Sharp LC-46SE94U Service Manual

Hide thumbs Also See for LC-46SE94U:
Table of Contents

Advertisement

Quick Links

See also: Operating Manual , User Manual
TopPage
LC-46SE94U
The stand (ST52SE94) and speakers (SP46SE94) for Model LC-46SE941U are separately sold.
OUTLINE
OUTLINE.................................................................... i
[1]
SPECIFICATIONS (LC-46SE94U) .........................1-1
[2]
SPECIFICATIONS (LC-46SE941U) .......................1-2
[1]
OPERATION MANUAL ..........................................2-1
[1]
DIMENSIONS ........................................................3-1
[1]
REMOVING OF MAJOR PARTS ...........................4-1
[1]
ADJUSTMENT PROCEDURE ...............................5-1
[2]
CHAPTER 6. TROUBLE SHOOTING TABLE
[1]
TROUBLE SHOOTING TABLE..............................6-1
Parts marked with "
" are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.

SERVICE MANUAL

LC-46SE941U
MODELS
In the interests of user-safety (Required by safety regulations in some countries) the set should
be restored to its original condition and only parts identical to those specified should be used.
OUTLINE
CONTENTS
LC-46SE94U/LC-46SE941U
No. S18D1LC46SE94

LCD COLOR TELEVISION

LC-46SE94U
LC-46SE941U
CHAPTER 7. MAJOR IC INFORMATIONS
[1]
MAJOR IC INFORMATIONS..................................7-1
[1]
OVERALL WIRING DIAGRAM ..............................8-1
[2]
SYSTEM BLOCK DIAGRAM .................................8-2
[1]
SPEAKER-L Unit....................................................9-1
[2]
SPEAKER-R Unit ...................................................9-1
[3]
TERMINAL Unit......................................................9-2
[4]
R/C, LED Unit.........................................................9-4
[5]
KEY Unit.................................................................9-5
[6]
MAIN Unit...............................................................9-6
[7]
SIDE Unit .............................................................9-10
[1]
[2]
SPEAKER-L Unit..................................................10-1
[3]
SPEAKER-R Unit .................................................10-1
[4]
TERMINAL Unit....................................................10-2
[5]
R/C, LED Unit.......................................................10-5
[6]
KEY Unit...............................................................10-6
[7]
MAIN Unit.............................................................10-7
[8]
SIDE Unit ...........................................................10-22
Parts Guide
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
