  • Page 1 Downloaded from ProjectorsManual.com Manuals...
  • Page 2 Downloaded from ProjectorsManual.com Manuals...
  • Page 3 SPECIAL NOTE FOR USERS IN THE U.K. The mains lead of this product is fitted with a non-rewireable (moulded) plug incorporat- ing a 10A fuse. Should the fuse need to be replaced, a BSI or ASTA approved BS 1362 fuse marked and of the same rating as above, which is also indicated on the pin face of the plug, must be used.
  • Page 4 Downloaded from ProjectorsManual.com Manuals...

  • Page 5: Bright

    Before using the projector, please read this operation manual carefully. Introduction IMPORTANT • For your assistance in reporting the loss Model No.: XV-Z100 or theft of your Projector, please record the Serial Number located on the bottom of the projector and retain this information.
  • Page 6 Mainte The warning lights (power indicator, lamp indicator and temperature warning indicator) on the projector indicate problems inside the projector. If a problem occurs, either the temperature warning indicator or the lamp indicator will illuminate red, and the projector will enter standby mode. After the projector has entered standby mode, follow the procedures given below.

  • Page 7: How To Read This Operation Manual

    Press Q or O and select “Picture” Picture SCR - ADJ PRJ - ADJ Help Picture Mode Standard to adjust. Contrast Bright Color Tint On-screen Sharp CLR Temp 7 5 0 0 Bright Boost display Progressive 3D Progressive Lamp Setting Bright Reset SEL./ADJ. ENTER Info ..Indicates safeguards for using the projector.

  • Page 8: Table Of Contents

    Contents Preparing Introduction Setup How to Read this Operation Manual ..3 Setting up the Projector ...... 18 Contents ..........4 Setting up the Projector ....... 18 Standard Setup (Front Projection) ..18 IMPORTANT SAFEGUARDS ....6 Ceiling-mount Setup ......18 Accessories ........

  • Page 9: Reset

    Reference Appendix Connecting Pin Assignments ..... 53 RS-232C Specifications and Command Maintenance ........47 Settings ..........54 Maintenance Indicators ...... 48 Computer Compatibility Chart .... 55 Regarding the Lamp ......50 Troubleshooting ........56 Lamp ............. 50 Specifications ........58 Caution Concerning the Lamp ....

  • Page 10: Important Safeguards

    IMPORTANT SAFEGUARDS CAUTION: Please read all of these instructions before you operate this product and save these instructions for later use. Electrical energy can perform many useful functions. This product has been engineered and manufactured to assure your personal safety. BUT IMPROPER USE CAN RESULT IN POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARDS.
  • Page 11 15. Overloading 19. Replacement Parts Do not overload wall outlets, extension cords, or When replacement parts are required, be sure integral convenience receptacles as this can the service technician has used replacement result in a risk of fire or electric shock. parts specified by the manufacturer or have the same characteristics as the original part.
  • Page 12 I Continuously watching the screen for long Internal cleaning should only be performed hours will cause eye strain. Be sure to occa- by a Sharp Authorized Projector Dealer or sionally rest your eyes. Service Center. Do not set up the projector in places ex- Avoid locations with extremes of tem- posed to direct sunlight or bright light.
  • Page 13 I When turning off the projector, the cooling fan Using the projector in other countries runs to decrease the internal temperature for I The power supply voltage and the shape of a while. Unplug the power cord after the cool- the plug may vary depending on the region ing fan stops.

  • Page 14: Accessories

    HEIGHT ADJUST lever ......... 31 SCR - ADJ ............. 43 Help..............46 Screen Size and Projection Distance ...... 20 • Operation manual Sharp ............. 42 Video cable INPUT 1 terminal ......23, 25, 26 adaptor QCNWGA001WJZZ SIDE BAR ..........34, 35 INPUT 1 –...

