  • Page 1 9150 Portable Furnace User's Guide PN 3729502 March 2014 © 2014 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies. GlobalTestSupply www. .com Find Quality Products Online at:...
  • Page 2 Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is available only if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable international price.

  • Page 3: Table Of Contents

    Table of Contents Chapter Title Page Before You Start .................. 1-1 Symbols Used................1-1 Safety Information ..............1-2 1.2.1 Warnings ................1-2 1.2.2 Cautions ................1-3 Authorized Service Centers ............1-4 Introduction ..................2-1 Specifications and Environmental Conditions ......... 3-1 Specifications................
  • Page 4 9150 User's Guide Controller Operation ................8-1 Well Temperature ..............8-1 Temperature Set-point ............... 8-1 8.2.1 Programmable Set-points ............8-1 8.2.2 Set-point Value ..............8-3 8.2.3 Temperature Scale Units ............8-4 Scan ..................8-4 8.3.1 Scan Control ................8-4 8.3.2 Scan Rate ................
  • Page 5 Contents (continued) Troubleshooting .................. 13-1 13.1 Troubleshooting Problems, Possible Causes, and Solutions ..13-1 13.2 Comments ................. 13-2 13.2.1 EMC Directive ................ 13-2 13.2.2 Low Voltage Directive (Safety) ..........13-2 Maintenance ..................12-1 Calibration Procedure ................. 11-1 11.1 Calibration Points............... 11-1 11.2 Calibration Procedure ..............
  • Page 6 9150 User's Guide GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
  • Page 7 List of Tables Table Title Page International Electrical Symbols ..............1-1 Communications Command Summary ............9-4 Communications Commands Summary continued ........9-5 Communications Commands Summary continued ........9-6 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
  • Page 8 9150 User's Guide GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
  • Page 9 List of Figures Figure Title Page Back Panel ....................6-1 Front Panel ....................6-2 Removable Inserts ..................6-3 Controller Operation Flowchart ..............8-2 Serial Cable Wiring Diagram ..............9-1 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
  • Page 10 9150 User's Guide viii GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...

  • Page 11: Before You Start

    Chapter 1 Before You Start 1.1 Symbols Used Table 1 lists the International Electrical Symbols. Some or all of these symbols may be used on the instrument or in this manual. Table 1. International Electrical Symbols Symbol Description  AC (Alternating Current) ...

  • Page 12: Safety Information

    9150 User's Guide  C-TICK Australian EMC mark The European Waste Electrical and Electronic Equipment  (WEEE) Directive (2002/96/ EC) mark. 1.2 Safety Information Use this instrument only as specified in this manual. Otherwise, the protection provided by the instrument may be impaired.

  • Page 13: Cautions

    Before You Start Safety Information • Always replace the fuse with one of the same rating, voltage, and type. • Overhead clearance is required. DO NOT place this instrument under a cabinet or other structure. • DO NOT use this unit for any application other than calibration work.

  • Page 14: Authorized Service Centers

    9150 User's Guide • Never introduce foreign material into the probe hole of the insert. Fluids, etc. can leak into the calibrator causing damage. • DO NOT change the values of the calibration constants from the factory set values. The correct setting of these parameters is important to the safety and proper operation of the calibrator.
  • Page 15 Before You Start 1.3 Authorized Service Centers • Model Number • Serial Number • Voltage • Complete description of the problem GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
  • Page 16 9150 User's Guide GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...

  • Page 17: Introduction

    The Hart Scientific 9150 thermocouple furnace can be used for calibrating ther- mocouple and RTD temperature probes. Calibrations may be done over a range of 150°C to 1200°C (302°F to 2192°F). Temperature display of the 9150 is 0.1 degrees below 1000°and 1 degrees above 1000°.
  • Page 18 9150 User's Guide GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...

