. To close, push the lid up until it latches.
Page 175 Storage compartment in the center console Fig. 101 Storage compartment in the center console (if equipped). Please first read and note the introductory information and heed the WARNINGS There may be a storage compartment in the center console ⇒ f ig. 101.
Page 176: Glove Compartments
Applicable only in the United States Glove compartments Fig. 103 On the passenger side: Opening the upper glove compartment (if equipped). Fig. 104 A: On the passenger side: Lower glove compartment. B: Open glove compartment. Please first read and note the introductory information and heed the WARNINGS Key to fig.
Page 177 Owner's Manual The lower glove compartment is designed to hold the Owner's Manual ⇒ f ig. 104 B (4). Always keep the Owner's Manual in the lower glove compartment. Button in the glove compartment The Tire Pressure Monitoring System (TPMS) SET button is also located in the glove compartment B (2).
Page 178 Fig. 106 A: On the passenger side: Lower glove compartment. B: Open glove compartment. Please first read and note the introductory information and heed the WARNINGS Key to ⇒ f ig. 106 Pen holder Factory-installed Media Device Interface (MDI)/(MEDIA-IN), if equipped Owner's Manual Note holder Eyeglass holder...
Page 179 WARNING An open glove compartment door can increase the risk of serious injury during sudden braking or driving maneuvers or in a crash. Always keep the glove compartment closed while the vehicle is moving. NOTICE In some vehicle models, design considerations have made it necessary to have openings in the glove compartment behind the Owner's Manual slot, for example.
Page 180: Cup Holders
Cup holders Introduction In this section you’ll find information about: Cup holders in the front center console Cup holder in the rear center console Beverage bottle holders There is a place for bottles in the open compartments in the driver and passenger doors. The bottle volume must not exceed 24 oz (0.5 liter) ⇒ ...
Page 181 Some cup holder inserts can be removed for cleaning. Cup holders in the front center console Fig. 107 In the front center console: Cup holders. Please first read and note the introductory information and heed the WARNINGS Place the drink in the cup holder ⇒ f ig.
Page 182: Power Outlets
Power outlets Introduction In this section you’ll find information about: 12 Volt sockets in the vehicle Electrical devices can be connected to the vehicle 12 Volt sockets. The connected devices must be in good working order. More information: Parts, accessories, repairs and modifications Consumer information WARNING Improper use of electrical sockets and electrical devices may start a fire and cause severe...
Page 183 12 Volt sockets in the vehicle Fig. 109 Front center console: 12 Volt socket. Fig. 110 Rear center console: 12 Volt socket. Please first read and note the introductory information and heed the WARNINGS Maximum power draw Socket Maximum power draw 12 Volts 120 watts The maximum power draw at any one socket must never be exceeded.
Page 184 Never exceed the maximum power consumption, or the entire vehicle electrical system may be damaged. 12 Volt socket: – Only use equipment that has been tested for electromagnetic compatibility and complies with applicable guidelines. – Never feed current into the socket, with a solar panel, for example. Unshielded devices may interfere with radio reception or the vehicle's electrical system.
Page 185: Starting And Stopping The Engine
Starting and stopping the engine Introduction In this section you’ll find information about: Indicator lights Vehicle key positions in the ignition switch Starter button Starting the engine Stopping the engine Electronic immobilizer ® Explanatory notes in this section regarding automatic transmissions also apply to the DSG Direct Shift Gearbox automatic transmission.
Page 186 WARNING To reduce the risk of serious personal injury when starting and running the vehicle's engine: Never start the engine or let it run in a confined or enclosed area. Engine exhaust contains carbon monoxide, a poisonous, colorless, and odorless gas. Carbon monoxide can cause unconsciousness and death.
Page 187 WARNING Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury. Never ignore warning lights or text WARNINGS. Always stop the vehicle as soon as it is safe to do so. Whenever stalled or stopped for repair, move the vehicle a safe distance off the road, turn on the emergency flashers, stop the engine, and use other warning devices to warn approaching traffic.
Page 188 WARNING Improper use of vehicle keys can result in serious personal injury. Always take the key with you when you leave the vehicle. The engine can be started and vehicle systems such as the power windows can be operated, leading to serious personal injury.
Page 189 Fig. 113 Hold the remote control vehicle key to the right of the steering column: Emergency starting feature on vehicles with Keyless Access. Please first read and note the introductory information and heed the WARNINGS For vehicles with Keyless Access, Power locking and closing system, the vehicle can be started and stopped with the starter button in the lower center console ⇒ ...
Page 190: Starting The Engine
WARNING Unintended vehicle movement can cause serious personal injury. Do not depress the brake or clutch pedals when switching on the ignition, as the engine could otherwise start immediately. WARNING Improper use of vehicle keys can result in serious personal injury. Always take the key with you when you leave the vehicle.
Page 191: Stopping The Engine
Please perform these steps only in the order listed. Step Vehicles without Keyless Access Vehicles with Keyless Access When the engine starts, release the vehicle When the engine starts, release the starter key. button. If the engine does not start, switch off the If the engine does not start, switch off the ignition and start again after about 1 minute.
Page 192 Please perform these steps only in the order listed. Step Vehicles without Keyless Access Vehicles with Keyless Access Bring the vehicle to a complete stop ⇒ Depress and hold down the brake pedal until step 4 is completed. Automatic transmission: Shift the transmission into Park (P). Apply the parking brake to help prevent the vehicle from moving Turn the vehicle key to position ⇒ ...
Page 193: Electronic Immobilizer
On vehicles with Keyless Access, the vehicle key must be outside the vehicle, Power locking and closing system. The engine can therefore only be started with an authorized and correctly coded genuine Volkswagen vehicle key. Coded vehicle keys are available from authorized Volkswagen dealers, authorized Volkswagen Service Facilities, and from certain independent repair facilities and locksmiths who are qualified to make these vehicle keys, Vehicle key set.
Page 194 Shifting Introduction In this section you’ll find information about: Warning and indicator lights Pedals Manual transmission: Gearshift lever Automatic transmission: Selector lever ® Shifting with Tiptronic Driving with automatic transmission Automatic transmission malfunction ...
Page 195 ® transmission overheating. If the warning does not turn off, do not continue driving. See your authorized Volkswagen dealer for assistance. Otherwise, serious transmission damage could result Brake pedal not depressed. Apply the brake pedal to select a drive gear...
Page 196 NOTICE Failure to heed warning lights or text WARNINGS can result in vehicle damage. Pedals Fig. 114 Pedals in vehicles with manual transmission: 1 Accelerator pedal, 2 Brake pedal, 3 Clutch pedal. Fig. 115 Pedals in vehicles with automatic transmission: 1 Accelerator pedal, 2 Brake pedal. Please first read and note the introductory information and heed the WARNINGS All pedals must always be able to move freely in and out without interference from floor mats or other things.
Page 197 NOTICE Always make sure that the pedals are able to move freely and that nothing can interfere with them. If a brake circuit fails, more brake pedal travel will be needed to bring the vehicle to a stop. The brake pedal must be pressed farther and harder than normal. Manual transmission: Gearshift lever Fig.
