Summary of Contents for Philips 26HF5443
- Page 1 26HF5443 32HF7443 Instruction for Use...
- Page 2 Care of the screen Do not touch, push, rub or strike the screen with anything hard as this may scratch or damage the screen permanently. Do not rub with chemically treated cloth. Do not touch the surface with bare hands or greasy cloth.
-
Page 3: Connecting The Mains
Make sure that air can circulate freely through the ventilation slots Connecting the Mains Insert the mains plug into the wall socket and switch on. Please refer to the label on the back of the television for the correct operating voltage. Installing the remote control Switch the TV on: Press the power switch... - Page 4 Accessing the Set-up Menu When the set is in the High Security Mode, the Setup menu can be accessed only by the Institutional Set-up Remote Control (RG4172BK or RC2573) by pressing the M key. The Institutional Set-Up Remote Control is available as an option.
- Page 5 Navigation The current menu item can be selected by means of the Up/Down keys. Submenus can be accessed from menu items indicated with a “>” symbol by pressing the Right key. • To exit any menu press “Menu” button • Select “YES”...
- Page 6 3.Under Multi RC sub-menu, select the corresponding colour to match the colour selected in Step 1 Notes: SP-SPI and SP-IC2 refers to the Philips communication protocols that are used in conjunction with the Data 1 (RJ12) or/and Data 2 (RJ45) connectivity to an external STB or Smart Card Xpress Box.
- Page 7 • No. of Channels: This sub menu allows setting the number of TV, PAY-TV, Info and Radio channels. • Channel Install: In the Channel Install sub-menu, various channel settings can be set. Please refer to the section on Channel Installation for further details. •...
- Page 8 • Mute: This item enables/disables picture and sound for the particular channel. NONE: normal picture and sound enabled VIDEO: picture is blanked for this channel (e.g. radio channel) AUDIO: sound is muted for this channel (e.g. information channel) • Auto Install TV: This sub menu allows the TV channels to be scanned and set automatically.
- Page 9 In this sub menu the behavior of the TV after switching on and the behavior of the On Screen Display can be selected. • Switch On Pic Fmt: This item sets the television’s Picture Format at switch on. Use the Right/Left key to select the desired format.
- Page 10 In this sub menu, the Picture and Sound settings of the TV can be selected. • Treble/Bass: This adjusts the level of treble and bass effects on the TV’s sound output. • Balance: This balances the sound on the left and right speakers. •...
- Page 11 In this sub menu, the Security settings of the TV can be configured. • Security Level: The “SECURITY” function allows the user to select one of two states - “HIGH” or “STANDARD”. The default is “STANDARD”. When the set is in the Security High Mode the setup menu can only be accessed by a Institutional Set-up Remote Control.
- Page 12 In this sub menu, the Control settings of the TV can be configured. • ESP: Energy Saving Programmability Mode (ESP) function controls the maximum continuous viewing time allowed and its valid values are 00 - 99 (in hours). 00 value means that the ESP function is OFF.
- Page 13 • Brightness/Colour/Contrast/Sharpness: Use the remote control Right/Left key to change the picture setting. • Sleeptimer: This item is to select an automatic period for the TV to switch to Standby when the TV does not receive any commands from the user. This is a useful feature for energy saving if hotel guests have left the room with the TV still in the On mode.
- Page 14 Alarm On (for sets with Clock display) Activates the wake-up alarm. After a valid time (0:00 to 23:59) is entered, the “Wake up Alarm” icon on the clock display will be visible. + Pay TV - To move up or down a Pay TV channel.
- Page 15 Teletext is an information system broadcast available in certain channels. In some countries, it also offers access to subtitles for viewers with hearing problems or who are not familiar with the transmission language (cable networks, satellite channels, etc.). Press: To switch Teletext On/Off In Teletext mode, press: To enter a (3-digit) page number For previous / next page...
- Page 16 The pictures you receive may be transmitted in 16:9 format (wide screen) or 4:3 format (conventional screen). 16:9 pictures sometimes have a black band at the top and bottom of the screen (letterbox format). This function allows you to optimize the picture display on screen. Using the different formats The Picture Format can be set via the Guest Menu or Set-Up Menu.
- Page 17 Fullscreen This mode displays images in full screen. The Philips Wireless Smart-Loader 22AV1120/00 is an installation tool especially designed for easy and fast installation of Philips Institutional TV’s. Preparation Make sure that the 3 R6/AA sized batteries are placed correctly in the battery compartment of the Wireless Smart-Loader.
- Page 18 A number display shows from 1~100 the percentage of memory storage progress > from the TV to the Wireless Smart-Loader (100 = fully loaded). When the data transfer is completed, ## is “100”, the following menu appears for > 3 seconds: Now the Wireless Smart-Loader is programmed and can be used to install other >...
- Page 19 Problems and Solutions: The message “WRONG VERSION” is displayed on the screen. => The program stored into the Wireless Smart-Loader has a software code incompatible with the actual TV. Reprogram the Wireless Smart-Loader from a master TV whose software code is compatible with the actual TV.
- Page 20 Should your remote be lost or broken you can still change some of the basic settings with the keys on top/side of your TV. Press: • The – Volume + key to adjust the volume; • The – Program+ key to select the TV channels or source Press the MENU key to summon the main menu (not available on all TVs).
- Page 21 This section provides information on the connectivity available for the respective TV models. Refer to the screen size that is relevant to your TV set. 32” / 26” LCD TV Connectors on the TV set: External Bathroom Speaker Connector (8 Ohm, 1 Watt). Video/Audio In Connector (Side AV, mini-jack) S-Video In Connector (Side S-Video) Data 2 (RJ45) jack –...
- Page 22 This section provides information on the connectivity available for the respective TV models. Refer to the screen size that is relevant to your TV set. 32” / 26” LCD TV - 22 -...
- Page 23 - 23 -...
- Page 24 ILC04 SD2 APAC English DFU– v7.2– 070706 - 24 -...