  • Page 15: Part Names And Functions

    Part Names and Functions Numbers in Z refer to the main pages in this operation manual where the topic is explained. Projector Top View Power Lamp indicator 28, 48 28, 48 indicator Temperature warning indicator STANDBY/ON button For turning the power on and Volume buttons putting the...

  • Page 16: Rear View

    Part Names and Functions (Continued) Numbers in Z refer to the main pages in this operation manual where the topic is explained. Rear View Exhaust vent Speaker Intake vent AC socket Kensington Security Connect the Standard connector supplied Power cord. Rear adjustment foot Using the Kensington Lock...
  • Page 17 Usable Range Remote control sensor The remote control can be used to control the projector within the ranges shown in the illustra- tion. Note • The signal from the remote control can be re- flected off a screen for easy operation. How- ever, the effective distance of the signal may differ depending on the screen material.

  • Page 18: Inserting The Batteries

    Part Names and Functions (Continued) Inserting the Batteries Press the P mark on the cover and slide it in the direction of the arrow. Insert the batteries. • Insert the batteries making sure the polarities correctly match the m and n marks inside the battery compartment. Attach the cover and slide it until it clicks into place.

  • Page 19: Usable Range

    Usable Range Remote control sensor The remote control can be used to control the projector within the ranges shown in the illustra- tion. Note • The signal from the remote control can be re- flected off a screen for easy operation. How- ever, the effective distance of the signal may differ depending on the screen material.

  • Page 20: Quick Start

    • English is the factory default language. If you ptor (supplied) want to change the on-screen display to another move the len As a part of policy of continuous improvement, SHARP reserves the right to make design and language, change the language according to ailable) INPUT3 l equip- specification changes for product improvement without prior notice.
  • Page 21 4. Turn the video equipment on and start playback 5. Select the INPUT mode Select the “INPUT 3” using the INPUT button on the projector or D INPUT 3 on the remote control. On the On the remote On-screen display projector control INPUT 3...

  • Page 22: Setting Up The Projector

    I g e t h e l a I g u a g e a c c o r d i I g t o As a part of policy of continuous improvement, SHARP reserves the right to make design and ailable)

  • Page 23: Projection (Prj) Mode

    When usin Picture (Screen) size Projection distance [L] Distance from the lens center to the bottom of the image [H] Diag. [ ] Width Height Minimum [L1] Maximum [L2] 300 (762 cm) 240 (610 cm) 180 (457 cm) 32 0 (9.8 m) 37 0 (11.3 m) ( 89 cm) 270 (686 cm)

  • Page 24: Screen Size And Projection Distance

    Setting up the Projector (Continued) Screen Size and Projection Distance When using a wide screen (16:9) and projecting 16:9 image Picture (Screen) size Projection distance [L] Distance from the lens center to the bottom of the image [H] Diag. [χ] Width Height Minimum [L1]...
  • Page 25 When usin Picture (Screen) size Projection distance [L] Distance from the lens center to the bottom of the image [H] Diag. [χ] Width Height Minimum [L1] Maximum [L2] 300 (762 cm) 240 (610 cm) 180 (457 cm) 32 0 (9.8 m) 37 0 (11.3 m) ( 89 cm) 270 (686 cm)

  • Page 26: Samples Of Cables For Connection

    • English is the factory default language. If you ptor (supplied) want to change the on-screen display to another move the len As a part of policy of continuous improvement, SHARP reserves the right to make design and language, change the language according to ailable) INPUT3 l equip- specification changes for product improvement without prior notice.

  • Page 27: Connecting To Video Equipment

    (e.g. Press “Fn” and “F5” keys simultaneously when using a SHARP notebook computer). Refer to the specific instructions in your computer's operation manual to enable your computer’s external output port. Component cable...

  • Page 28: Reset

    PRJ - ADJ Help to adjust. Picture Mode Standard ¥ The selected item is highlighted. Contrast Bright Color Tint Sharp CLR Temp 7 5 0 0 Bright Boost Progressive 3D Progressive Lamp Setting Bright Reset cting to Video Equipment (Continued) SEL./ADJ.

