Transmitter Programming Guide
This transmitter makes use of icons (symbols) to identify the reaction
your security system/keyless entry/and or remote start system, where
applicable, will have when any icon (button) is pressed. These icons
are programmed at time of installation to meet the needs of the individual
and to complement the vehicle that the system is installed in. To replace
a transmitter or add transmitters, please follow the programming
instructions listed on the pages of this manual.
RECEIVER
BUTTON
CHANNEL
1
2
1
3
3
4
5
* Where So Equipped
Model APS-2K4
SYSTEM FUNCTION
Lock And Arm Alarm, also initiate and
terminates *Panic
Unlock And Disarm, also initiates and
terminates *Panic. Programmable to
unlock drivers door and or all doors.
Lock and arm/unlock and disarm. May be
programmed to unlock driver's door or all
doors. Also will initiate and terminate
*Panic.
Pulsed or switched output to control
Remote Trunk Release or optional device
connected to channel 3.
When pressed and release two times, will
provide pulsed output or activate the
Remote Start option when installed.
When so equipped, this button can be used
to operate an optional device connected
to channel 4.
When so equipped, this button can be used
to operate an optional device connected
to channel 5.
Advertisement
Related Manuals for Audiovox Prestige APS-2K4
Summary of Contents for Audiovox Prestige APS-2K4
- Page 1 Transmitter Programming Guide This transmitter makes use of icons (symbols) to identify the reaction your security system/keyless entry/and or remote start system, where applicable, will have when any icon (button) is pressed. These icons are programmed at time of installation to meet the needs of the individual and to complement the vehicle that the system is installed in.
-
Page 2: To Program Additional Transmitters
Some of the more popular options available for the unused Option Buttons of your transmitter are: AS 9554 Remote Garage Door Interface AS 9075 Remote car starter AS 9153 Remote window roll up AS 9256 Remote trunk release relay Although the most common use of the transmitter buttons are shown on the front page of this guide, any button or button combination can be programmed into any receiver channel. - Page 3 "Repeat step 4 for each transmitter you wish to program". NOTE: If your transmitter button has the Lock/Unlock icon on one button, Press and release the valet push button switch 2 times then move on to step #8. 5) Press and release the valet push button switch one time to advance to channel 2.
-
Page 4: Erasing Transmitters
Enter the transmitter program mode: 1. Turn the ignition switch to the “ON” position. 2. Within 10 seconds, press and release the valet/program switch three times. (Siren emits 1 short chirp indicating channel 1 has been entered) 3. Within 10 Seconds, Press and hold the ARM or ARM/DISARM button of the first transmitter you wish to remain stored into the control unit until a single chirp is heard from the siren. -
Page 5: Battery Replacement
reprogrammed. Any other transmitter stored in the unit’s memory still remain operational. If the button is released and not pressed again within the 5 second period, no change in programming has been made to the receiver channel. The programmer can move onto a different channel or erase the transmitter codes as described in 1 above. - Page 6 Simply dial 1 - 800 - 645 - 4994, and follow the instructions from the operator interface. 9) Mail this form along with your payment to: Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, N.Y., 11788 Attn: TRANSMITTER DEPARTMENT © 2000Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, NY, 11788 $65.00...