Page 198 Depress the clutch pedal fully and hold ⇒ Move the gearshift lever to neutral and press down. Move the shift lever to the left and then push forward into the reverse gear position ⇒ f ig. 116 (R) or ⇒ f ig.
Page 199 Automatic transmission: Selector lever Fig. 118 Automatic transmission selector lever with shift lever release button (arrow). Please first read and note the introductory information and heed the WARNINGS .203. Automatic transmission vehicles have an Automatic Shift Lock (ASL). With ASL, you must depress the brake pedal and hold it down while pressing the release button on the selector lever handle in the direction of the arrow ⇒ ...
Page 200 To release the ASL, depress and hold the brake pedal with the ignition switched on. Press the release button on the selector lever at the same time. The ASL is not engaged if the selector lever is moved quickly through Neutral (N) (e.g., when shifting from Reverse (R) to Drive (D)).
Page 201 ® Shifting with Tiptronic Fig. 119 Selector lever in Tiptronic position. Fig. 120 Steering wheel with optional Tiptronic shift paddles. Please first read and note the introductory information and heed the WARNINGS Tiptronic lets you upshift and downshift manually with the automatic transmission. When Tiptronic mode is used, the transmission stays in the current gear and does not upshift or downshift automatically unless the transmission senses a situation where upshifting or downshifting is necessary to keep the engine from over- or under-revving.
Page 202: Driving With Automatic Transmission
To switch off Tiptronic mode, pull the paddle on the right + toward you and hold it there for about 1 second. Tiptronic will switch off automatically if the shift paddles have not been used for a while and the selector lever is not in the Tiptronic position.
Page 203 Direct Shift Gearbox automatic transmission may not be able to shift into reverse. It is then impossible to drive the vehicle backwards. In any event, have the automatic transmission checked by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
Page 204 Gear recommendation Please first read and note the introductory information and heed the WARNINGS Your vehicle may be equipped with a gear recommendation feature. The gear recommendation displays a gear in the instrument cluster display that can help reduce fuel consumption. Display Meaning The selected gear is optimal.
Page 205 Warning and indicator lights Please first read and note the introductory information and heed the WARNINGS Lights Possible cause Proper response Stop! Have the power steering system checked Power steering malfunction. immediately by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Page 206 Power steering assist is reduced. Otherwise, have the steering checked immediately by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. Vehicle battery was disconnected and Drive a short distance at about 10–12 mph has been reconnected.
Page 207 To help make it more difficult to steal your vehicle, you should always make sure the steering column is locked before leaving the vehicle. Electronic steering column lock Vehicles with Keyless Access: The steering column is locked if the driver door is opened with the ignition switched off.
Page 208: Braking And Parking
Driving with bad brakes or worn brake pads can cause a collision and serious personal injury. If the brake pads are worn or you notice changes in the way the vehicle brakes, immediately contact an authorized Volkswagen dealer or authorized Volkswagen Service Facility to have the brake pads checked and, if necessary, replaced.
Page 209 WARNING Parking improperly can cause serious personal injury. Never remove the key from the ignition switch while the vehicle is moving or rolling to a stop. The steering wheel will lock and you will not be able to steer or control the vehicle. Never park the vehicle where the hot exhaust system or catalytic converter could ignite flammable materials, such as brush, leaves, dry grass, spilled fuel, etc.
Page 210 Get professional assistance immediately Stop! ² Brake fluid level too low. Check brake fluid level See an authorized Volkswagen dealer or an Together with ABS indicator light authorized Volkswagen Service Facility. : ABS failure. The vehicle brakes will work without ABS.
Page 211: Parking Brake
ABS system is not working properly. The vehicle can then be stopped only with the standard brakes (without ABS). You will not have the protection ABS provides. Contact your authorized Volkswagen dealer or an authorized Volkswagen Service Facility as soon as possible.
Page 212 While holding the release button down, move the lever all the way down. WARNING Improper use of the parking brake can cause accidents and severe injuries. Never use the parking brake to slow down the vehicle when it is moving, except in an emergency.
Page 213 Brake pad wear depends mostly on operating conditions and the way the vehicle is driven. If you do a lot of city and short-distance driving and/or have a sporty driving style, you should have the brake pads checked by an authorized Volkswagen dealer or authorized Volkswagen Service Facility more often than the regular service intervals.
Page 214 If you believe the vehicle is safe to drive, immediately take it to the nearest authorized Volkswagen dealer or authorized Volkswagen Service Facility for repair. Drive slowly and very carefully, allow for the longer stopping distance, and be ready to push longer and harder on the brake pedal to slow the vehicle down.
Page 215: Braking Assistance Systems
The wear of all brake pads should be visually checked regularly. The best way to check for brake pad wear is to have your authorized Volkswagen dealer or authorized Volkswagen Service Facility visually inspect the pads through the openings in the wheel rims or from underneath the vehicle. If necessary, the wheels can be taken off for a more thorough inspection.
Page 216 causes you to run off the road before ESC can provide any assistance, you may not experience the benefits of ESC. ESC includes and/or works together with the ABS, BAS, ASR, EDL, and XDL systems (see below). ESC is switched on all the time and cannot be switched off. Anti-Lock Brake System (ABS) ABS helps to keep the wheels from locking up and helps to maintain the driver's ability to steer and control the vehicle.
Page 217 WARNING Driving fast on icy, slippery, or wet roads can lead to a loss of control and result in serious personal injury for you and your passengers. Always adjust your speed and driving style to road, traffic, weather, and visibility conditions.
Page 218: Brake Fluid
⇒ Brake fluid specifications Volkswagen has developed a special brake fluid that is optimized for the brake system in your Volkswagen. Volkswagen recommends that you use brake fluid that expressly conforms to quality standard VW Standard 501 14 for optimum performance of the brake system.
Page 219 Maintenance . Have the brake fluid checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. Refill only with new brake fluid that meets the standards listed above. WARNING Brake failure and reduced brake performance can be caused by not having enough brake fluid in the reservoir or by old or incorrect brake fluid.
Page 220 Saving fuel and helping the environment Introduction In this section you’ll find information about: Efficient driving style Fuel-efficient driving Fuel consumption, environmental impact, and wear and tear on engine, brakes and tires depend mainly on the following 3 factors: Your personal driving style.
Page 221 Defensive driving and “flowing” with traffic Frequent braking and acceleration increase fuel consumption significantly. Just by driving defensively and keeping a sufficiently large distance away from the vehicle in front of you can make up for the speed fluctuations caused by taking your foot off the accelerator. Active braking and accelerating is then not necessarily required.
Page 222 Fuel-efficient driving Fig. 123 Fuel consumption in mpg at 2 different outside air temperatures. Fig. 124 Fuel consumption in l/100 km at 2 different outside air temperatures. Please first read and note the introductory information and heed the WARNINGS Driving defensively and economically can easily reduce fuel consumption by 10 to 15%. The vehicle consumes the most fuel when accelerating.
Page 223 Always ensure the right engine oil level is maintained and keep to the scheduled service intervals (engine oil changes). Make sure the engine oil that you purchase expressly complies with Volkswagen oil quality standards and is the oil approved by Volkswagen for your vehicle.