  • Page 19: Specifications And Environmental Conditions

    Chapter 3 Specifications and Environmental Conditions 3.1 Specifications Temperature Range 150–1200°C (302–2192°F) Display Resolution 0.1° to 999.9°, 1° above 1000° Stability ±0.5°C Display Accuracy ±5.0°C Well Diameter 1.25" (32 mm) Well Depth 4" (102 mm) Heating Time 35 minutes to 1200°C Cooling Time 140 minutes with block Well to Well...

  • Page 20: Environmental Conditions

    9150 User's Guide 3.2 Environmental Conditions Although the instrument has been designed for optimum durability and trouble- free operation, it must be handled with care. The instrument should not be operated in an excessively dusty or dirty environment. Maintenance and cleaning recommendations can be found in the Maintenance Section of this manual.

  • Page 21: Safety Guidelines

    Chapter 4 Safety Guidelines • Operate the instrument in room temperatures between 5-50°C (41- 122°F). Allow sufficient air circulation by leaving at least 6 inches of space between the instrument and nearby objects. Overhead clearance needs to allow for safe and easy insertion and removal of probes for calibration. •...
  • Page 22 9150 User's Guide • If a mains supply power fluctuation occurs, immediately turn off the instrument. Power bumps from brownouts and blackouts could damage the instrument. Wait until the power has stabilized before re-energizing the instrument. • Air circulated through the unit keeps the chassis cool. DO NOT SHUT OFF THE FURNACE WHILE AT HIGH TEMPERATURES.

  • Page 23: Quick Start

    Unpack the furnace carefully and inspect it for any damage that may have occurred during shipment. If there is shipping damage, notify the carrier immediately. Verify that the following components are present: • 9150 Furnace • 3150, Insert • Insert Insulator •...

  • Page 24: Power

    9150 User's Guide The display begins to show the well temperature and the well heater starts operating to bring the temperature of the well to the set-point temperature. 5.3 Power Plug the furnace power cord into a mains outlet of the proper voltage, frequency, and current capability.

  • Page 25: Parts And Controls

    Chapter 6 Parts and Controls The user should become familiar with the furnace back panel, front panel, and constant temperature block assembly. 6.1 Back Panel The back panel (Figure 1) features the Power Entry Module (PEM) that contains the power cord socket, the power switch, and the heater voltage switch, the serial port, and the fan.

  • Page 26: Front Panel

    9150 User's Guide Heater Voltage Switch - To be used only when changing the input voltage. (See Section 7.2 for instructions.) Serial Port - A DB-9 male connector is present for interfacing the calibrator to a computer or terminal with serial RS-232 communications.

  • Page 27: Constant Temperature Block Assembly

    Parts and Controls Constant Temperature Block Assembly 6.3 Constant Temperature Block Assembly The constant temperature block assembly is shown in Figure 3 and consists of removable inserts. fig-3.eps Figure 3. Removable Inserts 6.3.1 Constant Temperature Block The “Block” is made of aluminum-oxide and provides a relatively constant and accurate temperature environment for the sensor that is to be calibrated.
  • Page 28 9150 User's Guide GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...

  • Page 29: General Operation

    3. Press “SET” to store changes and then “EXIT” to display the temperature. 7.2 Switching to 230V Operation The 9150 is switchable from 115 VAC to 230 VAC 50/60 Hz. Switching the voltage can change the calibration, so the unit should be calibrated after changing the input voltage.
  • Page 30 9150 User's Guide Note If the heater switches and the fuse holder do not all read “230V when complete, the unit will either not heat or only heat at a fraction of its capacity. If not done properly, the unit could become damaged and void the calibration and warranty.

  • Page 31: Controller Operation

    Chapter 8 Controller Operation This section discusses in detail how to operate the furnace temperature controller using the front control panel. By using the front panel key-switches and LED display the user may monitor the well temperature, adjust the set-point temperature in degrees C or F, monitor the heater output power, adjust the controller proportional band, and program the probe calibration parameters, operating parameters, serial interface configuration, and controller calibration...
  • Page 32 9150 User's Guide To set the temperature one must first select the set-point memory. This function is accessed from the temperature display function by pressing “SET”. The number of the set-point memory currently being used is shown at the left on the display followed by the current set-point value.

