Telefunken TK2529ST Service Manual
  1. Manuals
  2. Brands
  3. Telefunken Manuals
  4. CRT TV
  5. TK2529ST
  6. Service manual
Telefunken TK2529ST Service Manual

Telefunken TK2529ST Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

8. Explode View Diagram...................................................52
Downloaded from
www.Manualslib.com
TELELFUNKEN
SERVICE MANUAL
1. Caution.....................................................................2
2. Specification...............................................................6
3. BOM List ........................... ....................................9
4. Alignment Procedure....................................................45

5. Block Diagram............................................................49

6. Schematic Diagram......................................................50

7. PCB Layout................................................................51

This manual is the latest at the time of printing, and does not
include the modification which may be made after the printing, by
the constant improvement of product.
manuals search engine
TK2529ST

Advertisement

Table of Contents
loading

Related Manuals for Telefunken TK2529ST

Summary of Contents for Telefunken TK2529ST

  • Page 1: Block Diagram

    TELELFUNKEN SERVICE MANUAL TK2529ST 1. Caution……………………………………………………………2 2. Specification………………………………………………………6 3. BOM List ……………………… ………………………………9 4. Alignment Procedure………………………………………….…45 5. Block Diagram……………………………………………………49 6. Schematic Diagram………………………………………………50 7. PCB Layout………….……………………………………………51 8. Explode View Diagram……………………………………………52 This manual is the latest at the time of printing, and does not include the modification which may be made after the printing, by the constant improvement of product.
  • Page 2 CAUTION: Use of controls, adjustments or procedures other than those specified herein may result in hazardous radiation exposure. CA UTION: TO REDUCE THE RISK OF CAUTION ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE RISK RISK OF OF ELECTRI ELECTRIC C PARTS INSIDE.

