- Page 1 Operating and installation instructions Ceramic hobs To avoid the risk of accidents or damage to the appliance it is essential to read these instructions before it is installed and used for the first time. en-GB M.-Nr. 07 570 840...
-
Page 2: Table Of Contents
Contents Warning and Safety instructions................ 4 Caring for the environment ................ 13 Guide to the appliance .................. 14 Hob........................14 KM 5600 ...................... 14 KM 5603 ...................... 15 KM 5604 ...................... 16 KM 5607 ...................... 17 KM 5612 ...................... 18 KM 5613 ...................... - Page 3 Contents Cleaning and care .................... 40 Programming ....................... 42 Reset ........................44 What to do if ... .................... 45 Optional accessories .................. 48 Safety instructions for installation.............. 49 Safety distances .................... 50 Hob with frame or bevelled edge............... 54 Installation notes ....................54 Building-in dimensions ..................
-
Page 4: Warning And Safety Instructions
They contain important notes on installation, safety, use and maintenance. Miele cannot be held liable for damage caused by non-compliance with these instructions. Keep these instructions in a safe place and ensure that new users... - Page 5 Warning and Safety instructions Correct application This hob is intended for domestic use and use in other similar en- vironments. This hob is not intended for outdoor use. It is intended for domestic use only to cook food and keep it warm.
- Page 6 Warning and Safety instructions Safety with children Children under 8 years of age must be kept away from the hob unless they are constantly supervised. Children 8 years and older may only use the hob unsupervised if they have been shown how to use it in a safe way and can recognise and understand the consequences of incorrect operation.
- Page 7 Unauthorised installation, maintenance and repairs can cause considerable danger for the user. Installation, maintenance and re- pairs must only be carried out by a Miele authorised technician. Do not use a damaged appliance. It could be dangerous. Check the hob for visible signs of damage.
- Page 8 Warning and Safety instructions Miele can only guarantee the safety of the appliance when genu- ine original Miele replacement parts are used. Faulty components must only be replaced by Miele spare parts. The hob is not intended for use with an external timer switch or a remote control system.
- Page 9 Warning and Safety instructions Correct use The hob gets hot when in use and remains hot for a while after be- ing switched off. There is a danger of burning until the residual heat indicators go out. Due to the high temperatures radiated, objects left near the hob when it is in use could catch fire.
- Page 10 Warning and Safety instructions You could burn yourself on the hot hob. Protect your hands with heat-resistant pot holders or gloves when handling hot pots and pans. Do not let them get wet or damp, as this causes heat to trans- fer through the material more quickly with the risk of scalding or burning yourself.
- Page 11 Warning and Safety instructions Plastic and aluminium foil containers melt at high temperatures. Do not use plastic or aluminium foil containers on the hob. The hob frame or hob edges (on hobs with bevelled edges) and the controls can become hot due to the influence of the following factors: operating duration, high power level(s), large pans and the number of cooking zones being used.
- Page 12 Warning and Safety instructions Cleaning and care Do not use a steam cleaning appliance to clean this hob. The steam could reach electrical components and cause a short cir- cuit.
-
Page 13: Caring For The Environment
/ recycling centre for electrical and electronic ap- pliances, or contact your dealer or Miele for advice. You are also respons- ible (by law, depending on country) for deleting any personal data that may be stored on the appliance being disposed of. -
Page 14: Guide To The Appliance
Guide to the appliance KM 5600 a Single circle zone b Single circle zone c Single circle zone d Single circle zone e Controls / Indicators... - Page 15 Guide to the appliance KM 5603 a Double circle zone b Single circle zone c Extended cooking zone d Single circle zone e Controls / Indicators...
- Page 16 Guide to the appliance KM 5604 a Triple circle zone b Single circle zone c Single circle zone d Controls / Indicators...
- Page 17 Guide to the appliance KM 5607 a Double circle zone b Single circle zone c Extended cooking zone d Single circle zone e Controls / Indicators...
