- Page 1 Operating Manual Mode d’emploi Manual de Uso PRO 2000 Série Series Programmable Thermostats Thermostats programmables Termostatos programables...
- Page 2 To prevent possible compressor damage, do not use Cooling mode when the outdoor temperature is below 50 °F (10 °C). Need Help? For assistance with this product please visit http://yourhome.honeywell.com or call Honeywell Customer Care toll-free at 1-800-468-1502. Read and save these instructions.
-
Page 3: Table Of Contents
Operating Manual Table of contents Overview Appendices Thermostat features ......1 Battery replacement ......14 Quick start ..........2 In case of difficulty ......15 Quick reference to controls ....3 Customer assistance ......16 Quick reference to display....4 2-year limited warranty ....... -
Page 4: Overview Thermostat Features
PRO 2000 Series About your new thermostat Your new Honeywell thermostat has been designed to give you many years of reliable service and easy-to-use, push-button climate control. Features • Backlit display is easy to read • Displays ambient (measured) temperature at all times •... -
Page 5: Quick Start
Operating Manual This thermostat is ready to go Simply perform the three steps below and the thermostat is in operation: Set the clock....................See page 5 Select whether to heat or cool............... See page 6 Select whether to run the fan continuously or only when needed ....See page 7 If you do not wish to use the pre-programmed schedule settings, you can: ... -
Page 6: Quick Reference To Controls
PRO 2000 Series Quick reference to controls Screen Lit for 12 seconds when you press any button. Press to set clock, Fan Switch (see page 7) day or schedule • On: Fan runs all the time. (see pages 5 & 10). •... -
Page 7: Quick Reference To Display
Operating Manual Quick reference to display Clock Temporary schedule override (see page 11) Temperature The ambient (measured) temperature Setpoint indicator is normally displayed. To view the Appears when the setpoint setpoint temperature, press either of temperature is displayed. the temperature adjustment buttons once. -
Page 8: Programming & Operation Setting The Clock
PRO 2000 Series Set the clock Press the Set button. Set Time will appear on the screen and the time Set Time display will flash. Press the button to set the time. Press the Set button again. Set Day will flash on the screen. ... -
Page 9: System Switch (Heat/Cool)
Operating Manual System switch Use the System switch to place the system in one of the following modes: • Cool: System is in Cooling mode. • Off: System is off. • Heat: System is in Heating mode. • Em Heat: System is in Emergency Heat mode. Only auxiliary heating can be activated. -
Page 10: Fan Switch (Auto/On)
PRO 2000 Series Fan switch Use the Fan switch to select the fan operation. • Auto: The fan runs only when heating or cooling is activated (commonly used setting). • On: The fan runs all the time. -
Page 11: Using The Schedule
Operating Manual Using the schedule Press the Run button to follow the programmed schedule. For maximum energy savings while maintaining comfort, you can program the schedule such that the temperature is at an economical level when you sleep or leave for work and at a comfortable level when you are awake and at home. - Page 12 PRO 2000 Series Preprogrammed schedule settings The thermostat is preprogrammed with the following settings. Weekdays Weekends Period Start time Heat Cool Start time Heat Cool Wake 6:00 am 70 °F (21 °C) 75 °F (24 °C) 6:00 am 70 °F (21 °C) 75 °F (24 °C) Leave 8:00 am...
- Page 13 Operating Manual Modifying the schedule The Wake Press the Set button 3 times until Set Schedule appears. The start time of period for the the first period (Wake) of the week days (Mon-Fri) will flash. weekdays is set to 6 a.m. Press the button to set the time.
-
Page 14: Temporary Schedule Override
PRO 2000 Series Temporary override of schedule To temporarily ignore the schedule, press until the desired temperature is displayed. The word Temporary will appear on the screen and the period display will flash to indicate that the current period has been overridden. The new temperature will be used until the next period begins. -
Page 15: Permanent Schedule Override
Operating Manual Permanent override of schedule To permanently ignore the schedule, press until the desired temperature is displayed. Then, press the Hold button to maintain the new temperature indefinitely. The word Hold will appear on the screen. Press the Run button if you wish to cancel the override and resume the schedule. -
Page 16: Adaptive Intelligent Recovery
PRO 2000 Series Adaptive Intelligent Recovery (AIR) Adaptive Intelligent Recovery™ allows the thermostat to “learn” how long your furnace or air conditioner takes to reach the set temperature. Simply program the desired times and desired temperatures into the schedule. The thermostat will determine when to activate heating or cooling so that the desired temperature is attained at the desired time.