  • Page 33: Set-Point Value

    Controller Operation Temperature Set-point    Well temperature in degrees Celsius Access set-point memory    Set-point memory 1, 200.0°C currently used To change the set-point memory press “UP” or “DOWN”.    New set-point memory 5, 900.0°C Press “SET”...

  • Page 34: Temperature Scale Units

    9150 User's Guide 8.2.3 Temperature Scale Units Temperature Scale Units of the controller are set by the user to degrees Celsius (°C) or Fahrenheit (°F). The units are used in displaying the well temperature, set-point, and proportional band. Press “SET” after adjusting the set-point value to change display units.

  • Page 35: Ramp And Soak Program

    Accept scan rate 8.4 Ramp and Soak Program The ramp and soak program feature for the 9150 allows the user to program a number of set-points, cycle the furnace automatically between the temperatures at a scan rate set by the user, and hold the furnace at each temperature for a period of time set by the user.

  • Page 36: Program Set-Points

    9150 User's Guide Press “SET” to continue. Pressing “EXIT” causes any changes made to the parameter to be discarded. Accept the new number of program points. 8.4.3 Program Set-Points The controller allows the user to adjust up to eight program points. These are accessed by pressing “SET”...
  • Page 37 Controller Operation Ramp and Soak Program Press “SET” to edit the program soak time. Edit program point soak time  Current program point soak time Use “UP”, “DOWN”, and “SET” to adjust the program soak time. This value can be any integer from 0 to 14400. This time is the minutes the program set-point maintains after the temperature of the furnace has settled and before proceeding to the next set-point.

  • Page 38: Program Function Mode

    9150 User's Guide 8.4.4 Program Function Mode The next parameter is the program function or cycle mode. There are four possible modes which determine whether the program scans up (from set-point 1 to n) only or both up and down (from set-point n to 1), and also whether the program stops after one cycle or repeats the cycle indefinitely.

  • Page 39: Secondary Menu

    Controller Operation Secondary Menu 8.5 Secondary Menu Functions which are used less often are accessed within the secondary menu. The secondary menu is accessed by pressing “SET” and “EXIT” simultaneously and then releasing. The first function in the secondary menu is the heater power display.

  • Page 40: Proportional Band

    9150 User's Guide 8.8 Proportional Band In a proportional controller such a this the heater output power is proportional to the well temperature over a limited range of temperatures around the set-point. This range of temperature is called proportional band. At the bottom of the proportional band the heater output is 100%.

  • Page 41: Controller Configuration

    Controller Operation Controller Configuration To store the new setting press “SET”. Press “EXIT” to continue without storing the new value. Accept the new proportional band setting 8.9 Controller Configuration The controller has a number of configuration and operating options and calibration parameters which are programmable via the front panel.

  • Page 42: Soft Cutout

    9150 User's Guide   New HL setting Press “SET” to accept the new temperature limit. 8.10.2 Soft Cutout The Soft Cutout parameter is used by the controller to shut the unit down during over-temperature conditions.  Soft Cutout parameter Press “SET”...

  • Page 43: Serial Interface Parameters

    Controller Operation 8.11Serial Interface Parameters To change to manual reset mode press “UP” or “DOWN” and then “SET”.  Cutout set for manual reset 8.11 Serial Interface Parameters The serial RS-232 interface parameters menu is indicated by,  Serial RS-232 interface parameters menu The serial interface parameters menu contains parameters which determine the operation of the serial interface.

  • Page 44: Duplex Mode

    9150 User's Guide Press “SET” to choose to set the sample period. The current sample period value is displayed. = Current sample period (seconds) Adjust the value with “UP” or “DOWN” and then use “SET” to set the sample rate to the displayed value.