  • Page 29: Connecting To A Computer

    (e.g. Press “Fn” and “F5” keys simultaneously when using a SHARP notebook computer). Refer to the specific instructions in your computer's operation manual to enable your computer’s external output port. Component cable...

  • Page 30: Connecting To A Monitor With Rgb Input Terminal

    Connecting to a Monitor with RGB Input Terminal You can display computer images on both the projector and a separate monitor using two sets of RGB cables. Computer Monitor To INPUT 1 To OUTPUT To RGB To RGB terminal (INPUT 1, 2) input output terminal...

  • Page 31: Computer

    Controlling the Projector by a Computer When the RS-232C terminal on the projector is connected to a computer with a DIN-D-sub RS- 232C adaptor (optional accessory: AN-A1RS) and an RS-232C serial control cable (cross type, commercially available), the computer can be used to control the projector and check the status of the projector.

  • Page 32: Turning The Projector On/Off

    • English is the factory default language. If you ptor (supplied) want to change the on-screen display to another move the len As a part of policy of continuous improvement, SHARP reserves the right to make design and language, change the language according to ailable) INPUT3 l equip- specification changes for product improvement without prior notice.

  • Page 33: Turning The Power Off (Putting The Projector Into Standby Mode)

    Computer STRETCH SIDE BAR SVGA (800 600) XGA (1024 768) 4:3 aspect ratio SXGA (1280 960) SXGA (1400 1050) SXGA (1280 1024) Other aspect ratios 1280 Input Signal Output screen image Computer Image type STRETCH SIDE BAR CINEMA ZOOM KEYSTONE button ng Trapezoidal Resolution lower than SVGA...

  • Page 34: Image Projection

    Image Projection Switching the Input Mode Select the appropriate input mode for the connected equipment. C INPUT PressC INPUT DINPUT 3 or EINPUT 4 on the remote control to select the input mode. • When pressing INPUT (P/R) on the projector, input mode switches in the following order: INPUT1 INPUT2...
  • Page 35 Computer STRETCH SIDE BAR SVGA (800 600) XGA (1024 768) 4:3 aspect ratio SXGA (1280 960) SXGA (1400 1050) SXGA (1280 1024) Other aspect ratios 1280 Input Signal Output screen image Computer Image type STRETCH SIDE BAR CINEMA ZOOM KEYSTONE button ng Trapezoidal Resolution lower than SVGA...

  • Page 36: Adjusting The Volume

    Image Projection (Continued) Adjusting the Volume Press K/L on the remote control or –O/Q+ on the projector to adjust the vol- ume. AV MUTE button Note • Pressing K/–O will lower the volume. • Pressing L/Q+ will raise the volume. Volume buttons •...

  • Page 37: Correcting Trapezoidal Distortion

    Computer STRETCH SIDE BAR SVGA (800 600) XGA (1024 768) 4:3 aspect ratio SXGA (1280 960) SXGA (1400 1050) SXGA (1280 1024) Other aspect ratios 1280 Input Signal Output screen image Computer Image type STRETCH SIDE BAR CINEMA ZOOM KEYSTONE button ng Trapezoidal Resolution lower than SVGA...

  • Page 38: Resize Mode

    Image Projection (Continued) Resize Mode This function allows you to modify or customize the resize mode to enhance the input image. De- pending on the input signal, you can choose “STRETCH”, “SIDE BAR” or “CINEMA ZOOM” image. Press HRESIZE. • See page 43 for setting on menu screen. RESIZE button VIDEO •...
  • Page 39 Computer STRETCH SIDE BAR SVGA (800 K 600) XGA (1024 K 768) 4:3 aspect ratio 854 K 480 640 K 480 SXGA (1280 K 960) SXGA L (1400 K 1050) SXGA (1280 K 1024) 854 K 480 640 K 480 Other aspect ratios 1280 K 720 854 K 480...