Page 224 Starting assistance systems Introduction In this section you’ll find information about: Hill Hold More information: Volkswagen Information System Tires and wheels Braking and parking Vehicle battery Parts, accessories, repairs and modifications Jump-starting WARNING The intelligent technology of the dynamic starting assistance features cannot overcome the laws of physics.
Page 225 Reverse (manual transmission) or in Drive (D), Sport Drive (S), or Reverse (R) (automatic transmission) and you must use the foot brake to hold the vehicle before starting to move. Hill Hold keeps the brake applied for not quite 2 seconds with the same force you used to prevent the vehicle from moving.
Page 226 Cruise Control System (CCS) Introduction In this section you’ll find information about: Indicator lights Cruise control operation Your vehicle may be equipped with a Cruise Control System. The Cruise Control System (CCS) helps maintain an individually stored constant speed when driving above about 15 mph (20 km/h).
Page 227: Cruise Control Operation
When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds. Display Different cruise control versions are available. The stored speed is shown in the instrument cluster display on some equipment versions.
Page 228 In order to: Result: You must: ⇒ f ig. 125 Increase set speed Press button briefly to The vehicle will accelerate until the (while cruise control is increase the set speed in small new higher speed is reached and actively controlling steps of 1 mph (1 km/h) each.
Page 229 Rear Assist Applicable only in the United States Introduction In this section you’ll find information about: Operation Parking Depending on equipment, the vehicle may be equipped with a Rear Assist rearview camera. There is a camera in the rear hatch to assist the driver while backing up or maneuvering. The camera image is shown together with the orientation lines projected by the system on the screen of the factory-installed radio or navigation system.
Page 230 WARNING Rear Assist technology cannot overcome the laws of physics and the limits of the system. Careless or unintentional use of Rear Assist may result in accidents and severe injuries. Always adjust your speed and driving style to road, traffic, weather, and visibility conditions.
Page 231 – If the driver is not familiar with the system. – If the position or angle of the camera has changed, such as after a rear-end collision. Have the system checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Page 232 Never remove snow or ice on the camera lens with warm or hot water. This can damage the camera lens. Volkswagen recommends practicing parking with Rear Assist in a safe place with little or no traffic or in a parking lot under good visibility and weather conditions in order to familiarize yourself with the system, the orientation lines and the way they work.
Page 233 Applicable only in the United States Parking Fig. 128 On the screen: Static orientation lines for the parking space behind the vehicle. Please first read and note the introductory information and heed the WARNINGS Orientation lines overview The yellow area displayed stops about 2 yards (meters) behind the vehicle on the road. ⇒ ...
Page 234 Park Distance Control (PDC) Applicable only in the United States Introduction In this section you’ll find information about: Park Distance Control (PDC) Depending on vehicle equipment, the vehicle may be equipped with the Park Distance Control system (PDC). The Park Distance Control (PDC) system can help the driver when backing up and parking. PDC uses ultrasonic sensors in the bumpers to measure the distance between the vehicle and objects.
Page 235 Aftermarket components such as bicycle racks can impair the function of the Park Distance Control system. Volkswagen recommends practicing with the Park Distance Control system in a location or parking space with no traffic in order to become familiar with the system and how it works.
Page 236 For vehicles with automatic transmissions, there is no beeping when the transmission is in Park (P). The volume of the audible signals can be adjusted by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. Muting the Park Distance Control volume You can mute the PDC beeping signals by tapping the + function key on the Radio or Navigation system screen (if applicable).
Page 237 Park Distance Control system. Switch off the Park Distance Control system with the button and have it immediately checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Page 238: Heating And Air Conditioning
More information: Exterior views Passenger compartment Volkswagen Information System Seat functions Windshield wipers and washer Starting and stopping the engine Exterior care and cleaning...
Page 239 NOTICE If you think the air conditioner is not working properly or may be damaged, switch it off to help prevent more damage. Have the air conditioner checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. Air conditioner repair requires specialized knowledge and special tools. Volkswagen recommends that you see an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Page 240 Emergency starting and starting the engine with a very weak vehicle battery or after the vehicle battery has been replaced may change or delete system settings (including time, date, personal convenience settings, and programming). Check the settings and correct as necessary once the vehicle battery has built up a sufficient charge.
Page 241 NOTICE If you think the air conditioner is not working properly or may be damaged, switch it off to help prevent more damage. Have the air conditioner checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. Air conditioner repair requires specialized knowledge and special tools. Volkswagen recommends that you see an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Page 242 Emergency starting and starting the engine with a very weak vehicle battery or after the vehicle battery has been replaced may change or delete system settings (including time, date, personal convenience settings, and programming). Check the settings and correct as necessary once the vehicle battery has built up a sufficient charge.
Page 243 More information: Manual A/C ⇒ Button/Knob f ig. 131 Rear window defroster: Works only when the engine is running and switches off automatically after 10 minutes or less. Air recirculation mode Buttons for seat heating Press the button to switch the air conditioner on or off. Switching off Turn the fan switch to position 0.
Page 244 More information: Climatronic ⇒ Button/Knob f ig. 132. Air flow is automatically adjusted to a comfortable level. It can also be manually distribution adjusted with buttons (3). Displays Left-side and right-side digital temperature displays. Defog/defrost button. The incoming outside air is directed to the windshield, and air recirculation automatically switches off.
Page 245 Navigation system display The inside and outside temperatures can be displayed in either Fahrenheit (F) or Celsius (C). Select Units in the instrument cluster display in the Settings main menu ⇒ p age 31, Volkswagen Information System. You can also press and hold the...
Page 246 Special considerations When it is very hot and humid outside, water condensation can drip from the air conditioner evaporator and form a puddle under the vehicle. This is normal and does not indicate a leak. The climate control system adjusts the passenger compartment temperature as fast as possible considering the outside temperature.
Page 247: Air Vents
There is another malfunction in the vehicle. Have the air conditioner checked by an authorized Volkswagen dealer or authorized Volkswagen Service Facility. Special considerations When it is very hot and humid outside, water condensation can drip from the air conditioner evaporator and form a puddle under the vehicle.
Page 248: Air Recirculation
The air coming out of the vents flows through the passenger compartment and out through the vents in the luggage compartment. Do not cover these slots with clothing or other things. Applicable only in the United States Air recirculation Please first read and note the introductory information and heed the WARNINGS General information There are different types of air recirculation: Manual air recirculation (manual A/C).
Page 249 Switching off: Press the button repeatedly until no indicator light under the button is on. It is not possible to activate automatic air recirculation when the outside air temperature is colder than about +38 °F (+3 °C). Temporarily deactivating the automatic air recirculation Û...
Page 250 WARNING Stale air causes driver fatigue and reduces driver alertness, which can cause accidents, collisions and serious personal injury. Never use air recirculation mode over an extended period of time, since no fresh air will enter the passenger compartment. When the air conditioner is off and recirculation mode is on, condensation can quickly form on the windows and greatly reduce visibility.
