Summary of Contents for Clevo XMG-U505
-
Page 2: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy... -
Page 3: Power Safety
Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Removal Warning Use only approved brands of Unplug the power cord before When removing any peripherals. -
Page 4: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire. -
Page 5: Related Documents
Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on Disc This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1. -
Page 6: Specifications
Introduction Specifications Processor Options Memory Intel® Core™ i7 Processor Four 204 Pin SO-DIMM Sockets Supporting DDR3L 1600MHz Memory i7-4790K (4.00GHz) (The real memory operating frequency depends on the FSB 8MB L3 Cache, 22nm, DDR3L-1600MHz, TDP 88W of the processor.) i7-4790 (3.60GHz) Memory Expandable from 4GB (minimum) up to 32GB 8MB L3 Cache, 22nm, DDR3L-1600MHz, TDP 84W... - Page 7 Introduction Audio Communication High Definition Audio Compliant Interface Built-In Gigabit Ethernet LAN S/PDIF Digital Output 2.0M FHD PC Camera Module Two Speakers (Factory Option) M.2 3G/4G Module Sound Blaster Audio WLAN/ Bluetooth M.2 Modules: ANSP ™ 3D sound technology on headphone output (Factory Option) Intel®...
-
Page 8: External Locator - Top View With Lcd Panel Open
Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Built-In PC Camera 2. PC Camera LED 3. Built-In Microphone 4. LCD 5. Speakers 6. Power Button 7. LED Indicators 8. Keyboard 9. TouchPad and Buttons 10. -
Page 9: External Locator - Front & Right Side Views
Introduction External Locator - Front & Right side Views Figure 2 Front Views 1. Light Bar 2. LED Power Indicators Front Figure 3 Right Side Views 1. USB 3.0 Port 2. S/PDIF-Out Jack 3. Headphone Jack Right 4. Microphone Jack 5. -
Page 10: External Locator - Left Side & Rear View
Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. RJ-45 LAN Jack 2. USB 3.0 Port 3. USB 3.1 Ports 4. Multi-in-1 Card Left Reader 5. Combined eSATA/ Powered USB 3.0 Port Figure 5 Rear View 1. -
Page 11: External Locator - Bottom View
Introduction External Locator - Bottom View Figure 6 Bottom View 1. Vent 2. Component Bay Cover 3. Battery 4. HDD Bay Overheating To prevent your com- puter from overheating make sure nothing blocks the vent/fan in- takes while the com- puter is in use. -
Page 12: Maintenance Tools
Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •... -
Page 13: Maintenance Precautions
Disassembly Maintenance Precautions The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged. -
Page 14: Removing The Battery
Disassembly Removing the Battery Figure 1 1. Turn the computer off, and turn it over. Battery Removal 2. Slide the latch in the direction of the arrow (Figure 1a 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a 4. -
Page 15: Removing The Hard Disk Drive
Disassembly Removing the Hard Disk Drive Figure 2 HDD Assembly The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 7mm/ Removal 9.5mm (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as out- lined in Chapter 4 of the User’s Manual) when setting up a new hard disk. - Page 16 Disassembly 4. Lift the hard disk bay cover off the computer (Figure 3c Figure 3 5. Slightly lift and pull the HDD-2 assembly (if available) in the direction of the arrow to remove the hard disk HDD Assembly assembly (Figure 3d Removal (cont’d.) 6.
- Page 17 Disassembly Hard Disk Size Note (Foam Rubber Insert) Note that the hard disks pictured on the following pages are all 9.5mm(H) hard disk drives. In some cases 7mm(H) hard disk drives will be installed. Figure 4 Foam Rubber Insert for 7mm(H) HDDs HDD-2 HDD-1...
-
Page 18: Removing The M.2 Ssd Module
Disassembly Removing the M.2 SSD Module Figure 5 Note that the SSD (if installed) is beside the HDD bay. M.2 SSD Module Removal 1. Turn off the computer, and turn it over, remove the battery (page 2 - 2. Remove the screw from the SSD (Figure 5a a. -
Page 19: Removing The Primary System Memory (Ram)
Disassembly Removing the Primary System Memory (RAM) Figure 6 RAM Module The computer has four memory sockets for 204 pin Small Outline Dual In-line (SO-DIMM) DDR 3L type memory modules. Removal The total memory size is automatically detected by the POST routine once you turn on your computer. a. - Page 20 Disassembly 4. Lift the component bay cover off the computer case. The modules will be visible at point (Figure 7c Figure 7 5. Gently pull the two release latches ( ) on the sides of the memory socket(s) in the direction indicated below &...
-
Page 21: Removing The System Memory (Ram) From Under The Keyboard
Disassembly Removing the System Memory (RAM) from Under the Keyboard Figure 8 Keyboard The computer has four memory sockets for 204 pin Small Outline Dual In-line (SO-DIMM) DDR 3L type memory modules. Removal The total memory size is automatically detected by the POST routine once you turn on your computer. a. - Page 22 Disassembly 5. Carefully lift the keyboard up, being careful not to bend the keyboard ribbon cables Figure 9 6. Disconnect the keyboard ribbon cables from the locking collar socket by using a small flat-head screw- RAM Module driver to pry the locking collar pins away from the base (Figure 9d).
-
Page 23: Removing The Wireless Lan Module
Disassembly Removing the Wireless LAN Module Figure 13 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5) and the keyboard (page 2 - Module Removal 2. The Wireless LAN module will be visible at point under the keyboard (Figure 13a). -
Page 24: Wireless Lan, Combo, 3G & Lte Module Cables
Disassembly Wireless LAN, Combo, 3G & LTE Module Cables Note that the cables for connecting to the antennae on WLAN, WLAN & Bluetooth Combo, 3G and LTE modules are not labelled. The cables/covers (each cable will have either a black or transparent cable cover) are color coded for iden- tification as outlined in the table below. -
Page 25: Removing The M.2 Sata Module
Disassembly Removing the M.2 SATA Module Figure 14 M.2 SATA Module 1. Turn off the computer, remove the battery (page 2 - 5), and component bay cover (page 2 - 10). Removal 2. Locate the module; it is visible at point Figure 14a 3.
