Panasonic SA-VK460GS Service Manual

Dvd stereo system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Notes: This model's DVD/CD mechanism changer unit is CRS1D. Please refer to the original service
manual (Order No. MD0603065A3) for this mechanism.

Specifications

AMPLIFIER SECTION
RMS Output Power Stereo mode:
Front Ch (both ch driven)
115 W per channel (3 Ω), 1 kHz, 10% THD
Total RMS Stereo mode power
PMPO output power
FM/AM TUNER, TERMINALS SECTION
Preset station
Frequency Modulation (FM)
Frequency range
Sensitivity
S/N 26dB
Antenna terminals
Amplitude Modulation (AM)
Frequency range
AM Sensitivity S/N 20dB at 999 kHz
Digital audio output
Coaxial digital output
Music Port Input Jack
Sensitivity
230 W
2500 W
FM 20 stations
AM 15 stations
87.50 to 108.00 MHz (50 kHz
step)
2.5 µV (IHF)
1.3 µV
75 Ω (unbalanced)
522 to 1629 kHz (9 kHz step)
520 to 1630 kHz (10 kHz step)
505 µV/m
Pin jack
100 mV, 4.7 kΩ
DVD Stereo System
SA-VK460GC
SA-VK460GS
SA-VK460GCS
SA-VK460GCT
Colour
(S)... Silver Type
Terminal
Phone jack
Terminal
Mic jack
Sensitivity
Terminal
CASSETTE DECK SECTION
Type
Track system
Heads
Record/playback
Erasure
Motor
Recording system
Erasing system
Tape speed
Overall frequency response (+3, -6 dB) at DECK OUT
Normal
S/N ratio
Wow and flutter
Fast forward and rewind time
VIDEO SECTION
© 2007 Matsushita Electric Industrial Co. Ltd.. All
rights
reserved.
distribution is a violation of law.
ORDER NO. MD0707001CE
Stereo, 3.5 mm jack
Stereo, 3.5 mm jack
0.7 mV, 600 Ω
Mono, 6.3 mm jack (1 system)
1 way, Auto reverse
4 Track, 2 Channel
Solid permalloy head
Double gap ferrite head
DC servo motor
AC bias 100 kHz
AC erase 100 kHz
4.8 cm/s
35 Hz to 14 kHz
50 dB (A-Weighted)
0.18 % (WRMS)
Approx. 120 seconds with
C-60 cassette tape
Unauthorized
copying
and
