7.0 FUNCTIONAL TEST

Once installed, the product's functiona-
lity needs to be checked. Start the fun-
ctional test via the app. Cross the room
in order to test the detection range. The
Motion Detector will flash red every time
it detects movement.
When crossing the room, pay
attention to the route that a
trespasser would be most likely
to take.
42

8.0 PRODUCT DETAILS

8.1 Technical data

Model
Batteries
Battery life
Radio frequency
Max. transmission power
Protocol
1) 5 years, based on typical storage temperature (-10 to 55°C), ambient temperature, 160 motion detections/day and 2
software renewals of the device/year. High temperatures over 50 °C shorten the lifetime.
Motion Detector
123A
Up to 5 years
1)
2.4 GHz
10 dBm
Based on ZigBee HA1.1 with extended
encryption technology
43
