SERVICE
PLASMA DISPLAY TV
PLASMA DISPLAY TV
Chassis :
D68A(P)Europe42"_DNIe3
Model
:
PS42P4A1X/XEC
Manual
1.
Specifications
2.
Alignment and Adjustments
3.
Exploded View and Parts List
4.
Service Item
5.
Schematic Diagrams
C O N T E N T S

Advertisement

Table of Contents
loading

Related Manuals for Samsung PS42P4A1X

Summary of Contents for Samsung PS42P4A1X

  • Page 1 PLASMA DISPLAY TV Chassis : D68A(P)Europe42”_DNIe3 Model PS42P4A1X/XEC SERVICE Manual PLASMA DISPLAY TV C O N T E N T S Specifications Alignment and Adjustments Exploded View and Parts List Service Item Schematic Diagrams...
  • Page 2 ELECTRONICS © Samsung Electronics Co., Ltd. Nov. 2004 This Service Manual is a property of Samsung Electronics Co.,Ltd. Printed in Korea Any unauthorized use of Manual can be punished under applicable AA82-02078A International and/or domestic law.

  • Page 3: Specifications

    Specifications 1. Specifications Samsung Electronics...

  • Page 4: Alignment And Adjustments

    Release : Oct 06 2004 11 : 41 : 14 Version : T-NPL42PEU1-1215 2-1-2(B) Button Operations in SERVICE MODE Menu Displays all menus UP/DOWN Cursor move to select items LEFT/RIGHT Enable to increase and decrease the data of the selected items (ENTER) Confirm your choice(Store OR Enter) Samsung Electronics...
  • Page 5 Hence, it should be performed with the same method of (1) DVI adjustment. Also, Video adjustment should be performed with Video port and Graphic port separately. * Thus, Micom saves the W/B data separately for each memory mode of the block (See the block diagram given below) during W/B adjustment. Samsung Electronics...

  • Page 6: Factory Data

    Input Modes ☞ Motion Enhancing Adjustment 06. Motion ▶ ☞ DNIe Registers 07. DNIe ▶ ☞ DNIe Registers 08. DNIe Additional ▶ ☞ Logic Registers of the Panel 09. Logic ▶ ☞ Picture Size Registers 10. Picture Size ▶ Samsung Electronics...

  • Page 7: Mode-1 Mode

    ASI510 08.Sub Brightness 09.R Gain 10.G Gain 11.B Gain AD9883 12.R/Cr Offset 13.G/Y Offset 14.B/Cb Offset 15.Auto color on/off h Input modes require respective storing the changes after adjustment. 01~06 : DNIe 07~08 : ASI510 09~15 : AD9883 Samsung Electronics...

  • Page 8: Mode-3 Mode

    09.B Gamma 10.Gain-Sel 11.Cr Gain CXA2151 12.Cb Gain 13.Y Gain 14.FLI - Y/G Bir FLI2310 15.FLI - Cr/R Bir 16.FLI - Cb/B Bir 01 ~05 : VSP9437 07~09 : ASI510 06 , 14~16 : FLI2310 10~13 : CXA2151 Samsung Electronics...
  • Page 9 03.Cont/Bri Enhancement Mode-1 Mode-2 Mode-3 Mode-4 01.Contrast 02.Brightness VSP9437 03.RGB/YUV Contrast 04.RGB/YUV Brightness 05.FLI-Contrast FLI2310 06.FLI-Brightness 07.R Contrast 08.G Contrast 09.B Contrast ASI510 10.R Brightness 11.G Brightness 12.B Brightness 01~04 : VSP9437 07~12 : ASI510 05~06 : FLI2310 Samsung Electronics...
  • Page 10 Initial Values of Input Modes ITEM Relevant IC Video Component 04.Detail Enhancement Mode-1 Mode-2 Mode-3 Mode-4 01.VAPGAIN 02.VAPINV uPD64083 03.YPFT 04.YPFG 05.APK-1st-BPM 06.APK-2nd-BPM 07.Denoise-BPM VSP9437 08.APK-1st-HPM 09.APK-2nd-HPM 10.Denoise-HPM 11.HenhGain 12.HLEGain FLi2310 13.HChrEnGain 01~04 : uPD64083 05~10 : VSP9437 11~13 : FLI2310 Samsung Electronics...

