Necta Astro Installation, Operating And Maintenance Manual

Vending machine espresso instant

Hide thumbs Also See for Astro:

Brochure and installation manual (13 pages)

Table Of Contents

Table of Contents

Quick Links

INSTALLATION, OPERATING AND MAINTENANCE MANUAL

Astro

English

Espresso

Instant

DOC. NO. H 206U 00

EDITION 1 2002-10

Table of Contents

Summary of Contents for Necta Astro

Page 1 INSTALLATION, OPERATING AND MAINTENANCE MANUAL Astro Espresso Instant English DOC. NO. H 206U 00 EDITION 1 2002-10...
Page 3 DICHIARAZIONE DI CONFORMITA’ DECLARATION OF CONFORMITY DÉCLARATION DE CONFORMITÉ KONFORMITÄTSERKLÄRUNG DECLARACIÓN DE CONFORMIDAD DECLARAÇÃO DE CONFORMIDADE VERKLARING VAN OVEREENSTEMMING INTYG OM ÖVERENSSTÄMMELSE OVERENSSTEMMELSESERKLÆRING YHDENMUKAISUUSTODISTUS Valbrembo, 03/05/2001 Dichiara che la macchina descritta nella targhetta di identificazione, è conforme alle disposizioni legislative delle direttive: 89/392, 89/336, 73/23 CEE e successive modifiche ed integrazioni.
Page 5: Table Of Contents
PAGE 29 OPERATING MODES PAGE 15 TRANSFERRED DATA PAGE 29 CONFIGURING THE LANGUAGE PAGE 29 USER INTERFACE PAGE 15 NORMAL OPERATING MODE PAGE 15 HYDRAULIC SYSTEMS PAGE 30 WIRING DIAGRAM PAGE 58 © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 6: Introduction
It also assists in the spare parts management. Product code Serial number Model Frequency Type Operating voltage Current Absorbed power Water mains characteristics Boiler data Fig. 1 © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 7: Positioning The Vending Machine
Executive, BDV and MDB protocol, as well as for installation of 24 V validators. Beside the coin mechanism housing, suitable space is provided for the installation (optional) of the most widely used payment systems. © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 8: Power Consumption
- Overheating protection for: Doser units Coffee unit ratiomotor Coffee release magnets Pump Electric mixers Coffee grinder motor - Fuse protection for: Board power supply transformer and Coin mechanism (primary and secondary) © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 9: Variable Combination Lock
Keys with the old combination cannot be used for the point of view of both electrical safety and health regu- new combination. lations. © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 10: Loading And Cleaning
Any other use is unsuitable and thus potentially dangerous. compartment. NOISE LEVEL The continuous, weighted equivalent acoustic pressure level is below 70 dB. 0210 206-00 © by NECTA VENDING SOLUTIONS SpA...
Page 11: Loading Cups
3 - Shelf positioning magnet from the mixers (see Figure 7); 4 - Adjustable stirrer guide 5 - Cover 6 - Cup stacker 7 - Stirrer stacker 8 - Cup release button © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 12: Cleaning The Sugar Dispenser
Fig. 8 Every time coffee is refilled, or at least once a week, any powder residue should be removed from the external parts of the coffee unit, particularly from the coffee funnel. 0210 206-00 © by NECTA VENDING SOLUTIONS SpA...
Page 13: Regenerating The Softener Unit
- adjust the water flow in such a way as to completely dissolve the salt in 20 litres water within 35 minutes; Fig. 10 1 - From the tap 2 - To the drain 3 - Cap 4 - Softener unit © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 14: Installation
3 - Permanently live socket (230 V~ 2 A Max) 4 - Instant valves 5 - Mechanical counter 6 - RS232 serial port 7 - Mixer wash button 8 - Programming button © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 15: Connecting The Machine To The Water Mains
1 - Lift cover It is good practice to install the water supply tap 2 - Cable clamp outside the machine in an easily accessible position. 3 - Cable from the mains © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 16: Installing The Payment System
- re-insert the hose connected to the air-break. Fig. 16 1 - From the water inlet solenoid valve 2 - To the air-break 3 - Cap 4 - Softener unit © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 17: Coffee Unit Operation
2 - External disk To adjust them it is therefore necessary to follow the 3 - Upper piston programming procedures. 4 - Lower piston 5 - Pre-brewing spring 6 - Swinging lever © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 18: Standard Settings
2 - Grinding adjusting knob 3 - Dose regulator the finer the grade of grinding the longer the time necessary 4 - Dose adjusting lever for dispensing the coffee and vice versa. 5 - Reference notches © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 19: Operating Modes
Manual refilling and release of change-giver tubes “Boiler temperature" Displaying the boiler temperature in degree C. “Test” Complete selection Dispensing water only Dispensing powder only Dispensing without accessories Dispensing accessories only Fig. 21 © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 20: Statistics
Press the confirm button “ ” , and the message “Confirm?” starts blinking. Press the confirm button “ ” , the message “Working” is displayed for a few seconds and all statistics are reset. 0210 206-00 © by NECTA VENDING SOLUTIONS SpA...
