See also:
Operating Manual
SPLIT TYPE
ROOM AIR CONDITIONER
WALL MOUNTED TYPE
Indoor unit
Outdoor unit
ASU9RL
AOU9RL
ASU12RL
AOU12RL
CO NT ENTS
SPECIFICATIONS. . . . . . . . . . . . . . . . . . . . .
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . .
REFRIGERANT SYSTEM DIAGRAM . . . .
CIRCUIT DIAGRAM. . . . . . . . . . . . . . . . . . .
INDOOR PCB CIRCUIT DIAGRAM. . . . . .
ERROR DETECTION. . . . . . . . . . . . . . . . .
PARTS (Indoor unit) . . . . . . . . . . . . . . . . . .
PARTS (Outdoor unit). . . . . . . . . . . . . . . . .
ACCESSORIES . . . . . . . . . . . . . . . . . . . . .
1
2
3
4
5
8
10
11
15
19
Advertisement
Table of Contents
Related Manuals for Fujitsu ASU9RL
Summary of Contents for Fujitsu ASU9RL
-
Page 1: Table Of Contents
SPLIT TYPE ROOM AIR CONDITIONER WALL MOUNTED TYPE Indoor unit Outdoor unit ASU9RL AOU9RL ASU12RL AOU12RL CO NT ENTS SPECIFICATIONS..... -
Page 2: Specifications
S PECIF ICAT I ON S ELECTRICAL DATA NOISE LEVEL Cool & heat inverter TYPE High speed 43 dB 43 dB INDOOR ASU9RL ASU12RL INDOOR UNIT Middle speed 38 dB 38 dB UNIT OUTDOOR UNIT AOU9RL AOU12RL Low speed 33 dB... -
Page 3: Dimensions
DIMEN S IONS unit : mm INDOOR UNIT OUTDOOR UNIT 2009.01.26... -
Page 4: Refrigerant System Diagram
R EF R I GE R ANT SY ST E M DI A G RA M Heat exchanger (indoor unit) 2-Way valve 3-Way valve Compressor Muffler Strainer 4-Way valve Expansion valve Heat exchanger (outdoor unit) Strainer Refrigerant direction Cooling Heating Refrigerant pipe diameter Liquid : 1/4"... -
Page 5: Circuit Diagram
CIRC UIT DIAG R AM COMPRESSOR AOR12RL INDOOR UNIT R(R)U INDICATOR PCB ASSY 1 2 3 4 5 6 7 8 S(S)V WHITE OUTDOOR UNIT CN201 BLACK C(T)W WHITE ORANGE STEP MOTOR WHITE YELLOW WHITE PINK ( LOUVER ) COMPRESSOR REACTOR CONTROLLER PCB ASSY WHITE... -
Page 6: Indoor Pcb Circuit Diagram
IN DOOR P CB CIRCU IT DIAGR AM CONTROL UNIT ASU9RL : EZ-00819HSE ASU12RL : EZ-0081AHSE EARTH TERMINAL GREEN TERMINAL BOARD OUTDOOR UNIT THERMAL FUSE 102 WHITE BLACK EMI FILTER 1871843-2 2013485-1 1971032-4 PIPE THERMISTOR BLACK BLACK ROOM THERMISTOR BLACK... - Page 7 INDOOR UNIT CONTROLLER PCB ASSEMBLY ASU9RL : K07AN-080YHSE-C1 ASU12RL : K07AN-0810HSE-C1 20*20*18 F I H 0.6A - 10mH 340V 2013485-1 250V - 3.15A ( EM ) SS11V-06180 BLACK S1NBC60 TO TERMINAL BOARD WHITE 0.01 100K 0.01 <F> MY082G <1/2W> <ECQE>...
- Page 8 INDOOR UNIT INDICATOR PCB ASSEMBLY K07BJ-0700HSD-D0 CN201 07 JB20 / GIC 1061 L=230 D201 SLR-343MC <GREEN> D202 SLR-343DC <ORANGE> D203 SLR-343YC <YELLOW> SW201 MANUAL AUTO SWITCH KSHG0611BT R202 I C201 GP1UM261RKVF <1/4W> C203 C202 <F> 2009.01.20...
-
Page 9: Outdoor Pcb Circuit Diagram
O UT D OO R P CB CI RC U IT DI AG R A M INVERTER ASSEMBLY AOU9RL : EZ-008GHUE AOU12RL : EZ-008HHUE EMI FILTER EMI FILTER REACTOR W103 ( AOU12RL Only ) TO INDOOR UNIT F202 UL1015 5A - 250V UL1015 AWG14 AWG20 B W7... - Page 10 OUTDOOR UNIT CONTROLLER PSB ASSEMBLY AOU9RL : K07CJ-080AHUE-C1 AOU12RL : K07CJ-080BHUE-C1 POWER SOURCE REACTOR D102 AC230 - 208V UF4007 L300 47uH 60Hz AOU9RL : C4, C5 0.015 <YE> x 2 <ELC0607> D100 R401 - R408 R103 AOU12RL : C4, C5 0.010 <KH> x 2 D15XB60 0.2 <0.75W>...