  • Page 40: Operating With The Remote Control

    As a part of policy of continuous improvement, SHARP reserves the right to make design and ailable) INPUT3 l equip- t h e procedu r e on page specification changes for product improvement without prior notice.

  • Page 41: Menu Items

    Help RETURN button Contrast Standard Bright Color • Press l RETURN to Tint *1*2 return to the previous Sharp screen when the menu 7 5 0 0 is displayed. Blue 3D Progressive Page 42 Bright CLR Temp 5500K ENTER 6500K...

  • Page 42: Reset

    Menu Items (Continued) “Projection adjustment (PRJ-ADJ)” menu Main menu Sub menu Picture SCR - ADJ PRJ - ADJ Help PRJ - ADJ Auto Search [On/Off] Page 44 Page 44 Auto Search Auto Sync Auto Sync [On/Off] Auto Power Off Page 44 System Sound Speaker Auto Power Off [On/Off]...

  • Page 43: Using The Menu Screen

    PRJ - ADJ Help RETURN button Contrast Standard Bright Color • Press l RETURN to Tint *1*2 return to the previous Sharp screen when the menu 7 5 0 0 is displayed. Blue 3D Progressive Page 42 Bright CLR Temp 5500K ENTER...

  • Page 44: Reset

    PRJ - ADJ Help to adjust. Picture Mode Standard • The selected item is highlighted. Contrast Bright Color Tint Sharp CLR Temp 7 5 0 0 Bright Boost Progressive 3D Progressive Lamp Setting Bright Reset cting to Video Equipment (Continued) SEL./ADJ.

  • Page 45: Picture Adjustment ("Picture" Menu)

    Help Picture Mode Standard Picture Mode Standard Contrast Contrast Bright Bright Color Tint Blue Sharp CLR Temp 7 5 0 0 CLR Temp 7 5 0 0 Bright Boost Bright Boost Lamp Setting Bright Progressive 3D Progressive Reset Lamp Setting...

  • Page 46: Adjusting The Image

    Tint* For making skin For making skin film transformed with three-two pull down tones purplish. tones greenish. (NTSC and PAL60Hz) or two-two pull Sharp* For less For more down (PAL50Hz and SECAM) enhance- sharpness. sharpness. ment to progressive mode images.

  • Page 47: Adjusting The Projected Image ("Scr - Adj" Menu)

    Selectable items Description are set for the same baud rate. Approx. Approx. Operated exclusively the Resize mode, see pages 34 Logo Sharp logo screen with Lamp Setting set to 2,000 100 hours Selectable Description “Bright” hours Blue Blue screen...

  • Page 48: ("Prj - Adj" Menu)

    Regarding t h e Lamp ( C ont i n Remov e t h e lamp u n it . Handle ¥ Loo s e n t h e s e c u r ing s c re w s from t h e lamp u n it .

  • Page 49: Setting The Confirmation Sound (System Sound)

    S e l e c t a b l e i t e m s D e s c r i p t i o n Approx. Approx. Operated exclusively he Resize mode, see pages 34 Logo Sharp logo screen with Lamp Setting set to 2,000 100 hours Selectable Description “Bright”...

  • Page 50: Troubleshooting With "Help" Menu

    Troubleshooting with “Help” menu This function advises you to solve the problems during usage. Adjustment buttons (P/R/O/Q) Utilizing “Help” menu functions MENU/HELP button ENTER button Example: When the picture has a green tint When the picture has a green tint on INPUT 1 (Component)/INPUT 2 (Component).

  • Page 51: Maintenance

    Problem Check Page • Change the input signal type setting. Picture is green on INPUT 1 (Component)/ Select “Color is faded or poor” in the “Help” menu, and then select INPUT 2 (Component). an input signal type. Picture is pink (no green) on INPUT 1 (RGB)/INPUT 2 (RGB).

