Dimplex DXLWP800TI B Installation And Operating Instructions

Dimplex Low Wattage Panel Heaters
Models: DXLWP400, DXLWP400TI, DXLWP800,
DXLWP800TI N, DXLWP800TI B & ARLWP800TI
Dimensions
(millimetres)
Models Specification
DXLWP400
DXLWP400TI
DXLWP800
DXLWP800TI N
DXLWP800TI B
ARLWP800TI
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
Important Safety Advice
When using electrical appliances, basic
precautions should always be followed to
reduce the risk of fire, electrical shock, and
injury to persons, including the following:
IMPORTANT – The wall bracket supplied with
the appliance must be used.
WARNING – DO NOT USE THIS HEATER
IN THE IMMEDIATE SURROUNDINGS OF A
BATH, A SHOWER OR A SWIMMING POOL.
IMPORTANT – If the heater is installed in a
room containing a bath or shower, it must be so
installed that switches and other controls cannot
be touched by a person using a bath or shower.
Do not use outdoors.
Do not locate the heater immediately below a
fixed socket outlet or connection box.
WARNING: In order to avoid overheating, do
not cover the heater. Do not place material
or garments on the heater, or obstruct the
air circulation around the heater, for instance
by curtains or furniture, as this could cause
overheating and a fire risk.
NEVER cover or obstruct in any way the heat
outlet slots at the top of the heater or the air
inlet slots in the base of the heater.
The heater carries the Warning symbol
indicating that it must not be covered.
CAUTION - Some parts of this product can
become very hot and cause burns. Particular
attention has to be given where children and
vulnerable people are present.
This appliance can be used by children aged
from 8 years and above and by persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved.
400W Neon Heat Switch
400W Neon Heat Switch / 24 Hour Timer
800W Neon Heat Switch
800W Neon Heat Switch / 24 Hour Timer
800W ON/OFF, 2 Switches/ 24 Hour Timer
800W 2 Neon Heat Switches / 24 Hour Timer
Installation and Operating Instructions
600 mm - 400W
800 mm - 800W
Children shall not play with the appliance.
Cleaning and user maintenance shall not be
made by children without supervision.
Children of less than 3 years should be kept
away unless continuously supervised.
Children aged from 3 years and less than 8
years shall only switch on/off the appliance
provided that it has been placed or installed in
its intended normal operating position and they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
aged from 3 years and less than 8 years shall
not plug in, regulate and clean the appliance
or perform user maintenance.
Note that due care and consideration must be
taken when using this heater in series with a
thermal control, a program controller, a timer
or any other device that switches on the heat
automatically, since a fire risk exists when the
heater is accidentally covered or displaced.
If the supply cord is damaged it must be
replaced by the manufacturer or service agent
or a similarly qualified person in order to avoid
a hazard.
WARNING:
Servicing
repairs should only be undertaken by the
manufacturers approved service agent or a
similarly qualified person, using only exact
manufacturer approved spare parts.
WARNING: This heater is not equipped with
a device to control the room temperature.
Do not use this heater in small rooms when
they are occupied by persons not capable
of leaving the
unless constant supervision is provided.
INDUKLWPRG
500 mm
and product
room on their
Issue 13
own,