- Page 18 Guide to the appliance KM 5612 a Single circle zone b Single circle zone c Extended cooking zone d Single circle zone e Controls / Indicators...
- Page 19 Guide to the appliance KM 5613 a Double circle zone b Single circle zone c Extended cooking zone d Single circle zone e Controls / Indicators...
- Page 20 Guide to the appliance KM 5617 / KM 5618 a Double circle zone b Single circle zone c Extended cooking zone d Single circle zone e Controls / Indicators...
-
Page 21: Controls / Indicators
Guide to the appliance Controls / Indicators Sensor controls a For switching the hob on and off b Settings - For setting the power level - For setting the timer (only applies to hobs with a timer) - For activating/deactivating the system lock/safety lock (only applies to hobs with extended outer zones) - Page 22 Guide to the appliance c Extended outer zone For activating/deactivating the system lock/safety lock d For selecting the cooking zone e Timer - For switching on/off - For switching between timer functions - For selecting a cooking zone (see "Switching a cooking zone off automatic- ally") Indicator lights f - System lock/Safety lock activated (on hobs without extended outer zones)
-
Page 23: Cooking Zones
Guide to the appliance Cooking zones KM 5600 Ø in cm Cooking zone Rating in Watts for 230 V 18.0 1800 14.5 1200 21.0 2200 14.5 1200 Total: 6400 KM 5603 / KM 5613 Cooking zone Ø in cm Rating in Watts for 230 V ... - Page 24 Guide to the appliance KM 5607 / KM 5617 / KM 5618 Cooking zone Ø in cm Rating in Watts for 230 V 12.0 / 21.0 750 / 2200 14.5 1200 17.0 / 17.0 x 26.5 1500 / 2400 18.0 1800 Total: 7600 KM 5612 Ø in cm Cooking zone Rating in Watts for 230 V...
-
Page 25: Using For The First Time
Using for the first time Please stick the extra data plate for Switching on the hob for the the appliance supplied with this doc- first time umentation in the space provided in The metal components have a protect- the "After sales service, data plate, ive coating which when heated for the guarantee"... -
Page 26: How The Cooking Zones Work
How the cooking zones work Single circle cooking zones have one Single circle zone heating element, whilst double circle cooking zones and extended zones have two. Depending on model, the heating elements may be separated by an isolating ring. Each cooking zone has overheating protection (a temperature limiter), which stops the ceramic surface from becom- ing too hot (see "Overheating protec-... -
Page 27: Pans
Pans Most suitable: Pans with a thick base – Often the maximum diameter quoted which is very slightly concave when by manufacturers refers to the dia- cold. When heated, the base flattens to meter of the top rim of the pot or rest evenly on the hob, optimising the pan. -
Page 28: Tips On Saving Energy
Tips on saving energy – Check that the diameter of the pan base is wide enough for the cooking zone so that heat is not lost unneces- sarily. – Use a pan lid whenever possible to minimize heat loss. – Select a smaller pan when cooking small quantities. -
Page 29: Setting Range
Setting range The hob is programmed with 9 power levels at the factory. If you wish to fine-tune a setting, you can extend the power setting range to 17 power levels (see "Pro- gramming"). Setting range Default set- Extended set- ting tings (9 power... -
Page 30: Operation
Operation How the hob is operated Malfunction due to dirty and/or covered sensors This glass ceramic hob is equipped with If the sensors are dirty or covered electronic sensor controls which react this could cause them to fail to react, to finger contact. -
Page 31: Switching On
Operation Residual heat indicator Fire hazard. Do not leave the appliance unatten- If the cooking zone is still hot, the resid- ded whilst it is being used. ual heat indicator will light up after it has been switched off. Switching on The lines of the residual heat indicator go out one after another as the cooking... -
Page 32: Switching On An Extended Zone/Outer Ring
Operation Activating Switching on an extended zone/outer ring Touch the sensor for the cooking zone you want briefly. You can switch on the second or third ring of a cooking zone (see "Guide to Set the power level you want. the appliance"). -
Page 33: Auto Heat-Up