  • Page 11: 01 : Vsp9437-M

    Initial Values of Input Modes ITEM Relevant IC Video Component 06.Motion Mode-1 Mode-2 Mode-3 Mode-4 VSP9437-M 01.HPLL Speed-1 VSP9437-S 02.HPLL Speed-2 FLi2310 03.V-motion Tresh UVCORM 04. Chrominance coring VSP9437- 01 : VSP9437-M 02 : VSP9437-S 03 : FLI2310 04 : VSP9437-UVCORM Samsung Electronics...
  • Page 12 14. R ND ON 15. R CORING ON 16. PATT SEL 17. R CORING TH1 18. R CORING TH2 19. R CORING TH3 20. BLACK GAIN 21. WHITE GAIN 22. WTE GAIN 23. CTE GAIN 03~23 : DNIe Samsung Electronics...
  • Page 13 08. DNIe Additional Mode-1 Mode-2 Mode-3 Mode-4 01. R D ALPHAU 02. R BLACK GAIN MAX 03. R BLACK TILT DNIe 04. R WHITE GAIN MAX 05. DNIe Gamma 06. R GAIN3 X 01 ~ 06 : DNIe 2-10 Samsung Electronics...
  • Page 14 02. ERRS 03. ERRC(READ) 04. DSPBIT 05. QMODE 06. CCFMD 07. DCFMD Logic 08. DSETEN 09. CCFON 10. CCFORM 11. GAMSEL 12. R-RATIO 13. G-RATIO 14. B-RATIO 15. GAMOO 16. PWMP 17. PWMAX 18. DSET 01~18 : Logic Samsung Electronics 2-11...
  • Page 15 03. Movie 04. Custom 02.Initial Setting => 02.P-Mode Value 02. P-Mode Value Current Input Mode Available options for the PC/DVI Mode are High,Middle, 01. Dynamic ▶ Low and Custom. 02. Standard ▶ 03. Movie ▶ 04. Custom ▶ 2-12 Samsung Electronics...
  • Page 16 ♣ Available Settings for the PC Mode are 01. Cool2 Custom,Color Tone 1, Color Tone 2, Color Tone 3 02. Cool1 03. Normal ♣ Available options for the DVI Mode are 04. Warm1 ColorTone1, ColorTone2, ColorTone3 05. Warm2 Samsung Electronics 2-13...
  • Page 17 08.PIP FILTER ML 09.PIP FILTER MR 10.PIP FILTER UC 11. TTX CONT SDA6001 12. TTX BRIGHTNESS 13.LOG PATTERN Logic 14.LOG HIGH LEVEL ASI510 15.LOG LOW LEVEL 16.ASI COLORBAR 01~10 : ASI510 11~12 : SDA6001 13~16 : Logic, ASI510 2-14 Samsung Electronics...

  • Page 18: Language Group

    06. ATM : On => Off -. ATM available region : On -. ATM non-available region : Off 07. Plug & Play -. On : TV Model and plug&play funtion deletion model. -. Off : Monitor Model Samsung Electronics 2-15...

  • Page 19: Samsung Electronics

    05. Number Range ◀ Not Use ▶ 06. Line Range ◀ Not Use ▶ 07. Temp Protection ◀ ▶ 08. DNIe DEMO ◀ ▶ 09. PILOT HIGH ◀ ▶ 10. PILOT LOW ◀ ▶ 11. CHECKSUM 0000 ◀ ▶ 2-16 Samsung Electronics...
  • Page 20 ASSY COVER P-BACK SUB;42P4A,SECC,T0.8 S.N.A T0001 BN96-00998B ASSY COVER P-BACK;42P4A,AL,T1.2 T0054 SCREEN-EMI,FILTER;FILTER,42P3,984*584,T3 FT532 2901-001278 FILTER-EMI AC LINE;250V,6A,-,1000PF,50X2 T0132 BN94-00625B ASSY PCB MISC-DIGITAL;PS42P4A1X/XEC,D68A T0091 BN94-00519A ASSY PCB MISC-SIDE A/V;PS42P4AX/XEC,D68A M0145 BN96-01033A ASSY BOARD P-FUNCTION;SPD-42P4HD,FUNCTIO T0714 BN96-01034A ASSY BOARD P-IR;SPD-42P4HD,IR T0044 BN96-00774A ASSY PDP MODULE P;FPF42C128128UC-S3,994...
  • Page 21 Exploded View & Parts List 3-2 MODULE BLOCK Samsung Electronics...

