- Page 1 Clearfly SIP Trunks Configuration Guide PBX Platform: KX-TDE/NCP 6/19/2012 Version1...
- Page 2 SIP Gateway card. For those details, see the KX- NCP500/1000 and KX-TDE100/200/600 Programming Manual for Virtual SIP CO Line Card and the KX-TDE100/200/600 and KX-NCP500/1000 Manuals available from Panasonic Communication Solutio DSP card and Activation keys ...
-
Page 3: Architecture Overview
Architecture Overview The following diagram illustrates simple VOIP networks connecting the TDE/NCP PBX: The Case of Clearfly Setup: Clearfly will provide its services over the Public Internet sc.cfly.co Default GW 192.168.0.1 MPR IP Address 192.168.0.101 VOIP IP Address 192.168.0.102 Port Forwarding rules on the end router: Forward Port 35060 to MPR IP address Forward Port Range12000~12127 to VOIP-DSP IP address 6/19/2012... - Page 4 Basic V-SIPGW16 Settings for Clearfly Trunks 1-Install the PBX Maintenance console into your PC The maintenance console should be available to certified dealers; Dealers can get the latest version of the UPCMC from www.btsdealer.com (UPCMC version 7.2.1.0 or higher) 2- Connect to the PBX Start the UPCMC Click Connect and choose the method of connection using either LAN , RS- 232, Modem, or USB to Connect to your PBX for interactive configuration...
- Page 5 Go to 1-Configuration, 1-Slot, move your mouse over the MPR card and select the card property Make sure that the default gateway should be the end router LAN IP address Make sure that you have a valid DSP-VOIP LAN address 6/19/2012 Version1...
- Page 6 3- Installing V-SIP W16 card Go to 1-Configuration, 1-Slot, move your mouse towards the IPCMPR virtual shelf and click on select shelf Highlight the V-SIPGW16 card from the cards list in the left side Drag the VSIPGW16 card into the trunk portion of the virtual shelf by using the PC mouse lift button Release the Mouse lift button and click Yes on the dialogue box 6/19/2012...
- Page 7 Take the V-SIPGW16 card OUS in order to be able to enter the following settings 4-Configuring the VSIP-GW16 card a- Shelf Property settings: Move the computer mouse over the VSIPGW16 card and choose Shelf property The following settings are required for Clearfly SIP trunk services on the shelf property: 6/19/2012 Version1...
- Page 8 Click Apply and then OK to exit the shelf property settings screen. b- Card Property settings: Move the computer mouse over the VSIPGW16 card and choose Card property Click on Common settings DNS Server IP address method is Manual Provide your ISP DNS serevers IP addresses. (Contact your ISP to obtain DNS IP addresses if needed) 6/19/2012 Version1...
- Page 9 These addresses are just sample. Please use your ISP provided information Click Apply and then OK Click Cancel on the card property- Virtual SIP gateway screen to exit this screen c- Port Property settings: Move the computer mouse over the VSIPGW16 card and choose port property Basic Channel setup: Please locate the Clearfly SIP Trunks account details from your Clearfly account Welcome letter/email..
-
Page 10: Account Tab
To: New Customer cc: support <support@clearfly.net> Subject: Clearfly SIP Trunk Information: Hello, Your Clearfly SIP trunk is now active and has been provisioned as follows: IP: 1.2.3.4 NAT Fixed-Global IP address sc.cfly.co SIP Server Location Clearfly SIP Server Transport: UDP/5060 Codec: G.711u &... -
Page 11: Voice/Fax Tab
Register Tab: Changes from Default settings: 1- Register abilty== Enable Unregister ability when port INS= Disable NAT Tab: Same as default Calling Party tab: Changes from Default settings: 1- P-asserted Identity Header = Enable Called party Tab: Same as default Voice/Fax Tab: Changes from Default settings: 1- IP Codec priority (1st = G.729A, 2nd= G.711u, 3... - Page 12 Essential PBX Configuration: Please locate your DID information in the Clearfly Welcome letter To Assign the DID numbers destinations, Go to 10-3.CO & Incoming Call DID table Clearfly Important note: Make sure that you provide the 10 digits DID number in the DID number field to be able to make use of the additional DID’s assigned by the Provider.
-
Page 13: Useful Hints
2- Update your PCMC (Maintenance Tool) with the latest version available on the BTS website and through Panasonic Tech support department 3- Back up your configuration file with the Good known settings...