-
Page 11: Error Detection
ERROR DE T EC TI O N Indoor unit LED Wired Error Error remote Operation Coil dry Timer LED control 2 flash Serial signal (reverse) error, at operation start up 3 flash Serial signal (reverse) error, during oeration Serial signal error 4 flash Serial signal (forward) error, at operation start up 5 flash... -
Page 12: Parts (Indoor Unit)
P ART S INDOOR UNIT Front panel assy Ref. Description Part number Front Panel Assy 9316897175 Front Panel 9316558014 Intake Grille Assy 9317428088 Clamper (Grille) 9316906006 Air Filter 9316562004 Receiver Window 9316588004 Panel Cover 9316561007 Remote Control 9317475044 Remote Control Holder 9305642045 Air Clean Filter Assy 9317250009... - Page 13 INDOOR UNIT Evaporator Ref. Description Part number Evaporator Assy (09) 9316922013 Evaporator Assy (12) 9317268011 Joint Pipe Assy (09) 9316923010 Joint Pipe Assy (12) 9317190015 Filter Guide 9316578005 Rear Bracket 9316566002 Evaporator Holder R 9316565005 Evaporator Holder L 9316564008 Room Thermistor Holder 9316895003 Thermistor Assy 9900459017 2009.01.26...
- Page 14 INDOOR UNIT Casing assy Ref. Description Part number Casing Assy 9316892071 Casing 9316563001 Motor Cover 9316568006 Cable Guide 9317680011 Casing Cover B 9316569003 Casing Cover F 9316570009 R and L Louver B 9316961005 Louver Gear Holder 9316575004 Louver Gear 9316574007 Gear A 9309994003 Motor Step...
- Page 15 INDOOR UNIT Control box Ref. Description Part number Control Box 9316582019 Box Shield 9316580008 Control Cover 9316583016 Cover Shield 9316581005 Controller PCB Assy (09) 9707645385 Controller PCB Assy (12) 9707645392 Display Case 9316587007 Display PCB Assy 9707649017 Terminal 9900529017 Earth Terminal 9316586000 2009.01.26...
-
Page 16: Parts (Outdoor Unit)
P ARTS OUTDOOR UNIT AOU9RL AOU12RL Ref. Description Part number 1 Front Panel Assy 9316972018 2 Emblem 9317903011 Cabinet Left Assy 9313991043 4 Top Panel Assy 9316973022 5 Protective Net 9331262019 Switch Cover 9313940010 7 Cabinet Right Assy 9331336062 8 Valve Bracket 9316523012 9 Valve Bracket Cover 9331683005... - Page 17 OUTDOOR UNIT AOU9RL Ref. Description Part number Base Assy 9316916005 Condenser Assy 9317286008 Entrance Pipe Assy (Cond) 9317163019 Separate Pipe Assy (Cond) 9332015003 Exit Pipe 9317338004 Compressor Assy 9317083010 Cushion 9306410001 2 way Valve Assy 9317171014 Joint Pipe (2 way Valve) 9317344005 3 way Valve Assy 9317174015...
- Page 18 OUTDOOR UNIT AOU12RL Ref. Description Part number Base Assy 9316980006 Condenser Assy 9317193016 Entrance Pipe Assy (Cond) 9317194013 Separate Pipe Assy (Cond) 9317200011 Exit Pipe 9317239004 Compressor Assy 9317619004 Cushion 9306410001 2 way Valve Assy 9317171014 Joint Pipe (2 way Valve) 9317344005 3 way Valve Assy 9317174015...
- Page 19 OUTDOOR UNIT AOU9RL AOU12RL Ref. Description Part number 41 Sealed Panel 9331256018 Controller PCB Assy (09) 9707706161 Controller PCB Assy (12) 9707706178 43 PCB Holder 9331261012 Inverter Case Assy 9331279062 Inverter Case Cover 9331258036 46 Terminal Bracket 9317689014 47 Terminal 5P 9703874024 Terminal Cover Assy 9317898003...
-
Page 20: Accessories
A CCE SS ORI E S Wall hook bracket 9316590007 Remote control 9316397026 Remote control holder 9305642045 Battery (penlight) 0600185527 Cloth tape 9310519004 Tapping screw (big) 4 x 25) 0700076046 Tapping screw (small) 3 x 12) 0700019036 Air cleaning filter 9311925088 9312153077 2009.01.27... - Page 21 0901G3595...