Page 251 Refueling Introduction In this section you’ll find information about: Indicator lights and fuel gauge Refueling Misfueling guard for diesel vehicles Fuel capacities Refueling checklist The fuel filler flap is located on the rear right side of the vehicle. More information: Exterior views Fuel...
Page 252 Fuels can pollute the environment. Spilled fuel must be collected and disposed of properly, following all applicable environmental regulations. There is no emergency release for the fuel filler flap. Contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
Page 253 This is normal and no reason to take your vehicle in for service. If, however, the malfunction indicator light also comes on, drive to your nearest authorized Volkswagen dealer or authorized Volkswagen Service Facility and have the fuel system and the engine checked.
Page 254 WARNING Driving with a fuel tank that is almost empty can lead to stalling in traffic, a collision, and serious personal injuries. When the fuel tank is almost empty, fuel supply to the engine can be interrupted, especially when driving over bumps, across slopes, and up and down hills. Steering and braking assistance as well as ESC and related systems will not work if the engine “sputters”...
Page 255 Unscrew the fuel cap counterclockwise and remove. Use the slot on the filler flap to hold the cap while refueling ⇒ f ig. 135. Refueling The correct fuel grade for your vehicle, Fuel is listed on a sticker on the inside of the fuel filler flap (arrow).
Page 256 Under certain circumstances it may be necessary to turn the nozzle back and forth slightly with light pressure to open the misfueling guard. If the misfueling guard cannot be opened this way, see the nearest authorized Volkswagen dealer or authorized Volkswagen Service Facility and have the fuel system checked.
Page 257 Checklist If you are uncertain in any way, have the work done by an authorized Volkswagen dealer or authorized Volkswagen Service Facility. Serious personal injury may result from improperly performed work. Make sure that you check the following items regularly. The best thing is to check them every...
Page 258 Avoid high rpm and rapid acceleration. If these symptoms should appear right after refueling, switch off the engine. In both cases contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility to have the engine checked.
Page 259 Blend must contain no more than 15% MTBE. Seasonally adjusted gasoline Many fuels are blended especially for winter or summer conditions. When seasons change, Volkswagen suggests that you buy fuel at busy stations where the seasonal adjustment is more likely to be made earlier. WARNING Starting fluids can explode and cause a run-away vehicle condition.
Page 260: Gasoline Additives
Volkswagen recommends using only additives approved by Volkswagen. Appropriate additives as well as instructions on how to use them are available from your authorized Volkswagen dealer or authorized Volkswagen Service Facility. Do not add any other gasoline additives.
Page 261: Diesel Fuel
Due to Illinois state tax incentives or regulations for biofuels, biodiesel blends of B5 or less may not be available in Illinois. However, we want to assure you that Volkswagen will continue to honor the terms and conditions of the Volkswagen Limited Warranties that came with your vehicle. Use only Biodiesel from high quality sources, certified by the BQ-9000 label at the fuel station and complying to ASTM D 7467 S15, B6 to B20.
Page 262 Using diesel fuel with concentrations of methyl ester biodiesel higher than 20 % (B20), such as B100 is still contrary to the terms of your Emission warranties or any other Volkswagen Limited Warranty and remains strictly prohibited. ® Biodiesel blends (up to B20) may be used in your Illinois registered TDI Clean Diesel vehicle;...
Page 263 Damage to the engine and fuel system and performance problems caused by using fuels that are different from those specified above or by using “starting assist fluids” are not the responsibility of Volkswagen and are not covered under the Emission warranties or any other Volkswagen Limited Warranty.
Page 264: Working In The Engine Compartment
⇒ If you are uncertain in any way, have the work done by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. Serious personal injury may result from improperly performed work.
Page 265 If you are uncertain about what to do, have the work performed by an authorized Volkswagen dealer, an authorized Volkswagen Service Facility, or another qualified workshop. Serious personal injury may result from improperly performed work.
Page 266 WARNING High voltage systems in the engine compartment can cause electrical shocks or even electrocution, severe burns, other serious injuries, and even death! Never short-circuit the electrical system. Be especially careful when using jumper cables. The vehicle's battery could explode! To reduce the risk of electrical shock and personal injury while the engine is running or being started: –...
Page 267: Preparing To Work In The Engine Compartment
Fluid leaks and spills are harmful to the environment. Regularly check the ground underneath your vehicle for this reason. If you find spots of oil or other fluids, have your vehicle checked by your authorized Volkswagen dealer or authorized Volkswagen Service Facility. Dispose of leaked operating fluids properly.
Page 268 5. Stop the engine and remove the key from the ignition switch, Starting and stopping the engine. 6. Let the engine cool down sufficiently. 7. Keep children and others away from the vehicle. 8. Make sure the vehicle cannot move unexpectedly. WARNING Disregarding the safety-related checklist may result in serious injuries.
Page 269 Open the driver door and pull the inside hood release lever in the direction of the arrow ⇒ f ig. 137 A. The engine hood is released from its latch by a spring ⇒ Push the outside hood release lever B (arrow) and lift the hood all the way up. Pull the hood support out of its bracket in the direction of the arrow ⇒ ...
Page 270: Engine Oil
Engine oil Introduction In this section you’ll find information about: Warning and indicator lights Engine oil specifications Engine oil capacities Checking the engine oil level and adding oil Engine oil consumption Changing engine oil More information: Warranty and Maintenance ⇒ ...
Page 271: Engine Oil Specifications
Your engine was factory-filled with a high-quality, “synthetic” all-season engine oil that meets strict Volkswagen oil quality standards and has a viscosity grade of SAE 5W-40. or SAE 5W-30. You can use this oil for normal driving in all temperatures.
Page 272 Diesel engines VW 507 00 At the time this Manual was printed, the engine oils available in the U.S. that meet these Volkswagen standards are “synthetic” oils. This does not mean, however, that any “synthetic” engine oil will meet Volkswagen standards. Always use an approved oil that expressly complies with the Volkswagen oil quality standard that applies to your vehicle's engine.
Page 273 140 and the colored handle on the dipstick. If you are not sure where the cap and the dipstick are located, see your authorized Volkswagen dealer or authorized Volkswagen Service Facility for assistance. 5. Remove the dipstick from the guide tube and wipe the dipstick off using a clean cloth.
Page 274 140. 10. Only add engine oil that Volkswagen has approved for that engine. Add the oil gradually in small quantities (no more than 1 pint / 0.5 liter). 11. To help prevent overfilling, you must wait about 1 minute each time you add oil so that the oil can flow into the oil pan up to the marking on the dipstick.
Page 275: Engine Oil Consumption
Volkswagen recommends that you to check the engine oil level at regular intervals, preferably every time you fill the fuel tank, and always before a long trip. Your vehicle may consume engine oil depending on several variables.
Page 276 Volkswagen recommends that you have your oil and oil filter changed by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility ⇒ . They have the required expertise and special tools and will dispose of the old oil properly.
Page 277: Engine Coolant
⇒ If you are uncertain in any way, have the work done by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Page 278 When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds. The engine coolant temperature may also be shown in the Volkswagen Information System MFI display, MFI menu (Multi-Function Indicator). On some equipment versions, all symbols and information in the display are shown in red, Displays and warning lights (Basic version).