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS CAUTION: Read all of these instructions. Save these instructions for later use. Follow all Warnings and Instructions marked on the audio equipment. 1. Read Instructions- All the safety and operating instructions should be read before the product is operated. 2.
  • Page 4 PROTECTION AND LOCATION OF YOUR SET Do not use this television set near water ... for example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, etc. Never expose the set to rain or water. If the set has been exposed to rain or water, unplug the set from the wall outlet and refer servicing to qualified service personnel.
  • Page 5 OPERATION OF YOUR SET 18. This television set should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply at your home, consult your television dealer or local power company. For television sets designed to operate from battery power, refer to the operating instructions.
  • Page 6 PFS2 FORMAT-1 Report Date: 2003-11-26 15:30 ProductView..: Product:@ Report by....: TK2529ST Specs / Products SRF NO./ODF NO. ON43044004R2 MasterData Customer Id BGH S.A. Version Status WG Archived Brand TELEFUNKEN Reception +Tuning - presets/channels +Tuning - technology +Tuning - Indication +Freq Bands...
  • Page 7 Date: 2003-11-26 15:30 ProductView..: Product:@ Report by....: TK2529ST Specs / Products +Numb of Loc Cont (incl Mains) +Number of Ind. (incl Mains) Channel +-, Tact Switch, Vol +-, +Local Controls (Old) TV/AV, MENU Remote Control +Remote Control - scope +Remote Control - type...
  • Page 8 Date: 2003-11-26 15:30 ProductView..: Product:@ Report by....: TK2529ST Specs / Products Final Equipment +Packaging - methods +Documents and manuals +Languages DFU +Cables Supplied +Antenna Supplied +Stand Supplied +Aux Equipm Supplied Batteries for RC (2 x AA) Packaging - width cm...
  • Page 9 Item No. Description Quantity Req. Designator Remarks 08-02513M-AVY ASS'Y- AV BD 11-2SK362-YBX FET 2SK362-Y (N-CHANNEL) 1 Q962 11-2SK362-YBX FET 2SK362-Y (N-CHANNEL) 1 Q963 11-SK2541-0BX FET 2SK2541(N-CHANNEL) 1 Q961 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R952 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R953 18-CB0103-JNX RES.
  • Page 10 Item No. Description Quantity Req. Designator Remarks 47-SVI001-XX0 SOCKET 1 P951 08-02516M-YUY ASS'Y - YUV PARTS 11-SA1015-YBX TRANSISTOR 2SA1015Y 1 Q933 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q932 11-SC1815-YBX TRANSISTOR 2SC1815Y 1 Q934 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R939 18-CB0102-JNX RES.
  • Page 11 Item No. Description Quantity Req. Designator Remarks 76-00C276-0AF CARTON BOX 0.25 FOR F. CAB. 76-00C276-0AR CARTON BOX 0.333 FOR R. CAB. 76-346740-01A CARTON SHEET LWH 440X620X3MM 0.065 FOR OTHER 77-100100-6WC BUBBLE BAG (100cmX100cm) FOR F. CAB. 74-344740-50C EPE BOARD ((750MMX580MMX5MM) 0.667 FOR R.CAB 08-02575M-CRY...
  • Page 12 Item No. Description Quantity Req. Designator Remarks 18-FE0272-JNX RES. M.O. 2.7K OHM 1/2W +/-5% 1 R521 18-FG0183-JHX RES. M.O. 18K OHM 2W +/-5% 1 R516 18-FG0183-JHX RES. M.O. 18K OHM 2W +/-5% 1 R517 18-FG0183-JHX RES. M.O. 18K OHM 2W +/-5% 1 R518 25-BLA100-M1X CAP.
  • Page 13 Item No. Description Quantity Req. Designator Remarks 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C1114 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C1116 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C1117 26-EBP103-ZFX CAP. CER 0.01UF 50V +80/-20% F 1 C1118 26-EBP103-ZFX CAP.
  • Page 14 Item No. Description Quantity Req. Designator Remarks 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R1023 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R1024 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R1025 18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5% 1 R1003 18-CB0152-JNX RES.
