SPLIT-TYPE, AIR TO WATER HEAT PUMP

SERVICE MANUAL

Outdoor unit
[Service ref.]
[Model Name]
PUHZ-SW75VHA.UK
PUHZ-SW75VHA
PUHZ-SW75VHAR4.UK
PUHZ-SW100VHA.UK
PUHZ-SW100VHA
PUHZ-SW100VHAR4.UK
PUHZ-SW100YHA.UK
PUHZ-SW100YHA
PUHZ-SW100YHAR3.UK
PUHZ-SW120VHA.UK
PUHZ-SW120VHA
PUHZ-SW120VHAR4.UK
PUHZ-SW120YHA.UK
PUHZ-SW120YHA
PUHZ-SW120YHAR3.UK
Salt proof model
PUHZ-SW75VHA-BS.UK
PUHZ-SW75VHA-BS
PUHZ-SW75VHAR4-BS.UK
PUHZ-SW100VHA-BS
PUHZ-SW100VHA-BS.UK
PUHZ-SW100VHAR4-BS.UK
PUHZ-SW100YHA-BS.UK
PUHZ-SW100YHA-BS
PUHZ-SW100YHAR3-BS.UK PUHZ-SW100YHAR4-BS.UK
PUHZ-SW120VHA-BS.UK
PUHZ-SW120VHA-BS
PUHZ-SW120VHAR4-BS.UK
PUHZ-SW120YHA-BS.UK
PUHZ-SW120YHA-BS
PUHZ-SW120YHAR3-BS.UK PUHZ-SW120YHAR4-BS.UK
PUHZ-SW75VHA.UK
PUHZ-SW75VHA-BS.UK
R410A
PUHZ-SW75VHAR3.UK
PUHZ-SW100VHAR3.UK
PUHZ-SW100YHAR1.UK
PUHZ-SW100YHAR4.UK
PUHZ-SW120VHAR3.UK
PUHZ-SW120YHAR1.UK
PUHZ-SW120YHAR4.UK
PUHZ-SW75VHAR3-BS.UK
PUHZ-SW100VHAR3-BS.UK
PUHZ-SW100YHAR1-BS.UK
PUHZ-SW120VHAR3-BS.UK
PUHZ-SW120YHAR1-BS.UK
CONTENTS
1. TECHNICAL CHANGES ................................ 2
2. REFERENCE MANUAL ................................. 3
3. SAFETY PRECAUTION ................................. 4
4. FEATURES ..................................................... 8
5. SPECIFICATIONS .......................................... 9
6. DATA ............................................................. 13
7. OUTLINES AND DIMENSIONS ................... 15
8. WIRING DIAGRAM ...................................... 17
9. WIRING SPECIFICATIONS .......................... 24
10. REFRIGERANT SYSTEM DIAGRAM .............. 25
11. TROUBLESHOOTING .................................. 27
12. DISASSEMBLY PROCEDURE ..................... 82
PARTS CATALOG (OCB533)
August 2015
No. OCH533
REVISED EDITION-D
Revision:
• Added
PUHZ-SW75VHAR4.UK,
PUHZ-SW75VHAR4-BS.UK,
PUHZ-SW100VHAR4.UK,
PUHZ-SW100VHAR4-BS.UK,
PUHZ-SW100YHAR4.UK,
PUHZ-SW100YHAR4-BS.UK,
PUHZ-SW120VHAR4.UK,
PUHZ-SW120VHAR4-BS. UK,
PUHZ-SW120YHAR4.UK and
PUHZ-SW120YHAR4-BS.UK
in REVISED EDITION-D.
• Some descriptions have
been modified.
• Please void OCH533
REVISED EDITION-C.
Note:
• This manual describes
service data of the outdoor
units only.