Page 279 Please first read and note the introductory information and heed the WARNINGS The engine cooling system is filled at the factory with a mixture of specially conditioned water and at least 40 percent of Volkswagen engine coolant additive G 13 (TL-VW 774 J). This engine coolant additive is pink.
Page 280 If the fluid in the engine coolant reservoir is any color but pink, then G 13 was mixed with a different engine coolant. If this is the case, the engine coolant must be replaced immediately. Otherwise serious malfunctions or engine damage can occur! Engine coolant and engine coolant additives can pollute the environment.
Page 281 Screw the lid tightly. Even in an emergency, do not use any other kind of coolant additive if engine coolant meeting Volkswagen specifications ( Engine coolant specifications) is unavailable! Instead, add distilled water only ⇒ . As soon as possible, have the correct coolant ratio restored using engine coolant that meets Volkswagen specification, Engine coolant specifications.
Page 282 Have the engine cooling system checked immediately by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. Otherwise the engine may be damaged! When changing or topping off operating fluids, make sure that you pour the fluids into the correct reservoirs.
Page 283: Vehicle Battery
⇒ If you are uncertain in any way, have the work done by an authorized Volkswagen dealer or authorized Volkswagen Service Facility. Serious personal injury may result from improperly performed work.
Page 284 WARNING Working on the batteries or the electrical system in your vehicle can cause serious acid burns, fires, explosions, or electrical shocks. Always read and heed the following WARNINGS and safety precautions before working on the batteries or the electrical system. Before working on the electrical system, always switch off the ignition and all electrical consumers and disconnect the negative (-) cable from the standard 12 Volt battery.
Page 285 Please first read and note the introductory information and heed the WARNINGS Lights Possible cause Proper response See an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. Have the electrical system checked. Alternator malfunction. Switch off unnecessary electrical loads. The vehicle battery will not be charged by the alternator as you drive.
Page 286 Please first read and note the introductory information and heed the WARNINGS Charging the vehicle battery Vehicle batteries should be charged by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility because the factory-installed battery requires a charger with overload protection ⇒ ...
Page 287 After the battery is connected and the ignition is switched on, different indicator lights may come on. They should go out after you drive a short distance at 10–12 mph (15–20 km/h). If the indicator lights do not go out, contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility and have the vehicle checked.
Page 288 WARNING When the vehicle battery is charged, it produces highly explosive hydrogen gas. Charge vehicle batteries only in well-ventilated areas. Never charge a frozen or thawed battery. A dead battery can freeze at temperatures around +32 °F (0 °C). You must replace the vehicle battery if it was frozen. Incorrectly connected cables can cause a short-circuit.
Page 289 Regular and expert care helps to preserve the value of your vehicle. Such expert care may also be one of the requirements of your New Vehicle Limited Warranty if corrosion repair or repainting is necessary. Vehicle care products are available from your authorized Volkswagen dealer or authorized Volkswagen Service Facility. More information:...
Page 290: Washing The Vehicle
However, the effect on the paint depends to a large extent on the type of car wash. Volkswagen recommends using brushless car wash facilities. To remove wax residue from the windows and avoid jerky windshield wiper movement, heed the following tips, Cleaning windows and outside mirrors.
Page 291 WARNING After the vehicle has been washed, the wet brakes or, in winter, brake discs or pads coated with ice, react slower and need longer stopping distances. Always dry the brakes and clean off any ice coatings with a few careful applications of the brake.
Page 292 Never use a power washer to clean the engine compartment, Cleaning the engine compartment. WARNING Improper use of power washers can cause serious invisible permanent damage leading to tire failure and loss of vehicle control. This can cause accidents and severe personal injury. Keep sufficient distance between water jet and tires.
Page 293 Grease-removing cleaning agents cannot remove wax residue ⇒ Windshield cleaners, special cleaners, and cleaning cloths are available from your authorized Volkswagen dealer and authorized Volkswagen Service Facility. Removing snow Remove snow from all windows and outside mirrors with an appropriate brush.
Page 294 ⇒ Replace worn or damaged wiper blades immediately. Replacement blades may be purchased from any authorized Volkswagen dealer or authorized Volkswagen Service Facility. Lifting and tilting windshield wiper arms Move the wiper arms to the service position before lifting them away from the windshield, Windshield wipers and washer.
Page 295 Even if a wax solution is used regularly at the car wash, Volkswagen recommends applying a coat of hard wax at least twice a year to protect the paint.
Page 296 These differences can normally be reduced by polishing the vehicle. Volkswagen recommends contacting an authorized Volkswagen dealer or authorized Volkswagen Service Facility for information on suitable care products.
Page 297 Cleaning alloy wheels Every 2 weeks: Wash road salt and brake dust off alloy wheels, and clean the wheels with an acid- free detergent. Every 3 months: Volkswagen recommends applying a hard wax compound to the wheels. If road salt and brake dust are not removed regularly, they can corrode the metal.
Page 298 The engine compartment of a vehicle is a dangerous area , Working in the engine compartment. If necessary, the engine compartment should be cleaned by an authorized Volkswagen dealer or authorized Volkswagen Service Facility. Incorrect cleaning procedures could remove corrosion protection and damage electrical components, among other things.
Page 299 NOTICE Spraying or pouring water (for example, with a power washer) into the plenum chamber can cause severe damage to the vehicle. Wash the engine compartment only in special wash bays so that the oily dirt and fuel residue that are washed off the vehicle will not enter the sewage system.
Page 300 (especially on light-colored seat upholstery). This is caused by a lack of colorfastness in the clothing fabric, not by any fault in the seat upholstery fabric. To help prevent damage to the seat upholstery, always make sure your clothing is colorfast. Volkswagen recommends having a qualified specialist remove any discolorations from the seat upholstery.
Page 301 Remove stains, dirt, and other deposits as quickly as possible and do not allow them to dry. To help prevent damage, have stubborn stains removed by a professional who has the necessary expertise and experience. Suitable care products are available from authorized Volkswagen dealers and authorized Volkswagen Service Facilities. Caring for upholstery...
Page 302 Upholstery and fabric trim with light generalized soiling can be cleaned with a commercially available dry-foam cleaner. If the upholstery and fabric trim pieces are heavily soiled, see your authorized Volkswagen dealer or authorized Volkswagen Service Facility before you begin cleaning to learn about suitable cleaning options.
Page 303 If there is a malfunction in the airbag system, the airbag may not deploy correctly or at all, or it may deploy unexpectedly. This could cause fatal injuries. Have the airbag system inspected immediately by your authorized Volkswagen dealer or authorized Volkswagen Service Facility.
Page 304 Wipe the leather with a soft cloth. Cleaning Volkswagen recommends using a slightly moistened cotton or wool cloth for general cleaning. It is important not to let water soak through the leather or penetrate into seams. Before cleaning leather surfaces, read and heed the information, Cleaning upholstery on heated seats and power seats or seats with airbag components.
