Sonus
Child Restraint System
Owner's Manual
Keep for future use.
See back cover to remove Owner's Manual.
Rear-facing*
2.3 to 18 kg
(5 to 40 lbs)
48 to 102 cm
(19 to 40 in.)
Forward-facing*
10 to 22.6 kg
(22 to 50 lbs)
71 to 127 cm
(28 to 50 in.)
At least 2 years old
* See inside cover for complete requirements.
Para instrucciones en Español,
llamar al: 1-800-233-5921
WARNING:
To reduce the risk of serious injury
or death, read this owner's manual prior
to installing and using this child restraint.
© 2016 Evenflo Company, Inc.
TM
25700676
8/16