  • Page 15 Item No. Description Quantity Req. Designator Remarks 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C1016 25-BCB100-M1X CAP. ELEC 10 UF 16V +/-20% 1 C1008 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C1019 25-BFB339-M1X CAP. ELEC 3.3 UF 50V +/-20% 1 C1010 13-P3440G-B8P IC MSP3440G B8(52-PIN PSDIP)
  • Page 16 Item No. Description Quantity Req. Designator Remarks 48-TAC001-XX0 TACT SWITCH 1 S006A 08-0C276M-SW1 11-IRR001-3X0 IR RECEIVER MODULE HK381A 1 IR1001 14-LED05R-XX1 LED RED FB205 1 D1001 18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% 1 R1002 18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R1003 25-BCB470-M1X CAP.
  • Page 17 Item No. Description Quantity Req. Designator Remarks 10-HER108-FBX DIODE HER108 1 D803 10-HS10VC-DBX DIODE 500mW 10HSC 1 D840 10-HS16VC-DBX DIODE 500mW 16HSC 1 D807 10-HS2V4A-DBX DIODE 500mW 2.4HSA 1 D841 10-HS3V9A-DBX DIODE 500mW 3.9HSA 1 D839 11-0BF422-0BX TRANSISTOR BF422 (NPN) 1 Q831 11-SA1015-YBX TRANSISTOR 2SA1015Y...
  • Page 18 Item No. Description Quantity Req. Designator Remarks 18-CE0563-JNX RES. C.F. 56k OHM 1/2W +/-5% 1 R804 18-FG0223-JHX RES. M.O. 22K OHM 2W +/-5% 1 R836 18-FG0333-JHX RES. M.O. 33K OHM 2W +/-5% 1 R810 18-FG0333-JHX RES. M.O. 33K OHM 2W +/-5% 1 R839 18-KE0105-JN3 RES.
  • Page 19 Item No. Description Quantity Req. Designator Remarks 26-APK471-KB4 CAP. CER 470 pF 400VAC +/-10% 1 C812 26-APK471-KB4 CAP. CER 470 pF 400VAC +/-10% 1 C813 26-AQK472-ZFX CAP. CER 4700PF 250VAC+80-20%F 1 C803 26-AQK472-ZFX CAP. CER 4700PF 250VAC+80-20%F 1 C804 26-EBP102-KBX CAP.
  • Page 20 Item No. Description Quantity Req. Designator Remarks 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J816 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 D850 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J850 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J851 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J806 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM...
  • Page 21 Item No. Description Quantity Req. Designator Remarks 66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 FOR T802(P1,P9,P10,P18,P3) 66-343730-0B0 HOLLOW RIVET 1.6X3.0XL3.2 FOR DB801(+)/(-) 66-382330-0B7 RIVET 2.0X3.7X3.5 FOR C835 66-382330-0B7 RIVET 2.0X3.7X3.5 FOR C806 66-382330-0B7 RIVET 2.0X3.7X3.5 FOR P801 67-109180-4M2 HEAT SINK FOR IC851 67-H27292-3A0 HEAT SINK FOR IC841 67-H29550-8A0...
  • Page 22 Item No. Description Quantity Req. Designator Remarks 56-C276LS-0HC LENS 56-C276PK-0HA POWER KNOB 57-10654X-00F cable ties　(2.5mmX95mm) 59-130460-00X RUBBER PAD (25mmX7mm) STICK ON F.CAB. (FOOTING) 59-312160-000 SPEAKER RUBBER CUSHION FOR SPK & F. CAB. 63-B30100-AB4 S/T SCREW B 3 X 10 AB MTG PUSH BUTTON &...
  • Page 23 Item No. Description Quantity Req. Designator Remarks 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D631 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D711 10-1N4148-ABX DIODE 1N4148 (SWITCHING) 1 D721 10-79C33V-DBX DIODE ZENER 33V 1/2W 5% 1 D101 10-79C8V2-DBX DIODE ZENER 8V2 1/2W 5% 1 D471 10-HS12VC-DBX DIODE 500mW 12HSC 1 D731...
  • Page 24 Item No. Description Quantity Req. Designator Remarks 11-SK2541-0BX FET 2SK2541(N-CHANNEL) 1 Q007 13-000040-52P IC 4052 1 IC901 13-00M24C-04P IC 4K EEPROM M24C04-BN6 1 IC002 13-0TA842-7KS IC TA8427K 1 IC301 13-0TDA26-16S IC TDA2616 (AUDIO O/P) 1 IC601 13-A12V01-TOP IC TCL-A12V01-TO 1 IC001 13-TB1240-ANP IC TB1240AN 1 IC201...
  • Page 25 Item No. Description Quantity Req. Designator Remarks 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R304 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R451 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R909 18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5% 1 R915 18-CB0102-JNX RES.
  • Page 26 Item No. Description Quantity Req. Designator Remarks 18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% 1 R917 18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% 1 R271 18-CB0151-JNX RES. C.F. 150 OHM 1/6W +/-5% 1 R257 18-CB0152-JNX RES. C.F. 1.5k OHM 1/6W +/-5% 1 R204 18-CB0152-JNX RES.