Page 305 Type of stain Cleaning Special stains, such as – Dab dry with an absorbent cloth. ballpoint pen, marker, nail – Clean with a special stain remover designed for leather. polish, latex paint, or shoe polish. NOTICE Stains that have been left in place too long will penetrate the surface of the leather and cannot be removed.
Page 306 Clean plastic components (inside and outside of the vehicle) and the instrument panel only with a solvent-free care and cleaning product that is specifically designed for plastics and approved by Volkswagen ⇒ Clean wood trim with a mild soap solution.
Page 307 Safety belts that were subject to stress in an accident and stretched must be replaced with a correct, new safety belt, preferably by an authorized Volkswagen dealer or authorized Volkswagen Service Facility. Replacement after a crash may be necessary even if a safety belt shows no visible...
Page 308 Parts, accessories, repairs, and modifications Introduction In this section you’ll find information about: Break-in period Parts and accessories Operating fluids and equipment Repairs and technical modifications Repairs and other things that can affect Advanced Airbag performance ...
Page 309 . These parts and accessories have been evaluated by Volkswagen for their suitability, reliability and safety. Have repairs and vehicle modifications performed by an authorized Volkswagen dealer or authorized Volkswagen Service Facility. Authorized Volkswagen dealers and authorized Volkswagen Service Facilities have the required tools, diagnostic equipment, repair information, and trained personnel to properly replace any airbag in your vehicle and assure system effectiveness in a crash.
Page 310: Parts And Accessories
Volkswagen Service Facility before purchasing accessories, spare parts or other equipment. Always do so if you want to install additional accessories or replace parts. Your authorized Volkswagen dealer or authorized Volkswagen Service Facility can provide information about legal requirements and factory-recommended accessories, spare parts, and other equipment.
Page 311 Repairs and modifications of front bumpers, doors, front seats, headliners and the chassis can affect proper airbag performance and should be performed by an authorized Volkswagen dealer or authorized Volkswagen Service Facility. These vehicle areas can contain important parts of the airbag system.
Page 312 Changing the vehicle's suspension system can change the way that the airbag system works in a crash. For example, using tire-rim combinations not approved by Volkswagen, lowering the vehicle, changing the stiffness of the suspension, including the springs, suspension struts, shock absorbers etc.
Page 313 The airbag system can be activated only once. After an airbag has inflated, it must be replaced. Use only original equipment airbags approved by Volkswagen. Have them installed by a trained technician who has the necessary tools and diagnostic equipment to properly replace any airbag in your vehicle and assure system effectiveness in a crash.
Page 314 Because of the large number and variety of mobile telephones on the market and the frequency with which new models are introduced, Volkswagen does not offer cradles for mobile telephones. Please check with the manufacturer of the mobile telephone that you plan to use.
Page 315 WARNING Using a mobile phone or CB radio inside the vehicle without a properly installed and separate outside antenna can be dangerous to your health and that of your passengers because the electromagnetic radiation energy that mobile phones and CB radios emit may be above established limits.
Page 316: Consumer Information
In this section you’ll find information about: Operating your vehicle outside of the United States and Canada Radio antenna and reception Volkswagen service information More information: Exterior views Technical data Starting assistance systems Parts, accessories, repairs and modifications Warranty and Maintenance ⇒ ...
Page 317 Europe, and may not work in other countries outside of North America. NOTICE Volkswagen is not responsible for mechanical damage that may result from substandard fuel or service or the unavailability of Genuine Volkswagen parts. Volkswagen is not responsible if the vehicle does not meet the respective legal requirements in other countries and continents.
Page 318 Improperly performed repairs and modifications can cause vehicle damage and malfunctions, and can impair the efficiency of driver assistance systems and the airbag system. This can lead to accidents and severe personal injuries. Have repairs and vehicle modifications performed by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Page 319 Declaration of Compliance, Telecommunications and Electronic Systems Radio Frequency Devices and Radiocommunication Equipment User Manual Notice. Radio-based equipment Mobile Phone Package Electronic immobilizer Remote control vehicle key Keyless Access locking and starting system Park Distance Control (PDC) system These devices comply with: FCC Part 15.19 These devices comply with Part 15 of the FCC Rules.
Page 320 However, NHTSA cannot become involved in individual problems between you, your dealer, or Volkswagen of America, Inc. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1-888-327-4236 (TTY: 1-800- 424-9153);...
Page 321: Engine Control And Emission Control System
Indicator lights Please first read and note the introductory information and heed the WARNINGS Lights Possible cause Proper response Have engine checked immediately by an Engine control malfunction (Electronic authorized Volkswagen dealer or authorized Power Control). Volkswagen Service Facility.
Page 322: Catalytic Converter
45 mph (70 km/h). There may be a noticeable smell. Diesel particulate filter clogged with soot. Obey speed limits ⇒ See an authorized Volkswagen dealer or authorized Volkswagen Service Facility if the indicator light is still on. Flashes Possible cause...
Page 323: Diesel Particulate Filter
If you experience misfires, loss of power or the engine is not running smoothly while driving, reduce speed immediately and have the vehicle checked by an authorized Volkswagen dealer or authorized Volkswagen Service Facility. Otherwise, gasoline could reach the exhaust system and get into the atmosphere.
Page 324 Lift points for the vehicle Fig. 145 Front lift point for workshop hoist or floor jack. Fig. 146 Rear lift point for workshop hoist or floor jack. The vehicle may only be raised at the lift points shown in illustrations ⇒ and ⇒ ...
Page 325 WARNING Improperly lifting your vehicle with a workshop hoist or a floor jack can cause the vehicle to fall off and cause serious personal injury. Always read and heed the operating instructions from the floor jack manufacturer and legal regulations if necessary before using the floor jack to lift the vehicle. Never let anyone stay in the vehicle when it is being lifted or when it is off the ground.
Page 326: In An Emergency
In an emergency Introduction In this section you’ll find information about: Protecting yourself and the vehicle More information: Braking and parking Emergency closing and opening Vehicle tool kit Changing a wheel WARNING A vehicle breakdown in traffic is dangerous and creates a great risk for you, your passengers, and others.
Page 327 Protecting yourself and the vehicle Fig. 147 In the center of the instrument panel: Button for the emergency flashers. Please first read and note the introductory information and heed the WARNINGS Obey all legal requirements regarding protecting a broken-down vehicle. For example, turning on the emergency flashers and wearing a safety vest are mandatory in many countries.
Page 328 Switch on the emergency flashers when: Traffic suddenly slows down or stops in front of you to warn those approaching from behind. In any emergency situation. If the vehicle breaks down. When being towed. Always obey traffic laws that govern the use of emergency flashers where you are driving. If the emergency flashers are not working, a different method –...
Page 329 Emergency closing and opening Introduction In this section you’ll find information about: Manually unlocking and locking the driver door Manually locking the passenger door Opening the rear hatch from inside the luggage compartment Emergency release for the fuel filler flap ...
Page 330 NOTICE To help prevent vehicle damage, carefully remove and properly reinstall parts after emergency locking or unlocking. Manually unlocking and locking the driver door Fig. 148 Door handle on driver door: Concealed lock cylinder. Please first read and note the introductory information and heed the WARNINGS When locking the vehicle manually, all doors are locked.