Operation Auto heat-up Continued cook- Heat-up time ing setting* [min : sec] When Auto heat-up has been activated, the cooking zone switches on automat- 1 : 20 ically at the highest power setting and 2 : 00 then switches to the continued cooking setting. The heat-up time depends on 2 : 45 which continued cooking setting has 3 :25... -
Page 34: Timer
Timer Minute minder The hob has to be switched on if you wish to use the timer. Setting You can set a time between 1 minute () and 9.5 hours (.). Touch the sensor. and the minute minder indicator The timer can be used for two different lamp will flash in the timer display. -
Page 35: Switching A Cooking Zone Off Automatically
Timer If you want to set another cooking Switching a cooking zone off zone to switch off automatically, fol- automatically low the same steps as described You can set a time at the end of which a above. cooking zone will switch off automatic- ally. -
Page 36: Using Both Timer Functions At The Same Time
Timer If you want to show the times counting Using both timer functions at down in the background: the same time Touch the timer display repeately until The minute minder and automatic switch-off functions can be used at the –... -
Page 37: Safety Features
Safety features The safety lock is set when the hob is System lock / Safety lock switched on. When the safety lock is The system lock and safety lock are activated, deactivated if there is an interruption – the cooking zone power levels and to the power supply. -
Page 38: Safety Switch-Off
Safety features Safety switch-off The indicator light and go out after a short while. Safety switch-off with an overlong cooking time Deactivating The safety switch-off mechanism is Touch the sensor until and the triggered automatically if one of the safety lock indicator light go out. -
Page 39: Overheating Protection
Safety features Control panel Overheating protection The control panel electronic unit is Cooking zones equipped with overheating protection. Each zone is equipped with overheating This switches off the hob automatically protection (internal temperature limiter). before the electronic unit overheats. This switches the cooking zone heating The fault code ... -
Page 40: Cleaning And Care
Cleaning and care Clean the entire hob after each use. Al- Danger of burning. low it to cool down before cleaning. Dry The cooking zones must be switched the hob after using water to clean it. off. The hob must have cooled down. This helps prevents limescale deposits. - Page 41 Wipe all coarse soiling off using a damp cloth. Stubborn soiling may need to be removed with a shielded scraper blade. Then clean the hob with Miele ceramic and stainless steel hob cleaner (see "Optional accessories") or a suitable proprietary ceramic hob cleaning agent applied with kitchen paper or a clean cloth.
-
Page 42: Programming
Programming You can programme certain settings on To access programming mode the hob to suit your personal needs. With the hob switched off touch Several settings can be changed in suc- the and or sensors until the cession. indicator light flashes above the sym- After accessing programming mode, ... - Page 43 Programming Settings Programme Status Demonstration Demonstration mode on mode and factory Demonstration mode off default settings Factory default settings reinstated Number of power 9 power levels levels 17 power levels Keypad tone when a sensor is Quiet touched Medium Loud Audible tone for the timer Quiet...
-
Page 44: Reset
Programming Reset This function allows you to quickly reset all the programming settings back to their original factory default settings. To initiate reset Switch on the hob. Touch the sensors for selecting the front left and front right cooking zones at the same time until the cooking zone displays go out (ap- prox. -
Page 45: What To Do If
Do not open the casing of the appliance. Repairs and other work by unqualified persons could be dangerous and Miele cannot be held liable for unauthorised work. Problem... - Page 46 What to do if ... Problem Cause and remedy After switching on the The hob is in demonstration mode. hob, appears in the Deactivate demo mode (see "Programming"). front left cooking zone display and appears in the front right cooking zone display for a few seconds.
- Page 47 Interrupt the power supply to the hob for approx. 1 minute. If the problem persists after power has been re- stored, please contact Miele. One or more residual There was an interruption to the power supply during heat indicators are operation or when residual heat was present.