Page 21: Technician Menu
Extra sugar identification Sugar code Less sugar More sugar Initialising More water Less water More powder Less powder Coffee powder dose Extra milk MiscellaneousFB unit data Jug Facilities Password Enable filler menu © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 22: Failures
The machine is not locked, but all coffee-based selections are disabled. Coffee failure If after a period of 15 seconds of grinding coffee a dose is not obtained, all coffee-based selections are disabled. 0210 206-00 © by NECTA VENDING SOLUTIONS SpA...
Page 23 When pressing the B and C only coin return button, the available credit is returned if its value B only is lower than the maximum change value. B or C only C only © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 24: Selections
It is also possible to set the water flow rate of the single solenoid valves expressed in cc/s (the default value setting in cc/s is indicated in the selection dose table) to calculate the amount of water to be dispensed. 0210 206-00 © by NECTA VENDING SOLUTIONS SpA...
Page 25: Vending Machine Parameters
The time starts from the sound signal at the end of dispensing and can be set to 0 to 15 seconds. In any case the slider is released at the beginning of the next selection. © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 26: Miscellaneous
Press the confirm button “ ” and the message “Confirm?” starts blinking. Press the confirm button “ ” , the message “Working” is displayed for a few seconds and all statistics are reset. 0210 206-00 © by NECTA VENDING SOLUTIONS SpA...
Page 27: Miscellaneous
(from the default 0). PROGRAMMING THE OPERATOR CODE When the “Operator code” function is displayed the six-digit numeric code identifying groups of machines can be changed (from the default 0). © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 28: Maintenance
- Take the snap ring out of its seat; Important notice!!! - remove the piston from the crosspiece; Check that the handle pin of the ratiomotor is correctly - remove the filter and the piston seal. engaged in its seat. 0210 206-00 © by NECTA VENDING SOLUTIONS SpA...
Page 29: Cleaning The Cup Dispenser
- align the notch on the microswitch actuation gear with the arrow on the snail support; - ensure that the snails are oriented as indicated in the figure. © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 30: Printed Board Functions And Indicator Lights
14 - 230 V~ users MDFB 15 - 230 V~ users 16 - 230 V~ users 17 - 3-relay card connection MDFB 18 - "Can Bus" connection MAC2 MFFB 19 - Not used 0210 206-00 © by NECTA VENDING SOLUTIONS SpA...
Page 31: Relay Board
This board (see Fig. 28) controls the instant boiler heating element. The coffee boiler is controlled by a similar board fitted on the espresso module. Fig. 28 - RS232 serial port - Wash button - Failure reset button - C.P.U. board © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 32: Configuring The Electronic Boards
- J9 not used - J10 LCD (Liquid crystal display) - J11 Push-button panel - J16 Push-button panel - J12 MDB coin mechanism - Coin mechanism setting Minidip (SW2) - J13 Expansion for BDV/EXE 0210 206-00 © by NECTA VENDING SOLUTIONS SpA...
Page 33: Programmer
CONFIGURATION INITIALISING INITIALISING Confirm? CONFIGURATION CONFIG. END Exit from the configuration menu The software restarts from address 0000 (as when starting the machine) 1 - Connector 2 - Holder 3 - Programmer © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 34: Hydraulic Systems
10 - Anti-boiling thermostats 4 - Air-break 11 - Safety thermostat 5 - Volumetric counter 12 - Instant boiler 6 - Vibration pump 13 - Instant prod. solenoid valves 7 - Coffee boiler 0210 206-00 © by NECTA VENDING SOLUTIONS SpA...
Page 35 1 - Water inlet solenoid valve 2 - Safety thermostat 3 - Air break 4 - Anti-boiling thermostats 5 - Anti-boiling thermostats 6 - Instant prod. solenoid valves 7 - Liquid waste container © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 62: Wiring Diagram
SCHEDA TRIAC RISCALDAMENTO CALDAIA MACININO SCHEDA UNITA’ CENTRALE MOTORE APERTURA SPORTELLO TRASFORMATORE MD1-.. MOTODOSATORI SOLUBILI TX..FUSIBILE RITARDATO (X=CORRENTE) CONNETTORE PER GETTONIERA MDB SENSORE TAZZA MDFB MOTODOSATORE FRESH BREW VENT VENTILATORE MOTODOSATORE ZUCCHERO © by NECTA VENDING SOLUTIONS SpA 0210 206-00...
Page 64 NECTA VENDING SOLUTIONS SpA Sx37600...
Page 65 Astro...
Page 66 Sx37700...
Page 67 Astro...
Page 68 sx37800...
Page 69 Astro...
Page 83 The Manufacturer reserves the right to modify, without prior notice, the characteristics of the equipment described in this publication; and further declines to accept any responsibility for any inaccuracies contained in this publication which can be ascribed to printing and/or transcription errors. All instructions, drawings, tables and information contained in this publication are confidential and can neither be reproduced completely nor in part, nor be transmitted to third parties without the written permit of the Manufacturer, who has the sole ownership.