Page 331 Close the door. Make sure that the door is locked. Have the vehicle checked immediately by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. The passenger door can be unlocked and opened separately from inside the vehicle by pulling...
Page 332 Emergency release for the fuel filler flap Please first read and note the introductory information and heed the WARNINGS There is no emergency release for the fuel filler flap. Contact an authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
Page 333 Fig. 152 Releasing the selector lever lock. Please first read and note the introductory information and heed the WARNINGS If the power supply fails (due to a dead vehicle battery, for example) and the vehicle has to be pushed or towed, the emergency release must be used to move the selector lever to Neutral (N). The emergency release is located under the selector gate cover on the right side when viewed in the driving direction.
Page 334: Vehicle Tool Kit
Vehicle tool kit Introduction In this section you’ll find information about: Storage Contents When securing the vehicle after a breakdown, always obey all applicable legal requirements. More information: Working in the engine compartment In an emergency Changing a wheel WARNING Loose tools and other items in the vehicle tool kit and a loose compact spare wheel may be thrown through the passenger compartment if you brake suddenly or steer sharply or are...
Page 335 The vehicle tool kit is in the luggage compartment in one of several places, such as under the luggage compartment floor panel. Open the rear hatch, Luggage compartment. Lift the floor panel by the handle and hang it on the hook beneath the luggage compartment cover ⇒ ...
Page 336 Wheel trim Introduction In this section you’ll find information about: Hubcaps Wheel bolt caps Wheel covers More information: Exterior care and cleaning Vehicle tool kit Changing a wheel WARNING Unsuitable wheel covers and improper installation of wheel covers can cause accidents and severe injuries.
Page 337 Hubcaps Fig. 155 Pulling the hubcap off. Fig. 156 Twisting the hubcap off. Please first read and note the introductory information and heed the WARNINGS Depending on the vehicle model, the hubcaps can either be pulled off ⇒ f ig. 155 or removed by twisting ⇒ ...
Page 338: Wheel Covers
Wheel bolt caps Fig. 157 Pulling cover caps off wheel bolts. Please first read and note the introductory information and heed the WARNINGS Take the wire clip out of the vehicle tool kit, Vehicle tool kit. Insert the wire clip through the opening of the cover cap ⇒ f ig.
Page 339 Fig. 159 Pulling the wheel cover off (Version 2). Please first read and note the introductory information and heed the WARNINGS Pulling off the wheel cover (Version 1) Take the lug wrench and wire clip out of the vehicle tool kit, Vehicle tool kit. Place the wire clip hook in one of the openings of the wheel cover.
Page 340 Changing a wheel Introduction In this section you’ll find information about: Preparations for changing a wheel Wheel bolts Lifting the vehicle with the vehicle jack Changing a wheel After changing a wheel Change a wheel by yourself only if the vehicle is parked in a safe location, you are familiar with safety procedures and the technical steps, and you have proper tools available.
Page 341 Always use a jack that has been approved by the manufacturer for your vehicle. Never use other jacks, even if they have been approved for use on other Volkswagen models. To reduce the risk of losing control, crashes, and serious personal injuries, never loosen the screws on rims with threaded rim rings.
Page 342: Wheel Bolts
10. Take off the wheel covers, Wheel trim. WARNING Disregarding the safety-related checklist may lead to accidents and serious personal injuries. Always review and follow the checklist. Follow accepted safety practices and use common sense. Wheel bolts Fig. 160 Changing a wheel: Loosening wheel bolts. Please first read and note the introductory information and heed the WARNINGS Loosen the wheel bolts only with the lug wrench that was supplied with the vehicle.
Page 343 Never grease or oil the wheel bolts and the threads in the wheel hubs. The bolts can come loose while driving if greased or oiled, even if tightened to the required torque. WARNING Improperly tightened wheel bolts can come loose while driving and cause you to lose control over the vehicle, resulting in accidents and serious injuries.
Page 344 Fig. 162 Jack in position at the left rear lift point. Please first read and note the introductory information and heed the WARNINGS The jack must be positioned at one of the 4 lift points marked on the vehicle body (2 on each side as shown in ⇒ ...
Page 345 Improper use of your vehicle jack can cause the vehicle to fall off the jack leading to serious personal injury. To help reduce the risk of serious personal injury: Use only jacks approved by Volkswagen for the vehicle. Other jacks might slip, even those approved for other Volkswagen models, but not for your vehicle.
Page 346 Removing the wheel Review the checklist, Preparations for changing a wheel. Loosen the wheel bolts, Wheel bolts. Lift the vehicle, Lifting the vehicle with the vehicle jack. Completely unscrew and remove the previously loosened wheel bolts using the hexagonal socket in the screwdriver handle ⇒ ...
Page 347 Have the wheel bolt tightening torque immediately checked with a torque wrench, Wheel bolt tightening torque. Have the damaged wheel replaced as soon as possible. The Tire Pressure Monitoring System must be recalibrated after each tire change, Tire Pressure Monitoring System (TPMS).
Page 348 Detailed information regarding fuse box layout is available from authorized Volkswagen dealers and authorized Volkswagen Service Facilities. In general, one fuse can protect several loads. One load can also be protected by several fuses.
Page 349 Fuses in the vehicle Fig. 164 On the driver side in the instrument panel: Storage compartment in front of the fuse box. Fig. 165 In the engine compartment: Fuse box cover. Please first read and note the introductory information and heed the WARNINGS Replace a blown fuse only with a fuse of the same amperage (same color and same imprint) and same overall size.
Page 350 Open fuse boxes must be protected from dirt and moisture. Dirt and moisture in fuse boxes can cause damage to the electrical system. The vehicle contains other fuses in addition to those mentioned in this section. Have these fuses replaced by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Page 351 Replacing blown fuses Fig. 166 Blown fuse: A: Blade fuse. B: Cartridge fuse. Fig. 167 Removing or installing a blade fuse with the plastic tweezers: A: MINI. B: ATO. Please first read and note the introductory information and heed the WARNINGS Preparations Switch off the headlights, the ignition, and all electrical consumers.
Page 352 For blade fuses: Depending on the type of fuse, slide the tweezers ⇒ f ig. 167 or B onto the fuse in the direction of the arrow. Pull out the fuse. For cartridge fuses: Pull the fuse up and out by hand. If the fuse is blown, replace the fuse with a new fuse of the same amperage (same color and same imprint) and same size ⇒ ...
Page 353: Replacing Light Bulbs
Changing a light bulb requires a certain amount of skill. If you are uncertain about how to proceed, Volkswagen recommends having the light bulb changed by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility. Special training and knowledge are generally required when other vehicle parts must be disassembled to replace a bulb, or when HID –...
Page 354 If you are uncertain about what to do, have the work performed by an authorized Volkswagen dealer, an authorized Volkswagen Service Facility, or another qualified workshop. Serious personal injury may result from improperly performed work.
Page 355 14. Always have the headlights adjusted by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility after a headlight bulb has been replaced.
