MyQ® Garage (Universal Wi-Fi Hub)
INSTALLATION GUIDE
1 – Getting Started
Things You'll Need
Ladder
1)
IMPORTANT: Sufficient Wi-Fi signal in the garage
2)
-See troubleshooting section for weak signal strength rememdies
Wifi network name and password
3)
MyQ® Garage Universal Garage Door Controller
4)
-Wifi Hub (Gateway- Supports up to 16 MyQ® devices)
-Door sensor (Each Hub will support 2 door sensors)
Compatible garage door opener (See "Appendix")
5)
Dealer Site or Customer Site access through a laptop, tablet, or mobile
6)
device
In the MyQ® Garage Box You'll Find
Reference: Together in Garage
Copyright © 2015 Alarm.com
|
www.alarm.com
|
v4.0
®
LiftMaster MyQ
|
Installation Guide
Advertisement
Related Manuals for Chamberlain MyQ Garage 821 LM
Summary of Contents for Chamberlain MyQ Garage 821 LM
- Page 1 ® LiftMaster MyQ Installation Guide MyQ® Garage (Universal Wi-Fi Hub) INSTALLATION GUIDE Reference: Together in Garage 1 – Getting Started Things You’ll Need Ladder IMPORTANT: Sufficient Wi-Fi signal in the garage -See troubleshooting section for weak signal strength rememdies Wifi network name and password MyQ®...
- Page 2 ® LiftMaster MyQ Installation Guide 2 - Install Hardware Install Door Sensor This device will communicate the state of the door (open or closed) to the Wi-Fi Hub and must be mounted prior to step 4. A) To install, position the door sensor vertically and attach to a clean, dry location on the top panel of the garage door with fastening strips (provided).
- Page 3 ® LiftMaster MyQ Installation Guide Find the Bluetooth MyQ-nnn device and select MyQ-nnn device to pair. 3 - Setup Wi-Fi on the MyQ® Garage Wi-Fi Hub “nnn” is the last 3 digits of the Wi-Fi Hub’s serial number. Method 1: Using Internet Connected Device Note: If your phone believes the Hub is not connected to the internet, try forgetting the device before pairing.
- Page 4 Method 1: Using MobileTech App Note: You cannot register MyQ® Garage through Alarm.com if it is already registered through MyQ®/Liftmaster/Chamberlain or other similar apps. (See Troubleshooting section). Make sure the LED on the Hub is green before registering through Mobile Tech.
- Page 5 Method 2: Using the Dealer Website Note: You cannot register MyQ® Garage through Alarm.com if it is already registered through MyQ®/Liftmaster/Chamberlain or other similar apps. (See Troubleshooting section). Make sure the LED on the Hub is green before registering through the Alarm.com Dealer Site.
- Page 6 Method 3: Using the Customer Website Note: You cannot register MyQ® Garage through Alarm.com if it is already registered through MyQ®/Liftmaster/Chamberlain or other similar apps. (See Troubleshooting section). Make sure the LED on the Hub is green before registering through the Alarm.com Customer Site.
- Page 7 ® LiftMaster MyQ Installation Guide 5 – View Equipment & Test Validate that both the Wi-Fi Hub and garage door show up on the equipment list on the Dealer website. You may need to select ‘Get Equipment List’ and refresh the page. Test status and control through the Alarm.com web and mobile apps.
-
Page 8: Additional Resources
Most garage door openers manufactured by the following brands are compatible: Chamberlain: all garage door openers with the following program button colors on the monitor portion of the operator: yellow, purple, orange, green and red. -
Page 9: Troubleshooting
® LiftMaster MyQ Installation Guide Troubleshooting The door sensor will not program to the Wi-Fi Hub. Press the Test button on the door sensor (the Yellow LED should blink). If the Yellow LED on the door sensor does not blink, replace the battery and try programming the door sensor again. - Page 10 ® LiftMaster MyQ Installation Guide 4) Press and release the BUTTON. The Yellow and Green LEDs will blink. 5) Press and release the LEARN button on the garage door opener. 6) Press and release BUTTON 1 until the garage door opener clicks. Press and release BUTTON 1 again to activate the garage door opener. If the garage door opener does not activate, press and release the BUTTON, then repeat steps 3-6.
