SERVICE MANUAL
STEREO VIDEO CASSETTE RECORDER
POWER REQUIREMENTS .................
POWER CONSUMPTION ...................
WEIGHT ..............................................
DIMENSIONS ......................................
OPERATING TEMPERATURE ...........
VIDEO RECORDING SYSTEM ..........
VIDEO SIGNAL SYSTEM ...................
VIDEO HEAD ......................................
USABLE CASSETTES ........................
CHANNEL COVERAGE ......................
RF OUTPUT ........................................
HORIZONTAL RESOLUTION ............
TUNER SYSTEM ................................
TV SYSTEM ........................................
FAST-FORWARD/REWIND TIME ......
HI-FI DYNAMIC RANGE .....................
SPECIFICATIONS
120V AC, 60Hz
12W
TYP 2.5W (standby mode)
3.2kg (7.1lbs.)
360mm (W) x 232.5mm (D) x 94mm(H)
(14 1/4 x 13 1/8 x 3 3/4 in.)
5°C to 40°C
Rotary 2 head helical scanning system
NTSC color system, 525 lines, 60 fields
Double azimuth 4 heads
VHS video cassette
VHF: 2 to 13
UHF: 14 to 69
CATV: 5A, A-5 to A-1, A to W,
W+1 to W-84
VHF channel 3 or 4 (switchable),
66dBµ
230 lines (at SP)
Frequency synthesized tuner
M
Approx.110 seconds with T-120 tape
More than 90dB (at SP)
S/M Code No. 09-004-344-7N1
HV-FX8100
BASIC TAPE MECHANISM : OVD-6S
TAPE SPEED ......................................
RECORDING/PLAYBACK TIME ........
VIDEO INPUT ......................................
VIDEO OUTPUT .................................
VIDEO S/N ..........................................
AUDIO INPUT .....................................
AUDIO OUTPUT .................................
AUDIO TRACK ....................................
AUDIO FREQUENCY RESPONSE ....
AUDIO S/N ..........................................
•
Design and specifications are subject to change without
notice.
U
SP: 33.35 mm/sec
LP: 16.67 mm/sec
SLP: 11.12 mm/sec
SP: 3.5 hours with T-210 tape
LP: 7 hours with T-210 tape
SLP: 10.5 hours with T-210 tape
1.0Vp-p, 75ohm, unbalanced
1.0Vp-p, 75ohm, unbalanced
50dB (nominal)
–8dBs, 50K ohm
–8dBs, less than 1K ohm
3 tracks (Hi-Fi sound 2 tracks,
Normal sound 1 track)
Normal: 100Hz-10kHz (at SP)
Hi-Fi: 20Hz-20kHz (at SP)
Normal: more than 42 dB (at SP)