Page 356 WARNING Disregarding the safety-related checklist may lead to accidents and serious personal injuries. Always review and follow the checklist. Follow accepted safety practices and use common sense. NOTICE Always insert and remove lamps carefully to help prevent damage to the vehicle paint or to other parts of the vehicle.
Page 357 Please first read and note the introductory information and heed the WARNINGS The following instructions only apply to vehicles with halogen headlight bulbs. Contact your authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance with HID headlight replacement.
Page 358 You cannot replace the LEDs in LED daytime running lights or LED parking lights within the headlight assembly. Contact your authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
Page 359 Reinstalling the headlight assembly Fig. 171 Anchors 1 and connector plug 2 of the left headlight assembly. Fig. 172 In the engine compartment: Release lever for the left headlight. Please first read and note the introductory information and heed the WARNINGS Please carry out each step only in the order specified: Please review and follow the checklist Connect the headlight assembly connector plug ⇒ ...
Page 360 The illustrations show the left headlight. The right headlight is the mirror image. Replacing light bulbs in the front bumper Fig. 173 In front left bumper: Removing the light assembly. Fig. 174 Replacing light bulbs in the front bumper. Please first read and note the introductory information and heed the WARNINGS Please carry out each step only in the order specified: Turn signal ⇒ ...
Page 361 Please carry out each step only in the order specified: Turn signal ⇒ Front fog light / Cornering light f ig. 174 (2) Release the connector and pull it off. Use Release the connector and pull it off. the flat blade of the screwdriver from the vehicle tool kit, if necessary.
Page 362 Fig. 176 Replacing the bulb in the headlight. Please first read and note the introductory information and heed the WARNINGS .368. Please carry out each step only in the order specified: Front turn signal ⇒ Fog light / cornering light f ig.
Page 363 Removing and installing the subwoofer to replace bulbs Fig. 177 In the right side of the luggage compartment: Removing the subwoofer. Please first read and note the introductory information and heed the WARNINGS Please carry out each step only in the order specified: Please review and follow the checklist Open the rear hatch.
Page 364 Replacing taillight bulbs in the vehicle body Fig. 178 In the side of luggage compartment: A: Open cover of the rear side panel. B: Removing the taillight assembly. Fig. 179 Taillights: A: Removing the bulb holder. B: Removing the taillight bulbs. Please first read and note the introductory information and heed the WARNINGS Please carry out each step only in the order specified.
Page 365 Changing the light bulb Unscrew the fastening screws ⇒ f ig. 179 A (arrows) with the Phillips screwdriver from the vehicle tool kit Remove the bulb holder from the taillight. Replace the burned out light bulb with a new bulb of the same type B (arrows). Insert the bulb socket into the taillight.
Page 366 Different models may have different lights, and the location and design of covers, bulb holders, and bulbs may be in a different location than shown in the illustrations. You cannot replace the LEDs in LED license plate lights. Contact your authorized Volkswagen dealer or an authorized Volkswagen Service Facility for assistance.
Page 367 Jump-starting Introduction In this section you’ll find information about: Using jumper cables If your engine does not start because the vehicle battery is dead, your vehicle's battery can be connected to the battery of another vehicle to start your engine (jump-starting). Check the battery acid level indicator on the vehicle battery before jump-starting ⇒ ...
Page 368 WARNING Improper use of jumper cables when jump-starting a vehicle with a dead battery can cause the battery to explode, leading to serious personal injury. To help reduce the risk of battery explosion: All work on the batteries or the electrical system in your vehicle can cause serious acid burns, fires, or electrical shocks.
Page 369 Using jumper cables Fig. 182 Diagram for attaching the jumper cables: Dead battery 1 and booster battery 2. Please first read and note the introductory information and heed the WARNINGS The dead battery must be properly connected to the vehicle's electrical system. Make certain that the vehicles are not touching each other.
Page 370 Before removing the jumper cables Switch off the headlights (if they are on). In the vehicle with the dead battery, switch on the heater fan and the rear window defroster. This helps to minimize voltage spikes when the cables are disconnected. Removing jumper cables With the engine running, remove the jumper cables in reverse order to the way they were connected.
Page 371 If the vehicle loses power while it is being towed, stop towing the vehicle immediately and contact your authorized Volkswagen dealer or authorized Volkswagen Service Facility for assistance.
Page 372 WARNING Towing a vehicle changes the way it handles and brakes. To help reduce the risk of an accident and serious personal injury, note the following: The driver of the vehicle that is being towed: – Since the brake booster also does not work when the engine is stopped, you will need to press harder on the brake pedal to slow down or stop.
Page 373 If the front and rear wheels cannot turn. If the vehicle battery is dead (because the electronic steering column lock engages and cannot be released). If you have to tow an automatic transmission vehicle more than 30 miles (50 km). WARNING It is not safe for children or other persons to ride in a vehicle that is being towed.
Page 374 When not to tow your vehicle In the following situations, the vehicle cannot be towed and must be transported on a flatbed truck or trailer: If transmission fluid has leaked out of the transmission. If there is little or no oil in the transmission because of damage to your vehicle, it must be moved with the drive wheels off the ground.
Page 375 Fig. 184 In the right front bumper: Screwing in the towing eye. Please first read and note the introductory information and heed the WARNINGS There is a threaded hole for the towing eye in the right front bumper ⇒ f ig. 184.
Page 376 Installing the rear towing eye Fig. 185 In the right rear bumper: Removing the cover. Fig. 186 In the right rear bumper: Installing the towing eye. Please first read and note the introductory information and heed the WARNINGS There is a threaded hole for the towing eye in the right rear bumper ⇒ f ig.
Page 377 NOTICE Always make sure the towing eye is screwed all the way into threaded hole so that it is secure. If not, it could be pulled out while your vehicle is being towed. Installing the rear towing eye (Beetle R-Line) Fig.
Page 378 Screw the towing eye counterclockwise into the threaded hole as far as it will go (arrow) ⇒ ⇒ f ig. 188 . Use the lug wrench to turn and tighten the towing eye completely and securely. When towing is complete, unscrew the towing eye clockwise to remove it. Position the lower tab of the cover ⇒ ...
Page 379 Abbreviations Abbreviation Meaning 5S man 5-speed manual transmission 6S auto 6-speed automatic transmission 6S man 6-speed manual transmission Anti-lock Brake System Anti-Knock Index ANSI American National Standards Institute Anti-Slip Regulation Anti-Theft Alarm system Brake Assist System Cubic centimeter – metric unit of measure for engine displacement Cruise Control System Cubic inch displacement –...
Page 380 GVWR Gross Vehicle Weight Rating High Intensity Discharge headlights (Xenon) Horsepower – unit of measure for engine power Kilogram – metric unit of measure for weight Kilonewton – a unit of measure for force Kilopond – unit of measure for force Kilopascal –...

This manual is also suitable for:

Beetle

Volkswagen Beetle 2014 Owner's Manual

Quick Links

Side view

Related Manuals for Volkswagen Beetle 2014

Summary of Contents for Volkswagen Beetle 2014

This manual is also suitable for:

Table of Contents
