Tribute
Child Restraint System
Owner's Manual
Keep for future use.
Rear-facing*
2.3 to 18 kg
(5 to 40 lbs)
48 to 94cm
(19 to 37 in.)
Forward-facing*
10 to 18 kg
(22 to 40 lbs)
71 to 102 cm
(28 to 40 in.)
At least 2 years old
* See page 2 for complete requirements.
Para instrucciones en Español,
llamar al: 1-800-233-5921.
WARNING:
To reduce the risk of serious injury
or death, read this owner's manual prior
to installing and using this child restraint.
© 2017 Evenflo Company, Inc.
™
25701108
3/17
Advertisement
Table of Contents
Related Manuals for Evenflo Tribute
Summary of Contents for Evenflo Tribute
- Page 1 Tribute ™ Child Restraint System Owner’s Manual Keep for future use. Rear-facing* 2.3 to 18 kg (5 to 40 lbs) 48 to 94cm (19 to 37 in.) Forward-facing* 10 to 18 kg (22 to 40 lbs) 71 to 102 cm (28 to 40 in.)
-
Page 2: Table Of Contents
Table of Contents More children are killed every year as passengers in car crashes than by any other type of injury. Important Information To reduce the risk of SERIOUS INJURY or DEATH, read Child Requirements ............. 2 this owner’s manual and your vehicle owner’s manual Premature Infant Use ........... -
Page 3: Child Requirements
CHILD REQUIREMENTS PREMATURE INFANT USE Warning: Failure to follow these Child Requirements could result Before using this child restraint for preterm or low birth in serious injury or death. weight infants, ensure the Child Requirements are met and follow the guidelines in this section. This child restraint is designed for use by children in both rear-facing and forward-facing orientations. -
Page 4: Warnings
WARNING WARNING Air Bag Warnings General Warnings Rear-facing and Forward-facing Use Rear-facing and Forward-facing Use • DO NOT use this child restraint in the front seat of a • Failure to follow the Child Requirements for vehicle equipped with an air bag, unless the air bag rear-facing and forward-facing use of this child has been deactivated. - Page 5 WARNING WARNING Forward-facing Position Warnings – cont. Location Warnings – cont. • The headrest on the vehicle seat in front of the child Rear-facing and Forward-facing Use should be put in its lowest position. The vehicle seat If the child restraint cannot be properly installed, back that the child faces must be fully padded and use the child restraint.
-
Page 6: Latch Warnings
WARNING WARNING Tether Strap Warnings LATCH Warnings Forward-facing Use Only Rear-facing and Forward-facing Use • To avoid a strangulation hazard, you MUST tightly roll • The LATCH system is intended to be used ONLY or fold excess or unused tether strap and secure with described in these instructions. -
Page 7: Safe Practices
Safe Practices Motor Vehicle/Aircraft Usage • Everyone rides buckled up or the vehicle does When used with the internal harness and not go. Make no exceptions for adults or children. If properly installed pursuant to these instructions, someone unbuckles, stop the vehicle. Being firm and this restraint is certified for use only in consistent from the start will mean fewer discipline passenger and multi-purpose... -
Page 8: Visual Glossary
Visual Glossary Visual Glossary Your vehicle components may be significantly different than pictured. Consult your owner’s manual to help you identify your vehicle components. Front Seat Lap and Shoulder Belts Fold-down Armrest Consult your vehicle’s owners manual. Front Rear Headrests Back Seat Tether Anchors Headrests... -
Page 9: Child Restraint Features
Child Restraint Features Child Restraint Features Front Description Seat Pad Head Pillow* Harness Straps Chest Clip Buckle Crotch Strap Harness Release Button Harness Adjust Strap Body Pillow* Instruction Storage Area Tether Strap and Hook Harness Straps Splitter Plate Recline Stand Lower Anchor Connector Assembly Back * Not all features are available on all models. -
Page 10: Rear-Facing Use
Using the Child Restraint Rear-facing Installation Checklist Rear-facing 1. Secure child restraint to the vehicle seat. • Recline Stand is flipped to the recline position Child Requirements for Rear-facing: (page 18). • Weight: 2.3 to 18 kg (5 to 40 lbs) •... -
Page 11: Positioning The Recline Stand For Rear-Facing Use
Positioning the Recline Stand for Rear-facing Installation with Rear-facing Use Lower Anchor Connectors LATCH is a system for attaching the child restraint to your Lift the child restraint and vehicle seat. It is to be used in place of your vehicle’s seat flip the recline stand belts and can be used in vehicles with LATCH anchors. - Page 12 WARNING Pull the seat pad off of the front of the child restraint. Make sure both harness straps are installed Route the Lower Anchor completely on the splitter plate, as shown. Connector strap Failure to properly attach the harness straps to the hook through the rear- splitter plate may result in a loose harness and serious facing belt paths...