  • Page 52: Maintenance Indicators

    Mainte I The warning lights (power indicator, lamp indicator and temperature warning indicator) on the projector indicate problems inside the projector. I If a problem occurs, either the temperature warning indicator or the lamp indicator will illuminate red, and the projector will enter standby mode. After the projector has entered standby mode, follow the procedures given below.
  • Page 53 Problem Check Page • Change the input signal type setting. Picture is green on INPUT 1 (Component)/ Select “Color is faded or poor” in the “Help” menu, and then select INPUT 2 (Component). an input signal type. Picture is pink (no green) on INPUT 1 (RGB)/INPUT 2 (RGB).

  • Page 54: Regarding The Lamp

    Sharp Authorized Projector Dealer or Service Center. * If the new lamp does not light after replacement, take your projector to the nearest Sharp Authorized Projector Dealer or Service Center for repair.

  • Page 55: The Lamp Unit

    Problem Check Page • Change the input signal type setting. Picture is green on INPUT 1 (Component)/ Select “Color is faded or poor” in the “Help” menu, and then select INPUT 2 (Component). an input signal type. Picture is pink (no green) on INPUT 1 (RGB)/INPUT 2 (RGB).

  • Page 56: Resetting The Lamp Timer

    Regarding the Lamp (Continued) Remove the lamp unit. Handle • Loosen the securing screws from the lamp unit. Hold the lamp unit by the handle and pull it in the direction of the arrow. At this time, keep the lamp unit horizontal and do not tilt it.

  • Page 57: Connecting Pin Assignments

    Problem Check Page • Change the input signal type setting. Picture is green on INPUT 1 (Component)/ Select “Color is faded or poor” in the “Help” menu, and then select INPUT 2 (Component). an input signal type. Picture is pink (no green) on INPUT 1 (RGB)/INPUT 2 (RGB).

  • Page 58: Rs-232C Specifications And Command Settings

    RS-232C Specifications and Command Settings Computer control A computer can be used to control the projector by connecting an RS-232C serial control cable (cross type, sold separately) to the projector. (See page 27 for connection.) Communication conditions Set the serial port settings of the computer to match that of the table. Signal format: Conforms to RS-232C standard.

  • Page 59: Computer Compatibility Chart

    Problem Check Page • Change the input signal type setting. Picture is green on INPUT 1 (Component)/ Select “Color is faded or poor” in the “Help” menu, and then select INPUT 2 (Component). an input signal type. Picture is pink (no green) on INPUT 1 (RGB)/INPUT 2 (RGB).

  • Page 60: Troubleshooting

    Troubleshooting Problem Check Page • Projector power cord is not plugged into the wall outlet. • Power to the external connected devices is off. – • The selected input mode is wrong. • Cables incorrectly connected to the projector. 23–27 •...
  • Page 61 Problem Check Page • Change the input signal type setting. Picture is green on INPUT 1 (Component)/ Select “Color is faded or poor” in the “Help” menu, and then select INPUT 2 (Component). an input signal type. Picture is pink (no green) on INPUT 1 (RGB)/INPUT 2 (RGB).

  • Page 62: Specifications

    ¥ English is the factory default language. If you ptor (supplied) want to change the on-screen display to another move the len As a part of policy of continuous improvement, SHARP reserves the right to make design and language, change the language according to ailable) INPUT3 l equip- specification changes for product improvement without prior notice.

  • Page 63: Dimensions

    Dimensions Units: inches (mm) ø9 (69.2) (77.5) (80) (315) (33.8) (46.2) (65.5) (75) Downloaded from ProjectorsManual.com Manuals...

  • Page 64: Index

    HEIGHT ADJUST lever ......... 31 SCR - ADJ ............. 43 Help ..............46 Screen Size and Projection Distance ...... 20 • Operation manual Sharp ............. 42 Video cable INPUT 1 terminal ......23, 25, 26 adaptor QCNWGA001WJZZ SIDE BAR ..........34, 35 INPUT 1 –...

  • Page 65: Downloaded From Projectorsmanual.com Manuals
