Summary of Contents for Audiovox FPE3208
-
Page 2: Safety Precautions
SAFETY PRECAUTIONS WARNING : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. -
Page 4: Table Of Contents
SAFETY PRECAUTIONS ... 1 IMPORTANT SAFETY INSTRUCTIONS ... 2 CONTENTS ... 3 ACCESSORIES ... 4 GETTING STARTED ... 4 CONTROL REFERENCE GUIDE ... 5 - 7 CONNECTIONS ... 8 - 12 Connecting a TV Antenna / Cable / Satellite ... 8 Connecting an A / V Device ... -
Page 5: Accessories
Please check and identify the supplied accessories. Remote Control (with batteries) ... x 1 GETTING STARTED USING THE REMOTE CONTROL • Point the remote control at the remote sensor located on the unit. • When there is a strong ambient light source, the performance of the infrared remote sensor may be degraded, causing unreliable operation. -
Page 6: Control Reference Guide
CONTROL REFERENCE GUIDE REMOTE CONTROL STANDBY / ON button Press to turn ON the unit or put it in STANDBY (OFF) mode. 2. TV button Press to switch to TV mode. AV button Press to switch to source connected to AV 1 / AV 2 (composite) inputs. - Page 7 CONTROL REFERENCE GUIDE FRONT & SIDE VIEWS 1. STD.BY / ON button Turns the unit on and off. 2. MENU button Enters the on-screen TV menu. 3. FUNCTION button Selects TV / AV 1 / AV 2 / YUV in / HDMI 1 / HDMI 2 / PC in.
-
Page 8: Control Reference Guide
CONTROL REFERENCE GUIDE REAR VIEW 10. VIDEO OUT jack (AV OUT) AUDIO OUT (Left / Right) jacks (AV OUT) 11. MONITOR / VGA jack (PC IN) 12. AC Power Cord 13. HDMI IN jacks (HDMI IN 1 / HDMI IN 2) 14. -
Page 9: Connections
CONNECTING A TV ANTENNA / CABLE / SATELLITE To view television channels correctly, a signal must be received from one of the following sources: - An indoor or outdoor aerial antenna - A cable system - A satellite system Connecting a Digital Antenna The tuner in this TV receives ATSC TV signals from an antenna. -
Page 10: Connecting Devices With A Composite (Yellow Rca-Type) Video Output
CONNECTING DEVICES WITH A COMPOSITE (YELLOW RCA-TYPE) VIDEO OUTPUT To connect A/V devices such as a VCR, video game system or camcorder: Connecting to a VCR / Video Game System / Camcorder Connect the AUDIO / VIDEO cable (not included) as shown: Make sure you connect the cable from the other equipment (AUDIO and VIDEO OUT) to this unit AV IN 1 (AUDIO and VIDEO IN) or AV IN 2 (AUDIO and VIDEO IN). -
Page 11: Connecting A High Definition (Hd) Source
CONNECTING A HIGH-DEFINITION (HD) SOURCE High-Definition (HD) Devices with component video output must be connected to the YUV input. Connect the component video cable and audio cable (not included) as shown. Make sure you connect the component video cable and audio cable from the other equipment (COMPONENT VIDEO OUT and AUDIO OUT) to this unit (COMPONENT VIDEO IN and AUDIO IN - YUV IN). -
Page 12: Connecting Hdmi
CONNECTING HDMI HDMI (High Definition Multimedia Interface) supports both video and audio on a single digital connection for use with DVD players, DTV, set-top boxes and other digital AV devices. HDMI was developed to provide the technologies of High Bandwidth Digital Content Protection (HDCP) as well as Digital Visual Interface (DVI) in one specification. -
Page 13: Connecting The Ac Power Cord
CONNECTING THE AC POWER CORD • Connect the AC power cord into a wall outlet. • Press the STD. BY / ON button on the left side of the unit or use the remote control to turn on the unit. NOTES •... -
Page 14: Installation
INSTALLATION REMOVING THE BASE STAND WARNING: The LCD display is very fragile, and must be protected at all times when removing the base stand. Be sure that no hard or sharp objects, or anything that could scratch or damage the LCD display, come in contact with it. -
Page 15: Tv Setup
VIDEO MENU 1. Press the MENU button. 2. Press the ENTER or button to select Video. 3. Use the button to select the options (Picture Mode, Brightness, Contrast, Saturation, Tint, Sharpness or Color Temperature). Adjust them using the change to your desired setting); or press the ENTER or 4. -
Page 16: Audio Menu
AUDIO MENU 1. Press the MENU button. 2. Use the button to select Audio, then press the ENTER or settings. 3. Use the button to select the options (Balance, Bass, Treble, Virtual Surround, Reverb or Sound mode). Adjust them using the or press the ENTER or button to go into the detailed settings. -
Page 17: Tv Menu
TV MENU (For TV Mode Only) 1. Press the MENU button. 2. Use the button to select TV. Press the ENTER or 3. Use the button to select the options (Tuner Mode, Auto Scan, Auto Scan Add CH, Channel Skip, MTS or Audio Language). Adjust them using the change to your desired setting);... -
Page 18: Setup Menu
SETUP MENU 1. Press the MENU button. 2. Use the button to select Setup. Press the ENTER or 3. Use the button to select the options (OSD Language, Time Setup, Caption or Restore setting). Adjust them using the press the ENTER or button to go into the detailed settings. -
Page 19: Parental Menu
Caption Setting Video Analog Closed Caption Digital Closed Caption Audio Digital Caption Style Setup Parental Caption ENTER Enter Analog Closed Caption : Select the analog closed caption or turn it off. Digital Closed Caption : Select the digital closed caption or turn it off. Digital Caption Style : Select as Broadcaster to use the default digital caption style of the broadcaster. -
Page 20: Tv Setup
Parental Control Setting 1. Use the button to select various Parental settings. Press the ENTER or detailed settings. 2. Use the buttons to move among the rating levels. Press the ENTER button to change the mode between Blocked and Allowed. 3. -
Page 21: Troubleshooting Guide
TROUBLESHOOTING GUIDE SYMPTOM CAUSE (AND REMEDY) • Check that the AC power cord is connected. No power. • The unit is not turned on. The remote does not • Remove any obstacles between the remote and the unit. function. • Use the remote near the unit. •... - Page 22 Unit : INCH Print in China 811-363291W010 E - 21 PLV36320CS11_IB_Eng_14-21.pmd 13/09/2007, 14:59...