-
Page 48: Optional Accessories
Miele appliances. These products can be ordered through the Miele Webshop. These can also be ordered from Miele (see end of this booklet for contact de- tails) or from your Miele dealer. Ceramic and stainless steel... -
Page 49: Safety Instructions For Installation
Safety instructions for installation The appliance must only be installed and connected to the electricity supply by a suitably qualified and competent person in strict accordance with current national and local safety regulations. Fit the wall units and cooker hood before fitting the hob to avoid damaging the hob. -
Page 50: Safety Distances
Safety distances Safety distance above the hob A minimum safety distance must be maintained between the appliance and the cooker hood above it. See the cooker hood manufacturer's operating and installation instructions for details. If the manufacturer's instructions are not available for the cooker hood or if any flammable objects (e.g. - Page 51 Safety distances Safety distances to the sides and back of the hob Ideally the hob should be installed with plenty of space on either side. There may be a wall at the rear or a tall unit or wall on one side (right or left) (see illus- trations).
- Page 52 Safety distances Interim shelf It is not necessary to fit an interim shelf underneath the hob but one may be fit- ted if you wish. If an interim shelf is fitted under the hob, there must be a minimum gap of 110 mm between the top of the work- top and the top of the shelf.
- Page 53 Safety distances Safety distance when installing the appliance near a wall with additional niche cladding A minimum safety distance must be maintained between the worktop cut-out and any niche cladding to protect it from heat damage. If the niche cladding is made from a combustible material (e.g. wood) a minimum safety distance ...
-
Page 54: Hob With Frame Or Bevelled Edge
Hob with frame or bevelled edge Tiled worktop Installation notes Seal between the hob and the work- Grout lines and the hatched area un- derneath the hob frame must be smooth and even. If they are not the hob will not sit flush with the worktop and the sealing strip underneath the Do not use sealant between the hob hob will not provide a good seal... -
Page 55: Building-In Dimensions
Hob with frame or bevelled edge Building-in dimensions KM 5600 a Spring clamps b Casing depth c Casing depth including mains connection box with mains connection cable, L = 1440 mm d Front... - Page 56 Hob with frame or bevelled edge KM 5603 / KM 5612 / KM 5613 a Spring clamps b Casing depth c Casing depth including mains connection box with mains connection cable, L = 1440 mm d Front...
- Page 57 Hob with frame or bevelled edge KM 5604 a Spring clamps d Mains connection box with mains connection cable, L = 1440 mm b Casing depth e Wiring harness, L = 1550 mm c Casing depth including cable exit f Front...
- Page 58 Hob with frame or bevelled edge KM 5607 / KM 5617 a Spring clamps b Casing depth c Casing depth including mains connection box with mains connection cable, L = 1440 mm d Front...
-
Page 59: Installation
Hob with frame or bevelled edge Installation Preparing the worktop Make the worktop cut-out as shown in the building-in diagram. Observe the safety distances (see "Safety dis- tances"). Wooden worktops Seal the cut surfaces with a suitable Position the spring clamps and the sealant to avoid swelling caused by support brackets ... - Page 60 Hob with frame or bevelled edge Natural stone worktops You will need heavy duty double-side tape (not supplied) to secure the spring clamps and support brackets. Apply silicone to the side and lower edges of the spring clamps and the support brackets.
- Page 61 Hob with frame or bevelled edge Installing the hob Feed the mains connection cable down through the cut-out. Position the hob in the worktop cut- out. Using both hands, press down evenly on the edges of the hob until it clicks into position.
