- Page 1 ™ PV1600 Power Amplifier Operating Manual www.peavey.com...
- Page 2 ATTENTION: Afin de réduire le risque de choc électrique, ne pas enlever le couvercle. Il ne se trouve à l’intérieur aucune pièce pouvant être reparée par l’utilisateur. Confiez I’entretien et la réparation de l’appareil à un réparateur Peavey agréé. AVIS: Dans le but de reduire les risques d’incendie ou de decharge electrique, cet appareil ne doit pas etre expose a la pluie ou a l’humidite et aucun objet rempli de liquide, tel qu’un vase, ne doit...
-
Page 3: Important Safety Instructions
WARNING: When using electrical products, basic cautions should always be followed, including the following: Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any of the ventilation openings. Install in accordance with manufacturer’s instructions. Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including amplifiers) that produce heat. -
Page 4: Wichtige Sicherheitshinweise
ACHTUNG: Beim Einsatz von Elektrogeräten müssen u.a. grundlegende Vorsichtsmaßnahmen befolgt werden: Lesen Sie sich diese Anweisungen durch. Bewahren Sie diese Anweisungen auf. Beachten Sie alle Warnungen. Befolgen Sie alle Anweisungen. Setzen Sie dieses Gerät nicht in der Nähe von Wasser ein. Reinigen Sie es nur mit einem trockenen Tuch. -
Page 5: Instructions Importantes De Securite
INSTRUCTIONS IMPORTANTES DE SECURITE ATTENTION: L’utilisation de tout appareil électrique doit être soumise aux precautions d’usage incluant: Lire ces instructions. Gardez ce manuel pour de futures références. Prétez attention aux messages de précautions de ce manuel. Suivez ces instructions. N’utilisez pas cette unité proche de plans d’eau. N’utilisez qu’un tissu sec pour le nettoyage de votre unité. - Page 6 INSTRUCCIONES IMPORTANTES PARA SU SEGURIDAD CUIDADO: Cuando use productos electrónicos, debe tomar precauciones básicas, incluyendo las siguientes: Lea estas instrucciones. Guarde estas instrucciones. Haga caso de todos los consejos. Siga todas las instrucciones. No usar este aparato cerca del agua. Limpiar solamente con una tela seca.
- Page 7 Congratulations! You have just taken a giant step forward towards sonic clarity in your sound system. This PV amplifier was specially designed as an integrated bi-amped power package forming a system with Peavey SP2, SP4 or Impulse 1015 speakers. Not only does it provide the correct amount of power to optimally drive these speaker systems, it also features a carefully designed electronic crossover and processing section.
-
Page 8: Installation
Be sure to save the carton and all packing materials. Should you ever need to ship the unit back to Peavey Electronics, one of its service centers, or the dealer use only the original factory packing. Installation... - Page 9 Front Panel INPUT GAIN (dB) The low and high channels of this amp each have individual Input Sensitivity controls. Normally these controls should be set the same but may be adjusted as needed in each situation. The setting controls the amount of signal necessary to drive the amplifier, not the output of the amplifier. A higher setting will result in more system headroom while a lower setting will result in lower system noise.
- Page 10 When tripped, the button on the BREAKER will be outward approximately 1/4” and can be reset by pushing inward and upward. A normal reset button is relatively flat. If the breaker trips instantly each time you attempt to turn the unit on, it should be taken to a qualified Peavey Service Center for repair.
-
Page 11: Rear Panel
PV® 1600 utilizes 4-conductor Speakon connectors. Internally, the Speakons are wired with the Lows on pins 1+ and 1- and the Highs on pins 2+ and 2-. These will properly mate with all Peavey speakers that have Bi-amp inputs via Speakons. Note: For powering SP4 speakers, internal jumpers must be connected inside the speaker terminal plate (see the instructions in the PV4 owners manual). - Page 12 As a general rule, providing adequate ventilation to electronic equipment extends its service life. While in most low to medium-power applications, your amplifier can be mounted anywhere, Peavey® recommends locating your PV 1600 at the top of an equipment stack. This will prevent possible over- heating of sensitive equipment by the hot air rising from the power amplifier.
- Page 13 DDT® Peavey’s patented DDT (Distortion Detection Technique) compression circuit enables the sound techni- cian to maximize the performance of the amplifier/speaker combination by preventing the power ampli- fier from running out of headroom (clipping). This fully automatic compression system features a unique circuit that senses signal conditions that might overload the amplifier.
-
Page 14: Amplifier Configurations
Amplifier Configurations... -
Page 15: Circuit Breaker
When using full range speakers with a bi-amplification option, bi-amplification often provides more actual sound output capability and better reliability than merely bridging an amplifier. PV1600 Specifications Rated Power Low Freq: (4 ohms) 930 watts @ .1% T.H.D. - Page 16 NOTES...
- Page 17 NOTES...
- Page 18 What Peavey Will Do We will repair or replace (at Peavey's discretion) products covered by warranty at no charge for labor or materials. If the product or component must be shipped to Peavey for warranty service, the consumer must pay initial shipping charges. If the repairs are covered by warranty, Peavey will pay the return shipping charges.
- Page 20 Features and specifications subject to change without notice. Peavey Electronics Corporation • 711 A Street • Meridian, MS 39301 (601) 483-5365 • FAX (601) 486-1278 • www.peavey.com © 2005 80303155...