  • Page 45: Calibration Parameters

    New linefeed setting 8.12 Calibration Parameters The operator of the 9150 has access to the furnace calibration constants. These values are set at the factory and must not be altered. The correct values are important to the accuracy and proper and safe operation of the furnace. Access to these parameters is available to the user only so that in the event the controller memory fails, the user may restore these values to the factory settings.
  • Page 46 9150 User's Guide 8-16 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...

  • Page 47: Digital Communication Interface

    Chapter 9 Digital Communication Interface The furnace is capable of communicating with and being controlled by other equipment through the digital serial interface. With a digital interface the instrument may be connected to a computer or other equipment. This allows the user to set the set-point temperature, monitor the temperature, and access any of the other controller functions, all using remote communications equipment.

  • Page 48: Wiring

    BAUD rate. The current BAUD rate value is displayed. The BAUD rate of the 9150 serial communications may be programmed to 300, 600, 1200, 2400, 4800, or 9600 baud. The BAUD rate is preprogrammed to 2400 BAUD. Use “UP” or “DOWN”...

  • Page 49: Serial Operation

    Digital Communication Interface Interface Commands 9.1.3 Serial Operation Once the cable has been attached and the interface set up properly, the controller immediately begins transmitting temperature readings at the programmed rate. The serial communications uses 8 data bits, one stop bit, and no parity.
  • Page 50 9150 User's Guide Table 2. Communications Command Summary tab-2.eps GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
  • Page 51 Digital Communication Interface Interface Commands Table 3. Communications Commands Summary continued tab-3.eps GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
  • Page 52 9150 User's Guide Table 4. Communications Commands Summary continued tab-4.eps GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...

  • Page 53: Test Probe Calibration

    Chapter 10 Test Probe Calibration For optimum accuracy and stability, allow the calibrator to warm up for 10 minutes after power-up and then allow adequate stabilization time after reaching the set-point temperature. After completing operation of the calibrator, al- low the well to cool by setting the temperature to 150°C or less for one-half hour before switching the power off.

  • Page 54: Stabilization And Accuracy

    9150 User's Guide 10.2.1 Stabilization and Accuracy The stabilization time of the calibrator depends on the conditions and temperatures involved. Typically the test well is stable to 0.5°C within 20 minutes of reaching the set-point temperature as indicated by the display. Ultimate stability is achieved 10 to 20 minutes after reaching the set temperature.

  • Page 55: Calibration Procedure

    Chapter 11 Calibration Procedure At times the user may want to calibrate the unit to improve the temperature set- point accuracy. Calibration is done by adjusting the controller probe calibration constants CE1, CE2, and CE3 so that the temperature of the unit as measured with a standard thermocouple agrees more closely with the set-point.
  • Page 56 9150 User's Guide 4. Retrieve the original calibration errors from the unit or the Report of Calibration. 5. Record the previous values for CE1, CE2, and CE3 and calculate new values for CE1, CE2, and CE3 using the following formula.
  • Page 57 Chapter 12 Maintenance • The calibration instrument has been designed with the utmost care. Ease of operation and simplicity of maintenance have been a central theme in the product development. Therefore, with proper care the instrument should require very little maintenance. Avoid operating the instrument in an oily, wet, dirty, or dusty environment.
  • Page 58 9150 User's Guide 12-2 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...

  • Page 59: Troubleshooting

    CT2, CT3, CE1, CE2, and CE3 on the Report of Calibration that was shipped with the instrument (or from subsequent calibrations of the instrument). Reprogram the parameters into the Model 9150 memory (see Section 8.12, Calibration Parameters). Allow the instrument to stabilize and verify the accuracy of the temperature reading.

  • Page 60: Comments

    9150 User's Guide The instrument heats or Incorrect scan and scan rate settings. The scan and scan rate cools too quickly or too settings may be set to unwanted values. Check the Scan and slowly Scan Rate settings. The scan may be off (if the unit seems to be responding too quickly).
