- Page 1 IP8ESP 8 Port PoE Ethernet Switch User Manual...
-
Page 2: Key Features
5. Check if the installation is correct and device is good, make sure all the connection is reliable and power up the system. 6. Make sure every network device has power supply and work normally. IP8ESP - 8 Port PoE Ethernet Switch... -
Page 3: Technical Specification
1pc Network Working Status: Green Light on RJ45 Port Downlink Network Port Indicator 1 ~ 8 Ports: Green Light indicates Network Status, Yellow Light indicates PoE Status PoE Reset Button 8,Corresponding with 1~8 port, PoE reset after press the button Reset Button 1pc, Machine Reset Port Lightning Protection Level 3, Per: IEC61000-4-5 Level 3, Per: IEC61000-4-2 Temperature Conditions Working: -40°C ~ 75°C Storage: -40°C ~ 85°C Humidity: 0 ~ 95% (Non-Condensing) Dimensions (L x W x H) 159 x 110 x 46.5 mm Weight 575g Features and specifications are subject to change for further improvement without any notice IP8ESP - 8 Port PoE Ethernet Switch... -
Page 4: Board Diagram
• Replace the equipment that can not work with a proper functioning 8 Port PoE ethernet switch to check if the equipment is damaged. • Please contact your vendor if trouble still exists. IP8ESP - 8 Port PoE Ethernet Switch... - Page 5 White / Green Blue Blue White / Blue White / Blue Orange Green White / Brown White / Brown Brown Brown EIA/TIA 568 A EIA/TI A 568B • When you choose RJ45, make sure if one end is EIA/TIA568A, the other end should also be the same. • When you choose RJ45, make sure if one end is EIA/TIA568B, the other end should also be the same. IP8ESP - 8 Port PoE Ethernet Switch...
- Page 6 GENIE CCTV LTD. CCTV House, City Park, Watchmead, Welwyn Garden City, Hertfordshire, AL7 ILT Tel: +44 (0) 1707 330541 Fax: +44 (0) 1707 330543 www.geniecctv.com Edition. GN-November 2015...
