SERVICE MANUAL
COMPACT DISC STEREO RADIO
CASSETTE RECORDER
In the above models, the laser pickup of the CD mechanism is changed from DA-11T3C
to KSM-213CDM.
If requiring the other information, see Service Manual of the
CSD-TD34 (TYPE:K, EZ)/CSD-TD36 (TYPE:LH)/CSD-TD46 (TYPE:LH)(S/M Code No.09-012-
354-0N1).
CSD-TD34
CSD-TD36
CSD-TD46
BASIC TAPE MECHANISM : ZZM-1 R2NC2
BASIC CD MECHANISM : KSM-213CDM
S/M Code No. 09-012-354-0S1
K(H),EZ(H)
LH(H),HRJ(H)
LH(H),HA(H)
Advertisement
Related Manuals for Aiwa CSD-TD34
Summary of Contents for Aiwa CSD-TD34
- Page 1 BASIC CD MECHANISM : KSM-213CDM In the above models, the laser pickup of the CD mechanism is changed from DA-11T3C to KSM-213CDM. If requiring the other information, see Service Manual of the CSD-TD34 (TYPE:K, EZ)/CSD-TD36 (TYPE:LH)/CSD-TD46 (TYPE:LH)(S/M Code No.09-012- 354-0N1). S/M Code No. 09-012-354-0S1...
- Page 2 Precaution to replace Optical block (KSS-213C) Body or clothes electrostatic potential could ruin laser diode in the optical block. Be sure ground body and workbench, and use care the clothes do not touch the diode. 1) After the connection, remove solder shown in the right figure.
- Page 3 ALTERATION LIST-1/2 ELECTRICAL MAIN PARTS LIST-1/1 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION MAIN-CD C.B MOTOR C.B C422 87-010-183-080 C-CAP,S 2700P-50 K B GRM 9X-262-576-910 MOTOR GEAR ASSY C424 87-010-220-080 C-CAP,S 0.018-25 K B PIN3 91-564-722-110 CONNECTOR 6P C428...
- Page 4 ALTERATION LIST-2/2 MECHANICAL MAIN PARTS LIST-1/1 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 1 8B-CHB-024-010 CABI,ASSY FR (H)<TD36HRJHC> 18 8B-CHB-002-010 CHAS,CD U<TD36HRJHC> 2 8B-CDB-008-010 WINDOW,CASS<TD36HRJHC> 23 88-CH6-019-110 PANEL,CD 4 8B-CHM-008-010 WINDOW,DISP EX<TD46HAHCC> 51 85-CD7-217-110 HLDR,CHUCK A 4 8B-CHB-004-010 WINDOW,DISP EX<TD36HRJHC>...
- Page 5 SCHEMATIC DIAGRAM-1/1 (MAIN-CD 1/2) MAIN-CD C.B (1/2) LD CONT RW SW LC78622NE Q406-408 RW SW C469 150P CD MECHANISM KSM-213CDM CD +B SW OPTICAL PICK UP KSS-213C CD +B SW MOTOR 2SA19790/Y SIGNAL :...
- Page 6 WIRING-1/1 (MOTOR) MOTOR C.B (CONDUCTOR SIDE)
- Page 7 CD MECHANISM EXPLODED VIEW-1/1 (KSM-213CDM) COVER SPINDLE MOTOR (M3) (M2) MOTOR C.B...
- Page 8 CD MECHANISM PARTS LIST-1/1 (KSM-213CDM) REF. NO PART NO. KANRI DESCRIPTION 1 9X-262-620-210 MOTOR CHASSIS ASSY 2 92-626-907-010 GEAR(A) 3 87-A90-468-010 PICK UP KSS-213C 4 92-626-908-010 SHAFT SLED 5 92-627-003-020 GEAR(B)(RP) A 97-621-255-150 SCREW+P2-3...
- Page 9 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:03 (3827) 3111 H251701 Printed in Singapore...
