Thank you for purchasing the Sangoma A500 BRI card! Please follow these instructions to begin using your new card. 1. INSTALL YOUR PBX SOFTWARE Install your choice of supported software. (e.g., Asterisk , FreeSWITCH, Yate, CallWeaver, Netborder™, ResponsePoint™, etc.) ®...
Page 3
When running in NT mode, ensure both termination resistors S W 2 that correspond to the module are set to ON. (See SW2 in diagram.) You must switch all termination resistors that correspond to each module. Full product specifications available at SANGOMA.COM...
F) Insert the card into an open PCI or PCIe slot in server. PCI/PCIe Slots Fasten PCI bracket to chassis. Server 3. INSTALL THE DRIVERS (WANPIPE ® Visit wiki.sangoma.com for the latest drivers and instructions. You're done! Enjoy your new card. Technical specifications available at WIKI.SANGOMA.COM...
Page 5
(PATENT PENDING) Your A500 Card is fax synchronization ready. Send the clock signal from the A500 BRI card to a Sangoma analog card via a simple two-wire jumper cable (each sold separately). Plug the cable into the board jumper pins with the RED edge at the top.
LIFETIME WARRANTY New Sangoma A-Series hardware comes with a lifetime warranty for replacement and repair from the date of purchase. This includes a no-questions-asked 30-day money back guarantee, Sangoma's renowned free technical support, and free replacement in the unlikely event of a defect.