  • Page 27 Item No. Description Quantity Req. Designator Remarks 18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R901 18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R902 18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R906 18-CB0223-JNX RES. C.F. 22k OHM 1/6W +/-5% 1 R907 18-CB0223-JNX RES.
  • Page 28 Item No. Description Quantity Req. Designator Remarks 18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R913 18-CB0471-JNX RES. C.F. 470 OHM 1/6W +/-5% 1 R106 18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R049 18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5% 1 R211 18-CB0472-JNX RES.
  • Page 29 Item No. Description Quantity Req. Designator Remarks 18-CE0121-JNX RES. C.F. 120 OHM 1/2W +/-5% 1 R731 18-CE0229-JNX RES. C.F. 2.2 OHM 1/2W +/-5% 1 R305 18-EG0109-JHX RES. FUS. 1 OHM 2W +/-5% 1 R422 18-EG0109-JHX RES. FUS. 1 OHM 2W +/-5% 1 R431 18-EG0159-JHX RES.
  • Page 30 Item No. Description Quantity Req. Designator Remarks 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C274 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C630 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C912 25-BCB470-M1X CAP. ELEC 47 UF 16V +/-20% 1 C913 25-BCB470-M1X CAP.
  • Page 31 Item No. Description Quantity Req. Designator Remarks 25-GFB478-K1X CAP. ELEC 0.47 UF 50V 10%CEC-K 1 C243 26-AIC221-KBX CAP. CER 220 PF 500V +/-10% B 1 C431 26-AIC221-KBX CAP. CER 220 PF 500V +/-10% B 1 C441 26-AIC332-KBX CAP. CER 3300 PF 500V +/-10% B 1 C402 26-AIC391-KBX CAP.
  • Page 32 Item No. Description Quantity Req. Designator Remarks 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C615 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C616 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 T141 26-EBP102-KBX CAP. CER 1000 PF 50V +/-10% B 1 C022A 26-EBP103-ZFX CAP.
  • Page 33 Item No. Description Quantity Req. Designator Remarks 26-EBP220-JZX CAP. CER 22PF 50V +/-5% SL TU 1 C013 26-EBP221-JCX CAP. CER 220PF 50V +/-5% CH 1 C026 26-EBP221-JCX CAP. CER 220PF 50V +/-5% CH 1 C232 26-EBP222-KBX CAP. CER 2200PF 50V +/-10% B 1 C207 26-EBP222-KBX CAP.
  • Page 34 Item No. Description Quantity Req. Designator Remarks 27-PBC472-J0X CAP. P.E 0.0047UF 63V +/-5% 1 C244 27-PBC563-J0X CAP. P.E 0.056 UF 63V +/-5% 1 C304 27-PBC682-J0X CAP. P.E 0.0068UF 63V +/-5% 1 C251 27-RHQ223-J0X CAP. PP 0.022 UF 400V +/-5% 1 C416 27-RHQ563-J0X CAP.
  • Page 35 Item No. Description Quantity Req. Designator Remarks 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J010 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J011 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J041 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J046 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J054 41-WJ0060-B00 WIRE BARE JUMPER 6mm...
  • Page 36 Item No. Description Quantity Req. Designator Remarks 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R219A 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R224 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R238 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 R751 41-WJ0060-B00 WIRE BARE JUMPER 6mm 1 J081 41-WJ0065-B00 WIRE BARE JUMPER 6.5MM...
  • Page 37 Item No. Description Quantity Req. Designator Remarks 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J307 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J309 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J610 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J615 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM 1 J704 41-WJ0075-B00 WIRE BARE JUMPER 7.5MM...
  • Page 38 Item No. Description Quantity Req. Designator Remarks 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J708 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J902 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J913 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 J918 41-WJ0100-B00 WIRE BARE JUMPER 10MM 1 R282 41-WJ0100-B00 WIRE BARE JUMPER 10MM...