  • Page 22: Service Item

    TUNER;TMQZ6-405A,PAL-CW,PAL Hyper,38.9MH CIS3 BN40-00051A TUNER;TMQZ6-404C,PDP-NELSON,PAL B/G,PAL T0074 BN59-00397B REMOCON;MOZART,TM77,SAMSUNG,D65A,47,EX,P T0091 BN94-00519A ASSY PCB MISC-SIDE A/V;PS42P4AX/XEC,D68A T0132 BN94-00625B ASSY PCB MISC-DIGITAL;PS42P4A1X/XEC,D68A T0152 BN94-00626A ASSY PCB MISC-TUNER;PS42P4A1,D68A,DNIE3 T0044 BN96-00774A ASSY PDP MODULE P;FPF42C128128UC-S3,994 T0003 BN96-00997C ASSY COVER P-FRONT;42P4A,ABS+ACRYL,HB,GU T0001 BN96-00998B ASSY COVER P-BACK;42P4A,AL,T1.2...
  • Page 23 Schematic Diagrams 5. Schematic Diagrams 5-1 SCART This Document can not be used without Samsung’s authorization. Samsung Electronics...
  • Page 24 Schematic Diagrams 5-2 VIDEO SW This Document can not be used without Samsung’s authorization. Samsung Electronics...
  • Page 25 Schematic Diagrams 5-3 3D-COMB This Document can not be used without Samsung’s authorization. Samsung Electronics...
  • Page 26 Schematic Diagrams 5-4 VSP9437 This Document can not be used without Samsung’s authorization. Samsung Electronics...
  • Page 27 Schematic Diagrams 5-5 PCIN_9883_2151 This Document can not be used without Samsung’s authorization. Samsung Electronics...
  • Page 28 Schematic Diagrams 5-6 DVI_SiI169 This Document can not be used without Samsung’s authorization. Samsung Electronics...
  • Page 29 Schematic Diagrams 5-7 FLI2300 This Document can not be used without Samsung’s authorization. Samsung Electronics...
  • Page 30 Schematic Diagrams 5-8 JACK INPUT This Document can not be used without Samsung’s authorization. " 2 Samsung Electronics...
  • Page 31 Schematic Diagrams 5-9 POWER This Document can not be used without Samsung’s authorization. " 2 " 2 " 7 " 2 " 7 Samsung Electronics...
  • Page 32 Schematic Diagrams 5-10 LVDS This Document can not be used without Samsung’s authorization. 5-10 Samsung Electronics...
  • Page 33 Schematic Diagrams 5-11 FHP_PICO This Document can not be used without Samsung’s authorization. Samsung Electronics 5-11...
  • Page 34 Schematic Diagrams 5-12 SOUND_DELAY This Document can not be used without Samsung’s authorization. 5-12 Samsung Electronics...
  • Page 35 Schematic Diagrams 5-13 ASI510 This Document can not be used without Samsung’s authorization. Samsung Electronics 5-13...
  • Page 36 Schematic Diagrams 5-14 SDA6001 This Document can not be used without Samsung’s authorization. 5-14 Samsung Electronics...
  • Page 37 Schematic Diagrams 5-15 DNIe2 This Document can not be used without Samsung’s authorization. Samsung Electronics 5-15...
  • Page 38 Schematic Diagrams 5-16 AUDIO This Document can not be used without Samsung’s authorization. 5-16 Samsung Electronics...