-
Page 62: Flush-Fitted Hobs
Flush-fitted hobs The hob can be installed Installation notes – in a suitable cut-out in a natural stone Flush fit hobs are only suitable for in- worktop. stallation in natural stone (granite, marble), tiled or solid wood worktops. – in a suitable cut-out in a tiled or solid Certain models are suitable for build- wood worktop or a glass worktop ing into glass worktops - please see... -
Page 63: Building-In Dimensions
Flush-fitted hobs Building-in dimensions KM 5618 a Front c Casing depth including mains con- nection box with mains connection b Casing depth cable, L = 1440 mm d Stepped cut-out Please observe the detailed diagrams for cut-out dimensions in natural stone worktops. -
Page 64: Installation
Flush-fitted hobs Solid wood, tiled and glass worktops Installation Natural stone worktops a Worktop b Hob a Worktop c Gap b Hob d Wooden frame 13 mm (to be c Gap provided on site) As the ceramic glass and the worktop As the ceramic glass and the worktop cut-out have a certain dimensional tol- cut-out have a certain dimensional tol-... - Page 65 Flush-fitted hobs Preparing the worktop Make the worktop cut-out as shown in "Building-in dimensions". Observe the safety distances (see "Safety dis- tances"). Solid wood, tiled and glass worktops: Fix the wooden frame 7 mm below the top edge of the worktop (see dia- gram).
-
Page 66: Electrical Connection
Electrical connection External mains connection box The connection box can be installed: – separately in the base unit under- neath the hob, – on a side wall of the base unit, – on a wall behind the base unit, – in an adjacent unit. The connection box will be damaged by exposure to heat. - Page 67 Electrical connection Connection Danger of injury. Miele cannot be held liable for unau- AC 230 V, 50 Hz thorised installation, maintenance The connection data is quoted on the and repair work as this can be dan- dataplate. It must match the household gerous to users.
- Page 68 The earth lead must be connected to the point marked . If the mains cable needs to be replaced it must be replaced with a special con- nection cable, type H 05 VV-F (PVC-in- sulated), available from Miele. The connection data is quoted on the data plate.
-
Page 69: Wiring Diagram
Electrical connection Wiring diagram... -
Page 70: After Sales Service, Data Plate, Guarantee
N.B. A call-out charge will be applied to service visits where the problem could have been resolved as described in these instructions. When contacting your Dealer or Miele, please quote the model and serial number of your appliance. Data plate Space in which to stick the extra data plate supplied with the appliance. -
Page 71: Product Data Sheets
The following data sheets apply to the models described in this operating instruc- tion manual. Information for domestic electric hobs In acc. with regulation (EU) No. 66/2014 MIELE Model name / identifier KM 5600 Number of cooking zones and/or areas For circular cooking zones: diameter of useful sur- 1. - Page 72 Product data sheets Information for domestic electric hobs In acc. with regulation (EU) No. 66/2014 MIELE Model name / identifier KM 5604 Number of cooking zones and/or areas For circular cooking zones: diameter of useful sur- 1. = Ø 145 / Ø 210 / Ø 270 mm face area/cooking zone 2.
- Page 73 Product data sheets Information for domestic electric hobs In acc. with regulation (EU) No. 66/2014 MIELE Model name / identifier KM 5613 Number of cooking zones and/or areas For circular cooking zones: diameter of useful sur- 1. = Ø 120 / Ø 210 mm face area/cooking zone 2.
- Page 74 Product data sheets Information for domestic electric hobs In acc. with regulation (EU) No. 66/2014 MIELE Model name / identifier KM 5618 Number of cooking zones and/or areas For circular cooking zones: diameter of useful sur- 1. = Ø 120 / Ø 210 mm face area/cooking zone 2.
- Page 75 Tel. +971 4 3044 999 Tel: (01) 461 07 10, Fax: (01) 461 07 97 Fax. +971 4 3418 852 E-Mail: info@miele.ie, Internet: www.miele.ie 800-MIELE (64353) Manufacturer: Miele & Cie. KG E-Mail: info@miele.ae Website: www.miele.ae Carl-Miele-Straße 29, 33332 Gütersloh, Germany...
- Page 76 KM 5600 / KM 5603 / KM 5604 / KM 5607 / KM 5612 / KM 5613 / KM 5617 / KM 5618 en-GB M.-Nr. 07 570 840 / 05...