  • Page 39 Item No. Description Quantity Req. Designator Remarks 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J415 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J901 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J925 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J926 41-WJ0125-B00 WIRE BARE JUMPER 12.5MM 1 J211 41-WJ0135-B00 WIRE BARE JUMPER 13.5MM...
  • Page 40 Item No. Description Quantity Req. Designator Remarks 41-WJ0155-B00 WIRE BARE JUMPER 15.5MM 1 J407 41-WJ0155-B00 WIRE BARE JUMPER 15.5MM 1 J408 41-WJ0165-B00 WIRE BARE JUMPER 16.5MM 1 J616 41-WJ0165-B00 WIRE BARE JUMPER 16.5MM 1 J617 41-WJ0165-B00 WIRE BARE JUMPER 16.5MM 1 R103 41-WJ0170-B00 WIRE BARE JUMPER 17MM...
  • Page 41 Item No. Description Quantity Req. Designator Remarks 41-WJ0195-B00 WIRE BARE JUMPER 19.5MM 1 J305 41-WJ0195-B00 WIRE BARE JUMPER 19.5MM 1 J306 41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J228 41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J229 41-WJ0200-B00 WIRE BARE JUMPER 20MM 1 J230 41-WJ0200-B00 WIRE BARE JUMPER 20MM...
  • Page 42 Item No. Description Quantity Req. Designator Remarks 63-W30100-AB4 S/T SCREW W 3 X 10 AB MTG M. BD & M. BD BKT 64-B30120-104 M/C SCREW B 3 X 12 MTG IC601 64-P30080-104 M/C SCREW P 3 X 8 FOR Q722 & IC301 & Q412 65-Z30050-23M NUT M 3 FOR IC301 &...
  • Page 43 Item No. Description Quantity Req. Designator Remarks 58-C189RI-3UI INLAY REAR AV 58-D106SI-0UI INLAY SIDE AV 59-130460-00X RUBBER PAD (25mmX7mm) STICK ON R. CAB.(FOOTING) 62-389620-0UD POWER LINE BLOCK 63-B40250-AB2 S/T SCREW B 4 X 25 AB MTG FRONT & REAR CABINET 63-F30100-BT3 S/T SCREW F 3 X 10 BT (BLACK) MTG RCA JACK &...
  • Page 44 Item No. Description Quantity Req. Designator Remarks 58-HS45E2-9UI INLAY REMOTE HANDSET 74-009022-60C POLYBAG HANDSET (9CMX22CM) 25-HBB470-M1X CAP. ELEC 47UF 10V +/-20% 1 C1503 13-SC9028-23B IC SC9028-023 1 IC1501 67-X26968-0E2 BATT. TERMINAL (+/-) 67-X29681-1E2 BATTERY CONTACT SPRING (-) 67-X29682-0E2 BATTERY CONTACT SPRING (+) 08-HS45E0-PAY ASS'Y - PACKING OF IR HANDSET 76-002091-0AT...
  • Page 45 TB1240 + TCLM34 chassis alignment instruction Enter factory mode in production line Simply press the D-mode key on the factory remote handset. Enter service mode Press and hold the VOLUME DOWN key tightly on the unit until minimum level and don’t release the VOLUMN DOWN key, then press the “0”...
  • Page 46 Vertical VPOS50 (03) Input a PAL cross Adjust VPOS50 for vertical position. geometry for HIGH50 (1A) hatch pattern. Adjust HIGH50 for vertical amplitude. PAL system VLIN50 (04) Adjust VLIN50 for vertical linearity. (Key 2) VSC50 (05) Adjust VSC50 for vertical S-correction OSD50 (2F) Adjust OSD50 for OSD position (normally use default value).
  • Page 47 (curve of VLOMAX (7E) --------- VOLMAX is the volume output level at volume VOL05 (48) 100%. control) VOL25 (65) VOL05 is the volume output level at 5% VOL50 (70) VOL25 is the volume output level at 25% VOL50 is the volume output level at 50% Remark: The value of VOL05, VOL25 and VOL50 was not suggested to vary in every set.
  • Page 48 SKIP key SHPTV3 (17) ---------- SHPTV3 – 50% sharpness in 3.58 system (sharpness SHPAV3 (1A) (TV) adjustment) SHPTV4 (16) SHPAV3 – 50% sharpness in 3.58 system (AV) SHPAV4 (16) SHPTV4 – 50% sharpness in 4.43 system SHPX (25) (TV) SHPN (10) SHPAV4 –...
  • Page 49 M34 Block Diagram 2002/9/5 By GaoJF In the TV body Side TDA2822m TDA2616Q BTSC TUNER (MSP3440) AV2 IN S Video AV1 IN TDA2616Q C BUS AV Out WOOFER sp 4052 PIF&SIF COMB.F(TDA9181) CVBS CVBS/YC PAL/NTSC 1 CHIP EEPROM OSD RGB MICRO COMPUTER TB1240 TMP88CS38N...
  • Page 50 Downloaded from www.Manualslib.com manuals search engine...
  • Page 51 Downloaded from www.Manualslib.com manuals search engine...
  • Page 52 Downloaded from www.Manualslib.com manuals search engine...