-
Page 13: Rear-Facing Installation With Seat Belt
Rear-facing Installation with Seat Belt WARNING NEVER turn a child restraint forward-facing with an infant weighing less than 10 kg (22 lbs). Crash forces may cause serious injury or death. For complete child requirements for forward-facing use, see page 2. Infants MUST always ride... - Page 14 WARNING Install Locking Clip (not included), if necessary. DO NOT use the upper harness slots rear-facing. The harness If your vehicle was built prior Locking Clip may not properly restrain the child during a crash. to model year 1996, and installed properly has a lap/shoulder belt that is equipped with an emergency...
- Page 15 This page is intentionally blank. WARNING • If vehicle seat belts are not routed and fastened correctly, the child restraint may not protect your child in a crash. • Check your vehicle owner’s manual to determine how to lock your seat belt for child restraint installation. The seat belt must be locked to properly secure the child restraint.
-
Page 16: Forward-Facing Installation Checklist
Using the Child Restraint Forward-facing Installation Checklist Forward-facing 1. Secure child restraint to the vehicle seat. • Recline Stand is flipped to the upright position Child Requirements: (page 30). • Weight: 10 to 18 kg (22 to 40 lbs) • Install with the Lower Anchors Connector Assembly (page 31) or the vehicle seat belt (page 35). -
Page 17: Forward-Facing Installation With
Positioning the Recline Stand for Forward-facing Installation with Forward-facing Use Lower Anchor Connectors LATCH is a system for attaching the child restraint to your vehicle seat. It is to be used in place of your vehicle’s seat Lift the child restraint and belts and can be used in vehicles with LATCH anchors. - Page 18 WARNING Place the child restraint in your vehicle forward-facing. Route the lower anchor connector DO NOT use this child restraint if it moves more than strap and hook through the forward-facing belt path 25 mm (1 in.) side-to-side or front to back at the forward-facing belt path.
-
Page 19: Forward-Facing Installation With Seat Belt
Forward-facing Installation WARNING with Seat Belt • Failure to follow these instructions could result in WARNING serious injury to your child or other vehicle occupants. • The tether strap is for forward-facing use only. DO NOT use the lowest set of harness slots for forward-facing. - Page 20 Lap Belt Only Lap & Shoulder Belt Fasten the vehicle seat belt as shown depending on your type of seat belt. Note: Install locking clip on lap and shoulder belt combinations, if necessary. Install Locking Clip (not WARNING included), if necessary. If your vehicle was built prior •...
-
Page 21: General Information
General Information Positioning the Harness Strap Shoulder harness straps on this child restraint are adjustable to four positions. Forward-facing ONLY Top Harness Position Forward-facing OR Rear-facing Middle Two Harness Positions Connect the tether hook to the vehicle tether Rear-facing ONLY anchor behind the vehicle seat, as shown. -
Page 22: Securing Your Child In The Child Restraint
Make sure Harness Adjust Strap is routed over the Harness Strap To change the harness strap position, loosen the shoulder harness, as shown on page 43, step 2. Slide the harness strap off of the splitter plate . We suggest you do this one side at a time. -
Page 23: Adjusting The Crotch Strap
Adjusting the Harness Strap Align the two sides of the The harness straps must be To loosen the harness straps, To tighten the harness chest clip and snap snug against the child. A push the harness release straps, pull on the long them together. -
Page 24: Removing The Lower Anchor Connectors
WARNING When the Lower anchor connector assembly is not in use you MUST attach • To avoid a strangulation the hooks to the back hazard, you MUST tightly of the child restraint. roll or fold excess tether A loose Lower anchor strap and secure with the connector assembly strap strap/rubber band. -
Page 25: Securing Your Child Restraint In Aircraft
Securing Your Child Restraint in Installing Child Restraint Aircraft Rear-facing in Aircraft The Federal Aviation Administration (FAA) recommends that you secure your child for air travel in an appropriate child restraint based on your child’s weight and size. Turbulence can happen with little or no warning. When turbulence occurs, the safest place for your child is in a properly installed child restraint, not in an adult’s lap or on the aircraft seat with its seat belt. -
Page 26: Installing Child Restraint Rear-Facing In Aircraft
Installing Child Restraint Rear-facing Installing Child Restraint in Aircraft Forward-facing in Aircraft IMPORTANT: Before installing the child restraint, make sure the aircraft seat is in a fully upright position. Fasten the aircraft seat belt Aircraft Seat Belt Adjust the child restraint to its upright position (page 30), then place it on the aircraft seat forward-facing, as shown above. -
Page 27: Installing Child Restraint Forward-Facing In Aircraft
Installing Child Restraint Care and Cleaning Forward-facing in Aircraft • DO NOT lubricate or immerse in water the LATCH connectors, the buckle, or any other part of this child restraint, unless rinsing is permitted, as stated on the back of the buckle for your restraint. •... -
Page 28: Replacement Parts
LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY EPS Foam OR FITNESS FOR A PARTICULAR PURPOSE ON Retainer Strip THIS PRODUCT IS HEREBY DISCLAIMED. EVENFLO SHALL NOT BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL OR PUNITIVE DAMAGES OF ANY KIND FOR BREACH OF THE EXPRESS LIMITED... - Page 29 • www.evenflo.com • USA: 1-800-233-5921, 8 AM to 5 PM E.T. • Canada: 1-937-773-3971 • México: 01-800-706-12-00...
